unicore HPL EVK5.0 User manual
HPL EVK5.0 CD-Kit User Manual
i
Revision History
Version
Revision History
Date
R1.0
First release
Mar., 2023
R1.1
Add a note to RS232 to USB cable
Add Appendix
Dec., 2023
ii
Legal Right Notice
This manual provides information and details on the products of Unicore
Communication, Inc. (“Unicore”) referred to herein.
All rights, title and interest to this document and the information such as data, designs,
layouts contained in this manual are fully reserved, including but not limited to the
copyrights, patents, trademarks and other proprietary rights as relevant governing laws
may grant, and such rights may evolve and be approved, registered or granted from the
whole information aforesaid or any part(s) of it or any combination of those parts.
Unicore holds the trademarks of “和芯星通”,“UNICORECOMM” and other trade name,
trademark, icon, logo, brand name and/or service mark of Unicore products or their
product serial referred to in this manual (collectively “Unicore Trademarks”).
This manual or any part of it, shall not be deemed as, either expressly, implied, by
estoppel or any other form, the granting or transferring of Unicore rights and/or
interests (including but not limited to the aforementioned trademark rights), in whole or
in part.
Disclaimer
The information contained in this manual is provided “as is” and is believed to be true
and correct at the time of its publication or revision. This manual does not represent,
and in any case, shall not be construed as a commitments or warranty on the part of
Unicore with respect to the fitness for a particular purpose/use, the accuracy, reliability
and correctness of the information contained herein.
Information, such as product specifications, descriptions, features and user guide in this
manual, are subject to change by Unicore at any time without prior notice, which may
not be completely consistent with such information of the specific product you
purchase.
Should you purchase our product and encounter any inconsistency, please contact us or
our local authorized distributor for the most up-to-date version of this manual along
with any addenda or corrigenda.
HPL EVK5.0 CD-Kit User Manual
iii
Foreword
This document provides information about the HPL EVK5.0 CD-Kit from Unicore.
Target Readers
This document applies to technicians who possess the expertise on GNSS receivers.
I
Contents
1OVERVIEW..............................................................................................1
2INTERFACE .............................................................................................2
3CONNECTION .........................................................................................3
APPENDIX: DIMENSIONS..............................................................................4
HPL EVK5.0 CD-Kit User Manual
UC-00-E60 EN R1.1 Overview 1
1Overview
The HPL EVK5.0 CD-Kit is mainly used to evaluate the function and performance of
Nebulas modules
1
and boards from Unicore for the convenience of users.
Figure 1-1 shows the items in the package box.
1
2
3
4
Figure 1-1 Package List
(1) EVK
(2) Power Adapter
(3) Serial Port Cable
(4) RF Cable
1
To test the module, an adapter or an evaluation board should be installed on the EVK.
2 Interface UC-00-E60 EN R1.1
2Interface
5
6
7
8
9
2
134
Figure 2-1 Appearance of EVK
The main interfaces and buttons of the EVK are shown in Figure 2-1. See Table 2-1 for
the detailed descriptions.
Table 2-1 Interface/Button Description
Interface
Function
Description
1
EVK power supply interface
12 V power supply
2
EVK power supply switch
Turn to the right to supply power
3
COM1
Connect to COM1 of the board to be tested
4
COM3
Connect to COM3 of the board to be tested
5
COM2
Connect to COM2 of the board to be tested
6
RJ45
Ethernet interface2
7
SMA
The four SMA interfaces are: FWR, EVENT1,
PPS1, SPEED
8
28-pin board interface
28-pin connector to connect Unicore
products
9
42-pin board interface
42-pin connector to connect Unicore
products
2
Refer to the related user manuals of the boards/modules to be tested to confirm whether this
function is supported.
HPL EVK5.0 CD-Kit User Manual
UC-00-E60 EN R1.1 Connection 3
COM1 to COM3 can be set up as a straight-through or crossover connection
through a jumper cap near the DB9 interface. The jumper cap is installed parallel to
DB9 as a crossover and perpendicular to DB9 as a straight-through connection.
If the board to be tested needs a backup power, weld a 0 Ωresistor R118.
3Connection
This section takes UM980 as an example to give an introduction of how to evaluate the
modules or boards using the EVK.
Electrostatic discharge (ESD) may cause damage to the device. All
operations mentioned in this chapter should be carried out on an antistatic
workbench using an antistatic wrist strap and conductive foam pad. If there is
no antistatic workbench, wear an antistatic wrist strap and connect the other
end of the strap to the metal frame to avoid electrostatic damage.
Hold the edge of the evaluation board, and do NOT touch the components
directly.
Carefully check the EVK to make sure that there is no apparent loose or damaged
components. If you have any questions, please contact Unicore or the local distributors.
Do the following steps to evaluate.
1. Ensure adequate antistatic measures, such as wearing a grounded antistatic wrist
strap, using a grounded workbench, etc.
2. Connect the RF cable to the ANT interface on UM980eb.
Figure 3-1 Connection
4 Appendix: Dimensions UC-00-E60 EN R1.1
3. Install the UM980eb on the EVK by aligning the dual-row pins to the pinholes.
4. Connect one end of the serial port cable to the COM1 on the EVK, and connect the
other end of the cable to the computer if your computer has RS232 ports; otherwise,
you need a RS232 to USB cable to connect to the computer.
It is recommended to use the Z-TEK RS232 to USB cable.
5. Do step 4 again to connect the COM2 with the computer.
6. If necessary, connect the PPS and EVENT interfaces.
7. Connect the power adapter to the power supply interface on the EVK and plug it into
the electrical socket.
8. Select the GNSS antenna with appropriate gain (the system frequency supported by
the antenna should be consistent with the module), fix it in a non-occluded area,
and connect the antenna to the other end of the RF cable.
9. Turn the power supply switch to the right to initialize the UM980.
10. Start the UPrecise on the PC. Select the serial port and baud rate to connect the
receiver, then UPrecise shows the constellation, message, receiver status, etc.
UPrecise also supports firmware upgrade. Refer to
UPrecise User Manual
for more
details.
To evaluate a GNSS and INS integrated product, you can connect the speed signals
and direction signals from the odometer to the SPEED and FWD interfaces on the
EVK.
Appendix: Dimensions
See below for the dimensions of the EVK (Unit:mm).
HPL EVK5.0 CD-Kit User Manual
UC-00-E60 EN R1.1 Appendix: Dimensions 5
107.95
180.34
172.72
100.33
3.81
3.81
3.30 X 4
HPL EVK5.0 CD-Kit
