Uniden D1780 User manual

D1780 base
with answering
system and
cordless
handset
Battery
cover
Accessory handset
and charger
If you purchased
model number:
You should
have:
D1780 None
D1780-2 1 of each
D1780-3 2 of each
D1780-4 3 of each
... ...
D1780-11 10 of each
D1780-12 11 of each
You will also nd:
Not pictured:
xRechargeable
battery (BT-1021)
xAC adapter (PS-0035)
xTelephone cord
• If any items are missing or damaged, contact our Customer Care Line
immediately. Never use damaged products!
• Need help? Get answers 24/7 at our website: www.uniden.com.
If You... Contact Uniden’s... Phone Number
have a question or problem Customer Care Line* 817-858-2929 or
800-297-1023
need a replacement part or an
accessory Parts Department* 800-554-3988
need special assistance due to
a disability Accessibility Help Line 800-874-9314 (voice or TTY)
* During regular business hours, Central Standard Time; see our website for de-
tailed business hours.
D1780 Series User's Guide
What's in the box?
Not pictured:
xRechargeable
battery (BT-1021)
xBattery cover
xAC adapter
(PS-0035)
© 2012 Uniden America Corp. Printed in Vietnam
Ft. Worth, Texas U01UN420EZZ(0)

2 -English
Getting Started ................................ 3
Installing Your Phone .................................3
Getting to Know Your Phone ...................4
Using the Handset Menu ..........................7
Using Your Phone ............................. 8
Using the Phonebook .............................. 10
Using Special Features .................. 11
Silent Mode ..................................................11
Multihandset Features .............................12
Chain Dialing ...............................................13
Voice Message Notication ....................13
Using the Answering System ....... 14
Answering System Options
(
Answering Setup ) .................................14
Personalizing the Greeting.....................15
Accessing the Answering System ....... 16
Getting Your Messages ........................... 16
Using the System While
You're Away from Home ......................17
Important Information .................. 18
Solving Problems .......................................18
Resetting Handsets .................................. 20
Registering Handsets .............................. 20
Adapter and Battery Information ....... 20
Compliance Information ........................ 21
1-Year Limited Warranty ......................... 23
Important Safety Instructions!
When using your telephone equipment, basic safety precautions should
always be followed to reduce the risk of fire, electric shock and injury to
persons, including the following:
• This unit is NOT waterproof. DO NOT expose it to rain or moisture.
• Do not use this product near water, for example, near a bath tub,
wash bowl, kitchen sink or laundry tub, in a wet basement or near a
swimming pool.
• Avoid using a telephone (other than a cordless type) during an electrical
storm. There may be a remote risk of electric shock from lightning.
• Do not use the telephone to report a gas leak in the vicinity of the leak.
• Use only the power cord and batteries indicated in this manual. Do not
dispose of batteries in a fire. They may explode. Check with local codes
for possible special disposal instructions.
• Do not place the handset in any charging cradle without the battery
installed and the battery cover securely in place.
SAVE THESE INSTRUCTIONS!
CAUTION! Risk of explosion if battery is replaced by an incorrect type!
Dispose of used batteries according to the instructions. Do not open or
mutilate the battery. Disconnect the battery before shipping this product.
For more details, see the Important Information section.
What’s in the manual?

English - 3
Installing Your Phone
Charge the Battery
1. Unpack all handsets,
battery
packs, and
battery
covers. If
you need to
remove a
cover, press in on the notch and
slide the cover down and off.
2. Line up the battery connector
with the jack inside the handset;
the connector only fits one way.
3. Push the connector in until
it clicks into place; tug gently
on the wires to make sure the
battery is securely connected.
4. Replace the battery cover and
slide it into place.
5. Use an AC adapter to connect
the power jack on the base to a
regular indoor (120V AC) power
outlet. Connect any chargers the
same way.
6. Place a handset in the base with
the display facing forward. If
the display doesn’t light up,
reseat the handset or connect
the base to a different outlet. For
2 or more handsets, place each
handset in a charger.
#Charge all handsets
completely (about 15 hours)
before using.
Connect the Telephone Cord
Use the telephone cord to connect
the
TEL LINE
jack on the base to a
standard telephone wall jack.
Test the Connection
1. Pick up the handset and press
Talk . The handset sounds a dial
tone, and the display shows Talk .
– If you don't hear a dial tone or
the display says Check Tel Line,
check the connection between
the base and the phone jack.
2. Make a quick test call. (Press End
to hang up.)
– If you keep hearing a dial tone,
change to pulse dialing.
– If there’s a lot of noise, check
for interference (see p. 17).
3. Test all handsets the same way.
If you can't get a dial tone, move
the handset closer to the base.
Changing to Pulse Dialing
Your phone uses tone dialing by
default. If your phone company uses
pulse dialing, you need to change
your phone’s dial mode.
1. On a handset, press
MEnu/sElEcT
and choose Global Setup .
2. Select
Dial Mode then Pulse .
You’ll hear a confirmation tone.
To send DTMF tones during a call
(e.g., for an automated response
system), press * to temporarily
switch to tone dialing. When you
hang up, the phone automatically
returns to pulse dialing.
GETTING STARTED

4 -English
Getting to Know Your Phone
Parts of the Handset
Key (icon) What it does
PhonEbook
( )
xIn standby or during a call: open the phonebook.
xIn the menu: go back to the previous screen.
xWhen entering text: move the cursor to the left.
sPEakEr ( ) xSwitch a normal call to the speakerphone (and back).
Talk/flash
xIn standby: start a telephone call (get a dial tone).
xDuring a call: switch to a waiting call.
down ( )
xIn standby: decrease the ringer volume.
xDuring a call: decrease the audio volume.
xIn any menu or list: move the cursor down one line.
rEdial/PausE
xIn standby: open the redial list.
xWhen entering a phone number: insert a 2-second pause.
uP ( )
xIn standby: increase the ringer volume.
xDuring a call: increase the audio volume.
xIn any menu or list: move the cursor up one line.
MEnu/sElEcT
xIn standby: open the menu.
xIn the menu or any list: select the highlighted item.
Twelve-key
dial pad
UP
PHONEBOOK
SPEAKER
DOWN CID
REDIAL/PAUSE
MESSAGE/MUTE
INTERCOM/CLEAR
END
TALK/FLASH
MENU/SELECT
Status
Charging
contacts
Earpiece
Display
Microphone

English - 5
Key (icon) What it does
End
xDuring a call: hang up.
xIn the menu or any list: exit and go to standby.
cid ( ) xIn standby: or during a call: open the Caller ID list.
xWhen entering text: move the cursor to the right.
inTErcoM/
clEar
xIn standby: start an intercom call.
xDuring a call: put the call on hold and start a call transfer.
xWhen entering text or numbers: erase the character at the
cursor (press & hold to erase all characters).
MEssagE/
MuTE
( )
xIn standby: access your answering system.
xDuring a call: mute the microphone.
xWhile the phone is ringing: ignore this call (mute the ringer).
LED What it means
sTaTus
xOn: the battery is charging.
xBlinking: there are new messages.
Reading the Display
The table shows the possible
status icons & what they
mean. Since the icons appear
based on what the phone is
doing, you won't see all the
icons at the same time.
Icon What it means
The signal from the base is 1) strong or 2) weak.
The ringer is turned off and will not ring for new calls.
The speakerphone is on.
Indicates you have a new voice mail.
Privacy Mode is on: no other handset can join the call.
T-coil mode is on (see p. 7).
The battery is 1) full, 2) half charged, 3) getting low or 4) empty.
Status
icons
Current
call info
Answering
system
status
Time &
date

6 -English
Icon What it means
The handset is using ECO (power save) mode.
[Aa] [aA] Enter 1) capital or 2) lower case letters (see p. 7).
Parts of the Base
Key (icon) What it does
find hs
xIn standby: page all handsets.
rEV ( ) xWhile playing a message: restart the message.
xIn the first 2 seconds of a message: play the previous message.
dElETE ( ) xWhile playing a message: delete this message.
xIn standby: delete all messages.
fwd ( ) xWhile playing a message: skip to the next message.
uP (
+
) xIn standby: increase the ringer volume.
xWhile playing a message: increase the speaker volume.
down (
–
) xIn standby: decrease the ringer volume.
xWhile playing a message: decrease the speaker volume.
ans on/off
xIn standby: turn the answering system on or off.
Play/sToP
( )
xIn standby: start playing messages.
xWhile playing a message: stop playing messages.
xWhen the phone is ringing: ignore this call (mute the ringer).
MEssagE
counTEr
xDisplays the number of messages you have.
UP
DOWN
FWD
FIND HS
Charging
contacts
DELETE
PLAY/STOP
ANS ON/OFF
REV
Message
Counter

English - 7
Using the Handset Menu
If you don't press any keys for about 30
seconds, the handset
exits the menu.
During a call, use
PhonEbook to back
out of the menu
without hanging
up.
Handset Setup Menu
You can change these settings separately for each handset.
T-coil
Turn on T-coil mode to reduce noise on hearing aids
equipped with a telecoil (T-coil) feature. T-coil mode
shortens talk time, so keep your battery fully charged.
Ringer Tones
Choose this handset's ring tone. As you highlight each
ring tone, the phone plays a sample. When you hear
the tone you want, press MEnu/sElEcT .
Personal Ring
Turn on personal ring so you can assign a special ring
tone to people in your phonebook. With Caller ID, this
handset uses the assigned tone when the person calls.
AutoTalk
Have this handset answer a call when you pick it up
from the cradle (without pressing any buttons).
Any Key Answer
Have this handset answer a call when you press any
key on the 12-key dialpad.
Banner Change the name used on the handset's display.
Handset Language Change the display language.
Key Touch Tone Have the keypad sound a tone when you press a key.
Answering Setup Menu
Refer to p. 13 for details on setting up your answering system.
Date & Time Menu
Use this menu to set the clock Enter the date and time (MM/DD/YY);
select AM or PM . Use cid to move the cursor past a digit without changing
it. If you have CID service, you can set it to provide the time ( Global Setup/
Time Adjustment ).
Handset Setup
Personal Ring
Handset Setup
Ringer Tones
Handset Setup
T-coil
Handset Setup
Answering Setup
Use
UP
and
DOWN
to
rotate through the
options.
Press
MENU/SELECT
to
open the menu.
Press
MENU/SELECT
to choose
the current option.
Press
PHONEBOOK
to
go back a screen
OR
press
END
to exit
the menu.

8 -English
Global Setup Menu
The settings on this menu affect all handsets. Only one handset at a time
can change these menu options.
Dial Mode Choose tone or pulse dialing (see p. 3).
Set Line Mode
Do not change this setting unless instructed to by
customer service.
Voice Mail Tone Turn the tone indicating a new voice mail on or off.
VMWI Reset Reset the Voice Message Waiting Indicator (see p. 12)
CID Time Setting
Select Set by Caller ID to allow phone network to
automatically set cordless phone system time.
Entering Text on Your Phone
• Use the 12-key dial pad anytime you want to enter text into your phone
(a name in the phonebook, the handset banner, etc.).
• If two letters in a row use the same key, enter the first letter; wait for the
cursor to move to the next space and enter the second letter.
To... Press...
move the cursor left
PhonEbook .
move the cursor right
cid .
erase the character at the cursor
inTErcoM/clEar .
erase the entire entry and hold
inTErcoM/clEar .
enter a blank space
#
.
switch between upper and lower case letters *.
rotate through the punctuation and symbols
0
.
USING YOUR PHONE
This section explains the most common functions on the phone.
To... Using the
earpiece
Using the
speakerphone
make a call, dial the number & press
Talk/flash . press sPEakEr .
answer a call press
Talk/flash . press sPEakEr .
hang up press
End or put the handset in the cradle.
ignore a call/mute the ringer press
MEssagE/MuTE while the phone is
ringing.
switch to the speaker & back press
sPEakEr .

English - 9
To... Using the
earpiece
Using the
speakerphone
mute the microphone during
a call
press
MEssagE/MuTE (press again to turn the
microphone back on).
put a call on hold press
inTErcoM/clEar* .
return to a call on hold press
Talk/flash . press sPEakEr .
make a speed dial call
press and hold the speed dial number
for 1.5 seconds. After you verify that the
system is displaying the correct phonebook
data for that speed dial number, press
Talk/
flash
or sPEakEr on the handset.
* Aer 5 minutes on hold, the call will be disconnected.
Assigning a Speed Dial Number
You can assign a speed dial number to a phonebook entry when you create
that entry for the first time or when you edit it. Press
PhonEbook and select
Create New . As you enter the phonebook number, one of the options you
will see is to assign a speed dial number to that phonebook entry. You can
assign up to 10 speed dials, 0 - 9.
Finding a Lost Handset
With the phone in standby, press
find hs on the base. All handsets beep for
1 minute; to cancel, press
find hs again or press any handset key.
Changing the Volume
To change the... When... Press...
earpiece or speaker
volume for each handset
you are listening to that
earpiece or speaker (playing
messages, etc.)
uP to increase
the volume.
down to
decrease it.
base speaker volume
ringer volume for each
handset or the base* the phone is in standby
* If you turn the ringer all the way down, that particular ringer turns o.
Using the Caller ID and Redial Lists
Caller ID (CID) is a service available from your telephone provider that
shows the phone number (and sometimes the caller’s name) of incoming
calls. Contact your telephone provider for more information.

10 -English
Caller ID list Redial list
xThe phone saves the information for the last 50
received calls to the CID list. The NEW icon marks any
calls received since the last time you checked the list.
xAll handsets share the same CID list so only one
handset can access the list at a time.
xIn standby, handsets show how many calls came in
since the last time you checked the CID list.
xEach handset
remembers the
last 5 numbers
you dialed on it.
xOnly one handset
can access its
redial list at a time.
To… Press...
open the CID list
cid .
open the redial list
rEdial/PausE .
scroll through the
lists
down to scroll from newest to oldest.
uP to scroll from oldest to newest.
dial the
highlighted
number
Talk/flash or sPEakEr.
(If the number is a toll call but there is no 1 at the
beginning, press * to add 1 before dialing.)
close the lists
PhonEbook .
For individual record options, highlight a number and press MEnu/sElEcT :
Delete Entry Erase the number from the list.
Store Into Pb
Add the number to the phonebook. The handset prompts
you to edit the name and number and select a personal ring.
Delete All (CID list only) Erase all numbers from the list.
Using Call Waiting
• Call Waiting, a service available from your telephone provider, lets you
receive calls while you are on another call. Caller ID on Call Waiting
(CIDCW) service displays Caller ID information for a waiting call.
• If you get a Call Waiting call, the phone sounds a tone and displays
any CID information received from the waiting call. Press
Talk/flash
to switch between the current call and the waiting call; each time you
switch, there is a short pause before you're connected to the other call.
Using the Phonebook
The phone can store up to 100 entries in its phonebook. All handsets share
the same phonebook, so only one handset can access it at a time.

English - 11
To... Press...
open/close the phonebook
PhonEbook .
scroll through the entries
down to scroll through the entries from A to Z.
uP to scroll from Z to A.
jump to entries that start
with a certain letter
the number key corresponding to the letter
you want.
dial the current entry
Talk/flash or sPEakEr .
edit the current entry
MEnu/sElEcT , then select Edit .
delete the current entry
MEnu/sElEcT , then select Delete . When the
phone prompts you to confirm, select
Yes .
make a speed dial call
Press and hold the speed dial number (0 - 9)
for 1.5 seconds. The speed dial entry displays.
Press
Talk or sPEakEr to dial the number.
Adding Phonebook Entries
With the phone in standby, open the phonebook. Press
MEnu/sElEcT and
select Create New. Enter a name, number, and then assign a speed dial
number and a personal ring if desired.
• Enter the phone number (up to 20 digits) exactly as you would dial it.
• If you need the phone to wait before sending the next set of digits, press
rEdial/PausE to insert a 2-second pause. You can insert multiple pauses,
but each one counts as a digit (you’ll see P in the display).
Deleting All the Phonebook Entries
With the phone in standby, open the phonebook. Press
MEnu/sElEcT and
select Delete All . When the phone prompts you to confirm, select Yes .
USING SPECIAL FEATURES
Silent Mode
You can silence the ringers on the base and all handsets for a specific
period of time; the answering system answers any incoming calls without
playing anything through the speaker.
1. With the phone in standby, press and hold
#
on any handset. The phone
prompts you to select the number of hours ( 1 - 9 or Always On ) that you
want it to stay in silent mode.
2. To confirm, press
#
or just wait about 5 seconds. The phone turns on the
answering system and displays Silent Mode On on each handset.

12 -English
3. After the selected number of hours, the phone automatically exits silent
mode. To exit silent mode manually, press and hold
#
again.
#If the phone is in silent mode and you turn off the answering
system, the phone exits silent mode.
Multihandset Features
#To use the features in this section, you need at least 2 handsets.
• Your base supports a total of 12 cordless handsets: the one that came
with the base and up to 11 DCX170 accessory handsets. Your base also
supports a total of 2 DRX100 range extenders, including any that came
with your phone. If you have any DWX handsets, the D1780 is limited to
a total of 6 accessory handsets
• You must register accessory handsets to the base before using them.
(Handsets that came packaged with the base are already registered.)
• Handsets that aren’t registered display a Not Registered message. For
registration instructions, see p. 18, or see the accessory handset manual.
• If a handset was ever registered to a base, you must reset it before it can
register to a new base; see p. 18, or see the accessory handset manual.
Conference Calling
• When an outside call comes in, two handsets can join in a conference
call with the outside caller.
• To join a call that’s already in progress, just press
Talk/flash or sPEakEr .
• To leave the conference call, hang up normally; the other handset
remains connected to the call.
Call Transfer
To... Press...
transfer a call
inTErcoM/clEar . The phone puts the call on hold and
prompts you to select the handset you want to page.
When the other handset accepts the call, you'll be
disconnected (press Talk/flash to rejoin the call).
cancel a transfer
Talk/flash to return to the call.
accept a
transferred call
inTErcoM/clEar to answer the page and speak to the other
handset. Then, press Talk/flash to speak to the caller.
Privacy Mode
To activate privacy mode on a call in progress, press
MEnu/sElEcT twice.
As long as privacy mode is on, you'll see a in the display, and no other

English - 13
handsets can join your call. Privacy mode turns off automatically when
you hang up; you can also turn it off by pressing MEnu/sElEcT twice.
Handset to Handset Intercom
• Whenever the phone is in standby, you can make an intercom call
between handsets without using the phone line.
• You can make an intercom call from any handset, but only two handsets
can be in an intercom call at any time.
• If an outside call comes in during an intercom page, the phone cancels
the page so you can answer the incoming call.
• If an outside call comes in during an intercom call, press
Talk/flash to
hang up the intercom call and answer the outside call.
To... Press...
make an intercom
page
inTErcoM/clEar. Select the handset you want to talk
with, or All to page all handsets at the same time.
cancel a page
End .
answer a page
inTErcoM/clEar or Talk/flash .
end an intercom call
End . Both handsets return to standby.
Chain Dialing
If you often have to enter a series of digits or a code number during a
call, you can save that code number to a phonebook entry and use the
phonebook to send the code number.
1. Enter the code number (up to 20 digits) into the phonebook just like
a regular phonebook entry. Be sure to enter the code number into the
phonebook exactly as you would enter it during a call.
2. When you hear the prompt that tells you to enter the number, open the
phonebook and find the entry that contains your code number.
3. Press
MEnu/sElEcT to send the code. If you change your mind, just close
the phonebook.
Voice Message Notication
If you subscribe to a voice mail service, your phone displays the voice
mail icon ( ) when you have a new message. This feature supports
Frequency-Shift Keying (FSK) notification, which you can turn on and off
through
Global Setup/Voice Mail Tone .

14 -English
After you listen to your messages, the message icon turns off. If it doesn’t,
you can reset it: With the phone in standby, open the menu and select
Global Setup ; select VMWI Reset , then select Yes.
USING THE ANSWERING SYSTEM
Answering System Options ( Answering Setup )
You can set or change the answering system options from any handset. Just
open the menu and select Answering Setup . Select one of the following:
Security Code
Enter a 2-digit PIN so you can access your answering
system from any touch-tone phone (see p. 15).
Ring Time
Set the number of rings ( 2 , 4 , or 6 ) before the system
answers. Toll Saver makes the system answer after 2 rings
if you have new messages or after 4 rings if you don't.
Record Time
Set the amount of time ( 1 or 4 minutes) callers have to
leave a message. Choose
Announce Only if you don't
want the system to let callers to leave a message.
Message Alert
Have the system beep every 15 seconds when you have
a new message. The alert stops after you listen to all
your new messages or if you press any key on the base.
Ans. Language Change the language of the system's voice prompts.
Call Screen
Turn on the call screen feature so you can hear callers as
they leave messages on the base speaker (see p. 15).
Ans. On/off Turn your answering system on or off.
Record Greeting Record an outgoing message or greeting (see below).
Greeting Options Switch greetings or delete your greeting (see below).
Personalizing the Greeting
Your personal outgoing message or greeting can be from 2 to 30 seconds
long. If you don’t record a greeting, the system uses a pre-recorded
greeting: Hello, no one is available to take your call. Please leave a message
after the tone.

English - 15
To... Follow these steps:
Record a
personal
greeting
1. Open the menu with the phone in standby. Select
Answering Setup , then Record Greeting .
2. Press
MEnu/sElEcT to start recording. Wait until the system
says "Record greeting" before speaking.
3. Press
MEnu/sElEcT to stop recording. The system plays back
your new greeting.
4. To keep the greeting, press
End . To re-record it, press
MEnu/sElEcT .
Switch
between
greetings
1. Open the menu with the phone in standby. Select
Answering Setup , then Greeting Options .
2. The system plays back the current greeting. Press
MEnu/
sElEcT
to switch greetings.
Delete your
greeting Switch to your personal greeting, then press
inTErcoM/clEar .
Accessing the Answering System
When the phone’s in
standby, you can
access the system
from any handset:
• Only 1 handset
can access the
system at a time.
• If you do nothing
for 30 seconds,
the phone returns
to standby.
• During remote
access, the phone
beeps so you
know it's waiting
for the next command.
• You can press the number key shown next to each command instead of
scrolling through the screens.
1:Repeat 3:Skip
4:Delete 5:Stop
Press
MESSAGE/MUTE
to start
remote operation mode.
Press a correspond
-
ing number key to
choose an operation
OR
END
to exit remote
operation mode.

16 -English
Getting Your Messages
To... From the base From a handset
play new
messages
Press
Play/sToP. Press MEssagE/MuTE .
The system announces the number of new & old
messages, then plays each new message (followed by the
day and time) in the order it was received.
restart this
message
Wait at least 5 seconds after the message starts playing,
press
rEV. select 1:Repeat .
replay an
earlier message
Within 2 seconds after a message starts playing,
press
rEV. select 1:Repeat .
skip a message Press
fwd . Select 3:Skip .
delete a
message
While a message is playing, press
dElETE .
While a message is
playing, select 4:Delete .
delete all
messages
With the phone in standby,
press
dElETE ; press dElETE again to
confirm.
Not available.
play old
messages
After the system plays all new messages,
press
Play/sToP again. select 2:Play .
stop playback Press
Play/sToP . Select 5:Stop .
Screening Your Calls
You can use the answering system for call screening. While the system
takes a message, you can listen on the base speaker (if you turn on
Call
Screen) or from a handset. Only one handset can screen calls at a time. If
another handset tries to screen calls, it beeps and returns to standby.
To... From the base From a handset
hear the caller leaving a
message
Listen to the caller over
the speaker. Press
MEssagE/MuTE .
answer the call NA Press
Talk/flash .
mute the call screen
without answering* Press
Play/sToP . Press
End or return the
handset to the cradle.
* If you mute the call screen, the system continues taking the message: it just
stops playing through the speaker.
Using the System While You're Away from Home
You can dial in to your answering system from any touch-tone phone.
Before you can use this feature, you must program a security code.

English - 17
Programming a Security Code
With the phone in standby, open the menu; select
Ans. Setup , then select
Security Code . Use the number keypad to enter a two-digit security code
(
01 to 99 ). Press MEnu/sElEcT when you’re finished.
#Remember to make a note of your new security code!
Dialing In to Your System
1. Call your phone number & wait until the system answers. (If the system
is turned off, it answers after 10 rings & sounds a series of beeps.)
2. During the greeting or beeps, press
0
and immediately enter your
security code. If you enter it incorrectly 3 times, the system hangs up
and returns to standby.
3. The system announces the time, the number
of messages in memory, and a help prompt. It beeps to let you know it's
waiting for a command.
4. When you hear beeping, enter a 2-digit command from the chart.
#If you don't press any keys for 15 seconds, the system hangs up
and return to standby.
IMPORTANT INFORMATION
Solving Problems
If you have any trouble with your phone, check this section first. If you
need help, call our Customer Care Line listed on the front cover.
General problems Possible solutions
No handsets can make or
receive calls.
xCheck the telephone cord connection.
xDisconnect the base AC adapter for a few
minutes; then reconnect it.
01 Repeat message 05 Stop playback
02 Play message 06 Turn the system on
03 Skip message 09 Turn the system off
04 Delete message 10 Hear help prompts

18 -English
A handset can’t make or
receive calls. xMove the handset closer to the base.
A handset can make calls,
but it won’t ring.
xMake sure the ringer is turned on.
xMake sure Silent Mode is turned off (see p. 10).
A handset is not working. xCharge the battery for 15-20 hours.
xCheck the battery connection.
The phone keeps ringing
when I answer on an
extension.
xYou may have to change the line mode.
Contact Customer Service for instructions.
Caller ID problems Possible solutions
No handsets display
Caller ID information.
xLet calls ring twice before answering.
xMake sure your Caller ID service is active.
Caller ID displays briefly
and then clears.
xYou may have to change the line mode.
Contact Customer Service for instructions.
Multi-handset problems Possible solutions
I can’t transfer calls. xReset the handset (see p. 18).
Two handsets can’t talk to a caller. xSee if any handset is in Privacy Mode.
A handset says Unavailable . xMove the handset closer to the base.
xSee if any handset is in Privacy Mode.
I can’t register a new handset. xReset the handset (see p. 18).
xSee if you have 12 registered handsets.
Answering system problems Possible solutions
The answering system does
not work.
xMake sure the answering system is on.
xMake sure the base is plugged in.
The system won't record
messages.
xSee if Record Time is set to Announce Only .
xDelete messages (memory may be full).
A handset can't access the
answering system.
xSee if another handset is using the system.
xMake sure the phone is in standby.
My outgoing message is gone. xIf there was a power failure, re-record
your personal outgoing message.
I can’t hear the base speaker. xMake sure call screening is turned on.
xChange the base speaker volume.
Messages are incomplete. xIncrease the
Record Time .
xDelete messages (memory may be full).

English - 19
Answering system problems Possible solutions
The system keeps recording
when I answer on an
extension.
xYou may have to change the line
mode. Contact Customer Service for
instructions.
Installing a Line Filter or DSL Filter
A telephone line lter or DSL lter prevents services that use the phone line from
causing interference on your phone. To get a line lter, contact your service pro-
vider or look in an electronics store.
Plug the lter into the telephone wall jack and plug the base into the lter. Make a
test call to make sure the noise is gone.
Liquid Damage
CAUTION: If the base is covered in liquid, disconnect the adapter & phone
cord from the wall before touching it.
If the liquid is only on the exterior housing of the base or handset, wipe it o and
use as normal. If you can hear liquid inside the housing:
1. Remove all compartment covers, and disconnect all cables and cords.
2. If liquid is leaking from any vent or hole, turn the phone so that vent faces
down. If not, place the largest vent face down.
3. Let dry for at least 3 days. Check for liquid inside the phone before replacing
compartment covers & reconnecting cords.
Resetting Handsets
If you have trouble with a handset or if you want to replace one, clear the registra-
tion information from the base and the handset:
1. Press & hold
End and
#
at the same time until you see the System Reset menu.
2. If you still have the base the handset is registered to, select
Deregister HS , then
select the handset you want to reset. If you don’t have that base anymore, select
Base Unavailable .
3. To conrm, select
Yes . e handset displays Handset not registered .
Registering Handsets
If you see a “not registered” message on a handset, you must register it to a base
before using it.
1. Place the handset in the base; the display should say
Handset Registering .
2. Wait until the display says
Registration Complete (about 30 seconds), then pick
up the handset and press
Talk/flash .
3. If you don’t hear a dial tone or the display says
Registration Failed , charge the
battery completely, then try again.

20 -English
Adapter and Battery
Information
AC adapter
Part number PS-0035
Input voltage 120V AC, 60 Hz
Output voltage 8V AC @ 300mA
xUse only the supplied AC adapters.
xUse the proper adapter for the base &
any chargers.
xDo not place the unit in direct sunlight
or subject it to high temperatures.
Battery pack (with normal use)
Part number BT-1021
Capacity 300mAh, 2.4V DC
Talk time about 7 hours
Standby time about 7 days
Battery life about 1 year
xReplace the battery when the talk or
standby time becomes noticeably re-
duced. For replacements, call the Parts
Department (see the front cover).
xWhen the battery gets low, the handset
beeps and shows a low battery alert;
put the handset in the cradle for
recharging.
Rechargeable Battery Warning
xis equipment contains a recharge-
able Nickel-Metal-Hydride (Ni-MH)
battery.
xNickel is a chemical known to the state
of California to cause cancer.
xDo not short-circuit the battery.
xe batteries in this equipment may
explode if disposed of in a re.
xDo not charge the batteries in any
charger other than the one specied
in the owner's manual. Using another
charger may damage the battery or
cause it to explode.
xAs part of our commitment to
protecting our environ-
ment and conserving
natural resources,
Uniden voluntarily
participates in an
RBRC® industry
program to collect and
recycle used Ni-MH batteries within
the United States. Please call
1-800-8-BATTERY for information on
Ni-MH battery recycling in your area.
(RBRC® is a registered trademark of the
Rechargeable Battery Recycling
Corporation.)
Rechargeable batteries must be
recycled or disposed of properly.
Warning! The cords on this
product and/or accessories
contain lead, a chemical known
to the state of California to
cause birth defects or other
reproductive harm. Wash hands
after handling.
Uniden works to reduce lead
content in our products &
accessories.
Compliance Information
FCC Part 68 Information
is equipment complies with Part
68 of the FCC rules and the require-
ments adopted by the ACTA. On the
bottom of this equipment is a label that
contains, among other information,
a product identier in the format US:
AAAEQ##TXXXX. If requested, this
number must be provided to the phone
company.
An applicable Universal Service
Order Codes (USOC) certication for
the jacks used in this equipment is
provided (i.e., RJ11C) in the packaging
with each piece of approved terminal
equipment. A plug and jack used to
