Uniden UIP165P User manual

UIP165P
OWNER'S
MANUAL

[1]
www.uniden.com
Welcome/Features/Terminology 2
Controls & Functions 5
Setting up your Broadband Phone 7
Before You Start! 8
Expanding Your Phone 14
Ten Handset Expandability 14
Registering Expansion Handsets 14
Installing the Beltclip 16
Headset Installation 16
Display and Icons 17
Soft Key Function 18
In standby mode 18
In talk mode 18
Accessing the menus 19
Entering letters and special characters 19
Main Menu Options 21
Default Settings 22
Global Setup 23
Handset and Base Setup Menu Options 24
Using Your Phone 32
Calling with Packet8 service 32
Making and Receiving Calls 32
Switching to the Handset Speakerphone 33
Call Waiting 33
Placing a Call on Hold 34
Redialing a Call 35
Adjusting the Earpiece and Speaker Volume 36
Muting the Ringer 36
Mute Microphone 37
Find Handset 37
Traveling Out of Range 38
Privacy Mode 38
Holding a Conference Call 39
Using the Intercom 39
Transferring a Call 41
Using One Touch Voice Mail Access 43
Resetting the New Message LED 43
Using the Phonebook and Speed Dial 44
Entering New Phonebook Entries and Speed Dial Numbers 44
Chain Dialing 45
Viewing the Phonebook 46
Making Calls Using the Phonebook 47
Speed Dialing 47
Editing or Erasing a Phonebook Entry 48
Copying Phonebook Entries 49
Caller ID and CIDCW (Caller ID on Call Waiting) 50
Viewing the Caller ID List 51
Deleting a Caller ID Record 52
Deleting All Caller ID names/numbers 53
Calling a party from the Caller ID list 53
Storing Caller ID records in the Phonebook 54
Special Features 55
Using the DirectLInk Two-Way Radio Feature 55
Using the Room/Baby Monitor 57
Troubleshooting 58
Getting Help 58
Understanding the LED Indicators 58
Resetting the UIP165P 60
Logging into the UIP165P's Configuration Utility 61
Common Issues 62
Note on Power Sources 66
Power Failure 66
Battery Life 66
Battery replacement and handling 67
General Information 68
Liquid Damage 69
Precautions & Warranty 70
Index 71
Contents

WELCOME/FEATURES/TERMINOLOGY [2] www.uniden.com
With the UIP165P voice-over-Internet Protocol (VoIP) telephone, Packet8 VoIP service
and your broadband connection, you can access the Internet and make phone calls
simultaneously. The UIP165P can connect directly to your broadband modem or can
connect to a router or switch in your home network. It generates and receives voice
data and forwards data traffic to your computer or network.
Note: Illustrations in this manual are used for explanation purposes.
Some illustrations in this manual may differ from the actual unit.
• 5.8GHz Digital Expandable
• Dual Keypad and LCD Screen at Base
• 10 Multi-Handset Expandability
• Hands-Free Duplex Speakerphone in the Handset and Base
• Caller ID/Call Waiting
• 100 (handset) and 50 (base) Programmable CID or Memory Locations
• Trilingual Display Options (English, French and Spanish)
• Intercom/Call Transfer Between Handsets and base
• 20 Distinctive Ring Options (10 ringer tones and 10 melody ringers)
• Mute and Hold Features
• Ringer off Feature
• DirectLink Mode
• Room/Baby Monitoring
• Battery Level Indicator
• Clock Display
•AnimationDisplays
Welcome
Features

[3] WELCOME/FEATURES/TERMINOLOGY www.uniden.com
This series features AutoTalkand AutoStandby. AutoTalk allows you to answer a call by just removing
the handset from the cradle so you don't have to waste time pushing buttons. AutoStandby allows you to
hang up by simply returning the handset to the cradle.
To protect you against mis-billed calls that might result from your phone being activated by other
equipment, this series has Random Codedigital security, which automatically selects one of more than
10,000,000 digital security codes for the handset and base.
Digital Spread Spectrum Technology uses a wider frequency band than standard digital transmissions. The
result is a more secure conversation with the clarity of digital sound, extended range, and minimal
interference from other cordless phones.
IntegriSoundBuilt in sound quality which provides life-like conversations.
With DirectLinkmode, you can use two or more handsets as radio transceivers (walkie-talkies).
Be sure to visit our web site: www.uniden.com
Unidenis a registered trademark of Uniden America Corporation.
AutoTalk, AutoStandby, DirectLink, IntegriSound and Random Code are trademarks of Uniden America.

WELCOME/FEATURES/TERMINOLOGY [4] www.uniden.com
Accessibility
If you have a disability and need customer service assistance or if you have any questions about how
Uniden's products can accommodate persons with disabilities, please call the accessibility voice/TTY
line:1-800-874-9314
A representative is available to talk to you M-F, 8:00 am to 5:00 pm, CST. After hours, you can leave us a
message, and we will call you back. Information is also available on our website, www.uniden.com, under
the "Accessibility" link.
Terminology
•Standby Mode - No station is currently in use. No dial tone is present.
•Talk Mode - The handset is off the cradle and talk/flash or on the handset, or on the base has
been pressed, enabling a dial tone.
•VoIP - Voice over Internet Protocol, a method of sending voice signals over broadband Internet
connections.
•Station - The main base or any registered handset.
•Configuration utility - The internal user interface that allows you to change configurations settings in the
UIP165P. You can access the configuration utility with an Internet web browser.

[5] CONTROLS & FUNCTIONS www.uniden.com
Controls & Functions
1. Handset Antenna
2. Beltclip Hole
3. Speakerphone Speaker and Ringer
4. Handset Battery Compartment
5. New Message LED
6. Handset Earpiece
7. LCD Display
8. soft Keys (P. 18)
9. cid/vol/ (volume up) (P. 51, 36 & 19)
10.redial/p/vol/ (volume down) (P. 35, 36 & 19)
11.
*
/tone/< (P. 20)
12. (speaker) (P. 32 & 33)
13.intcom/hold (P. 39 & 34)
14.Headset Jack Cover
15.talk/flash (P. 32, 33 & 34)
16.end (P. 19 & 32)
17. (phonebook) (P. 44)
18.#/> (P. 20)
19. (message) (P. 43)
20.Handset Microphone
21.Handset Charging Contacts
2
1
4
3
5
6
7
8
9
10
11
12
13 20
21
15
18
19
16
17
14
CONTROLS &
FUNCTIONS

CONTROLS & FUNCTIONS [6] www.uniden.com
47 48 49 50 51
22 23 24
25
26
27
28
29
30
31
32
41
46
42
43
44
45
33
34353637383940
22.
(
p
h
one
b
oo
k)
(P
. 44
)
23. exit ( P. 19 & 52 )
24. LCD Display
25. volume /(up/down)
(P. 36 & 19)
26. Soft keys (P. 18)
27. (Caller Id) (P. 51)
28. mute (P. 37)
29. flash (P. 33)
30. (speaker) /speaker LED (P. 32)
31. #/> (P. 20)
32. Base Microphone
33. p
h
one
LED
34. wan LED
35. lan LED
36. link LED
37. pwr (power) LED
38.
*
/tone/< (P. 20)
39. in use LED
40. charge LED
41.
Base Speaker
42. ring off (ringer off) (P. 36)/Ringer
off LED
43. find hs (handset) (P. 37)
44.
i
ntcom
(i
ntercom
)
(P
. 40
)
45. Base Charging Contacts
46. Base Antenna
47. POWER port
48. RESET switch
49. INTERNET[WAN] port
50. ETHERNET[LAN] port
51. PHONE port
CONTROLS &
FUNCTIONS

[7] SETTING UP YOUR BROADBAND PHONE www.uniden.com
SETTING UP YOUR
BROADBAND PHONE
Setting up your Broadband Phone
Safety Recommendations
To ensure general safety, follow these guidelines:
• Do not open or disassemble this product.
• Do not expose the product to moisture.
• Do not perform any action that creates a potential hazard to people or makes the
equipment unsafe.
• Ultimate disposal of this product should be handled according to all national laws and
regulations.
• Do not touch the wires on the cable ports or the wires of cables connected to a port as
hazardous voltage may be present on these wires when the equipment is powered on.
• The plug-socket combination must be accessible at all times because it serves as the power
disconnect.
• To avoid electric shock, do not connect the UIP165P to any RJ-11 telephone wall jacks.
Use caution when connecting cables. This could damage the UIP165P or the telephone
wiring in the building.
• Do not work on the system or connect or disconnect cables if lightning or thunder are
present in your area.
• Do not cover or block the air vents on the top or bottom surface of the UIP165P.
Overheating can cause permanent damage to the unit.
• Read the instructions completely before connecting the system to its power source.
GETTING STARTED

SETTING UP YOUR BROADBAND PHONE [8] www.uniden.com
SETTING UP YOUR
BROADBAND PHONE
911 Service Notice
911 dialing is not automatic.
Packet8 offers Enhanced 911 calling as a standard feature of its Internet phone
service. However, there are certain circumstances, when you dial 911 from a phone
connected to the Packet8 service, where E911 service may not function, or the E911
service may be in some way limited by comparison to traditional 911 service. Please
review the Terms and Conditions at www.packet8.net for additional information.
Before You Start!
Visit the Packet8 activation website http://activate.packet8.net/ and enter the
MAC address ID found on the bottom of your UIP165P. After you activate the
UIP165P, you will receive an email containing a 10-digit activation code. You will
need this activation code in Step 3.
STEP 1: Check Your Equipment
Check your broadband setup and the other equipment you will need:
• A broadband modem and a broadband Internet connection
• A computer with an Ethernet port (or a local Ethernet switch or router)
• One CAT-5 Ethernet cables
• The Packet8 10-digit activation code that was emailed to you when you created your
account. (If you don't have this email, go to www.packet8.net and enter the email address
and password used to create the account in the account sign in at the top of the screen.)
• If you want to use an analog phone or fax machine with the UIP165P, you will need a
standard telephone cable (RJ-11).
If you ordered your
UIP165P directly from
Packet8, it will already
be activated for you.
Your 10-digit activation
code was in the
confirmation email you
received when your
UIP165P shipped. (If
you don’t have this
email, go to
www.packet8.net and
enter the email address
and password used to
create the account in
the account sign in
page.)
note

[9] SETTING UP YOUR BROADBAND PHONE www.uniden.com
SETTING UP YOUR
BROADBAND PHONE
STEP 2: Install the rechargeable battery pack into the handset
The handset is powered by a rechargeable battery pack. The battery recharges
automatically when the handset is placed in the cradle.
1) Press down on the handset battery case cover (use the
finger indention for a better grip) and slide the cover
downward to remove.
2) Plug the battery pack connector (red & black wires) into
the jack inside the battery compartment. (The connector
notches fit into the grooves of the jack only one way.)
Match the wire colors to the polarity label in the battery
compartment, connect the battery and listen for a click to
insure connection.
3) Make sure you have a good connection by slightly pulling
on the battery wires. If the connection is secure, the
battery jack will remain in place.
4) Place the battery case cover back on the handset and slide
it upwards until it clicks into place.
•Use only the Uniden
(BT-446) rechargeable
battery pack supplied
with your cordless
telephone.
•Replacement battery
packs are also
available through the
Uniden Parts
Department (see back
cover page).
note

SETTING UP YOUR BROADBAND PHONE [10] www.uniden.com
SETTING UP YOUR
BROADBAND PHONE
STEP 3: Check Your Broadband Configuration
The UIP165P supports the two most common broadband connection protocols:
DHCP and PPPoE. If your broadband connection uses DHCP, you do not need to
change any settings on the UIP165P. If your broadband connection uses PPPoE,
you will need to enter your user name and password in "STEP 5: Activate your
Packet8 Service" on page 13.
If your broadband provider has given you a static IP address, you will need a special
configuration for your UIP165P. See the User Interface Guide at www.uniden.com/
voip for more information on configuring your UIP165P.
STEP 4: Connect Your UIP165P
Once your account is set up, you can connect your UIP165P.
1) Use the Ethernet cable to connect your broadband modem to the RJ-45 port labeled
INTERNET [WAN]. If you use a switch or a router for your local network, then you can
connect it to the INTERNET[WAN] port instead.
or

[11] SETTING UP YOUR BROADBAND PHONE www.uniden.com
SETTING UP YOUR
BROADBAND PHONE
2) Use another Ethernet cable to connect your PC to the RJ-45 port labeled ETHERNET
(LAN).
3) OPTIONAL: If you have a second phone you want to use, connect it to the RJ-11 port
labeled PHONE.
CAUTION
Do not connect the UIP165P to
a regular telephone wall jack.
•You can also connect a
wireless access point
to the ETHERNET (LAN)
port, if desired.
•PHONE is not a
separate line. Any
phone connected to
PHONE will share VoIP
line with all the
UIP165P's cordless
handsets and base.
note

SETTING UP YOUR BROADBAND PHONE [12] www.uniden.com
SETTING UP YOUR
BROADBAND PHONE
4) Use the included AC adapter to
connect the POWER port to a
100-240 Vac continuous power
outlet.
CAUTION
To avoid risk of fire or
electrical hazard, use ONLY the
included AC adapter!
LEDs flash several times, and the
pwr LED will remain on. If the
UIP165P was properly recognized by Packet8’s network, the link LED will remain on.
Test your connection by making a call with the handset and browsing to a web page
from your PC. If you have any difficulty, see the Troubleshooting section.
See the User Interface Guide at www.uniden.com/voip for more information on
configuring your UIP165P.
5) Place the handset in the cradle with the keypad facing forward.
6) Make sure that the charge LED illuminates. If the LED does not illuminate, check to see
that the AC adapter is plugged in and the handset makes good contact with the cradle
charging contacts.
7) Charge the handset battery pack for at least 15-20 hours before using your new cordless
handset for the first time.

[13] SETTING UP YOUR BROADBAND PHONE www.uniden.com
SETTING UP YOUR
BROADBAND PHONE
STEP 5: Activate your Packet8 Service
Once you have connected your UIP165P, you can activate your Packet8 service.
• You will need your 10-digit activation code that was sent to you by email when your
Packet8 order shipped. (You can also obtain your activation code at www.packet8.net by
signing in at your account page.)
• Pick up your telephone handset and dial the Activation Service number **012-0001.
• Follow the voice instructions and enter your 10-digit activation code.
• When you enter a valid code, your account will be activated and your Packet8 phone
number will be emailed to you. This Packet8 phone number can also be found in your
account details page after signing in at www.packet8.net.

EXPANDING YOUR PHONE [14] www.uniden.com
EXPANDING YOUR
PHONE
Expanding Your Phone
Ten Handset Expandability
Your phone supports up to ten handsets, including any handsets supplied with your
phone. You can place a fully-featured cordless handset anywhere power is available to
connect the handset charger. All the registered handsets ring when a call is received.
Your phone is compatible with a variety of handsets, including the TCX805, TCX905,
ELX500, TCX400, TCX440 and TCX450. (Please check www.uniden.com for an updated
list of expansion handsets compatible with this series.)
Registering Expansion Handsets
If you purchase an expansion handset, you need to register the handset before use.
Only one handset can be registered at a time.
Handsets supplied with the phone are registered to the base by the factory. When
you register an extra handset to the base, the handset ID will be assigned.
Before the expansion handset is registered, the battery pack MUST be charged for
15-20 hours.
To register TCX805 and TCX905 handsets
1) Make sure the base is in standby mode
2) Place the handset in the main base.
While the handset is registering,
Handset Registering will appear in the LCD. When
Registration Complete is displayed, the handset has been registered to the base. If
Registration Failed appears, please try these steps again.

[15] EXPANDING YOUR PHONE www.uniden.com
EXPANDING YOUR
PHONE
To register an ELX500, TCX450, TCX440, or TCX400 handset, follow the steps
below:
1) Disconnect the AC adapter from the main base.
2) While pressing down find hs, reconnect the AC adapter.
3) On the handset, press and hold # until you hear a beep.
While the handset is registering,
Handset Registering will appear in the LCD. When
Registration Complete is displayed, the handset has been registered to the base. If
Registration Failed appears, please try these steps again.
De-register the Handset
Deregister the handset's ID from the main base unit or the base ID from the
handset. You will usually only deregister the handset if you are moving it from one
base to another, if you are having a problem with your phone or if you need to
change the digital security code. The digital security code is an identification code
used to connect the handset and the base unit. Normally, setting the code is not
necessary. In the rare situation that you suspect another cordless telephone is
using the same security code, you can change the code by de-registering and
reregistering all handsets.
1) With the phone in standby mode, press the MENU soft
key on the handset and select Deregister HS. Then,
press the OK soft key.
Deregister HS? appears.
2) Press cid/vol/ or redial/p/vol/ to select
Yes and
then the OK soft key.
When de-registration is complete you will hear a confirmation tone, and
Deregistration Complete appears.
3) After de-registering the handset, place the handset to the base to register. You
must re-register the handset before you can use it.
&GTGIKUVGT*5!
;GU
0Q
$#%- &'.'6' 1-

INSTALLING THE BELTCLIP [16] www.uniden.com
INSTALLING THE
BELTCLIP
Installing the Beltclip
To attach the beltclip
Insert the beltclip into the holes on each side of the handset.
Press down until it clicks.
To remove the beltclip
Pull either side of the beltclip to release the tabs from the holes.
Headset Installation
Your cordless handset may be used with an optional headset.
To use this feature, insert the headset plug into the headset
jack. Your phone is ready for hands-free conversations.
(Headsets may be purchased by calling the Uniden Parts
Department or visiting the web site. See back cover page.)

[17] DISPLAY AND ICONS www.uniden.com
Display and Icons
Example of the standby mode display
•Handset
•Base
* This icon changes depending on ringer volume level (High, low and off)
ICON Appears During DESCRIPTION
Standby/Talk Battery icons indicate the handset battery status. This icon changes depending
on the battery status (empty, low, medium and full).
(for handset) Standby The Ringer off icon indicates that ringer is turned off.
Talk The Mute icon appears when you mute the handset or base.
Talk The Speaker icon appears when the handset speaker phone is used (handset only).
Talk The Privacy icon appears when the Privacy Mode is turned on.
Standby When a new message is received, an envelope icon is displayed on the LCD screen
(base only).
570#
*CPFUGV
0GY%+&
/'07
Ringer off icon (when the ringer is off)/ day of the week and time / battery icon
Handset ID and Banner
Number of new Caller ID calls received (If there are no new Caller ID messages,
Handset ID appears here.)
* Ringer Volume Level
Day of the week and time
envelope icon
Number of new Caller ID calls received

SOFT KEY FUNCTION [18] www.uniden.com
SOFT KEY
FUNCTION
Soft Key Function
"Soft" keys are keys that change function during the operation of the phone.
The function of each soft key is determined by the icon that appears directly above it. For example, when
the handset is in standby mode, pressing soft key 2 will access the main menu. When the handset is in
talk mode, pressing soft key 1 will mute the microphone.
Complete information on the features controlled by the soft keys can be found under each feature. There
are three soft keys on the base and each handset.
In standby mode
Handset Base
In talk mode
Handset Base
570#
*CPFUGV
0GY%+&
/'07
Soft key 2
570#
0GY%+&
4'&+#. /'07
Soft key 1 Soft key 2 Soft key 3
6CNM

/76' /'07
522JQPG
%9&: 24+8#%;

Soft key 1 Soft key 2 Soft key 2 Soft key 3

[19] ACCESSING THE MENUS www.uniden.com
Accessing the menus
Below are some tips for using the software interface on your phone.
• Press the MENU soft key to access the main menu.
•Usevolume up/down to scroll through options.
• Press the OK soft key to make a selection.
• Press the BACK soft key to return to the previous screen.
• Press end or exit to exit the menu.
Entering letters and special characters
There are several places in your phone
where you may want to enter letters and
other special characters, for instance, as
part of a phonebook entry or in the
handset banner. To enter letters, refer to
the letters above the numbers on the
keypad. When you are in a text area (like
the name field in the phonebook), the
displayed characters appear in the
following order each time you press the
number key:
1) upper case letters
2) lower case letters
3) the number corresponding to the
key
The table to the right lists every
available character and shows how many
times to press the key to enter that
character.
