Unipro UN-H1715DS-EA User manual

Operation Care Service
UniPro Dual-Speed
175 RPM / 320 RPM
Floor Machine
UniPro Dual-Speed
175 RPM / 320 RPM Floor Machine

Subject to Change Without Noce
Specificaons
Model # UN-H1715DS-EA UN-H2015DS-EA
Machine Size 17 inch 20 inch
Pad Size 16 inch 19 inch
Pad Speed 175 RPM / 320 RPM 175 RPM / 320 RPM
Current Draw 8.1 / 8.5 Amp 8.5 / 9.1 Amp
All Sizes
Motor 1.5 HP, 66 frame, dual capacitor AC motor
Power 115V, 60 Hz power, (230V oponal)
Power Cord 50 . 14-3 STO industrial power cord w/molded plug
Drive System Triple-planetary HD 10:1 commercial gears
dB Rang 60 dB - Meets GS42 standard
Warranty 3-Year Limited
UniPro 175 RPM
Floor Machine
Stripping, Scrubbing, Carpet Care
Realize maximum power with the twin capacitor, AC motor and
the ruggedly reliable floor machine Unipro design. Machine
operators appreciate the solid performance of an extremely well-
built floor machine that delivers reliability on every job.
Power
Ÿ1.5 HP, 66 frame, dual capacitor AC motor
Ÿ115V, 60 Hz power, (230V oponal)
Ÿ50 . 14-3 STO industrial power cord with molded plug
Drive System
ŸTriple-planetary HD 10:1 helical-cut commercial gears drive
pads and brushes at 175 RPM
Engineered Design
ŸAll steel construcon with welded, powder-coated frame
ŸOne piece chrome, heavy-duty steel handle with vinyl grips
ŸVariable posion posive handle lock
Ÿ17” and 20” steel brush covers with full wraparound bumper
ŸDual steel operang triggers
ŸNegave pressure on/off switch
ŸThumb-operated safety switch
Ÿ1” x 5” non-marking ball bearing wheels
ŸThe addion of weights can stress equipment components.
Adding weights to non XHD models is not recommended.
Safety Features
ŸQuiet 60 dB operaon. Meets GS42 standard.
ŸUL/CUL listed
UniPro Dual-Speed
175 RPM / 320 RPM Floor Machine

SERVICE INFORMATION
To obtain consistent performance over the life of this
machine, read through these instructions and save for
future reference. If you require service, contact your
dealer or the dealer’s authorized service provider.
Always refer to your Limited Warranty for complete
service information.
The model, type and serial number for the machine
are indicated on the data plate on the side of the
handle. For prompt and complete service, refer to
these numbers when inquiring about service.
IMPORTANT SAFETY INFORMATION
When using this floor machine, basic precautions
should always be followed including the following:
READ ALL INSTRUCTIONS BEFORE USING
THIS FLOOR MACHINE
WARNING: ELECTRIC SHOCK
CAN CAUSE SERIOUS INJURY
OR BE FATAL. READ THE
FOLLOWING INSTRUCTION
ON THE USE AND OPERATION
OF FLOOR MACHINES
ŸThis floor machine is equipped with a safety lock
and power switch triggers designed for your safety.
Do not attempt to bypass or defeat the safety
switch lock. Never use any device to lock the
power switch triggers in the “ON” position.
ŸDo not leave the machine alone and unplugged.
Unplug the machine before servicing or changing
brushes or pads.
ŸDo not allow this machine to be used as a toy.
Close attention is necessary when used near
children.
ŸDo not leave the machine connected to an
electrical outlet unattended.
ŸUse only as described in this manual. Use only
with factory recommended attachments.
ŸDo not use this machine with a damaged power
cord or plug. If the machine is not working
properly or has been dropped, damaged or left
outdoors, return to your service provider for
inspection and repair before use.
ŸUse care to keep the electric power cord away
from sharp edges or corners.
ŸKeep the cord away from heated surfaces.
ŸConnect only to properly grounded (3-wire)
outlets. See Grounding Instructions on Page 4.
ŸDo not use extension cords or outlets with
inadequate current carrying capacity.
ŸTurn off all controls before unplugging.
ŸDo not unplug by pulling on the cord. To
unplug, grasp the plug and pull.
ŸDo not handle the plug, cord, or floor machine
with wet hands.
ŸWind the cord no tighter than necessary to retain
it during storage. See Cord Storage on Page 5.
ŸUse extra care when working on or near stairs.
ŸDo not use in conjunction with flammable or
combustible liquids like gasoline, or use in areas
where explosive vapors or dusts may be present.
ŸStore the machine in a cool, dry area.
ŸKeep your work area well lit.
ŸWARNING: To avoid electrical shock, use
indoors only.
UniPro Dual-Speed
175 RPM / 320 RPM Floor Machine

OPERATION / ACCESSORIES
GROUNDING INSTRUCTIONS
This machine must be grounded. If it should
malfunction or break down, grounding provides path of
least resistance for electric current to reduce the risk of
electric shock. This machine is equipped with a cord that
has an equipment-grounding conductor and grounding
plug. The plug must be plugged into an appropriate
outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
FOR FLOOR MACHINES RATED
LESS THAN 150 VOLTS
WARNING: DO NO USE
GROUNDING ADAPTERS ON
FLOOR MACHINES IN CANADA.
CHECK WITH CANADIAN CODES
FOR PROPER EQUIPMENT
USAGE. IMPROPER USE OF
GROUND ADAPTORS CAN CAUSE
SERIOUS INJURY, FIRE, OR BE
FATAL.
Improper connection of an equipment grounding
conductor can result in risk of electric shock. Check
with a qualified electrician if you are in doubt as to
whether the outlet is properly grounded. Do not modify
the plug provided with the machine. If the plug will not
fit the outlet, have a proper outlet installed by a qualified
electrician.
This machine is for use on a nominal 120 Volt circuit and
has a grounding plug that looks like the plug in Figure 1.
A temporary adapter (Figure 2) may be used to connect
the machine to a 2 pole receptacle as shown, if a properly
grounded outlet is not available. The temporary adapter
should be used only until a properly grounded outlet
(Figure 1) can be installed by a qualified electrician. The
green colored rigid ear, lug, or the like extending from
the adapter must be connected to a permanent ground
such as a properly grounded outlet box cover. Whenever
the adapter is used, it must be held in place by metal
screws.
FOR FLOOR MACHINES RATED 150-220 VOLTS:
If a machine is provided with an attachment plug cap as
shown in Figure 3, it is intended for use on a 240 Volt
circuit. No adapter is available for this cap.
CHOOSE THE RIGHT BRUSH AND
PAD DRIVER
This floor machine is packed, completely assembled
and ready for use after you install a brush or pad
driver.
This machine is designed to be used for many
different floor care applications. Use the correct
brush or pad for the type of job to perform. Other
accessories are available to expand floor care
capabilities. See optional accessories on Page 10)
When ordering brushes or pad drivers, refer to the
table below:
Machine Pad Driver Brush
Size Size Size
13” 12” 11”
15” 14” 13”
17” 16” 15”
20” 19” 18”
A “B” Style clutch plate is common on all models.
UniPro Dual-Speed
175 RPM / 320 RPM Floor Machine

Figure 6
4
CONTROLS
ON/OFF POWER SWITCH TRIGGERS
The ON/OFF switch is located in the dual triggers
underneath the handle grips. Squeeze the triggers to
power the motor.
TO TURN THE MACHINE ON
The operating handle must be lowered to the
operating position before switching the machine
ON. Place both hands firmly on the handle grips
with your fingers around the power triggers. DO
NOT apply pressure on the triggers before the safety
switch lock is disengaged.
Disengage the safety switch lock by pushing it
forward with one thumb. Then, while holding the
safety switch lock in the disengaged position,
squeeze the power triggers forward toward the
handle grip and return your thumb to the handle grip
(Figure 7)
To stop the machine, simply release the triggers.
The safety switch lock will automatically return to
the engaged position (Figure 7).
BRUSH AND PAD DRIVER INSTALLATUION
NOTE: Disconnect the power cord from the
electrical outlet before installing a brush or pad
driver.
To install a brush or pad driver, leave the handle in the
upright position and tip the machine back so it rests
on its wheels and upper handle. The brush and pad
driver both attach in the same manner. Align the
cutouts on the inner ring of the brush with the tables
on the inside of the ring of the drive hub (Figure 5)
Push the brush firmly in position then turn it counter-
clockwise until it locks into place. To remove, turn
the brush clockwise until it stops, and then lift it off.
NOTE: Remove the brush or pad driver for when
storing the machine. Never store the machine standing
on brush or pad driver. This can damage the tool
bristles.
NOTE: Disconnect power cord from the electrical
outlet before installing or removing brush, pad or pad
driver.
HANDLE ADJUSTMENTS
The handle can be adjusted to any desired work
position by simply pushing up the handle lock
(Figure 5). Move the handle to the desired position
then firmly push down on the handle lock which will
lock the handle in position. NEVER operate the
machine with the handle unlocked.
HANDLE CAM LOCK ADJUSTMENT
With the handle cam lock in the “UP” position (un
locked), tighten the adjusting nuts until there is a
slight drag when the handle is raised or lowered. The
tube should be locked securely when the handle lock
is pressed downward (Figure 6).
Figure 4
Figure 5
Figure 6
UniPro Dual-Speed
175 RPM / 320 RPM Floor Machine

Push forward to
disengage safety
GUIDELINES FOR OPERATION
ŸThis floor machine is a very sensitive, powerful
unit. When in operation it should be guided
gradually and smoothly without sudden or rough
motions. Practice with your machine on a
smooth surface until you gain operating
experience.
ŸFor ease of operation, always keep the brush or
pad surface level, balanced, and flat on the floor
at all times.
ŸAlways adjust the operating handle to a
comfortable height at which the brush or pad
surface is balanced before starting the machine.
See Handle Adjustments on page 4.
ŸYour floor machine will operate differently on
different surfaces. For example, there will be
much more resistance when the machine is used
with a brush on carpeted surfaces, than when it is
used with a pad on a smooth floor. The operator
should be prepared to adjust for these
differences.
ŸBEGIN OPERATING THE FLOOR MACHINE
WITH THE BRUSH OR PAD SURFACE
LEVEL, BALANCED, AND FLAT ON THE
FLOOR.
ŸTo move the machine to the right, slowly apply
slight upward pressure on the handle.
ŸTo move the machine left, slowly apply slight
downward pressure on the handle.
ŸTo move the machine forwards or back, keep the
brush or pad flat on the floor and push or pull the
machine in the desired directions.
CLEANUP AND STORAGE
After being used, your floor machine can be wiped
clean with a soft, damp cloth and should be stored
in a clean dry place.
NEVER store with your machine standing on the
brush or pad driver. This can alter the bend of the
bristles and cause the machine to wobble.+
DO NOT LET THE MACHINE REST ON THE
PAD OR BRUSH FOR AN EXTENDED
PERIOD OF TIME. This may alter the shape of
the pad or brush which may cause the machine to
wobble.
CORD STORAGE
When not in use, loosely wind the power cord
around the cord storage hook on the handle shaft
and both of the handle grips as shown.
This 175/300 RPM 2-Speed floor machine is
designed for stripping, scrubbing and shampooing
at 175 RPM or for buffing at 300 RPM. A toggle
switch on the left side of the switch box selects the
brush speed. DO NOT operate this floor machine
for buffing at low speed. It will not do an effective
job and tends to overload the motor.
UniPro Dual-Speed
175 RPM / 320 RPM Floor Machine

UniPro Dual-Speed
175 RPM / 320 RPM Floor Machine
Company name
Contact Name Title E-mail
Street Address
City State Zip
Phone Fax
Email
Machine Serial Number Purchase Date
Purchased From
Please complete, mail or fax your registration card to
JonDon Inc.
400 Medinah Road
Roselle, IL 60172
or e-mail the registration card to [email protected]
.
For multiple units, please list serial numbers on a separate sheet. This warranty card and
your bill of sale must be presented for warranty service
BY MAIL

LIMITED WARRANTY
This floor machine has been manufactured, tested and inspected in accordance with carefully specified engineering
requirements, is warranted to be free from defects in material and workmanship.
This Limited Warranty is, however, subject to the following qualifications, conditions and limitations which are set
forth to provide all users of this floor machine with information concerning the duration, extent, availability, and
applicability of this Limited Warranty, the procedure to be taken to obtain its performance, and other information
concerning the Limited Warranty policy.
This Limited Warranty is extended to the original end user as follows:
Floor Machines: 3 year parts replacement and 1 year service labor warranty.
Replacement parts guaranteed for 90 days from date of installation against defects in material and workmanship.
This Limited Warranty will not cover damage attributable to (1) Improper, unreasonable or negligent use or abuse of
the equipment and (2) abrasions or punctures of the equipment
The start date of the Limited Warranty coverage shall be the purchase date of the original end user or six months
from the date the machine was shipped from the factory, whichever comes first.
PARTS OF EQUIPMENT NOT COVERED BY THE LIMITED WARRANTY
Certain parts of equipment require replacement in the ordinary use due to normal wear by reason of their
characteristics. Normal wear items such as cords, switches, bumpers, bearings, etc. are excluded from the Limited
Warranty.
EXCEPTIONS AND EXCLUSIONS FROM THE LIMITED WARRANTY
This equipment is required to be used on electric current as indicated on the data plate. Otherwise damage, defects,
malfunctions or other failure of the equipment arising from use on electric current not as indicated are excepted and
excluded from this Limited Warranty. Defects, malfunctions, failure or damage of the equipment caused by
improper, unreasonable or neglect use or abuse while in possession of the purchaser are likewise excluded from this
warranty. If repair is done on your equipment by anyone other than those designated as authorized to perform such
work without first having obtained factory instructions. The dealer may determine that this warranty will not apply
and that reimbursement for such repair will not be made because of the failure to comply with such factory specified
instructions.
PROCEDURE TO BE TAKEN TO OBTAIN PERFORMANCE OF LIMITED WARRANTY REPAIR
To secure repair of the equipment or any warranted parts under this Limited Warranty, the inoperative equipment or
warranted parts, together with satisfactory evidence of the purchase date, must be delivered, with shipping and
delivery charges prepaid, to the dealer or the dealer’s Authorized Service Provider.
If these terms are met, this floor machine or accessory will be repaired, at no additional charge or costs to the
customer, and the repaired product returned to the customer, with all shipping and delivery charges pre-paid. In
following the procedures set forth,
PLEASE MAKE CERTAIN to state the model, type and serial number as shown on the data plate of the equipment.
REPLACEMENT
In the event of a defect, malfunction or failure of your this floor machine or any warranted part, the dealer may, at
its sole option and own expense, replace the equipment or any warranted part.
NO REFUND OF PURCHASE PRICE
The dealer will not, as a matter of it’s Limited Warranty policy, refund the customer’s purchase price.
UniPro Dual-Speed
175 RPM / 320 RPM Floor Machine
