United States Stove CAVALIER C9830L User manual

227 Industrial Park Road • P.O. Box 151 • South Pittsburg, TN 37380 • [phone]
UNITED STATES STOVE COMPANY
Propane (LPG) Model
C9830L
Natural Gas Model
C9830N
851257A 11/97
WARNINGS
WARNING: If the information in this manual is not followed
exactly, a fire or explosion may result causing property
damage, personal injury or loss of life.
THIS APPLIANCE MAY BE INSTALLED IN
AN AFTERMARKET* MANUFACTURED
(MOBILE) HOME, WHERE NOT
PROHIBITED BY STATE OR LOCAL
CODES.
*Aftermarket: Completion of sale, not
for purpose of resale, from the
manufacturer.
THIS APPLIANCE IS ONLY FOR USE WITH
THE TYPE OF GAS INDICATED ON THE
RATING PLATE. THIS APPLIANCE IS NOT
CONVERTIBLE FOR USE WITH OTHER
GASES.
This is an unvented gas-fired heater. It uses
air(oxygen)fromtheroominwhichitisinstalled.
Provisions for adequate combustion and
ventilation air must be provided. Refer to
"Adequate Combustion And Ventilation Air"
on page 6 of this manual.
WARNING: Do not use a blower insert, heat
exchanger insert or other accessory not approved
for use with this heater.
VENT-FREE PEDESTAL GAS HEATER
INSTALLATION AND OPERATION INSTRUCTIONS
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
•Do nottouch anyelectrical switch;do notuse anyphone
in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
Installation and service must be performed by a qualified
installer, service agency or the gas supplier.

TABLE OF CONTENTS
TC
IMPORTANT SAFETY INFORMATION....................................................3-4
PRODUCT FEATURES..........................................................................................4
SPECIFICATIONS .........................................................................................5
CONTENTS ................................................................................................. 5
ITEMS REQUIRED FOR INSTALLATION.................................................. 6
INSTALLATION........................................................................................... 7
GAS CONNECTION................................................................................. 8-9
GAS PRESSURE CHECK............................................................................ 9
LOG ASSEMBLY .......................................................................................10
OPERATING INSTRUCTIONS............................................................... 11-13
CLEANING/SERVICING ......................................................................13-14
FLAME APPEARANCE .............................................................................14
PARTS LIST FOR HEATER ASSEMBLY..............................................15-16
PARTS LIST FOR BURNER& LOG ASSEMBLY......................................17-18
TROUBLE SHOOTING..........................................................................19-20
OPTIONAL EQUIPMENT.....................................................................................21
NOTE.......................................................................................................................22
LIMITED WARRANTY POLICY................................................................23
NOTICE
Installation and repair must be done by a qualified service person. The appliance
should be inspected before use and at least annually by a professional service
person.Morefrequentcleaningmayberequiredduetoexcessivelintfromcarpeting,
bedding material, etc. It is imperative that control compartments, burners and
circulating air passageways of the appliance be kept clean.

IMPORTANT SAFETY INFORMATION
3
INSTALLER: Please leave these instructions with the owner.
OWNER: Please retain these instructions for future reference.
IMPORTANT: Read these instructions carefully before installing or trying to operate this heater.
WARNING: Any change to this heater or its controls can be dangerous.
Improper installation or use of the heater can cause serious injury or
death from fire, burns, explosion or carbon monoxide poisoning.
WARNING
CARBON MONOXIDE POISONING: Earlysigns ofcarbon monoxidepoisoning aresimilar tothe
fluwithheadaches,dizzinessand/ornausea.Ifyouhavethesesigns,obtainfreshairimmediately.
Have the heater serviced as it may not be operating properly.
The installation must conform with local codes or, in the absence of local codes, with the National
Fuel Gas Code, ANSI Z223.1.
The 9830N/9830L vent-free gas heater system cannot be installed in a bedroom.
Do not install the heaters in a bathroom.
WARNING:Improperinstallation,adjustment,alteration,serviceormaintenancecancauseinjury
orproperty damage. Refertothis owner'smanual. Installationand servicemustbe performedby
a qualified installer; service agency or the gas supplier.
Topreventmalfunctionand/orsooting,anunventedgasheatershouldbecleanedatleastannually
byaprofessionalserviceperson.Morefrequentcleaningmayberequiredduetoexcessivelintfrom
carpeting,etc.Itisimperativethatcontrolcompartments,burnersandcirculatingairpassageways
be kept clean.
Correct placement of the ceramic fiber logs is necessary to avoid problems with sooting. Sooting
cansettleonsurfacesoutsidetheheater and causediscoloration.Seetheappropriatesectionsof
this manual for instructions.
WARNING: Do not allow fans to blow directly into the fireplace. Avoid any drafts that alter burner
flame patterns. Do not place a blower inside burn area of firebox. Ceiling fans may create drafts
that alter burner flame patterns. Sooting and improper burning will occur.
This is a vent-free gas-fired heater. It uses air (oxygen) from the room in which it is installed.
Provisions for adequate combustion and ventilation air must be provided. Refer to installation
guidelines.
Children and adults should be alerted to the hazard of high surface temperature and should stay
away to avoid burns or clothing ignition.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11. Young children should be carefully supervised when they are in the same room with the appliance.

IMPORTANT SAFETY INFORMATION
Do not place clothing or other flammable material near the appliance.
Keep appliance area clear and free from combustible materials, gasoline and other flammable
vapors and liquids.
Any safety screen or guard removed for servicing must be replaced prior to operating the heater.
Thisvent-free gasheateris intendedto be smokeless.If logsappearto smoke,turnoff theheater
andcallaqualifiedserviceperson.Initialburnoffmaycauseslightsmokeandodorduringthefirst
four hours of operation.
Input ratings are shown in BTU per hour and are for elevations up to 2,000 feet. For elevations
above 2,000 feet, input ratings should be reduced 4 percent for each 1,000 feet above sea level.
Refer to the National Fuel Gas Code.
Theheateranditsindividualshutoffvalvemustbedisconnectedfromthegassupplypipingsystem
during any pressure testing of that system at test pressures in excess of 1/2 psig (3.5 kPa).
The heater must be isolated from the gas supply piping system by closing its individual manual
shutoff valve during any pressure testing of the gas supply piping system at test pressures equal
to or less than 1/2 psig (3.5 kPa).
Do not use this room heater if any part has been under water. Immediately call a qualified service
technician to inspect the room heater and to replace any part of the control system and any gas
control which has been under water.
PRODUCT FEATURES
4
12.
13.
14.
15.
16.
17.
18.
19.
FIGURE1.9830Vent-FreePedestal
GasHeater.
Features:
• Heating Efficiency - 99.9%
• Wide BTU Range: 8,000 - 30,000.
• Safe Operation - Oxygen Depletion Sensor (ODS).
• No Electricity Required.
• Fiber Ceramic Logs.
• Push-Button Piezo Ignitor.
• Clean Operation.
• Wide Bay Front.
• Compact Design.
• Easy Operation.
• Heats up to 1,000 square feet.

SPECIFICATIONS
NaturalGas
ManifoldPressureSetting4"w.c.
GasInletPressure Maximum10-1/2"w.c.
Minimum5"w.c. GasRate Number
Model Number Type Max BTU/Hr Min BTU/Hr ofBurners
9830N Manual 30,000 8,000 2
Propane/LPG
Note:Anexternalregulatorisrequiredtoreducesupplypressuretoamaximumof13"w.c.
ManifoldPressureSetting10"w.c.
GasInletPressure Maximum13"w.c.
Minimum11"w.c. GasRate Number
Model Number Type Max BTU/Hr Min BTU/Hr ofBurners
9830L Manual 30,000 8,000 2
Controls-Maincontrolhas4positions:
1.OFF-Allgastothegaslogsisshutoffatthecontrol
2.IGN-Piezoignitorallowsignitionofthepilotwithouttheuseofmatchesorbatteries
3.PILOT-Valvepositiontolight/maintainastandingpilot
4.ON-Gasflowtocompletesystem,frontburnerignition
FrontBurnerControlKnob-Infinitecontrol,rotateclockwisetominimumrateandcounter
clockwiseformaximumrate.
RearBurnerControlKnob-Has3positions:
1.OFF-Gastorearburnerisshutoffatcontrol
2.ON/MAX-Maximumgasflowtorearburner
3.MIN-Minimumgasflowratetorearburner
5
GLOVES ARE RECOMMENDEDWHEN HANDLING CERAMIC FIBER LOGS
TO PREVENT SKIN IRRITATION FROM LOOSE FIBERS. LOGS ARE
FRAGILE, HANDLE WITH CARE.
Carefullyinspectthecontentsforshippingdamageandimmediatelyinformyourdealerifanydamageisfound.
CAUTION
9830Land9830NUnventedGasHeaters
1. PacketcontainingHomeowners/Installationinstructions.
2. Logboxcontainingfour(4)fiberceramiclogs,refertoinstallationinstructions.
3. Unventedgasheater.
CHECKTHAT ALLLISTEDPARTS HAVEBEENRECEIVED
CONTENTS

6
ITEMS REQUIRED FOR INSTALLATION
ITEMS REQUIRED FOR INSTALLATION
Ensure that the following items are available before proceeding with installation:
• External regulator (for propane/LPG only) • Manual shutoff valve
• Piping which complies with local codes • Sediment trap
• Pipe sealant approved for use with • Pipe wrench
propane/LPG (resistant to sulfur compounds)
CODES
Adheretoalllocalcodesorintheirabsence,thelatesteditionofTHENATIONALFUELGASCODEANSI
Z223.1 or NFPA54 which can be obtained from:
American National Standards Institute, Inc. National Fire Protection Association, Inc.
1430 Broadway or BatterymarchPark
New York, NY 10018 Quincy, MA 02269
WARNING
ADEQUATE COMBUSTION AND VENTILATION AIR
Thisheatershallnotbeinstalledinaconfinedspaceorunusuallytightconstructionunlessprovisionsare
provided for adequate combustion and ventilation air.
Unusually tight construction is defined as construction where:
(a) Wallsandceilingsexposedtotheoutsideatmospherehaveacontinuouswatervaporretarder
with a rating of 1 perm (6 x 10½ kg per pa-sec-m ) or less with openings gasketed or sealed, and
(b) Weather stripping has been added on openable windows and doors, and
(c) Caulking or sealants are applied to areas such as joints around window and door frames,
between soleplates and floors, between wall-ceiling joints, between wall panels, at penetrations
for plumbing, electrical, and gas lines, and at other openings.
The National Fuel Gas Code defines a confined space as a space whose volume is less than 50 cubic
feet per 1,000 BTU per hour (4.8m per kw) of the aggregate input rating of all appliances installed in that
space and an unconfined space is defined as a space whose volume is not less than 50 cubic feet per
1,000 BTU per hour (4.8m per kw) of the aggregate input rating of all appliances installed in that space.
Roomscommunicatingdirectlywiththespaceinwhichtheappliancesareinstalled,throughopeningsnot
furnished with doors, are considered a part of the unconfined space.
Due to high temperatures, do not install the heater:
• Where curtains, furniture, clothing or other flammable objects are less than 42"
from the front of the heater.
• In high traffic areas.
• In windy or drafty areas.
DO NOT PLACE CLOTHING OR OTHER FLAMMABLE MATERIAL ON OR NEAR THE
APPLIANCE.
11
3
3

INSTALLATION
Thefollowingformulacanbeusedtodeterminethemaximum
heaterratingperthedefinitionofunconfinedspace:
BTU/HR= (L1+L2)Ftx (W)Ftx (H)Ftx 1000
50
Considertwoconnectingroomswithanopenareabetween,
withthefollowingdimensions:(SeeFig.2,Example)
L1=15-1/2Ft.,L2=12Ft.,W=12ft.,H=8Ft
50
=52800BTU/HR
Iftherewereadoorbetweenthetworoomsthecalculation
wouldbebasedonlyontheroomwiththeheater.
BTU/HR=(15-1/2)x(12)x(8)x1000
50
=29760BTU/HR
7
FIGURE 2.
WARNINGWARNING WARNING
Ensuretheminimum clearancesshowninFIGURE 3aremaintainedfor accessibility
for purposes of servicing and proper operation. Left and right clearances are
determined when facing the front of the heater.
FIGURE3.MinimumClearances
Maintain these
clearances to ensure
adequate space around
air opening for proper
operation.
Minimum clearances to
combustibles:
Topofheater.................................36"
Sidesofheater...............................8"
Frontofheater.............................42"
Rearofheater................................4"
L2 (12')
L1 (15-1/2') W (12')
H (8')
36"
8"
8"
4"
42"
If the area in which the heater may be operated is smaller than that defined as an
unconfined space or if the building is of unusually tight construction, provide
adequate combustion and ventilation air by one of the methods described in the
National Fuel Gas Code, ANSI Z223.1, Section 5.3, or applicable local codes.
When installing the appliance directly on carpeting, tile or other combustible
material, other than wood flooring, the appliance must be installed on a metal or
wood panel extending the full width and depth of the appliance.

GAS CONNECTION
NOTICE
CAUTION
IMPORTANT:Loosenthepipeadapter
on the flex tube before installing to the
systempiping.
FIGURE4.GasConnection
CHECKGASTYPE:Thegassupplymustbethesameasstatedonheater'sratingplate.Ifthegassupplyis
different,DONOTINSTALLtheheater.Contactyourdealerforthecorrectmodel.
8
A qualified gas appliance installer must connect the fireplace to the gas supply.
Consult all local codes.
Use new black iron or steel pipe only. Internally tinned copper tubing can be used
in some areas when permitted by local codes. Only use pipe of 1/2" or greater
diameter to allow full gas volume to heater. Excessive pressure loss will occur if the
pipe is too small.
Amanualshutoffvalve,unionandplugged 1/8" NPT pressure tapping point must be
installed upstream of the heater (FIGURE 4).
A sediment trap must be installed upstream of the heater to prevent moisture and
contaminants from passing through the pipe to the heater controls and burners.
Failure to do so could prevent the heater from operating reliably (FIGURE 4).
WARNING
TO HEATER
CONTROL VALVE STAINLESS
FLEXIBLE TUBE
PIPE
COUPLING
PIPE
MANUAL
SHUTOFF VALVE
TEE JOINT
PIPE NIPPLE
CAP
SEDIMENT TRAP
Connecting directly to an unregulated propane/LPG tank can cause an
explosion.

GAS CONNECTION
9
GAS PRESSURE CHECK
Theheaterregulatorcontrolstheburnerpressurewhichshouldbecheckedatthepressuretestpointlocatedonthe
rightsideofthemaincontrolandisaccessiblefromthesideofthegaslogassembly(seeFIGURE6).
Thepressureshouldbecheckedwiththeheaterburningandthecontrolsettohigh(HI).
Thepressureregulatorispresetandlockedtoavoidtampering.IfthepressureisnotasspecifiedinProduct
Specifications(Page5),contactyourdealerandreplacetheregulator.
FIGURE6.PressureTestPointLocation
Control Valve
Control Bracket
(Rightside view
facing heater)
Test Pressure
Input Test Pressure
Output
Gas Inlet Connection (3/8" NPT)
FIGURE5.RearViewof9830Vent-FreeGasHeater
The gasinletconnectionis3/8"NPT,madeat
therearofthemaincontrolthroughtheareaat
therearofthepedestal.
Testallgasjointsfromthegasmetertothe
heaterforleaksusingsoapandwatersolution
aftercompletingconnection.DONOTUSE
ANOPENFLAME.

10
REMOVING FRONT SCREEN
WARNING
FRONT SCREEN
Thefrontscreenmustbeinplaceatalltimeswhentheapplianceisoperating.Donotobstructthescreenedopenings
oftheheater.
The positioning of the logs is critical to the safe and clean operation of this heater.
Sootingandotherproblemsmayresultifthelogsarenotproperlyandfirmlysituated
in the appliance. Never add additional logs or embellishments such as pine cones,
vermiculite or rock wool to the heater.
FIGURE8.LogSetAssembly
#1
#2
WARNING: Failure to position the
partsinaccordancewiththesedia-
grams or failure to use only parts
specificallyapprovedwiththisheater
may result in property damage or
personalinjury.
LOG POSITIONING
Thisunitissuppliedwithasetoffourceramicfiberlogs. Donothandletheselogswithyourbarehands! Always
wearglovestopreventskinirritationfromceramicfibers. Afterhandlinglogs,washyourhandsgentlywithsoap
andwatertoremoveanytracesoffibers.
PROPER INSTALLATION SEQUENCE:
1. Installtherearlog(#2)ontherearsetoflocators. Visuallychecktoverifythelogissecurelyplacedonthelocators.
2. Installthefrontlog(#1)onthefrontlocators. Visuallychecktoverifythelogissecurelyplacedonthelocators.
3. Installtheleftandrightcrosstwigsasillustrated,onthelocatorpinsprovidedinthefrontandrearlogs.Holes
providedinthebottomofthecrosstwigsshouldallowthemtoseatcompletelyoverthesepins.
FIG 7B FIG 7C
1)Liftthefrontscreenslightlyup(Fig.7A)andthentiltthebottomofthescreeninwardanddownward(Fig.
2B). 2) Lean the top of the screen toward you slightly (Fig. 7B) and then proceed to carefully bring the
screen straight back (Fig. 7C). NOTE: To reinstall the front screen, reverse steps 1 & 2.
LOG ASSEMBLY
FIG 7A

11
OPERATING INSTRUCTIONS
Avoidanydraftsthataltertheburnerflamepatterns.Donotallowfanstoblowdirectlyintotheheater.Donotplace
ablowerinsideburnareaoffirebox.Ceilingfansmaycreatedraftsthatalterburnerflamepatterns.Sootingand
improperburningwilloccur.
Thisvent-freegasheaterisintendedtobesmokeless.Iflogsappeartosmoke,turnofftheheaterandcallaqualified
serviceperson.Initialburnoffmaycauseslightsmokeandodorduringthefirstfourhoursofoperation.
WARNING: If you do not follow these instructions exactly, a fire or explosion may
result causing property damage, personal injury or loss of life.
Thisapplianceisequippedwithanignitiondevice(piezo)whichautomaticallylightsthepilot. Ifpiezofails,
thenlightthepilotusingmatches. Refertomatchlightinginstructions(page13). Whenlightingthepilot,
followtheseinstructionsexactly.
BEFORELIGHTINGsmellallaroundtheapplianceareaforgas.Besuretosmellnexttothefloorbecause
somegasisheavierthanairandwillsettleonthefloor.
WHAT TO DO IF YOU SMELL GAS
•Donotattempttolightanyappliance.
•Donottouchanyelectricswitch;donotuseanyphoneinyourbuilding.
•Immediatelycallyourgassupplierfromaneighbor'sphone.Followthegassupplier'sinstructions.
•Ifyoucannotreachyourgassupplier,callthefiredepartment.
Useonlyyourhandtopushinorturnthegascontrolknob.Neverusetools.Iftheknobwillnotpushinor
turnbyhand,don'ttrytorepairit,callaqualifiedservicetechnician.Forceorattemptedrepairmayresult
inafireorexplosion.
Donotusethisapplianceifanyparthasbeenunderwater.Immediatelycallaqualifiedservicetechnician
toinspecttheapplianceandtoreplaceanypartofthecontrolsystemandanygascontrolwhichhasbeenunder
water.
A.
WARNING
FOR YOUR SAFETY READ BEFORE LIGHTING
Donotstoreorusegasolineorotherflammablevaporsandliquidsinthevicinityofthisoranyother
appliance.
FOR YOUR SAFETY
B.
C.
D.

12
OPERATING INSTRUCTIONS
LIGHTING INSTRUCTIONS
1. Open access door.
2. Set front burner to Min. and turn off the rear burner by depressing knob and rotating clockwise
until stop.
3. Unplug all electric power (optional blower) if service is to be performed.
4. Push in gas control knob slightly and turn clockwise to "OFF". Do not force.
5. Close access door.
TURN OFF GAS TO APPLIANCE
6. Push in the control (knob 1) all the way and
rotatecounter-clockwise to"PILOT".
The piezo ignitor will light the pilot as the knob
passes "IGN" traveling to the "PILOT". Con
tinue to hold the control (knob 1) in for about
ten (10) seconds after the pilot is lit. Release
knob and it should pop back up. Pilot should
remainlit. Ifitgoesout,repeatsteps4through
6. Ifthecontrol(knob1)doesnotpopupwhen
released, stop and immediately call your ser
vice technician or gas supplier. If the pilot will
not stay lit after several tries, turn the gas
control(knob 1)to "OFF"and callyour service
technician or your gas supplier.
7. Turn gas control (knob1) counter-clockwise
to "ON".
8. Set the front burner (knob 2) to the desired
setting rotating counter-clockwise to
MAX. and clockwise to MIN.
9. Set the rear burner (knob 3) to the desired
setting rotating counter-clockwise to
MAX./ ON or MIN.
10. Closeaccessdoorandturnonelectricalpower.
1. STOP! Read the safety information on the
previous page.
2. Turn off all electrical power and open the
access door.
3. Turnofftherearburnerandsetthefrontburner
to low.
4. Push in gas control (knob 1) slightly and turn
clockwise to "OFF".
NOTE: Knob cannot be turned from "PILOT" to
"OFF" unless knob is pushed in slightly. Do not
force.
5. Waitfive(5)minutestoclearoutanygas. Then
smell for gas, including near the floor. If you
smell gas, STOP! Follow "B" in the safety
information on the previous page. If you don't
smell gas, go on to the next step.
PILOT LOCATION
TOP VIEW OF BURNER ASSEMBLY
OFF
IGN
PILOT
ON
OFF
ON
MAX
MIN
Meritik
MAXITROL
KNOB 1
1. PILOT 2. FRONT BURNER
3. REAR BURNER
KNOB 2
KNOB 3

13
Annualinspectionandcleaningbyyourdealerorqualifiedservicetechnicianisrecommendedtoprevent
malfunction and/or sooting.
Removefrontscreen,(seepage6).Carefullyliftscreenfromlocatingstubsandsetasideduringcleaning.
Refer to instructions on page 6 for installation of screen. Do not operate the unit with the screen
removed.
Removelogs,handlingcarefullybyholdinggentlyateachend.Glovesarerecommended to prevent skin
irritationfromceramic.Iftheskinbecomesirritated,washgentlywithsoapandwater.Refertomanualfor
correct log placement.
OPERATING INSTRUCTIONS
Wait 30 seconds before readjusting the heater when the control has been turned
down to a lower setting.
WARNING
MATCH LIGHTING INSTRUCTIONS
Ifthepilotwillnotlightusingthepiezoignitor,youcanlightthepilotwithamatch. First,locatethepilot. Thepilot
islocatedbetweenthetwoburnertubesontherightend(facingtheunit),insidethefirebox. Tolightpilotwitha
match,movethegascontrol(knob1,pg.12)tothepilotpositionandholddown. Lightmatchandplacenearpilot.
Oncepilotislit,continuetoholdtheknobforabouttenseconds. Thenfollowsteps7thru10onpage12.
PILOT FLAME
Thepilotflameshouldalwaysbepresentwhenthe
heaterisinoperationandshouldjusttouchthetopof
thethermocoupletip(FIGURE9).
Ifthepilotflamedoesnottouchthethermocouple,
thenthemainburnerisunlikelytofunctionreliably
(FIGURE10).
CHECKING FLAME APPEARANCE
Flamesfromthepilot,frontandrearburnershouldbevisuallycheckedwhentheheaterisinstalled.Inadditiona
periodicvisualcheckoftheflamesshouldbemade.
WARNING Turn off heater and allow to cool before cleaning.
CLEANING / SERVICING
FIGURE10.IncorrectShapeofPilotFlameFIGURE9.PilotFlame

14
CLEANING / SERVICING
Periodic Cleaning
• Do not use cleaning fluid to clean logs or any part of heater.
• Logs - Brush with soft bristle brush or vacuum with brush attachment.
• Vacuum loose particles and dust from the front and rear burner, control, and piezo.
• Inspect burner's and air intake hole. Remove lint or particles with vacuum.
• External case should be dusted and wiped with a wet soapy cloth.
Annual Cleaning/Inspection
• Inspect and clean burner air intake holes.
• Inspect and clean all burner ports.
• Inspect ODS pilot for operation and accumulation of lint at air intake holes.
• Verify flame pattern and log placement for proper operation.
FLAME APPEARANCE
• Verify smooth and responsive ignition of main burner and rear burner.
In normal operation at full rate after 15 minutes the following flame appearance should be observed.
FLAMES
The flames behind log #1, and in front of log #2, should be yellow with a blue base. The flames should
FIGURE 11. Flames - Natural Gas and LP Gas
#2 #1
not be impinging on the small cross twigs. (See Below, Figure 11)

15
HEATER ASSEMBLY REPLACEMENT PARTS
1
2
3
4
5
6
7
8
11
10
9
12
13

16
PARTS LIST FOR HEATER ASSEMBLY
KEY PART # DESCRIPTION QTY.
1 69114 CABINET TOP 1
2 69104 FIREBOX BACK WELDMENT 1
3 24535 FIREBOX TOP 1
4 24538 INSIDE BACK 1
5 69066 FIREBOX WELDMENT 1
6 24534 FIREBOX BOTTOM 1
7 69067 PEDESTAL WELDMENT 1
8 24530 PEDESTAL BASE 1
9 24457 CONTROL DOOR 1
10 89336 BRASS KNOB 1
11 83115 10-32 x 1/2 MACHINE SCREW 1
12 89850 FRONT SCREEN 1
13 89851 BRASS TRIM 2
N/S 89824 MAGNETIC LATCH 1
N/S 83343 #10 x 1/2 HX HD SCREWS 53
N/S = NOT SHOWN

17
BURNER & LOG ASSEMBLY
5
16
15
6
89
2
3
7
4
10
11
17
1
19
18
A
B
CD
20
13
14 12

18
PARTS LIST FOR GAS LOG ASSEMBLY
KEY PART # DESCRIPTION QTY.
1 24610 BURNER PLATE 1
2 24611 CONTROL BRACKET 1
3 81193 CONTROL VALVE (NATURAL) 1
81194 CONTROL VALVE (L.P.) 1
4 83251 10-24 x 1 SL ROD 2
5 83244 10-24 KEP NUT 2
N/S 83343 #10 X 1/2 HX HD SCREW 10
6 89831 BURNER/CONTROL FITTING 1
7 89834 1/4" TUBE, BURNER/REGULATOR 1
8 89838 1/4 CC X 3/8-27 FITTING 1
9 89839 1/4 COMPRESSION NUT 1
10 89840 1/4 COMPRESSION SLEEVE 1
11 24612 PILOT BRACKET 1
12 89872 "O.P. AMERICA" NAT. PILOT 1
89873 "O.P. AMERICA" L.P. PILOT 1
N/S 83437 10-3/4 HX HD SCREW (TO MOUNT PILOT) 2
13 89841 3/16 COMPRESSION NUT 1
14 89842 3/16 COMPRESSION SLEEVE 1
15 89853 #50 NATURAL BURNER ORIFICE(FRONT) 1
89854 #56 L.P. BURNER ORIFICE (FRONT) 1
16 89853 #50 NATURAL BURNER ORIFICE(REAR) 1
89854 #56 L.P. BURNER ORIFICE (REAR) 1
17 24613 BURNER (PAINTED) 2
18 89857 LOG SET (CONSISTS OF 4 PIECES) 1
a 89857-1 FRONT LOG -
b 89857-2 REAR LOG -
c 89857-3 RIGHT TWIG -
d 89857-4 LEFT TWIG -
19 89856 3/16" LOXIT FITTING 1
N/S 86318 16GA WIRE LINK 1FT.
20 89855 PILOT TUBE 1
N/S = NOT SHOWN

19
TROUBLESHOOTING
Turnoff andletcoolbeforeservicing.Onlyaqualified servicepersonshouldservice
and repair heater.
NOTE:Alltroubleshootingitemsarelistedinorderofoperation.
REMEDYPOSSIBLE CAUSE
OBSERVED PROBLEM
When ignitor button is pressed, there is
no spark at ODS/Pilot.
Ignitor electrode positioned wrong
Ignitor electrode is broken
Ignitor electrode not connected to ignitor
cable.
Ignitor cable pinched or wet keep ignitor
cable dry.
Broken ignitor cable
Bad piezo ignitor
Replace ignitor.
Replace ignitor.
Reconnect ignitor cable.
Free ignitor cable if pinched by any metal
or tubing.
Replace ignitor cable.
Replace piezo ignitor.
Ventilate room. Stop using odor-causing
products while heater is running.
Locate and correct all leaks.
Appliance burning vapors from paint, hair
spray, glues, etc.
Gas leak.
Appliance produces unwanted odors.
Not enough fresh air is available for ODS/
Pilot to operate.
Low line pressure.
ODS/Pilot is partially clogged.
Open window and/or door ventilation
Contact local gas company.
Clean ODS/Pilot.
Appliance shuts off in use.
Gas leak.
Control valve defective.
Locate and correct all leaks.
Replace control valve.
Gas odor even when control knob is in
OFF position.
Gas supply turned off or manual shutoff
valve closed.
Control knob not in PILOT position.
Control knob not pressed in while in Pilot
position
Air in gas lines when installed.
ODS/Pilot is clogged.
Gas regulator setting is not correct.
Turnongassupplyoropenmanualshutoff
valve.
Turncontrolknob whileinPILOTposition.
Press in control knob while in PILOT posi-
tion.
Continue holding down control knob. Re-
peat igniting operation until air is removed
Replace ODS/pilot assembly or get is
serviced
Replace gas regulator.
When ignitor button is pressed, there is
spark at ODS/Pilot, but no ignition.
WARNING
ODS/Pilotlights,butflamegoesoutwhen
control knob is released.
Press in control knob fully.
After ODS/pilot lights, keep control knob
pressed in 30 seconds.
Fully open manual shutoff valve.
Control knob not fully pressed in.
Control knob not pressed in long enough.
Manual shutoff valve not fully open.

20
TROUBLESHOOTING, CONTINUED...
ODS/Pilot lights, but flame goes out
When control knob is released.
(continued from page 19)
One or both burner do not
light after ODS/pilot is lit.
Burner backfires during
combustion.
Slight smoke or odor during
initial operation.
Logs appear to smoke after
initial operation.
Heater produces a whistling
noise when burner is lit.
No gas to pilot.
Thermocouple connection loose at
control valve.
Pilot flame not touching thermocouple,
which allows thermocouple to cool,
causing pilot flame to go out. This
problem could be caused by either
low gas pressure, or a dirty or partially
clogged ODS/pilot.
Thermocouple damaged.
Control valve damaged.
Burner orifice is clogged.
Burner orifice diameter is too small.
Inlet gas pressure is too low.
Manifold pressure is too low.
Burner orifice is clogged.
Burner orifice is clogged or damaged.
Burner is damaged.
Gas regulator defective.
Vapors from paint or curing process
of logs.
Turning control knob to HIGH (3)
position when burner is cold.
Air in gas line.
Dirty or partially clogged burner
orifice.
LP-regulator shut down due to inlet
pressure too high.
Hand tighten until snug, then
tighten 1/4 turn more.
Contact local gas company.
Replace thermocouple.
Replace control valve.
Clean burner or replace burner
orifice.
Replace burner orifice.
Contact qualified service person.
Contact local gas company.
Clean burner or replace burner
orifice.
Clean burner or replace burner
orifice.
Replace burner.
Replace gas regulator.
Problem will stop after a few hours
of operation. Run the heater with
the damper open if you have one,
or open a window for the first few
hours.
Log heater is intended to be
smokeless. Turn OFF heater and
call qualified service person.
Turn control knob to LOW (2)
position and let warm up for a
minute.
Operate burner until air is removed
from line. Have gas line checked
by local gas company.
Clean burner or replace burner
orifice.
Verify LP tank regulator is
installed and set to 11" to 13"w.c.
Replace regulator on heater.
POSSIBLE CAUSEOBSERVED PROBLEM REMEDY
WARNING
If the gas quality is bad, your pilot may not stay lit, the burners may produce soot
and the heater may backfire when lit. If the gas quality or pressure is low, contact
your local gas supplier immediately.
