UNITED PGC-2324 User manual

Portable gas stove
Instructions Manual
Model: PGC-2324
Read and save these instructions for future reference

PRODUCT FEATURES
2X2.3KW(166g/h)
Rotary piezo ignition
Pressure sensing safety shut-off device
Convenient storage/carry box
Only for outdoor use
Uses standard butane cartridge
For outdoor use only
WARNING: carbon monoxide
Only for outdoor use
HAZARD: this appliance can produce carbon monoxide which has no
odor.
Using it in an enclosed space (for example, caravan, tent, car, mobile
home) may cause death.
DO NOT use oversized cooking devices (14cm-19cm diameter).
DO NOT use as space heater of for any purpose other than cooking.
PARTS LIST
IMPORTANT:
Read these instructions for use carefully. Familiarize yourself with the
appliance before connecting it to its gas container. Keep these instructions
for future reference. The butane gas cartridge is certified to EN 417 or
equivalent. It may be hazardous to attempt to fit other type of gas containers.
Remove any transit protection material.

Check that the seals between the appliance and the gas container are in
place and in good condition before connecting the gas container.
DO NOT use this appliance if it has damaged or worn seals.
DO NOT use this appliance if it is leaking, damaged or does not operate
properly
TO START
Inserting the gas cartridge
1. Turn the ignition knob to OFF and set the cartridge lever
to UNLOCK. (Fig 1)
Note: if the ignition knob is ON the gas cartridge cannot be
loaded into the cooker.
2. Open the cartridge cover: slide the gas cartridge, top
end first and with its notch up, into the compartment. Align
the notch with the loading guide in the compartment. (Fig 2)
3. Push the cartridge lock down to LOCK in one firm
motion (Fig 3)
WARNING!
THE OPENINGS AT THE BASE OF THE BURNER PROVIDE AIR FOR
COMBUSTION, SHOULD NEVER BE OBSTRUCTED. IF THE FLAME
BECOMES SIGNIFICANTLY ORANGE CHECK THESE OPENINGS
FOR A BLOCKAGE.
IF THE APPLIANCE CANNOT BE ADJUSTED TO PERFORM
CORRECTLY IT SHOULD NOT BE USED UNTIL SERVICED OR
REPAIRED.

LIGHTING THE COOKER
1. Turn the knob anti-clockwise past the high position
until a click is heard.
2. If the burner fails to light, immediately turn the ignition
knob to the OFF position and repeat step 1.
TO ADJUST HEAT
1. Flame can be controlled by turning the ignition knob
between the LOW and HIGH position.
TO SHUT OFF
1. Turn the ignition knob to shut off fuel supply (Fig 5).
Wait until the flame is fully extinguished before performing
the next step.
2. Raise the cartridge lock lever to UNLOCK and remove
the gas cartridge from the compartment.
Note: do not leave the gas cartridge inside the unit when
not in use.
AFTER USE
1. Replace the cap on the gas cartridge after removing it from the unit. Store
upright in a cool dry place.
2. Make sure the burner is cool to touch before packing the unit away.
3. Do not store the cartridge near other flammables.
DO NOT store the cartridge near sources of heat or direct sunlight.
DO NOT store in the glove compartment or boot of your car.
DO NOT puncture or incinerate empty cartridges.
HANDLING WHEN THE AUTOMATIC SAFETY SHUT-OFF DEVICE
IS ACTIVATED
1. When used in high temperature areas, such as the beach during summer
or in a hot room, the internal pressure of the cartridge may rise to more than
7kg/cm2 (normal pressure =3-4kg/cm2). This will activate the automatic safety
shut-off device inside the regulator.
*The cartridge may be disconnected even if some gas remains.
*Check the contents by shaking and listening for the liquid gas.
Gas containers shall only be changed in a well-ventilated location, preferably
outside, away from people and away from sources of ignition; such as naked
flames pilot, electric heaters/ equipment.
If there is a leak on your appliance (smell of gas) and you cannot stop the gas
flow, remove the appliance to a well-ventilated location away from any
ignition source. Only check for leaks outdoors using soapy water. Do not try
to detect leaks using a flame.
This appliance must only be serviced by an authorized person.

2. Remove the gas cartridge from the compartment. Push the nozzle inward
to release internal pressure and place in a cool or shady area.
3. Turn the ignition knob to ON to release any excess gas inside the regulator.
Repeat the 3 steps for inserting the gas cartridge after it has cooled down.
SAFETY TIPS
DO
Turn gas off at ignition knob after use.
Check that the burner is fully
extinguished before disconnecting the
gas container.
Remove the gas container outside and
away from people.
Change the gas container outside and
away from people.
Check the seals before connecting a
new gas container to the appliance.
Always remove the cooker from the
carry box prior to use.
Keep children away from this appliance
Make sure there is adequate ventilation
under the unit.
Only operate on flat, horizontal surfaces
Use the cooker in cool places or in the
shade. Keep the cartridge compartment
out of direct sunlight.
Always check the gas cartridge position
inside the compartment for leaks. If a
leak occurs, turn off the supply and
remove the gas cartridge.
DO NOT
Do not operate in an enclosed
area without ventilation
Do not operate in a boat, caravan
or tent
Do not modify this appliance.
Do not use the cooker in sand or
on gravel surfaces
Do not move the cooker while it is
lit.
Avoid using the cooker in very
windy conditions.
Do not use a cooking pan that is
smaller than 14cm and larger than
19 cm in diameter
Do not use the appliance as a
room heater or clothes drier.
Do not place articles on or against
this appliance.
Do not place chemicals or
flammable materials or spray
aerosols near this appliance.
CARE AND CLEANING:
The outside of the cooker can be wiped clean with a mild solution of
dishwashing detergent and finished off with a dry cloth. Do not use abrasive
pads.
The drip pan can be washed thoroughly. Always dry after washing.
We recommend the burner head to be cleaned by gentle scrubbing with a dry
brush at least annually. Ensure that the burner ports are free of any
obstructions.
Occasionally clean the point of the piezo plug with a hard brush.

Keep this appliance away from combustible materials
Minimum clearances: rear 600mm-side 600mm- top 500mm
Gas consumption: 2x2.3kw(166g/h)
Injector size: 0.56mm
Troubleshooting：
Problem
Cause
No ignition
No burning
Unstable flame
Uneven flame
Slow burning
Gas smell
Stopped working while in use
Continued burning
solution
Lack of fuel
·
·
·
·
Replace
cartridge
Piezo plug
dirty
·
Clean spark
point
Dirty burner
·
·
·
·
·
Clean burner
Cartridge
misaligned
·
·
·
·
·
Reset
correctly
Dirty burner
or empty
cartridge
·
·
·
·
Request for
inspection/
service
Faulty knob
mechanism
·
·
·
Request for
inspection/
repair
Internal gas
pressure too
high
·
Cool down
gas
Safety
device
activated
·
·
Request for
inspection/
service
Improper
setting of
spark point
·
Set spark
point to 2mm
away from
burner

NOTICE ABOUT RECYCLING
Your product is designed and manufactured with high quality
materials and components which can be recycled and reused.
This symbol means that electrical and electronic equipment, at
their end-of-life,
should be disposed of separately from your household waste.
Please dispose of this equipment at your local community
waste collection/ recycling centre.
In the European Union there are separate collection systems for used
electrical and electronic products.
Please help us to conserve the environment we live in!
DECLARATION OF CONFORMITY
Herewith, Amiridis-Savvidis S.A. states that this product, complies with the
requirements of below directives:
Gas Appliance Directive 2009/142/EC
The detailed declaration of conformity can be found at
www.united-electronics.gr
Exclusive importer in Greece:
Amiridis –Savvidis S.A.
87A, 17th Noemvriou str, P.C. 55534
Thessaloniki –Greece
T: [phone] | F: [phone]
www.amiridis-savvidis.gr
www.united-electronics.gr
