Univox P-CTC User manual

1
P-CTC
Portable Cross The Counter hearing loop system
User Guide
P-CTC
Part No 202070/202070A
The User Guide is based on the information available at the time of printing and are subject to change without notice.

2
Introduction
Thank you for choosing the Portable Cross The Counter hearing loop system. We hope you
will be satisfied!
Providing versatile desktop induction loop assistance for hearing aid wearers, the portable
induction loop is powered by a rechargeable battery and is always ready for immediate use
if charged. No installation works are required.
Please read this user guide before use of this product.
To Charge
Plug the switched power supply into the P-CTC unit and to the power outlet.
The unit can be charged whilst in use but does so in a slow charge mode. The LED on the
rear side flashes red rapidly when the unit is being charged. When the LED shows a steady
red, the unit is fully charged. The unit can be used for about 4 hours on a full charge and
has 24 hours stand-by time. When the battery needs charging the LED will flash red every
few seconds.
To use
Place the P-CTC unit on the table or desk between the speaker and hearing aid user. The
unit’s rear side, where the microphone is located should face the speaker. Activate the unit
by moving the rear side slide switch to “ON” position. The LED should then show a steady
green. Note that the hearing aid user must put their hearing aid in T or MT position to
activate the t-coil. The working range for the listener is approximately 1.2m from the unit.
The speaker should sit about 1m from the microphone on the rear side of the unit. The
speaker should talk in a normal tone and volume. Should the listener experience the sound
too loud or too quiet, simply move the unit further from or closer to the listener.
When you are done using the unit, we recommend that you put it back on charge for it to
be fully charged for the next user.
Connect a boundary microphone
The P-CTC unit can also be used in meetings with more than one speaker. For this we
recommend that you use a Univox 13T boundary microphone. Connect the 13T’s 3.5mm
plug into the 3.5mm socket marked EXT. The P-CTC unit should as before be placed

3
approximately 1.2m from the listener. The microphone is placed on a solid surface in the
middle of the meeting table with fairly equal distance to all speakers.
Safety/Warranty
Please note that the warranty is not valid for any damage or defects on the product due to
incorrect or incautious installation, usage or maintenance.
Bo Edin AB shall not be held responsible or liable for interference to radio or TV equipment,
and/or to any direct, incidental or consequential damages or losses to any person or
entity, if the equipment has been installed by unqualified personnel and/or if installation
instructions stated in the product Installation Guide have not been strictly followed.
Maintenance and care
Under normal circumstances the product does not need any special maintenance.
Should the unit become dirty, wipe it with a clean damp cloth. Do not use solvent or strong
detergents.
Troubleshooting guide and service
Verify the control LEDs following the instructions in this installation guide.
Should the system not work aer having made the product test as described above, please
contact the local distributor of the product for further instructions.
Please also note that the warranty is not valid for any damage or defects on the product
due to incorrect or incautious installation, usage or maintenance.
Technical data
For additional information, please refer to product data sheet/brochure and CE certificate
which can be downloaded from www.univox.eu. If required other technical documents can
be ordered from your local distributor or from [email protected].
Environment
Please follow existing disposal regulations in your country. If you respect these instructions
you ensure human health and environmental protection.

4
p-ctc-du-gb -180315 Copyright © Bo Edin AB
Distributor
Univox by edin, the world’s leading expert and producer of high quality hearing loop
systems, created the very first true loop amplifier 1969. Ever since our mission is to serve
the hearing community with the highest degree of service and performance with strong
focus on Research and Development for new technical solutions.
Hearing excellence since 1965
Bo Edin AB, Stockby Hantverksby 3, SE-181 75 Lidingö, Sweden www.univox.eu
Accessories
Part No Description
202071 Shelf unit for P-CTC
