URC DMS-IN User manual

Order Number
: GETEC-C1-16-415
FCC Part 15 Certification
Test Report Number
: GETEC-E3-16-053
Page 1 / 1
EUT Type: Stream Injector Output Device
FCC ID.: OZ5URCDMSIN
APPENDIX G
: USER’S MANUAL

Universal Remote Control www.UniversalRemote.com
DMS-IN
Owner’s Manual

Overview
The DMS-IN allows an additional audio source to be added to the DMS
“family” of streaming sources. Whether it is simply adding an additional
audio input to the system or adding a device from a different room, the
DMS-IN makes this possible. This is a perfect solution device to help
overcome the native input capacity created by the DMS-1200 and the
DMS-100.
Online Help:
Visit the URC Control Room for software downloads, training materials, and
frequently asked questions.
Contact Support:
Total Control is a URC product sold direct or through distribution. For
questions or assistance contact your Custom Installer/Programmer.
My Installer/Programmer:
or URC Technical Support at: [email protected]
[phone]
Universal Remote Control, Inc.
500 Mamaroneck Ave
Harrison, New York 10528
Toll Free: [phone]
Table of Contents
Features and Benefits.........................................1
Parts & Pieces......................................................1
Requirements......................................................1
Rear Panel............................................................2
Top Panel & LED States......................................4
Bottom Panel.......................................................5
Wiring the DMS-IN.............................................6
DMS-IN Owner’s Manual

Page 1
Features and Benefits
The DMS-IN is loaded with features to provide the perfect audio experience. Enjoy features such as:
●Additional Source
DMS-IN adds an additional streaming source to any existing DMS Multi-zone audio system.
●Audio Sensing Capability
The DMS-IN, similar to the URC Audio Sensor (SEN-AUD), can detect an audio signal which can then trigger n activity (macro).
●Flexible Power Source
Use the supplied 5V DC power adapter or take advantage of the DMS-IN’s PoE (Power Over Ethernet) capability using a CAT 5/6 wiring.
DMS-IN Owner’s Manual
Parts & Pieces
Contained within the DMS-IN box:
1. DMS-IN Stream Injector Input Device
2. 5v DC Power Adapter
3. Wall Mount and 4x Screws
Requirements
As with all Total Control products, the DMS-IN is not a
plug-and-play device. It requires programming by a
certified Total Control installer in order to work properly.
Be sure the system contains the following:
●MFS-8 or MFSPOE-8
●MRX-10 or MRX-8 Master System Controller
●URC User Interface (TRC-1080, TKP-7000, etc.)

Page 2
DMS-IN Owner’s Manual
Rear Panel:
5V DC Input:
Provides power to the DMS-IN. PoE may be used
as a substitute.
Analog Input:
Standard RCA (analog) connector.
Note: Does not natively support phono audio. If phono
is desired a line level converter is required.
Digital Input - Optical:
This input uses standard S/PDIF OPTICAL TOSLINK
connector.
Note: The DMS-IN converts Dolby Digital 5.1/DTS 5.1
to a DMS Stream.

LAN Port:
This 10/100 Ethernet port supports PoE and sends
the URC Audio stream through the local network,
this is also how the DMS-IN receives commands
and sends audio.
Note: The DMS-IN does not support Wi-Fi
Digital Input - Coax:
Standard RCA (analog) connector, this receives
bitstreams of audio data.
Note: The DMS-IN converts Dolby Digital 5.1/DTS 5.1
to a DMS Stream.
DMS-IN Owner’s Manual
Page 3

Page 4
DMS-IN Owner’s Manual
Top Panel & LED States:
There are three (3) LED lights at the top of the DMS-IN which can provide users with basic troubleshooting information.
Status LED
●Off
Unit has not been programmed with a Total Control file.
●Yellow
Unit has been programmed with a Total Control file; however, is not creating
a DMS Audio Stream.
●Blue
Unit has been programmed with a Total Control file and is creating a DMS
Audio Stream through the network.
Power LED
●Off
Unit is not receiving power.
●Blue
Unit is receiving power via 5V DC adapter or PoE.

Page 5
DMS-IN Owner’s Manual
Network LED
●Off
Unit is not connected to the local area network and cannot send/receive data.
●Blinking Green
Unit is connected to the local network, but has not received an IP address.
●Green
Unit is connected to the local network and has an IP address.
Bottom Panel
Located beneath the DMS-IN is a Reset button. The Reset button is recessed so a
paperclip or something similar is required to press. This button allows for:
●Rebooting the DMS-IN
A momentary press of the Reset button reboots the DMS-IN, similar to
unplugging it from the power supply.
●Factory Default
Pressing and holding the Reset button for ten (10) seconds or longer, factory
resets the DMS-IN to its factory state. The DMS-IN requires re-programming
after this has been performed.

Page 6
DMS-IN Owner’s Manual
Wiring the DMS-IN
In order for the DMS-IN to provide the best possible experience, it must be first wired correctly then programmed by a Total Control Certified
Installer. Follow these steps to prepare the DMS–IN for programming:
1. Power the DMS-IN with the supplied 5V DC adapter OR PoE using the LAN port (see below)
2. Connect and Ethernet cable from the LAN 10/100 port to an MFS-8/MFSPOE-8
●The 5V DC adapter is not required when using PoE
3. Connect a source via Analog or Digital that is to be a part of the DMS Audio Stream
Additional set up is required via the URC Accelerator software. Contact a Certified Total Control Installer to properly configure the DMS-IN to a
new or existing system.
OR
Only one source can be used at a time, further audio
adjustments can be made from within Accelerator.

Specifications
Microprocessor: Cortex-A5 600MHz
Memory: 128MB NAND, 128MB RAM
Network: One 10/100 Ethernet port (PoE)
Weight: 5.8oz
Size: 4.6” x 4.6” x 1.2”
Power: Standard PoE Injector or PoE Switch (purchased separately), DC 5V/1A
Page 7
DMS-IN Owner’s Manual
