US SAWS JS - SERIES User manual

U.S.SAWS JS - SERIES
OPERATING MANUAL
TO PREVENT SERIOUS INJURY DO NOT OPERATE SAW WITHOUTPROPER TRAINING AND.
UNDERSTANDING OF THE OWNERS MANUAL
WHEN OPERATING THIS MACHINE
ALWAYS WEAR SAFETY APPROVED
HEARING PROTECTION
EYE OR FACE PROTECTION
PROTECTIVE HELMET
PROTECTIVE GLASSES OR FULL FACE PROTECTION
WEAR HAND PROTECTION
WARNING: Improperly maintaining the JS including the Honda engine or failing to correct a problem before
operation could cause a malfunction resulting in a serious injury. Always perform a pre-operation inspection before
each operation and correct any problem. See Honda Engines Owner's Manual.
5.2 Check the condition of the Honda engine. See the section titled "Before operation - is your
engine ready to go?" in the Honda Engines Owner's Manual.
WARNING: Exhaust gas from gasoline engines contains dangerous carbon monoxide. Breathing it can cause
unconsciousness and even kill you. Always operate gasoline engine machines in a well-ventilated area. Do not
operate in areas where exhaust fumes could accumulate without wearing appropriate respiratory protection.
Consult your employer and OSHA regarding use of appropriate respirator for dangerous carbon monoxide
gases. See Figure 7.
EEnnggiinneeeexxhhaauussttccoonnttaaiinnss
ppooiissoonnoouussccaarrbboonn
mmoonnooxxiiddeeggaass..Breathing
it could cause death.
Operate machine in well
ventilated area.
FFiigguurree77--WWaarrnniinnggllaabbeell--eennggiinneeeexxhhaauussttccoonnttaaiinnssccaarrbboonnmmoonnooxxiiddeeggaass1111
U.S. English
05-31-2020
Notice of Copyright Protection
Copyright 2020, by U.S.SAWS . All rights reserved. This work may not be reproduced or disseminated in whole or in part by any
means without the prior written permission of U.S.SAWS
Surface Prep
Division
P: 877-817- 6687 F: 813-621-7125
Visit us at www.ussaws.com
[email protected]

INTRODUCTION & SPECIFICATIONS
Surface Prep
Division
P: 877-817- 6687 F: 813-621-7125
Visit us at www.ussaws.com
[email protected]
Read this entire operations and maintenance manual before using your new
tool. Pay close attention to the Rules for safer operation,
Dangers, Warnings and Cautions.
The purpose of safety symbols and explanations are to attract your atten-
tion to possible hazards and how to avoid them. The safety symbols and
explanations do not by themselves eliminate any danger. The instructions
or warnings they give are not substitutes for proper accident prevention
measures.
Model Identication: Record machine serial number plate information
below for future reference
Table of Contents & Introduction ..................................................... 2
Symbols & Decals ................................................................... 3
Safety Instruction ................................................................... 4 - 5
Pre-Operation Checklist ..............................................................6 - 8
Operation ................................................................... 9 - 12
Maintenance & Inspection .................................................... 13 - 14
Warranty & Service ............................................................. 15 - 18
Section Page
1.0 INSTRUCTIONS FOR USE OF MANUAL SECTIONS
2.0 SPECIFICATIONS
Foreword/Introduction
DANGER: Indicates an imminently hazardous situation that if not avoided,
will result in death or serious injury. This signal word is limited to the most
extreme situations.
WARNING: Indicates a potentially hazardous situation that, if not avoided,
could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation that, if not avoided
may result in minor or moderate injury. It may also be used to alert against
unsafe practices that may cause property damage.
JS SERIES SAWS engine:
JS SERIES SAWS engine:
Fuel type:
Oil type & capacity:
JS SERIES SAWS Weight:
JS SERIES SAWS weight:
Blade speed:
Blade diameter sizes:
Blade depth cut:
Blade type:
Overall size:
Blade nut wrench size:
Shaft diameter:
Flanged bearing grease:
Assembly part numbers:
Recommended
dust collector system:
Vacuum hose size:
Honda 11.7 HP Gas Powered
5HP 230v 1-phase, 5HP 208/480v 3-phase
Unleaded gasoline, 86 octane or higher
SAE10W-30, 1.16qt
160 pounds gas
180 pounds electric
5400 RPM maximum
8” and 10”
3” with 10” blade, 2” with 8” blade
Dry diamond, 1” arbor hole, & single drive pinhole
28.3” W X 35.5” L X 37.5” H
1-1/2”
1”
ALVANIA® Grease 3 every 100 hours
JS SERIES SAWS 11.7 hp GAS SX77131
230v 1-phase Electric SX77100
208/480v 3-phase Electric SX77104
Propane SX77160
U.S. SAWS Ultra -Vac Gas SX50005G
3” SX73408
2
The owner’s manual is intended to point out some of the basic safety situa-
tions that maybe encountered during the normal operation & maintenance
of the JS Walk Behind Machine & to instruct you in safety practices for deal-
ing with these conditions. Keep all manuals provided with your
machine in a safe place at all times.
The information and specications included in this publication were
in effect at the time of approval for printing. U.S.SAWS reserves the right,
however, to discontinue or change specications or design at any time with-
out notice and without incurring any obligation.
Typical applications for the U.S.SAWS JS SERIES SAWS would be joint
cleanout and trench cutting. The saw uses dry cut diamond blades in either
8” diameters or 10” diameters with an allowable maximum depth cut of 3”.
The blade rotates in an upward direction allowing for easy dust collection
when connected to an appropriate vacuum system. The machine should al-
ways be operated with a dust collection system and in a well-ventilated area
due to carbon monoxide fumes emitted from the gasoline engine.
TO PREVENT SERIOUS INJURY DO NOT OPERATE SAW WITHOUTPROPER TRAINING AND.
UNDERSTANDING OF THE OWNERS MANUAL
WHEN OPERATING THIS MACHINE
ALWAYS WEAR SAFETY APPROVED
HEARING PROTECTION
EYE OR FACE PROTECTION
PROTECTIVE HELMET
PROTECTIVE GLASSES OR FULL FACE PROTECTION
WEAR HAND PROTECTION
WARNING: Improperly maintaining the JS including the Honda engine or failing to correct a problem before
operation could cause a malfunction resulting in a serious injury. Always perform a pre-operation inspection before
each operation and correct any problem. See Honda Engines Owner's Manual.
5.2 Check the condition of the Honda engine. See the section titled "Before operation - is your
engine ready to go?" in the Honda Engines Owner's Manual.
WARNING: Exhaust gas from gasoline engines contains dangerous carbon monoxide. Breathing it can cause
unconsciousness and even kill you. Always operate gasoline engine machines in a well-ventilated area. Do not
operate in areas where exhaust fumes could accumulate without wearing appropriate respiratory protection.
Consult your employer and OSHA regarding use of appropriate respirator for dangerous carbon monoxide
gases. See Figure 7.
EEnnggiinneeeexxhhaauussttccoonnttaaiinnss
ppooiissoonnoouussccaarrbboonn
mmoonnooxxiiddeeggaass..Breathing
it could cause death.
Operate machine in well
ventilated area.
FFiigguurree77--WWaarrnniinnggllaabbeell--eennggiinneeeexxhhaauussttccoonnttaaiinnssccaarrbboonnmmoonnooxxiiddeeggaass1111
