usha CJ2000WTC User manual

Instruction Manual
INDUCTION COOKTOP
CJ2000WTC
Size:148x210mm (A5)

1 Induction Cooktop
Dear Customer,
Congratulations!
You are now the proud owner of USHA 'CookJoy' Induction Cooktop – a state of art,
technologically advanced Induction Cooktop. This modern Induction Cooktop makes
cooking healthy and safe. This is another unique quality product from Usha International
Limited, a name synonymous with trust and reliability.
All USHA products are designed to give you trouble free performance. We suggest you to
read this user manual carefully to ensure many years of trouble free and easy cooking.
Enjoy Cooking
Size:148x210mm (A5)

CONTENTS
Induction Cooktop 2
Know your Induction Cooktop
Description of Parts .............................................................................................................................. 3
Control Panel .......................................................................................................................................... 3
Key Features ............................................................................................................................................ 4
How Induction Cooking works......................................................................................................... 4
Advantages of Induction Cooking................................................................................................... 4
Operating Instructions
Connecting your Induction Cooktop.............................................................................................. 4-5
Presest Functions................................................................................................................................... 5-6
Cookware for the induction Cooktop............................................................................................. 6
Safety Instructions
Important Safeguards ......................................................................................................................... 7
Care and Cleaning .............................................................................................................................. 8
Miscellaneous
Technical Specications ..................................................................................................................... 8
Troubleshooting ................................................................................................................................... 9
Warranty Card ...................................................................................................................................... 10
Size:148x210mm (A5)

KNOW YOUR INDUCTION COOKTOP
DESCRIPTION OF PARTS
3 Induction Cooktop
Size:148x210mm (A5)
1. Induction Cooker 2. Function 3. Water/Tea 4. Chapati/Dosa 5. Deep Fry 6. Pressure Cook
7. Saute 8. Heat Milk 9. Curry 10. Idli 11. - 12. Digital window
13. + 14. Pause 15. Timer 16. Child lock 17. ON/OFF
4 6 8 10 11 13 15 17
CONTROL PANEL
2 3 5 7 9 12 14 16
1

Induction Cooktop 4
KEY FEATURES
1. Slim and sleek design with convenient touch panel.
2. Keep Warm Function :- This will keep food ready-to-eat for a long time (Pressure Cook and Curry
Mode only). Keep Warm setting makes it convenient for family members eating at dierent times.
3. Pause :- Pause allows you to cook at your own pace.
4. 8 Pre-set Indian menu & 24 hours timer.
5. Auto switched to power saving mode to prevent overheating.
6. Pan sensor technology – operates only when Cookware is placed on Induction Cooktop.
7. For uctuations upto 3 000 V : safety varistor protects the Induction Cooktop.
8. Anti skid feet.
HOW INDUCTION COOKING WORKS
An electric voltage is applied on a conductor Coil, which is beneath the
ceramic glass. This produces a high frequency electromagnetic eld. This
eld penetrates the metal of the ferrous (magnetic material) cooking
vessel and generates heat. This heat generated in the cooking vessel is
transferred to the vessel's contents. Nothing outside the vessel is
aected by the eld. As soon as the vessel is removed, the heat genera-
tion stops.
ADVANTAGES OF INDUCTION COOKING
•It is a powerful cooking medium with precise and instant heat application.
•No wastage of heat, maximum energy utilization as the energy is supplied directly to the cooking
vessel.
•Safety from open flames, no re hazards, or gas leakages.
•Once the cookware is taken o the ceramic plate the device automatically switches to standby
mode.
•lf unsuitable cookware is placed, the unit will detect the same and no energy will be transmitted.
•Spilled food will not stick and burn as the top plate is heated through the base of cookware
•Auto switch o at high temperature.
•Specially designed body to prevent ingress of water and insects.
CONNECTING YOUR 'COOKJOY’ INDUCTION COOKTOP
•Check the unit for visible damage.
•Place the unit on a stable and level surface. It is preferred that the product be placed on a
concrete, stone or a wooden surface as to avoid heating of surface and any damage to the device.
•Never place the unit on a flammable surface (e.g. table cloth. carpet, etc.)
•Do not block the ventilation slots of the unit. This may overheat the unit.
•Keep a minimum distance of 10 cm from the wall.
OPERATING INSTRUCTIONS
Size:148x210mm (A5)

Function
Default
Cooking
time
Default
wattage
Adjustable
cooking
time range
Usage
Water/Tea
Deep Fry
Pressure
Cook
120 min 1 600 W
Chapati/
Dosa 1 000 W
The Chapati/Dosa mode can be used to cook food on a
at induction type tawa. In case the tawa gets
overheated or less heated, the power can be increased
or decreased by using +/- button.
240 ° C
1 800 W
This cooking mode is applicable for high temperature
cooking and typically used for deep frying like samosa,
puris etc. You can increase or decrease the power as
required by using +/- button.
This cooking mode can be used for all pressure cooking.
The power/timer is adjustable in this mode, you can
increase or decrease the power/timer by using +/-
button as requirement.
Saute
20 min
1 400 W
Heat Milk N.A.
This cooking mode can be used for boiling milk. You can
increase or decrease the power as required by using +/-
button.
This cooking mode can be used to sauté vegetables.
You can increase or decrease the power as required by
using +/- button.
5 Induction Cooktop
•Do not place the induction cooktop next to devices or objects which have a magnetic eld (e.g. TV, Music
Systems, etc.)
•Do not place the unit near to open re, a heater or other source of heat.
•Ensure that power cord is not damaged or squeezed beneath the unit.
•Oversize pot may damage the product.
PRE-SET FUNCTIONS**
There are various preset healthy cooking options.
After switching ON the Induction Cooktop, press the corresponding preset function button to select the
desired cooking mode.
Note: Power in each cooking mode is restricted complying with the normal cooking requirements & you can
use manual mode if higher watt is required.
Size:148x210mm (A5)
This cooking mode can be used for boiling water/tea.
You can increase or decrease the power as required by
using +/- button.
1 min - 24 hours
1 min - 24 hours
1 min - 24 hours
1 min - 24 hours
1 min - 24 hours
1 min - 24 hours
120 min
120 min
120 min
120 min

Function
Default
Cooking
time
Default
wattage
Adjustable
cooking
time range
Usage
Curry
Idli
10 min 1 200 W
15 min
Induction Cooktop 6
TIMER
The timer function on the device helps you set a desired time for your cooking requirements. The timer can be
adjusted as per your cooking need by the (+) and (-) buttons on the device. Once set the display would ash
the set time and begin the countdown.
Press ”+”, one time , overall time will increase by 1 minute, on pressing it longer, set time will increase by 10
minutes. Press ”-” one time, the time will decrease by 1 minute, press it longer, set time will decrease by 10
minutes”. 00 : 01 - 24 : 00 hours is the Time Setting Range.
PAUSE
Press the Pause button to stop heating, when the induction cooktop is in pause. On selecting the Pause
function, || symbol will be displayed. Press the “Pause“ button again or select a cooking mode to quit the
pause status & return to the normal cooking. After setting pause the induction cooktop stops heating but after
reaching the default pause time. If the pause state is not cancelled, Induction cooktop may sound an alarm &
automatically switch o.
COOKWARE FOR THE INDUCTION COOKTOP
Stainless
steel pot
Enamel cooking
utensils Enamel stainless steel kettle
Iron kettle Iron frying pan Iron plate Iron pan
Size:148x210mm (A5)
This cooking mode can be used for gravy or curry
dishes. You can increase or decrease the power as
required by using +/- button.
This cooking mode can be used for steaming idli
/dhokla/vegetables etc. You can increase or decrease
the power by using +/- button.
CHILD LOCK
Child lock gets activated after pressing for 3 second at any mode.
To cancel Child lock mode, press Child Lock key again.
•
•
KEEP WARM FUNCTION
This will keep food ready-to-eat for long time (Pressure Cook and Curry Mode only).
Keep Warm setting makes it convenient for family members eating at dierent times.
•
Note:
•The results may vary depending on the power supply, quality of ingredients and the amount of water.
•Above shown watt is for ideal vessel. Actual watt may dier depending upon the vessel used.
N.A.
1 min - 24 hours
1 min - 24 hours

7 Induction Cooktop
•All pots and pans with magnetic bottom, stainless steel pots with iron bottom, cast iron enameled pans.
•Flat-bottom pans and pots with the diameter of the size of the heating area with magnetic
bottom.
•Utensils such as ceramic pots, heat—proof glass, copper pots and pans, aluminium pots and
pans, and containers with curved bottom should be avoided.
•Pressure vessels should be substituted with pots.
Size:148x210mm (A5)
SAFETY INSTRUCTIONS
IMPORTANT SAFEGUARDS
•In case of damage, even if it is only a small wear and tear, disconnect the device from the power
supply immediately & contact customer service.
•It is recommended not to place any metal kitchen utensils, cookware or pan lids, knives or other
metal objects on the induction cooktop. These may heat up when the device is turned on.
•Place the hot pan in the hob area or the heating area only and not on the control panel or the frame.
•Any magnetic objects Iike credit cards, cassettes etc. should be kept away from the device when in use.
•Keep metal plates or aluminium foil away from the device to avoid overheating.
•Avoid keeping the Induction cooktop on a steel or iron board while operating. Due to
electromagnetic waves, the iron or steel board may heat up and damage the bottom of the device.
•To avoid aecting product performance and to prevent injury, do not heat empty pots. When in
use, do not leave the appliance without supervision for a long time. When leaving the appliance
without supervision, make sure there is enough water in the pot.
•Do not heat iron items on the induction cooktop heating plate to avoid danger caused by high
temperatures.
•The utensils provided for the induction cooktop can only be used for cooking with it. These
cooking utensils cannot be used on both induction cooktop and gas stove.
•Do not use the induction cooktop near a gas stove, kerosene stove, gas cooker or in any space
with an open fire or an environment with high temperature.
•Do not use the induction cooktop by putting it onto a carpet, tablecloth or thin paper to avoid
blocking the air inlet opening or air outlet opening, which results in influencing heat emission.
•Do not insert any objects like wires or tools in the ventilation slots, this may cause electric shock.
•Avoid touching the hot surface of the ceramic glass. The hotplate does not heat up during
cooking, but the temperature of the cookware heats up the hotplate.
•Unopened tins or cans are not to be heated on the hotplate. They might explode, and therefore
please remove the lid beforehand.
•It is recommended to disconnect the device from the electric outlet when not in use.
•Stay away from the device or the power plug, if hands are wet.
•Connect the device to a suitable outlet. Do not connect the device to the same outlet with other
devices plugged in.
•Never pull the device by pulling on the power cable.
•The device should not be left unattended when in use.
•If the Induction surface gets cracked by any means, switch o the appliance to avoid electric shock.
•Metallic objects such as knives, forks, spoons and lids should not be placed on the Induction Cooktop
glass plate as they may get hot.

Induction Cooktop 8
•Unplug the power cord prior to cleaning the device. Avoid using any caustic cleansing agents and
make sure that no water penetrates the device.
•To avoid electric shocks, never immerse the device, the cables and the plug in water or other
liquid.
•Wipe o the ceramic field with a damp cloth or use a mild, non abrasive soap solution.
•Wipe o the chasing and the operating area with a soft cloth.
•For better life of the device, do not use any petroleum product on the device as it may damage
the plastic parts.
•Clean the device properly and store in a dry place
CARE AND CLEANING
MISCELLANEOUS
Size:148x210mm (A5)
•People with limited physical, sensory or mental abilities or who lack the necessary experience
and/or skills should not use the appliance alone. They should only be allowed to use the device
under the supervision of a person responsible for their safety.
•It is recommended not to move the device during cooking or with the cookware on top of it.
•Avoid using the device when it does not function properly or is damaged.
•Keep children as well as people under inuence of drugs or alcohol away from the device.
•Do not submerge the device in water or other liquids and do not wash it in the dishwasher.
•In case of any problem with the device, do not try to repair it yourself. It should be only done by a
qualied expert using original replacement and accessory parts.
•The maximum weight the Usha Cookjoy Induction cooktop can with stand along with the
cookware and its contents is 8 kg
•It has been scientifically proven that an induction hotplate does not pose a risk. However, people
with pacemakers should check with their doctor.
Model
Operating Power Range
Operating Voltage
Power Plug 16 A 3 pin Plug
Product Dimension (L*W*H)
Product Weight
Color Black
230 V AC
Frequency 50 Hz
TECHNICAL SPECIFICATIONS
CJ2000WTC
2 000 W
350 mm x 280 mm x 48 mm
2 . 01 kg

9 Induction Cooktop
TROUBLESHOOTING
Abnormalities Key checking points and trouble shooting
Is the power plug properly connected?
Is the switch, power outlet, fuse or power cord damaged?
After plugging in the power cord and
pressing the “ON/OFF” key, the
indicator and display do not light up.
Is the pot material proper?
Is the appliance in a “Preset” working status?
For other causes, please take the appliance to a service
centre to be xed.
The “ON/OFF” indicator lights up and
the display works normally, but
heating does not start.
Is the temperature of the oil too high when frying dishes?
Is the temperature of the surroundings very high?
Is the air inlet or air outlet of the induction cooktop
blocked?
Is the default heating time of the induction cooktop over?
The self-safety protection of the induction cooktop starts,
wait for several minutes and connect power to use it.
Heating suddenly stops during the
process.
Size:148x210mm (A5)
If the error code E0 is reported, please check if the
cookware you are using is suitable for induction cooking or
wait for the appliance to cool down and then switch it on
again.
Check for proper Voltage.
Check for proper Voltage.
Contact service center.
Please wait for the appliance to cool down and then switch
on Induction Cooktop again.
Code of
failure
E0
E1
E2
E3 - E7
E8 - E9

Induction Cooktop 10
WARRANTY CARD
Liability for consequential loss or damage is neither accepted nor implied.
S.No: DATE:
CASH MEMO:
DEALER’S NAME AND ADDRESS:
OWNER’S NAME & ADDRESS:
TERMS AND CONDITIONS OF WARRANTY:
•USHA 'Cookjoy' Induction Cooktop carries a one year warranty against manufacturing defects
only from the date of sale.
• In the event of any complaint, please contact USHA CARE at Toll Free No: 1800 1033 111
•Please preserve the warranty card and original invoice and ensure that they are duly stamped and
signed by the dealer. A warranty card or invoice which is not stamped and signed will be treated
as invalid.
•This warranty does not cover damages to the Induction Cooktop due to improper use, storage,
mishandling, negligence, breakage or cracking of plastic parts or ceramic plate and fluctuation in
voltage supply.
•If the Induction Cooktop is opened, tampered or serviced by anyone except our authorized
customer care center or technician, the warranty becomes void.
•Warranty is void if the Induction Cooktop is used for other than the domestic use.
•Warranty shall not be applicable for damages caused by Force Majeure.
•Warranty does not cover the man made issues or problems caused by incorrect use.
•All repairs within 1 year warranty period (arising from manufacturing defects) will be done 'Free of
Charge’.
•Warranty is void if the serial no. has been deleted, defaced or altered.
•Under no circumstances, whether based on limited warranty or otherwise the company be liable
for incidental, special or consequential damages.
•Use of product indicates acceptance of the aforesaid terms & conditions.
•For service & repair of product outside the warranty period, You may contact the Usha Service
Centre. We will be happy to serve you.
Size:148x210mm (A5)

Size:148x210mm (A5)
USHA INTERNATIONAL LTD.
ISO 9001 : 2015 Certied Company
To explore our range of
product and recipe log
on to www.usha.com
www.ushacook.com COOK
Plot No. 15, Institutional Area, Sector 32, Gurugram - 122 001 (Haryana) Tel : [phone],
Fax : [phone], E-mail : [email protected]
Regd. Oce : Surya Kiran Building, 19 Kasturba Gandhi Marg, New Delhi 110 001 (India) Tel : [phone] Fax : [phone]
[email protected]om
