USSC USG730SS Operation and maintenance manual

853636B-0902K
USG730SS (The Cumberland)
USG890SS (The Irondale)
Model Numbers:
U.S. Patent No. 10,201,247
* All Pictures In This Manual Are For Illustrative Purposes Only. Actual Product May Vary.
© 2021 United States Stove Company, 227 Industrial Park Rd., South Pittsburg, TN 37380 Ph. 800-750-2723
THIS MANUAL IS SUBJECT TO CHANGE WITHOUT NOTICE.
Owner’s Instruction and Operation Manual
SAFETY NOTICE: FOR OUTDOOR USE ONLY! Please read this entire manual before
installation and use of this pellet fuel-burning appliance. Failure to follow these
instructions could result in property damage, bodily injury or even death. Contact local
building or fire ocials about restrictions and installation inspection requirements in
your area. Save these instructions.
A MAJOR CAUSE OF FIRES IS FAILURE TO MAINTAIN REQUIRED CLEARANCES (AIR
SPACE) TO COMBUSTIBLE MATERIALS. IT IS OF UTMOST IMPORTANCE THAT THIS
PRODUCT BE INSTALLED ONLY IN ACCORDANCE WITH THESE INSTRUCTIONS.
Save These Instructions In A Safe Place For Future Reference.
CALIFORNIAPROPOSITION65WARNING:
This product can expose you to chemicals including carbon
monoxide, which is known to the State of California to cause
cancer, birth defects, and/or other reproductive harm. For
more information, go to www.P65warnings.ca.gov

INTRODUCTION
PRODUCT FEATURES
Use only wood cooking pellets specified by the
manufacturer. It is important to use only cooking pellets
that is dry and free from dirt or other impurities. The
cooking pellet industry has established standards for
wood pellet manufacturers. We recommend that cooking
pellets used in all U.S. Stove pellet burning grills meet or
exceed the following specifications:
Use ONLY pelletized fuel formulated for cooking
Do Not Use Cooking Pellets Labeled as Having
Additives
Fines (fine particles) Maximum through a 1/8”
screen
Bulk Density Minimum 40 lbs per cubic foot
Size Maximum 3/8” Diameter by
1-1/2” length
Ash Content
1% Maximum (Premium grade)
3% Maximum (Standard
grade)
Moisture Content 8% Maximum
Heat Content Minimum 8,200 btu’s per hour
Use only wood pellets formulated for cooking in this
pellet grill.
It is important to note that the ash content of the fuel and
the frequency of operation will determine the frequency
of required cleaning for this pellet grill. A high ash fuel
may result in daily cleaning, while a low ash fuel may
result in less frequent cleaning.
Occasionally, impurities in the fuel will cause a hard mass
build up in the burn pot of this pellet grill. Impurities,
such as silica, can virtually form little glass balls when
subjected to the high heat generated in the burn pot. When
allowed to collect, a hard base build up may block air flow
through the burn pot, which will significantly aect the
performance and eciency of this pellet grill. It is a good
idea to check the burn pot for any hard mass buildup or
other blockage on a daily basis, and if necessary, let the
burn pot cool and then clean the burn pot.
U.S. Stove Company realizes that it cannot control the
quality of cooking pellets you choose to use in your
pellet grill; U.S. Stove assumes no responsibility for
that choice.
CAUTION: BE SURE TO STORE COOKING PELLETS A
MINIMUM OF 3 FEET (914.5mm) AWAY FROM THE
PELLET GRILL. RADIANT HEAT CAN IGNITE THE
FUEL.
Please note that the rating label is located on the
inside of the hopper lid.
• Stainless lid and pedestal sides with cast aluminum
sides.
• Improved hinging and lid stops.
• Convenient cord wrap located at the back of the hopper.
• Handy meat probe holder.
• Easily removable stainless steel insert for the side
table.
• Heat relief on side table.
• Wire basket/tool hanger for side table (can be mounted
in 3 locations on side table-front side or back).
• Wheel locks to prevent movement.
• New grease management system internally; removable
for cleaning.
• New drip tray designed for standard commercially
available aluminum pan.
• New gasket materials.
• New push to close hopper latch
2
© 2021 United States Stove Company

SAFETY INFORMATION
• IMPORTANT: READ ALL INSTRUCTIONS BEFORE
INSTALLING AND USING THE APPLIANCE. Failure
to do so may result in property damage, bodily injury, or
even death. Proper utilization of this grill is crucial for
safe and ecient operation.
• Warning: do not operate this grill under a ceiling or
overhang.
• Contact your local building ocials to obtain a
permit and information on any additional installation
restrictions or inspection requirements in your area.
• Do not throw this manual away. This manual has
important operating and maintenance instructions
that you will need at a later time. Always follow the
instructions in this manual.
• This appliance is designed for the use of pelletized fuel
that is specificity made for cooking. The use of other
than cooking pellets will not give satisfactory results.
• Never use gasoline, gasoline-type lantern fuel,
kerosene, charcoal lighter fluid, or similar liquids to
start or “freshen up” a fire in this appliance. Keep all
such liquids well away from the appliance when in use.
• Do not unplug the grill if you suspect a malfunction.
Turn the “On/O” switch to “O” and contact your
dealer.
• Your grill requires periodic maintenance and cleaning
(see the “Maintenance” section of this manual). Failure
to maintain your grill may lead to improper and/or
unsafe operation.
• Never try to repair or replace any part of the grill unless
instructions for doing so are given in this manual. All
other work should be done by a trained technician.
• Do not touch the hot surfaces of the grill. Educate all
children on the dangers of a high-temperature grill.
Young children should be supervised when they are in
the same vicinity as the grill.
• The hopper and grill top will be hot during operation;
therefore, you should always use some type of hand
protection when refueling your grill.
• A power surge protector is required. This unit must be
plugged into a 110 - 120V, 60 Hz grounded electrical
outlet. Do not use an adapter plug or sever the grounding
plug. Do not route the electrical cord underneath, in
front of, or over the grill. Do not route the cord in foot
trac areas or pinch the cord under any object.
• Unplug the grill when not in use.
• The grill will not operate during a power outage. If
a power outage does occur, check for unsafe burn
conditions that might have occurred.
• Never block free airflow through the open vents of the
unit.
• Keep foreign objects out of the hopper.
• The moving parts of this grill are propelled by high
torque electric motors. Keep all body parts away from
the auger while the grill is plugged into an electrical
outlet. These moving parts may begin to move at any
time while the grill is plugged in.
• Do not place clothing or other flammable items on or
near this grill.
• This appliance is not intended for commercial use.
• Warning: Operate your pellet grill only on a
noncombustible floor or provide floor protection
adequate to provide ember protection around grill.
• Creosote-Formation and need for removal. When wood
pellets are burned slowly, they produce tar and other
organic vapors that combine with expelled moisture
to form creosote. The creosote vapors condense in a
relatively cool oven flue and exhaust hood of a slow
burning fire. As a result, creosote residue accumulates
on the flue lining and exhaust hood. When ignited, this
creosote makes an extremely hot fire. When grease
or creosote has accumulated, it should be removed to
reduce risk of fire.
• Do not use accessories not specified for use with this
appliance.
• Follow these guidelines to prevent this colorless,
odorless gas from poisoning you, your family or others.
• Know the symptoms of carbon monoxide poisoning:
headache, dizziness, weakness, nausea, vomiting,
sleepiness, and confusion. Carbon monoxide reduces
the blood’s ability to carry oxygen. Low blood oxygen
levels can result in loss of consciousness and death.
• See a doctor if you or others develop cold or flu-like
symptoms while cooking or in the vicinity of this
appliance. Carbon monoxide poisoning, which can
easily be mistaken for a cold or flu, is often detected
too late.
• Alcohol consumption and drug use increase the eects
of carbon monoxide poisoning.
• Carbon monoxide is especially toxic to mother and
child during pregnancy, infants, the elderly, smokers,
and people with blood or circulatory system problems,
such as anemia, or heart disease.
• SAVE THESE INSTRUCTION
© 2021 United States Stove Company
3

CLEARANCE TO COMBUSTIBLES
OVERALL DIMENSIONS
This pellet grill must be installed with the clearance to
combustibles as shown in this manual.
WARNING:
DO NOT OPERATE THIS GRILL UNDER A CEILING
OR OVERHANG.
24”
REAR WALL
SIDE WALL
SIDE WALL
12”
12”
55-3/4”
45-1/2”
28-5/16”
USG730SS
USG890SS
45-5/8”
28-1/2” 61-11/16”
4
© 2021 United States Stove Company

© 2021 United States Stove Company
5

READ ALL INSTRUCTIONS BEFORE INSTALLING
AND USING THE APPLIANCE
TOOLS & MATERIALS NEEDED FOR
INSTALLATION
• #3 phillip screwdriver (use of a drill with a phillips bit
will speed up the assembly process)
Use proper assembly technique when installing bolts,
start all bolts first and then tighten appropriately. The
assistance of a second person is strongly recommended.
Remove the grill contents for assembly. Do Not
Remove The Searing Station.
STEP 1 BASE AND PEDESTAL ASSEMBLY
1. Swivel Wheel Installation
• Attach both swivel wheels, one at a time; to the grill
base using the provided bolts, lock washers, and flat
washers.
2. Fixed Wheels Installation
• Slide the axle through the hole located in the front side
flange of the grill base.
• Secure the axle to the grill base using the provided
washer, lock washer, and nut.
• Repeat these steps to attach the second fixed wheel to
the other side of the unit.
3. Assembling the Pedestal
• Attach the left and right pedestal panel to the center
pedestal panel using the provided washers and bolts.
4. Attaching the Pedestal
• Attach the assembled pedestal to the base using the
provided washers and bolts.
5. Attaching the Main Body
ATTENTION:
THE ASSISTANCE OF A SECOND PERSON IS
STRONGLY RECOMMENDED FOR THIS STEP.
• Attach the main grill body to the assembled pedestal
with the provided washers and bolts.
Note: The three cushioned pads installed between the lid
and the body of the unit are for shipping purposes only.
Please remove them.
ASSEMBLY INSTRUCTIONS
Screw C
Washer H
Washer E
Screw A
Washer H
Washer E
Screw A
Washer H
Washer E
6
© 2021 United States Stove Company

IMPORTANT:
DO NOT REMOVE THE SEARING STATION. THE
SEARING STATION IS NOT SHOWN IN THE IMAGES
BELOW FOR CLARITY PURPOSES ONLY.
STEP 2 SIDE TABLE ASSEMBLY & INITIAL
FIRING
1. Attaching the Side Table
• Attach the side table to the main grill body using the
provided bolts and washers.
• NOTE: Washer (G) must be placed between the side
table and the grill.
• Place the stainless steel plate into position.
2. Spice Rack Assembly
• Attach the spice rack to the side table. The provided
predrilled holes allow the spice rack to be attached to
the front, side, or rear of the side table.
ASSEMBLY INSTRUCTIONS
Screw A
Washer H
Washer F
Screw A
Washer H
Washer F
Screw B
Washer H
Washer E
Washer G
Screw D
Washer J
© 2021 United States Stove Company
7

3. Drip Pan
• Place the disposable pan into the drip pan holder and
slide into place.
• NOTE: Make sure that the pan is aligned with the drip
hole
4. Initial Firing System Check
IMPORTANT:
DO NOT PUT ANY PELLETS INTO THE HOPPER
OR GRILL DURING THE INITIAL FIRING SYSTEM
CHECK.
• Open the pellet hopper lid to check for foreign objects
in the hopper.
• Plug the grill into a three-wire, grounded wall outlet.
• Press the power button to turn the unit on. DO NOT
TOUCH THE AUGER OR THE IGNITOR! Open the
hopper lid and check to see that the auger is turning
freely - approximately 2 rpm. LOOK TO SEE THAT THE
AUGER IS TURNING. DO NOT TOUCH.
• Place your fingers over the burn pot and feel the air
movement from the combustion blower. Ignitor will
glow within 1 minute.
• Press the power button to turn the unit o.
• Clean the drip pans, flame plate, warming grate, and
grill grate with soap and water, then rinse. Allow the
components to dry before continuing the assembly. DO
NOT TOUCH THE IGNITOR OR THE AUGER.
STEP 3 GRILL SURFACE, DRIP PAN, AND
FLAME PLATE ASSEMBLY
1. Flame Plate Installation
• There are two cutouts along the bottom edge of the
flame plate, one in the front and one in the rear. Use
the two cutouts to position the flame plate accurately.
NOTE: One side of the flame plate is longer than the
other. When installing the flame plate ensure that the
longer side is installed to the rear of the unit.
WARNING:
IF THE FLAME PLATE IS INSTALLED INCORRECTLY
THE PELLETS MAY BURN BACK INTO THE HOPPER,
AND/OR THE GRILL MAY SMOKE EXCESSIVELY
DURING COOK MODE AND MAY NOT MAINTAIN
SET COOKING TEMPERATURE PROPERLY.
Front Of
The Unit
Rear Of
The Unit
2. Drip Pan Installation
ASSEMBLY INSTRUCTIONS
8
© 2021 United States Stove Company

• Place the right drip pan. Make sure the drip pan slides
into the grease drain.
• Slide the left drip pan into position.
3. Grilling Grate
• Place the main grilling surface onto the grill mounting
bracket. Align with the searing station. .
4. Warming Grate
• Place the warmer onto the warmer mounting brackets.
STEP 4 PREPARING THE GRILL FOR USE
1. Seasoning The Grill
IMPORTANT: THE GRILL MUST BE SEASONED
BEFORE COOKING ANY FOOD ON IT FOR THE
FIRST TIME.
The grill is now fully assembled and it is time to season
the grill. The seasoning process is an important part of
preparing your grill for use. It allows any oil residue from
the manufacturing process to burn o and it allows the
high-temperature paint to cure. Do Not place anything
on the unit during the seasoning process as the paint
could be permanently damaged. Once you have read and
understood the “Standard Use And Operation” section of
this manual follow the steps below to season the grill:
a. Fill the hopper 1/2 full with cooking pellets.
b. Press the power button to turn the grill on.
c. Prime the auger by pressing and holding the “PRIME”
button for two minutes.
PRIME
d. Close the grill’s lid.
e. When smoke is visible use the “COOK TEMP” button
to adjust the grill to the maximum temperature
(500°F).
COOK
TEMP
f. Run the grill at maximum temperature for a minimum
of 1 hour.
SAVE THESE INSTRUCTIONS
ASSEMBLY INSTRUCTIONS
© 2021 United States Stove Company
9

ACTUAL COOK
SETPOINT SMOKE
DISPLAY MODE
WOOD PELLET FIRED CONVECTION GRILL
COOK
TEMP
PRIME
USSC GRILLS • USSCGRILLS.COM
TEMPERATURE CONTROL
Power
Adjust cook
temperature Chage temperature
display
Change between “Cook”
and “Smoke” mode
Meat Probe
Primes
the auger
STANDARD USE & OPERATING INSTRUCTIONS
Make sure the grill is always sitting level.
STANDARD STARTUP SEQUENCE
1. Fill the hopper with pellet fuel. Never leave pellets
in the hopper and only use the minimum amount of
pellets needed for cooking. Be sure to close and latch
the hopper lid. Only burn pellet fuel that is specifically
manufactured for use in pellet grills and cookers.
2. Open the grill lid and press the “Power” button. The
three dots between the numbers on the temperature
readout will begin to flash; showing that the grill is in
startup-sequenceinthecorrespondingmode.Thegrill
will automatically light 5 to 8 minutes after pressing
the “Power” button. Remember, start-up times may
vary based on outside ambient temperature and fuel
quality). Prime your auger press the button found on
the control panel labeled “Prime.” When pressed, the
auger spins and feeds pellet fuel to the burn pot. Hold
the “Prime” button in for up to 1 minute to prime the
auger tube with pellets.
NOTE: The startup mode will last approximately 15
minutes. Excessive smoke during startup is typical.
3. Set the control board to the desired cooking
temperature using the “Cook Temp” buttons on
the control board. Temperature settings are in 5°F
increments.
4. Once the grill ignites, you can hear a flowing sound
slightly louder than the blower motor of the grill. At
this point, the grill produces significantly less smoke.
Close the grill lid once ignition has occurred.
NOTE: Allow the grill lid to remain closed during
the pre-heat and as much as possible during cook
time. Feed rates during run mode are determined by
temperature readings. Each time the lid opens, the
temperature goes down, causing the auger to feed
more. This can lead to potential overcooking of food.
5. Check the actual temperature compared to the set-
point temperature by using the “Display” button
on the control board. The display button helps to
determine when the grill has preheated to the desired
cooking temperature.
NOTE: During the startup, the grill temperature can
exceed the set-point temperature. It is advisable
to keep the display in “Actual” mode to check the
temperature readings and avoid overcooking or
burning. It is easy to tell if the grill is still in startup
by the “Cook” or “Smoke” light blinking. The grills
settings will determine which light blinks.
6. Once the 15 minute startup time is met, and the grill
has reached its set-point temperature, the grill is
ready to have food added.
NOTE: As previously mentioned, keep the lid closed
as much as possible to maintain constant cooking
temperature. The temperature may fluctuate slightly.
NOTICE !! During operation, the technology in this
grill’s programming learns the fuel rate needed to
sustain the selected cooking temperature. Therefore,
start-up times may vary based on outside ambient
temperature and fuel quality or type (flavored or not).
Using the “Prime” button may help facilitate a quicker
start-up time.
STANDARD SHUTDOWN SEQUENCE
1. To turn the grill o, make sure the searing station is
o. The light will be o when the searing station is o.
2. Press the power button.
3. The word “Cool” will show on the display, and the grill
will enter a shutdown mode. The blower will continue
to run until it has reached a safe temperature.
NOTE: The “Cook” light will stay solid, and the
“Smoke” light will flash during the shutdown
sequence. Shutdown sequence can take up to 1 hour
depending on the cooking temperature and the outside
temperature.
DO NOT TURN THE GRILL OFF BY UNPLUGGING IT.
SAVE THESE INSTRUCTIONS.When the grill is plugged
in, the control board will flash through a sequence of
letters and numbers before going to a blank display
10
© 2021 United States Stove Company

OPERATING TIPS
screen.
• When the grill is turned on, there will be three flashing
lights found between the numbers of the display. The
three lights will continue to flash until the grill reaches
180°F, then the startup sequence will be finished.
• Grill operating temperatures are 180°F to 500°F.
• When the grill is first turned on, the control board will
go to 350°F on the first ignition. If the grill has been
used, the control board will go to the last setting used.
• “Smoke” mode ranges from 180°F to 230°F. The
concentration of smoke will vary depending on
the temperature selected. There will be a higher
concentration of smoke at lower settings than there
is when operating at higher temperatures for “Smoke”
mode.
• The combustion blower is on constantly during “Cook”
mode and does not vary in speed.
• If the grill is turned o during “Startup” mode,
everything shuts o without a shutdown sequence.
• If the flame plate is installed improperly, a burn back
may occur due to the airflow restrictions at the burn
pot.
• If the grill is in “Cook” mode and change to “Smoke”
mode, the temperature will automatically go to 180°F.
• If the grill is in “Smoke” mode and change to “Cook”
mode, the temperature will automatically go to 450°F.
• Temperature control doesn’t begin to control the feed
rate for 15 minutes, due to the 15-minute start-up
sequence.
• Make sure to unplug the grill only after it has gone
through the shutdown sequence, cooled o, and is not
in use.
• DO NOT unplug the grill during use or to shorten the
shutdown sequence.
SEARING STATION
• The searing station control is operable from the toggle
switch only (found next to the display board). Only turn
on the searing station for the needed time of use. Make
sure to turn the searing station o when not in use. The
searing station will function even if the grill is not in
operation. Always unplug the grill when not in use.
• Using the searing station during general cooking
needs is not recommended, as it can interfere with the
temperature sensor. Only use the searing station to
quickly sear the food and then turn it o. The searing
station takes approximately 5 minutes to reach a
searing temperature during use in the “Cook” settings.
MEAT PROBE
The grills meat probe will track the temperature of the
food as it cooks without having open the grill lid several
times to test the food with an instant-read thermometer.
The correct placement of the meat probe is especially
important when cooking at a higher heat as opposed to
low and slow; because there is such a large dierence
within just one inch of space in the food. When inserting
the meat probe, avoid the bone because it will give
inaccurate readings. After inserting the probe, make sure
it is secured into place. As the thermometer nears its
target temperature, spot-check other areas to see if they
are also close. Be careful, the meat probe and its wires
are hot.
To use the meat probe, first follow the startup
instructions in this manual. Bring the grill up to the
desired temperature. Once preheating is complete, place
the meat onto the grill surface with the probe inserted
into the best section of meat. Plug the meat probe into
the display panel and push the “Display” button until
both the “Actual” and “Setpoint” lights are not lit. The
temperature shown on the display will be the internal
meat temperature. Using the meat probe will prevent
the need of opening and checking the internal meat
temperature, therefore preserving heat and pellet usage.
© 2021 United States Stove Company
11

Note: These are suggested approximations only and intended as guidelines only. For best results please follow
appropriate recipe.
Meat
Type Cut Cooking Temp. Approximate Suggested Cook Time
Beef Hamburgers 425°F 10 min on each side
Beef T-Bone/Ribeye 450°F 10 to 20 min (depending on degree of doneness desired) turning once
Beef Tenderloin 400°F 25 to 30 min (depending on degree of doneness desired)
Beef Brisket 225°F 4-6 hrs
Beef Filet Mignon 450°F 10 to 15 min (depending on degree of doneness desired) turning once
Beef Flank Steak 450°F 10 to 15 min (depending on degree of doneness desired) turning once
Beef Ribs 225°F 3-4 hrs
Pork Loin 350°F 1 to 1.5 hrs
Pork Baby Back Ribs 325°F 2 hrs
Pork Shoulder Steak 325°F 35 to 40 min
Pork Ground Pork 300°F 45 min
Pork Pork Chops 325°F 45-50 min
Chicken Breast 350°F 25-30 min, turning once 1/2 way through
Chicken Thighs 350°F 40-45 min
Chicken Whole Chicken
4-5 lbs 450°F 70-90 min
Turkey 10-12lb Turkey 325°F 3 hrs
Turkey Legs 225°F 4-5 hrs
Lamb Rack of Lamb 400°F 30 min, for Rare, longer if desired
Lamb Lamb Chops 450°F 12 min, turn once 1/2 way through
Salmon Filet 350°F 25-30 min
Cod Loin 400°F 20 min
Scallop Scallop 450°F 8-10 min
Shrimp Whole Shrimp 450°F 2-3 min/side
Lobster Tail 400°F 25-30 min
OPERATING TIPS
12
© 2021 United States Stove Company

WARNING:
DISCONNECT THE POWER CORD BEFORE
PERFORMING ANY MAINTENANCE! NOTE:
TURNING THE “ON/OFF” SWITCH TO “OFF”
DOES NOT DISCONNECT ALL POWER TO THE
ELECTRICAL COMPONENTS OF THE GRILL.
Failure to clean and maintain this unit as described in
this manual may cause poor performance and hazardous
situations. Adjust the maintenance schedules based on
the frequency of usage to ensure the proper operation and
maximum eciency of this pellet grill. When performing
any maintenance on this grill, make sure the unit has
powered o, allowed full shutdown sequence, and then
unplugged from the power source.
Maintenance Schedule
Operation Interval
Clean or change drip pan After Each Use
Inspect and clean burn pot After Each Use
Inspect hopper for fines (sawdust) Biweekly
Ash removal After Each Use
Inspect and clean combustion air
blower Annually
CLEAN DRIP PAN
Note: Allow the unit to cool to ambient temperature
before inspecting or cleaning the grill.
1. Take out the main grilling surface. DO NOT REMOVE
THE SEARING STATION.
2. Scrape drippings down the grease drain and into the
grease pan provided.
3. Clean or change the drip pan with a food-safe de-
greasing agent and ensure all the cleaning solvents
and chemicals are thoroughly rinsed o after
cleaning.
4. Empty the grease pan if necessary.
5. Reinstall the grilling surface.
INSPECT AND CLEAN BURN POT
Note: Allow the unit to cool to ambient temperature
before inspecting or cleaning the grill.
1. Remove the main grilling surface. DO NOT REMOVE
THE SEARING STATION.
2. Inspect the burn pot to check that the combustion air
holes have not become plugged. If necessary, clean
thoroughly.
3. Replace the flame plate, drip pan, and grilling surface.
INSPECT HOPPER FOR FINES
Note: Allow the unit to cool to ambient temperature
before inspecting or cleaning the grill.
Periodically check the hopper for pellet dust (fines) build-
up. The accumulation of fines can reduce the eciency of
the grill, increase the chance of hopper fires, and other
unsafe operating conditions. If dust (fines) accumulate
suciently, vacuum out and reload the hopper with new
pellets.
ASH REMOVAL
Note: Allow the unit to cool to ambient temperature
before inspecting or cleaning the grill.
1. Use an ash vacuum to remove ashes from the burn
pot and the bottom of the grill’s body.
WARNING:
BE SURE ALL ASH EMBERS ARE EXTINGUISHED
AND ALL ASHES ARE COOL TO THE TOUCH
BEFORE VACUUMING.
2. Dispose of ashes into a metal container.
DISPOSAL OF ASHES
Ashes should be placed in a steel metal container with
a tight-fitting lid. The closed container of ashes should
be placed on a non-combustible floor or on the ground
well away from all combustible materials, pending final
disposal. If the ashes are disposed of by burial in soil or
otherwise locally dispersed, they should be retained in the
closed container until all cinders have been thoroughly
cooled. Do not place other waste in the same container.
INSPECT AND CLEAN COMBUSTION AIR
BLOWER
Note: Let the unit cool to ambient temperature before
inspecting or cleaning the grill.
DANGER:
RISK OF ELECTRIC SHOCK. DISCONNECT POWER
BEFORE SERVICING UNIT.
Over time, ash or dust may accumulate on the blades
of the fans. Inspect the fans and if any accumulation is
present vacuum clean. The accumulated ash or dust can
impede the fan’s performance.
MAINTENANCE
© 2021 United States Stove Company
13

MAINTENANCE
1. Open the service panel by removing the six screws. 2. Inspect the fan for dust or ash build-up and clean if
necessary.
3. Close the service panel and reinsert screws.
TROUBLESHOOTING
ERROR CODES
Possible Causes Possible Remedies (Unplug grill first when possible)
Error Code 1 - Power Failure - The power
failed while the grill was operating and
the grill temperature was below the warm
set point when power was returned
Call Customer service [phone] if the error doesn’t go away by
restarting.
Error Code 2 - The circuit for the RTD
(temperature probe mounted in the grill)
is open.
Check to see if the wires for the RTD have come unplugged. If they are not
unplugged the RTD has failed.
Error Code 3 - Grill Temperature drops
significantly / Failure to Ignite - Grill has
ran out of pellets, Auger is not turning.
Igniter did not ignite pellets.
Check to see if the grill has ran out of pellets. If there are still pellets in
the hopper check to see if the auger is turning. If the auger is not turning
it may be jammed or the auger motor has failed. If the grill does not ignite
check to see if the Igniter is working. If the igniter is not getting hot call
customer service at [phone]
GRILL WON’T IGNITE
Possible Causes Possible Remedies (Unplug grill first when possible)
Verify power at the electrical outlet Plug another electrical device into that outlet to confirm power
If the power cord is connected to a GFI
(Ground Fault Interrupter), check and
reset if necessary
Reset the GFI and initiate startup procedure
14
© 2021 United States Stove Company

AFTER GRILL HAS BEEN ON FOR A WHILE, THE BURN POT OVERFILLS
Possible Causes Possible Remedies (Unplug grill first when possible)
Grill is dirty, which restricts airflow
through the burnpot
Follow all cleaning procedures in the “Maintenance” section of the
owner’s manual.
Burnpot holes are blocked Remove the burnpot and thoroughly clean it.
Blockage in air intake pipe Visually inspect the air intake that leads into the burnpot for foreign
material.
Combustion blower is not spinning fast
enough
Clean fan blades and inspect bearings for wear. Ensure the fan is free of
any obstructions.
Bad Pellets
The brand of pellets or the batch of pellets that is being used may be of
poor quality. If possible, try a dierent brand of pellets. It is advisable
to try a brand that is made from a dierent type of wood (softwood vs.
hardwood). Dierent woods have dierent characteristics when being
burned.
GRILL ENTERS SHUTDOWN MODE UNEXPECTEDLY
Possible Causes Possible Remedies (Unplug grill first when possible)
The convection blower is overheating and
tripping the internal temperature shuto
Clean any dust o of the windings and fan blades. If oiling the blower does
not help, the blower may be bad.
Fuel other than wood pellets is being
burned in the grill
This pellet grill is designed and tested to use cooking wood pellets. Check
for signs of fuel other than wood pellets. No other types of fuel have been
approved for this pellet grill. If there are signs of other types of fuel being
used, stop using them immediately.
Power surge or brown out situation A power surge, spike, or voltage drop could cause the thermocouple to
malfunction. Use a surge protector
Thermocouple is malfunctioning If the other items check out good, replace the thermocouple.
TROUBLESHOOTING
GRILL FEEDS PELLETS, BUT WILL NOT IGNITE
Possible Causes Possible Remedies (Unplug grill first when possible)
Bad igniter element
Put power directly to the igniter element. Watch the tip of the igniter from
the front of the grill. After about 2 minutes the tip should glow. If it does
not, the element is bad.
The control board is not sending power to
the igniter
Check the voltage going to the igniter during startup. It should be 110-
115 volts. If the voltage is lower than full voltage, check the wiring. If the
wiring checks out good, the board could be bad.
POWER FAILURE DURING USE
Possible Causes Possible Remedies (Unplug grill first when possible)
Power goes out during operation Observe the grill to make certain unsafe burning conditions do not occur
during the outage.
Restarting the unit after a power outage Press the power and the prime button at the same time to resume
standard operation.
© 2021 United States Stove Company
15

TROUBLESHOOTING
GRILL WILL NOT FEED PELLETS
Possible Causes Possible Remedies (Unplug grill first when possible)
Thermocouple is defective Wait for the grill to cool for about 30 - 45 minutes. Check the thermocouple
to see if it’s bad. Check resistance with volt meter.
Bad auger motor
Remove the six retaining screws in the service panel. Remove the auger
motor from the auger shaft and try to run the unit. If the motor will turn,
the shaft is jammed on something. If the motor will not turn, the motor is
bad.
Auger jam
Start by emptying the hopper. Then remove the auger motor by removing
the auger pin. Remove the two screws holding the auger bushing. Gently
pull the auger shaft straight out so that the end of the auger shaft comes
out. After the shaft is removed, inspect it for bent flights, burrs, or broken
welds. Remove any foreign material that might have caused the jam. Also,
check the auger tube for signs of damage such as burrs, rough spots, or
grooves cut into the metal that could have caused a jam.
Loose wire or connector Check all wires and connectors that connect to the auger motor,
thermocouple, and fan.
Bad control board
If the fuse and the wires and connectors check out good, and if the high
limit switch did not trip, test for power going to the auger motor. If there
is not a full current going to the auger motor when the fuel feed light is on,
the control board is bad.
For Parts Assistance Call: 800-750-2723 Ext 5051 or Email: [e-mail]
The information in this owner’s manual is specific to your unit. When ordering replacement parts the information in
this manual will help to ensure the correct items are ordered. Before contacting customer service write down the model
number and the serial number of this unit. That information can be found on the label attached to the back of the unit.
Other information that may be needed would be the part number and part description of the item(s) in question. Part
numbers and descriptions can be found in the “Repair Parts” section of this manual. Once this information has been
gathered you can contact customer service by phone [phone] Ext 5051 or Email [e-mail].
Model Information
Model Number
Serial Number
HOW TO ORDER REPAIR PARTS
16
© 2021 United States Stove Company

1
2
4
11
12
13
3
10
9
8
7
5
14
6
REPLACEMENT PARTS
18
19
17
15
16
© 2021 United States Stove Company
17

REPLACEMENT PARTS
Key Description Model # Part # Qty
1 Grilling Grate USG730SS 893119 1
USG890SS 893120 1
2 Searing Station 80825 1
3 Drip Pan Assembly USG730SS 893191 1
USG890SS 893192 1
4 Temperature Probe 80826 1
5 Flame Plate 893193 1
6 Side Table Plate 893560 1
7 Grill Basket 893561 1
8 Drip Pan Holder 893536 1
9 Caster Wheel Assembly (set of two) 893115 1
10 Fixed Wheel Assembly (set of two) 893114 1
11 Control Board 80827 1
12 Switch 80833 1
13 Fuel Grate 893206 1
14 Felt Gasket 88349 1
15 Auger Motor 80828 1
16 Auger USG730SS 893287 1
USG890SS 893288
17 Induction Fan 80829 1
18 Ignitor Cartridge 80830 1
19 Burnpot 893189 1
N/S Meat Probe 80843 1
IN ORDER TO MAINTAIN WARRANTY, COMPONENTS MUST BE REPLACED USING ORIGINAL
MANUFACTURERS PARTS PURCHASED THROUGH YOUR DEALER OR DIRECTLY FROM THE APPLIANCE
MANUFACTURER. USE OF THIRD PARTY COMPONENTS WILL VOID THE WARRANTY.
To order parts:
Call 1-800-750-2723 Ext 5051 or
Email to: [e-mail]
18
© 2021 United States Stove Company

WIRING DIAGRAM
WHITE
WHITE
FUSE
IGN FANAUG
IGNITOR
AUGER
MOTOR
INDUCTION
FAN
SEARING STATION
M
M
RED
YELLOW
PURPLE
WHITE
POWER SUPPLY
115 VOLTS AC
TEMPERATURE
PROBE
GND
SWITCH
POWERED CONTROL BOARD
BLACK
BLACK
BLACK
YELLOW
WHITE
BLACK
HOT
WHITE
GRILL
WHITE
PURPLE
RED
COM
853641
© 2021 United States Stove Company
19

NOTES
20
© 2021 United States Stove Company
