UTP BALUN SP-BNC User manual

Copyright 2011-2012. 1 SP-91N
Specifications & appearance are subject to change without notice. R201208-V20
Single Channel Video Surge Protector
Model: SP-BNC
Features:
Suitable for protection for video signal of CCTV surveillance systems
Low restricted voltage, quick response time and convenient mounting
Application Diagram:
Panel View:
Specification:
Model
SP-BNC
Connection Properties
Connector Type
BNC
Power & Surge
Properties
Normal Discharge Current
5KA
Max Discharge Current
10KA
Rated Load Current
300mA
Rated Load Voltage
5V DC
Action Voltage
6.5V DC
Limiting Voltage
90V DC
Video Properties
Response Time
1ns
Max Transmission Rate
0~1GHz
Insertion Loss
< 0.2dB
Return Loss
16dB
Physical Properties
Dimensions L x W x H
43 x 25 x 25 mm / 1.69 x 0.98 x 0.98 inches
Weight
60 g / 2.1 oz
*Specifications are subject to change without notice
USER MANUAL

Copyright 2011-2012. 2 SP-91N
Specifications & appearance are subject to change without notice. R201208-V20
Installation & Maintenance:
1. The section of the grounding line should be more than 4mm2and be as short as possible.
2. No maintenance is required, but inspecting the product after a thunderstorm or lightning storm is essential.
3. The circuitry connects with the input terminal of the surge protector (IN) and the output terminal (OUT) connects with the
protective equipment. And both terminals must not be reversed.
Note: Video: The circuitry connects with the input terminal of the surge protector (IN) and the output terminal (OUT) connects with the
protective equipment. And the both terminals must not be reversed.
Package Contents:
One (1) Single Channel Video Surge Protector
One (1) User Manual
Caution:
Do not connect this device to any power source other than what is supplied.
Do not handle the unit with wet hands.
The unit is not waterproof and should not be used outdoors.
Limited Warranty:
LIMITED ONE (1) YEAR WARRANTY AND EXCLUSIONS
Manufacturer warrants to the original consumer purchaser and not for the benefit of anyone else that this product at the time of its
sale by Manufacturer is free of defects in materials and workmanship under normal and proper use for one (1) year from the
purchase date. Manufacturer's only obligation is to correct such defects by repair or replacement, at its option, if within such one (1)
year period the product is returned prepaid, with proof of purchase date, and a description of the problem. This warrant excludes
and there is disclaimed liability for labor for removal of this product or reinstallation. This warranty is voided if this product is
installed improperly or in an improper environment, overloaded, misused, opened, abused, or altered in any manner, or is
not used under normal operating conditions or not in accordance with any labels or instructions. There are no other
implied warranties of any kind, including merchantability and fitness or a particular purpose, but if any implied warranty is
required by the applicable jurisdiction, the duration of any such implied warrant, including merchantability and fitness of or a
particular purpose, is limited to one (1) year. Manufacturer is not liable for incidental, indirect, special, or consequential
damages, including without limitation, damage to, or loss of use of, any equipment, loss sales or profits or delay or failure
to perform this warranty obligation. The remedies, provided therein are the exclusive remedies under this warranty, whether
based on contract, tort or otherwise.
