UVC PureLight 360 User manual

UVC SANITIZING Cart
User Manual
Product No.: Voltage Input Wattage Product Size
PL-UVC360-1 AC120-277V 320WL940*W500*H1540mm
This uvc sanitizing cart is only for commercial use , such as in the Hotel, Resorts,
Shoppingmall,Office,Workspace ,Meeting room ,Manufacturing workshops,Medical&Dental
examrooms,Retail&commercialspaces,Hospitals,Schools,Bathrooms,Restaurants&Kithen
s ,Cruise Ships ,Military Bases etc., it was only used by professional person. The warning
sign as below shall be shown on the way to the fixture during operation.
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be followed including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
a) This equipment is designed for using with germicidal UV radiation sources. UV radiation can cause a risk of personal
injury. Overexposure can result in damage to eyes and bare skin. To reduce the risk of overexposure, this equipment
must be operated by professional person.
b) Maintenance and servicing of this UV equipment shall be operated by professional person. Operating person must
wear appropriate Personal Protective Equipment (PPE). If the equipment needs to be in operation during the
maintenance or servicing work, pls contact the equipment manufacturer for PPE recommendations and guidance.
c) Do not use this equipment for other purpose.
d) If using accessory, which is not recommended by the manufacturer, to the equipment, it may cause unsafe condition.
e) People, pets, and plants should be away from the sterilizing area when using the equipment.
f) The equipment should be stored well to avoid any potential accidental damage after used.
Warning: Don't look at the disinfection light directly.
People, pets and plants should be away from the sterilizing area when using the disinfection cart.
Ventilate for 30-40 minutes for sterilized area after working.
TECHNICAL SPECIFICATIONS:
Fixture power 320W Ambient temperature 0~+40℃
UV lamp power 300W Storage temperature -10~+60℃
Input voltage 120-277Vac Time shutdown 0~20min
Peak wavelength 253.7nm Power factor ＞0.9

manual opration
1.Plug in the cart and turn on power switch . Rotate the rotary dial to choose sanitizing cycle 5min、10min、20min (default
option is OFF). 90S countdown is started and shown on display. At the end of 90S, chime sound warns users leave sanitizing
area (three,Di Di Di)
2.During the 90S countdown, PIR sensor doesn’t active. After 90s end, the cart enter sanitizing cycle, at the meantime, PIR
sensor starts to work. When PIR sensor detected someone is still in the sanitizing area, UVC lamp will turn off automatically.
When motion is no longer detected, UVC lamp will not turn on to proceed work automatically. If users want to restart the cart,
they need to turn off the power switch then turn on the power switch to restart it manually;
3.IF the cart with WIFI,Plug in the cart and turn on power switch . Press pairing button 5S till blue pairing indicator
light flash quickly,after successful connection, the indicator light will always be on . Open phone and enter APP UI，
users can set the time. When PIR sensor detected motion during sanitizing cycle, UVC lamp will turn off automatically. When
motion is no longer detected, UVC lamp will not turn on to proceed work automatically. Users need to click on/off button
on APP if they want to restart the cart( there is no 90S countdown). When users don't know whose phone connected to
the device,Long press the press pairing button to remove the device
III. Motion Sensor Operation(If the lamp with Motion Sensor):
1. Turn on the UV lamp, select the disinfection time and left the room, after 90 seconds ,alarming(Di….Di…Di….), the UV lamps will switch on
automatically, the motion sensor will activated.
2. It will turn off when it detects that someone moving around . If users want to restart the cart, they need to turn off the power switch
then turn on the power switch to restart it manually
IV. Note:
1. The surface of the lamp should be kept clean.
2. The lamp is fragile. Please handle it with care.
3. A room should be ventilated after UV disinfection, and people are suggested to enter the room 30-40minutes later.
V. Warning
SAVE THESE INSTRUCTIONS
Beam angle 360°Weight 28.5kg
Life 60000Hrs IP level IP20
UV radiation intensity(1m) 1300uW/cm²Color Black
Safety classification Class ⅠDimensions(L*W*H)(mm L940*W500*H1540mm

FCC Warning
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any inte rference received, including interference that may
cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interferenceto
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance 20cm between the radiator and your body.
