USER INSTRUCTION
uvex aXess one:
Active earmuffs with Bluetooth® function for communication, audio streaming and a listening through
function called RAL (Real Active Listening). The uvex aXess one limits the sound pressure level of the
audio signal for entertainment purposes to 82dB(A). The perceptibility of warning signals at certain
workplaces may be impaired when using the sound reproduction system.
The uvex aXess one is equipped with foldable headband and continuous length adjustment.
This is a category III, harmful noise, PPE product.
Warning:
This hearing protection serves to protect against harmful noise when used in accordance with these
instructions for use. Wear the hearing protection during the entire time you are in the noise area. The
hearing protection must be checked before each use. Sealing pads may show signs of age, look for
defects or cracks and check the flexibility of the sealing pads. If damaged, do not use the hearing
protection. Replace sealing cushions twice a year to maintain seal, hygiene and comfort. Brush long
hair to the side and remove jewelry or other objects that interfere with the acoustic seal. The fitting of
hygiene covers to the cushions may affect the acoustic performance.
This earmuff is equipped with a communication device. The user should check for proper operation
before use. If distortion or failure is detected, the user should follow the manufacturer's
recommendations for maintenance. Warning. The output sound pressure level of the communication
device of this hearing protector may exceed the daily limit. This earmuff is equipped with level-
dependent sound attenuation. The user should verify proper operation before use. If battery
displacement or failure is detected, the user should follow the manufacturer's advice for battery
maintenance and replacement. Warning: performance may deteriorate due to battery wear. The typical
duration of continuous use that can be expected from the earmuff battery is 50 hours. Warning: Sound
output from the sound regeneration circuitry may exceed the external sound level. Failure to follow the
instructions may adversely affect the effectiveness of the earmuffs, resulting in hearing damage.
Storage:
Storage location, in original packaging, dry, clean, protected from light, UV and heat.
heat protected in the temperature range -10°to 55 °C, humidity max. 85%.
Storage period 5 years, from date of manufacture. Date of manufacture see product
or packaging. Make sure that during storage the headband is not stretched and the sealing cushions
are not compressed. In case of longer storage, the battery must be charged intermediately.
Useful life:
Useful life, 5 years from date of manufacture. Recommendation regular replacement of the sealing
cushions extends the useful life. Dispose of the product after expiry or immediately if it is damaged or
can no longer be cleaned.
User instruction:
1. Pull apart and put on hearing protection capsule (fig. 1)
2. Positioning the capsule by sliding it up or down at the temple ends. The ears must be completely
covered and sealed. (fig. 2)
3. Note right/left direction, the voice microphone must face forward to get good voice quality during
communication
4. Correct fit (fig. 3)
Cleaning, disinfection:
Do not use disinfectants, solvents or chemical substances for cleaning, this product may be adversely
affected by certain chemical substances. Further information should be requested from the
manufacturer. Clean with damp cloth with mild soapy water, allow to dry before reuse.
Do not immerse hearing protection in water!
Maintenance:
Replace sealing cushion, pull off old sealing cushion (Fig. 5a).
Position new sealing cushion, cushion vent downwards (Fig. 5b)
Press sealing cushion firmly all around (Fig. 5c)
Accessories:
Hygiene kit Art. No: 2599.972
Microphone covers Art. No: 259.2640
Comfort pad Art. No: 259.9978
Earmuff bag Art. No: 200.0002
Components:
Headband: Stainless steel /PVC/PUR-foam

Cup: ABS
Sealing cushion: PVC/PUR-foam
Absorptive faom: PE
Authorization:
The product mmets the harmonized standard EN 352-1:2020, EN 352-4, EN 352-6, EN 352-8, ANSI S-
3.19-1974, CSA Z94.2-02, AS/NZS 1270:2002 and complies with the PPE regulation (EU)2016/425
and 2014/53/EU, RED 2014/53/EU and FCC.
The applicable jurisdiction can be found in the Declaration of Conformity; this can be found at:
www.uvex-safety.com/ce
for UK: www.uvex-safety.co.uk/en/media/uk-declarations-of-conformity/
Bluetooth Licence:
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use
of such marks by UVEX ARBEITSSCHUTZ GMBH is under license. Other trademarks and trade names are
those of their respective owners.

Instruction manual for electronic functions:
See also: uvex aXess one - Quick Start Guide
Charge the battery:
Charge the battery before using it for the first time. The entire system is switched off during the
charging process. The battery is permanently installed and cannot be replaced. During the charging
process, the LED display lights up red; when fully charged, the LED display changes to green. Never
leave the uvex aXess one unattended during charging.
Bluetooth pairing:
Press and hold the button for 5 seconds until the LED status indicator flashes RED/BLUE and you
hear "power on". The automatic pairing mode starts and "pairing" sounds. The uvex aXess one
appears in the Bluetooth menu on the external device, now select and activate it, now "connected"
sounds. The hearing protector is now connected to the Bluetooth device.
Bluetooth pairing second device:
Um ein Zweites Gerät zu koppeln, ist einmalig folgender Schritt nötig, deaktivieren Sie Bluetooth am
erstem Gerät, er ertönt „disconnected“. Bluetooth am zweiten Gerät aktivieren, es erscheint die uvex
aXesss one am zweiten Gerät, diese nun auswählen und aktivieren. Nun kann am ersten Gerät wieder
Bluetooth aktiviert werden und auch hier die uvex aXess one auswählen. Nun sind beide Geräte mit
der uvex aXess one verbunden.
Bluetooth disconnect/delete connections:
Press and hold the key and the key together for 3 seconds. To clear the memory completely,
press and hold both keys for 5 seconds.
Automatic shutdown without pairing: 5min
Real Active Listening RAL:
The RAL function is a stand-alone function. To ensure that the ambient sounds are permanently
perceived, there is no automatic switch-off. Note, RAL always requires a switch-off by the user.
The RAL function is equipped with a level limiter that cuts off the maximum output level at 82dB. The
volume below 82dB can be adjusted in 5 steps. This allows a slight amplification for soft sounds.
Einschalten / Ausschalten: Taste (1) und (2) für 3 Sekunden gedrückt halten, es ertönt „RAL
on“ und die grüne Status LED leuchtet.
RAL leiser: Taste und zusammen einmal drücken, es ertönt ein Bestätigungston.
RAL lauter: Taste und zusammen einmal drücken, es ertönt ein Bestätigungston.

Switch on / switch off:
Press key (1) and (2) for 3 seconds, you will hear "RAL on" and the green status LED will light up.
RAL quieter: Press key and together once, a confirmation tone sounds.
RAL louder: Press key and together once, a confirmation tone sounds.
Phone mode:
Answer / end call: Press key
Reject call: Press and hold the key for 2 seconds
Call back last dialed number: Press key 2 times in quick succession
Adjust volume during call with louder with or quieter with
Audio streaming:
Titel Vorwärts/Rückwärts: Taste oder Taste für 2 Sekunden gedrückt halten
Switch on uvex aXess one, press and hold for 5 seconds. Start music playback on the external
device.
Play/pause: press key
Volume, louder/quieter: press key or key
Track forward/backward: press key and hold key for 2 seconds
Connection via AUX cable:
Connect the external device with the supplied AUX cable. Note the AUX function has priority and
disables the Bluetooth connection.

uvex aXess one: Weight: 364g Size Range: S/M/L
Tested according to European Standard EN 352-1:2020 SNR:31dB
Freq. Hz
63 125 250 500 1000 2000 4000 8000 H M L SNR
Mean att. dB
18.8
16.3
21.0
27.3
37.1
37.8
44.2
43.2
39.1
30.3
22.8
32.8
Std. dev. dB
2.9
2.5
1.7
2.5
2.3
2.9
4.2
4.4
2.3
1.7
1.9
1.7
APV
15.9
13.7
19.2
24.9
34.8
35.0
40.0
38.8
37
29
21
31
EN 352-4: Pegelabhängingkeit H=115 dB, M= 104dB, L= 87 dB
EN352-6: 82dBA Kriteriumspegel = -4,6dBV oder 587.2mV
Tested according to Australian Standard AS/NZS 1270:2002 SLC80: 27dB Class 5
Freq. Hz
125 250 500 1000 2000 4000 8000
Mean att. dB
14.8
16.3
23.5
33.1
34.3
41.4
40.1
Std. dev. dB
3.5
3.3
3.7
3.5
3.4
5.6
4.2
APV
11.3
13.0
19.8
29.6
30.9
35.8
35.9
Clamping force: 11.1N, 10.2N, 10.7N
Hearing protector class 5 tested to AS/NZS 1270. When selected, used and maintained as specified
in AS/NZS 1269, this protector may be used in noise up to 110dB(A) assuming an 85 dB(A) criterion. A
lower criterion may require a higher protector class.
Tested according to American Standard ANSI S-3.19-1974 NRR: 23dB CSA Class A
Freq. Hz
125 250 500 1000 2000 4000 8000
Mean att. dB
16.4
18.4
26.5
34.6
35.4
43.3
39.2
Std. dev. dB
3.0
2.6
2.8
3.5
3.5
3.6
4.4
Headband Force: lbs 2.5
Information required by E.P.A. (US)
The level of noise entering a person’s ear, when hearing protectors are worn as directed, is closely
approximated by the difference between the A-weighted environmental noise level and the NRR.
For example:
1. The environmental noise level as measured at the ear is 92 dBA.
2. The NRR is 29 decibels (dB).
3. The level of noise entering the ear is approximately equal to 63 dBA.
Caution: For noise environments dominated by frequencies below 500 Hz, the C-weighted
environmental noise level should be used. Improper fit of this device will reduce its effectiveness in
attenuating noise. Consult the enclosed instructions for proper fit. Although hearing protectors can be
recommended for protection against the harmful effects of impulsive noise, the Noise Reduction
Rating (NRR) is based on the attenuation of continuous noise and may not be an accurate indicator of
the protection attainable against impulsive noise such as gunfire. Constant or repetitive exposure to
impulsive noise may lead to serious injury, including temporary or permanent deafness. The Noise
Reduction Rating (NRR) calculated from the attenuation data is 29 dB. Earplugs must be fitted to
attenuate noise effectively. Refer to instructions.
FCC Compliance Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions:
This device may not cause harmful interference, and this device must accept any interference
received, including interference that my cause undesired operation.

Test Institute, Michael & Associates, Inc., 2766 W. College Ave Suite 1, State College, PA 16801
Notified body No. 2797: BSI Group The Netherlands B.V. Say Building, John M.
Keynesplein 9, 1066 EP, Amsterdam, Netherlands
Freq. - Frequency
Mean att. - Mean value of attenuation
Std. dev. - Standard deviation
APV - Assumed protective effect
SNR - Attenuation value according to single number rating
H - attenuation value at high frequencies
M - attenuation value at medium frequencies
L - attenuation value at low frequencies
Technical data:
Operating voltage: 5V DC via USB
Battery: 3.7V lithium polymer battery, 750mA
Charging time: 2.5 hours
Operating time: 50 hours
Bluetooth® 5.0
Profile support: A2DP, AVRCP, HSP,HFP
Waste management:
This product falls under the Waste Electrical and Electronic Equipment (WEEE) Directive 2012/19/EU
Do not dispose of with normal household waste. The rechargeable batteries must be disposed of in
accordance with national regulations. Proper disposal at an official recycling center.
CAUTION! Explosion hazard! Do not throw the product into a fire.

FCCCaution
Thisdevice complieswithpart15 oftheFCCRules. Operation issubjecttothe
followingtwoconditions:(1)Thisdevice maynotcauseharmfulinterference,and (2)
thisdevice mustacceptanyinterferencereceived, including interferencethatmay
causeundesired operation.
AnyChangesormodifications notexpresslyapprovedbythepartyresponsiblefor
compliance could void theuser's authorityto operatetheequipment.
Note: Thisequipmenthasbeentestedand foundtocomplywiththelimitsforaClass
Bdigitaldevice,pursuanttopart15 oftheFCCRules. Theselimitsare designedto
providereasonableprotection againstharmfulinterferenceinaresidentialinstallation.
Thisequipmentgeneratesusesand canradiateradiofrequencyenergyand, ifnot
installedand usedinaccordancewiththeinstructions, maycauseharmfulinterference
toradiocommunications. However,there isno guaranteethatinterference will not
occurinaparticular installation. Ifthisequipmentdoescauseharmfulinterferenceto
radioortelevision reception, whichcanbedeterminedbyturning theequipmentoff
and on, theuser isencouragedtotrytocorrecttheinterferencebyoneormore ofthe
followingmeasures:
-Reorientorrelocatethereceivingantenna.
-Increasetheseparation between theequipmentand receiver.
-Connecttheequipmentintoanoutleton acircuit differentfromthattowhichthe
receiver is connected.
-Consult thedealer oranexperienced radio/TVtechnician forhelp.
Thedevice has been evaluated to meetgeneralRF exposure requirement.Thedevice
can beused in portableexposure condition withoutrestriction.
