EUCHNER MGB2-I-BP Series User manual

EN
Operating Instructions
Safety Systems
MGB2-I-BP.-… / MGB2-I-BR.-…
From V1.0.0

Operating Instructions Safety Systems
MGB2-I-BP.-… / MGB2-I-BR.-…
2(translation of the original operating instructions) 2530674-02-03/21
Contents
1. About this document............................................................................................. 4
1.1. Scope............................................................................................................................................4
1.1.1. Notes on older product versions ......................................................................................4
1.2. Target group ..................................................................................................................................4
1.3. Key to symbols...............................................................................................................................4
1.4. Supplementary documents ..............................................................................................................5
2. Correct use .......................................................................................................... 6
2.1. Main differences, MGB2-BP and MGB2-BR.........................................................................................7
3. Description of the safety function .......................................................................... 7
4. Exclusion of liability and warranty ......................................................................... 7
5. General safety precautions ................................................................................... 8
6. Function............................................................................................................... 8
7. System overview................................................................................................... 9
7.1. Interlocking module MGB2-I…..........................................................................................................9
7.2. Handle module MGB2-H-…...............................................................................................................9
7.3. Escape release MGB-E-… (optional)................................................................................................10
7.4. Dimension drawing .......................................................................................................................11
7.4.1. Drilling pattern, overall system .......................................................................................12
7.5. Lockout mechanism......................................................................................................................13
7.6. Escape release (optional) ..............................................................................................................13
7.6.1. Preparing escape release ..............................................................................................14
8. Mounting............................................................................................................ 15
8.1. Replacing modules........................................................................................................................17
8.2. Mounting submodules ...................................................................................................................17
8.3. Replacing submodules ..................................................................................................................17
8.3.1. Replacing submodule with a submodule with a different function (changing conguration) ...18
8.3.2. Fitting and removing lenses and labels for controls and indicators ....................................18
8.4. Changing direction of connection ...................................................................................................19
9. Changing the door hinge position ........................................................................ 20
9.1. Changing the interlocking module to a different door hinge position..................................................20
9.2. Changing actuating direction of the handle module ..........................................................................20
10. Protection against environmental effects............................................................. 23
11. Controls and indicators....................................................................................... 23
12. Electrical connection .......................................................................................... 24
12.1. Using submodules ........................................................................................................................25
12.2. Notes about .........................................................................................................................25
12.3. Safety in case of faults..................................................................................................................25
12.4. Fuse protection for power supply...................................................................................................26
12.5. Requirements for connecting cables...............................................................................................26
12.6. Notes on cable laying....................................................................................................................27

3
2530674-02-03/21 (translation of the original operating instructions)
Operating Instructions Safety Systems
MGB2-I-BP.-… / MGB2-I-BR.-…
EN
12.7. Changing device conguration (using DIP switches) .........................................................................28
12.7.1. Changing system family (BR/BP switching)......................................................................28
12.8. Notes on operation with control systems ........................................................................................29
12.9. Terminal assignment and contact description..................................................................................30
12.10. Terminal assignment, submodule with plug connector M23 (X7) .......................................................31
12.11. Operation as separate device ........................................................................................................32
12.12. Information on operation in a BR switch chain .................................................................................33
12.12.1. System times ...............................................................................................................33
12.12.2. Wiring of a BR switch chain............................................................................................33
12.12.3. Number of devices in switch chains................................................................................33
12.12.4. Resetting in switch chains..............................................................................................33
13. Setup ................................................................................................................. 34
13.1. Teach-in operation (only for MGB2 unicode).....................................................................................34
13.2. Mechanical function test................................................................................................................34
13.3. Electrical function test...................................................................................................................35
14. System states..................................................................................................... 35
14.1. Key to symbols.............................................................................................................................35
14.2. System status table MGB2-BR .......................................................................................................36
14.3. System status table MGB2-BP........................................................................................................38
14.4. System status table (Slot LED).......................................................................................................40
15. Technical data .................................................................................................... 41
15.1. Radio frequency approvals.............................................................................................................42
15.2. Typical system times.....................................................................................................................43
16. Troubleshooting and assistance........................................................................... 44
16.1. Resetting errors ...........................................................................................................................44
16.2. Troubleshooting help on the Internet...............................................................................................44
16.3. Mounting help on the Internet.........................................................................................................44
16.4. Application examples ....................................................................................................................44
17. Service .............................................................................................................. 44
18. Inspection and service ........................................................................................ 45
19. Declaration of conformity ................................................................................... 46

Operating Instructions Safety Systems
MGB2-I-BP.-… / MGB2-I-BR.-…
4(translation of the original operating instructions) 2530674-02-03/21
1. About this document
1.1. Scope
These operating instructions are valid for all interlocking modules MGB2-I-BP.-…/MGB2-I-BR.-… These operating instructions,
the document Safety information and any enclosed data sheet form the complete user information for your device.
Series Version System families Product versions
MGB2 I (without guard locking) …-BP… From V1.0.0
…-BR…
1.1.1. Notes on older product versions
Products with lower product versions or without a version number are not described by these operating instructions. Please
contact our support team in this case.
1.2. Target group
Design engineers and installation planners for safety systems on machines, as well as setup and servicing staff possessing
special expertise in handling safety components as well as expertise in the installation, setup, programming and diagnostics
of programmable logic controllers (PLCs).
1.3. Key to symbols
Symbol/depiction Meaning
BP
This section applies to operation as MGB2-BP
BR
This section applies to operation as MGB2-BR
DIP
OFF
ON
In this section, attention must be paid to the DIP switch settings
Printed document
Internet
www Document is available for download at www.euchner.com
DANGER
WARNING
CAUTION
Safety precautions
Danger of death or severe injuries
Warning about possible injuries
Caution Slight injuries possible
NOTICE
Important!
Notice about possible device damage
Important information
Tip Useful information

5
2530674-02-03/21 (translation of the original operating instructions)
Operating Instructions Safety Systems
MGB2-I-BP.-… / MGB2-I-BR.-…
EN
1.4. Supplementary documents
The overall documentation for this device consists of the following documents:
Document title
(document number) Contents
Safety information
(2525460) Basic safety information
Operating instructions
(2530674) (this document)
Internet
www
Possibly enclosed data
sheets Item-specic information about deviations or additions
Important!
Always read all documents to gain a complete overview of safe installation, setup and use of the
device. The documents can be downloaded from www.euchner.com. For this purpose enter the doc.
no. in the search box.

Operating Instructions Safety Systems
MGB2-I-BP.-… / MGB2-I-BR.-…
6(translation of the original operating instructions) 2530674-02-03/21
2. Correct use
The following applies to MGB2-I…:
The system comprises at least one interlocking module MGB2-I… and one handle module MGB2-H…
The safety system MGB2-I… is an interlocking device without guard locking (type 4). Devices with unicode evaluation possess
a high coding level, devices with multicode evaluation possess a low coding level.
In combination with a movable guard and the machine control, this safety component prevents dangerous machine functions
from occurring while the guard is open. A stop command is triggered if the guard is opened during the dangerous machine
function.
This means:
ÌStarting commands that cause a dangerous machine function must become active only when the guard is closed.
ÌOpening the guard triggers a stop command.
ÌClosing a guard must not cause automatic starting of a dangerous machine function. A separate start command must
be issued. For exceptions, refer to ENISO12100 or relevant C-standards.
Before the device is used, a risk assessment must be performed on the machine, e.g. in accordance with the following
standards:
ÌENISO13849-1
ÌENISO12100
ÌENIEC62061
Correct use includes observing the relevant requirements for installation and operation, particularly based on the following
standards:
ÌENISO13849-1
ÌENISO14119
ÌENIEC60204-1
The safety system MGB2 may be combined only with the intended modules in the MGB2 system family.
On the modication of system components, EUCHNER provides no warranty for function.
BR
Interlocking modules with the conguration MGB2-BR can be integrated into a BR switch chain.
Connection of several devices in a BR switch chain is permitted only using devices intended for series connection
in a BR switch chain. Check the operating instructions for the related device.
Important!
ÌThe user is responsible for the proper integration of the device into a safe overall system. For this
purpose, the overall system must be validated, e.g. in accordance with ENISO13849-2.
ÌCorrect use requires observing the permissible operating parameters (see chapter 15. Technical
data on page 41).
ÌIf a data sheet is included with the product, the information on the data sheet applies.
Table 1: Possible combinations for MGB2 components
Evaluation unit
Handle module Submodules Submodules
MGB2-H-…
from V1.0.0
MSM-.-P-…
MSM-.-N-…
MSM-.-K-…
MSM-.-R-…
MGB2…BR/BP
From V1.0.0 –
Key to symbols Combination possible
– Combination not possible

7
2530674-02-03/21 (translation of the original operating instructions)
Operating Instructions Safety Systems
MGB2-I-BP.-… / MGB2-I-BR.-…
EN
2.1. Main differences, MGB2-BP and MGB2-BR
System family Symbol Use
MGB2-BP
BP
Optimized for operation in safe control systems.
If series connection is not necessary, the number of terminals required can be reduced using this system family.
MGB2-BR
BR
Linking of several guards on one shutdown path. As a consequence, several safety doors can be very simply polled using one evalua-
tion unit or two control system inputs.
3. Description of the safety function
Devices from this series feature the following safety functions:
Monitoring of the guard position
(interlocking device according to ENISO14119)
ÌSafety function: The safety outputs are switched off when the guard is open (see chapter 6. Function on page 8).
ÌSafety characteristics: category, Performance Level, PFHD (see chapter 15. Technical data on page 41).
The following applies to devices with emergency stop:
Emergency stop
(emergency stop device according to ENISO13850)
ÌSafety function: emergency stop function
ÌSafety characteristics: B10D value (see chapter 15. Technical data on page 41)
4. Exclusion of liability and warranty
In case of failure to comply with the conditions for correct use stated above, or if the safety regulations are not followed,
or if any servicing is not performed as required, liability will be excluded and the warranty void.

Operating Instructions Safety Systems
MGB2-I-BP.-… / MGB2-I-BR.-…
8(translation of the original operating instructions) 2530674-02-03/21
5. General safety precautions
Safety switches fulll personnel protection functions. Incorrect installation or tampering can lead to fatal injuries to personnel.
Check the safe function of the safeguard and, if necessary, other safety functions particularly
Ìafter any setup work
Ìafter the replacement of a system component relevant for safety
Ìafter an extended period without use
Ìafter every fault
Ìafter any change to the DIP switch settings
Independent of these checks, the safe function of the safeguard should be checked at suitable intervals as part of the
maintenance schedule.
WARNING
Danger to life due to improper installation or due to bypassing (tampering). Safety components fulll
a personnel protection function.
ÌSafety components must not be bypassed, turned away, removed or otherwise rendered ineffec-
tive. On this topic pay attention in particular to the measures for reducing the possibility of bypass-
ing according to ENISO14119:2013, section 7.
ÌThe switching operation is allowed to be triggered only by the intended handle module MGB2-H…
that is positively fastened to the guard.
ÌPrevent bypassing by means of replacement actuators (only for multicode evaluation). For this
purpose, restrict access to actuators and to keys for releases, for example.
ÌMounting, electrical connection and setup only by authorized personnel possessing the following
knowledge:
- specialist knowledge in handling safety components
- knowledge about the applicable EMC regulations
- knowledge about the applicable regulations on operational safety and accident prevention.
Important!
Prior to use, read the operating instructions and keep these in a safe place. Ensure the operating
instructions are always available during mounting, setup and servicing. For this reason you should
archive a printed copy of the operating instructions. You can download the operating instructions from
www.euchner.com.
6. Function
Together with a handle module, the interlocking module makes it possible to interlock movable guards. The combination
also serves as a mechanical door stop at the same time.
The following switch-on condition applies to the safety outputs FO1A and FO1B (also see chapters 14.2. System status table
MGB2-BR on page 36 and 14.3. System status table MGB2-BP on page 38):
ÌGuard closed
ÌBolt tongue inserted into the interlocking module
The interlocking module detects the position of the guard and the position of the bolt tongue. The bolt tongue in the handle
module is moved into and out of the interlocking module by actuating the door handle.

9
2530674-02-03/21 (translation of the original operating instructions)
Operating Instructions Safety Systems
MGB2-I-BP.-… / MGB2-I-BR.-…
EN
7. System overview
Key:
1Interlocking module (MGB2-I…)
2Escape release, optional (MGB-E-…)
3Handle module (MGB2-H…)
1 2
3
Fig. 1: Overall system
7.1. Interlocking module MGB2-I…
Key:
1Depending on version:
cable entry M20x1.5 or plug connec-
tor X7
2Module function LED indicators
3LED indicator for submodule in
SLOT1
4Submodule in SLOT1
(conguration example)
5Auxiliary marking for correct align-
ment in relation to the handle module
6Terminals (X1 - X4)
7Internal reset
8Cover, terminals X5 and X6
Notice:
Depending on version, additional controls
and indicators may be integrated into
the cover and a mounting plate can be
included.
See enclosed data sheet.








Fig. 2: Interlocking module MGB2-I…
7.2. Handle module MGB2-H-…
1
2
3
4
5
6
Key:
1Door handle
2Fold-out lockout mechanism
3Automatically extending lockout mechanism (optional)
4Auxiliary markings for max. permissible mounting distance
5Bolt tongue
6Locking bolt for handle adjustment
Fig. 3: Handle module MGB2-H-…

Operating Instructions Safety Systems
MGB2-I-BP.-… / MGB2-I-BR.-…
10 (translation of the original operating instructions) 2530674-02-03/21
7.3. Escape release MGB-E-… (optional)
1 2 3 4
Key:
1Door handle
2Housing
3Actuation axis 8 x 8 mm
(different lengths available)
4Protective sleeve
Notice:
Depending on version, a mounting plate can be included.
See enclosed data sheet.
Fig. 4: Escape release MGB-E-…

11
2530674-02-03/21 (translation of the original operating instructions)
Operating Instructions Safety Systems
MGB2-I-BP.-… / MGB2-I-BR.-…
EN
7.4. Dimension drawing
40
15
40
155
4
130
114
114,2 110,59
62,322,2
40
130
63
52,5
155
4
42
115,5
(289)
Fig. 5: Dimension drawing of MGB2 mounted, without optional mounting plates

Operating Instructions Safety Systems
MGB2-I-BP.-… / MGB2-I-BR.-…
12 (translation of the original operating instructions) 2530674-02-03/21
7.4.1. Drilling pattern, overall system
92,5
(10,75)
114
155
4
±4
15
6,3
25
16
MGB2-I/L MGB2-H
73,5
130
(25)
16,515
114
89,4
6,3 (12,3)
16
Fig. 6: Drilling pattern, overall system

13
2530674-02-03/21 (translation of the original operating instructions)
Operating Instructions Safety Systems
MGB2-I-BP.-… / MGB2-I-BR.-…
EN
7.5. Lockout mechanism
If the lockout mechanism is pivoted out, the bolt tongue cannot be extended. The lockout mechanism can be secured with
padlocks (see Fig. 7). This is intended to prevent people from being locked in unintentionally. The lockout mechanism does
not fulll any safety function.
¨To pivot out, press the grooved part (possible only with bolt tongue retracted).
2
1
Key:
1Hinged lockout mechanism
Padlock ∅min. 2mm, ∅max. 10 mm
2Automatically extending lockout mechanism (optional)
Padlock ∅min. 6mm, ∅max. 10 mm
Notice:
You can t up to three locks ∅8mm per lockout mechanism.
Fig. 7: Lockout mechanism secured with padlock
7.6. Escape release (optional)
The escape release is used to open a guard from the inside without tools.
DIP
OFF
ON When release monitoring is active, the system enters into a latching fault when the escape release is actuated.
See System status table, signal sequence incorrect status (DIA red, Lock ashes 1 time).
The system might not enter into a latching fault if the escape release is actuated very slowly.
Important!
ÌIt must be possible to actuate the escape release manually from inside the protected area without
tools.
ÌIt must not be possible to reach the escape release from the outside.
ÌThe bolt tongue must not be under tensile stress during manual release.
ÌThe escape release meets the requirements of Category B according to ENISO13849-1:2015.
ÌThe correct function must be checked at regular intervals.
ÌObserve the notes on any enclosed data sheets.
ÌFit escape release such that operation, inspection and service are possible.
ÌThe actuation axis for the escape release must be inserted min. 9 mm into the handle module. Note the information on
the different prole widths in chapter 7.6.1. Preparing escape release on page 14.
ÌAdjust escape release axis at right angles to the handle module. See Fig. 9.

Operating Instructions Safety Systems
MGB2-I-BP.-… / MGB2-I-BR.-…
14 (translation of the original operating instructions) 2530674-02-03/21
7.6.1. Preparing escape release
Notice: Various escape releases with different axis lengths are available, as well as mounting plates and door handles/door
knobs. You will nd further information at www.euchner.com.
Prole width Length required for actuation
axis
Which EUCHNERparts are required? Necessary work steps
Without
mounting
plates
With mounting
plates
(4 mm each)
D D+9 D+17
30 mm 39 mm 47 mm Standard escape release
with 107 mm axis
(order no. 100465)
Shorten to required length
40 mm 49 mm 57 mm Standard escape release
with 107 mm axis
(order no. 100465)
If necessary,
extended actuation axis (order no. 106761)
Without mounting plates:
none
With mounting plates:
Use extended actuation axis and protective sleeve and
shorten to required length
45 mm 54 mm 62 mm Standard escape release
with 107 mm axis
(order no. 100465)
and
extended actuation axis (order no. 106761)
Use extended actuation axis and protective sleeve and
shorten to required length
50 mm 59 mm 67 mm Standard escape release
with 107 mm axis
(order no. 100465)
and
extended actuation axis (order no. 106761)
Use extended actuation axis and protective sleeve and
shorten to required length
55,5
M4
250
182
D -1
D + 10,25
±1,25
D
(11,5) 55,5
Example without mounting plates:
Escape release
Handle module
Actuation axis Protective sleeve
(+4 mm per mounting plate)
(+4 mm per mounting plate)
1Insert actuation axis. The snap ring Amust be in contact with the escape release B.
2Fit door handle.
3Tighten xing screw to 2Nm and push in cap.
4Fit protective sleeve.
1
3
2
4
A
B
Fig. 8: Preparing escape release

15
2530674-02-03/21 (translation of the original operating instructions)
Operating Instructions Safety Systems
MGB2-I-BP.-… / MGB2-I-BR.-…
EN
8. Mounting
WARNING
Mounting must be performed only by authorized personnel.
NOTICE
Risk of damage to equipment and malfunctions as a result of incorrect installation.
Observe ENISO14119:2013, sections 5.2 and 5.3, for information about mounting the safety switch
and the actuator.
With two-leaf hinged doors, one of the two door leaves must also be latched mechanically.
Use a rod latch (Item) or a double-door lock (Bosch Rexroth) for this purpose, for example.
Important!
ÌIn case of ush installation, the operating distances change as a function of the installation depth
and the guard material.
Interlocking
module Handle module
Interlocking
module Handle module
Surface mounting
Flush installation
Actuating range
Actuating range
Tip!
ÌYou will nd an animation on the mounting process at www.euchner.com.
ÌThe pushbuttons and indicators can be customized using replaceable color covers and labels.
For mounting steps, see Fig. 9 and Fig. 12 to Fig. 21.
Install system so that inspection and service are possible.

Operating Instructions Safety Systems
MGB2-I-BP.-… / MGB2-I-BR.-…
16 (translation of the original operating instructions) 2530674-02-03/21
M6
T10
Fig. 9: Installation example for door hinged on the right (general view)

17
2530674-02-03/21 (translation of the original operating instructions)
Operating Instructions Safety Systems
MGB2-I-BP.-… / MGB2-I-BR.-…
EN
8.1. Replacing modules
CAUTION
Risk of damage to equipment or malfunction as a result of uncontrolled machine stop.
ÌThe communication within the system is interrupted by the replacement of a module. If a process
is running, this situation can result in an uncontrolled stop and damage to the installation or the
product. Before replacement, make sure the installation is in a suitable operating status.
An interlocking module with the BP conguration can be replaced only in combination with an overall system restart. On
the disconnection of the module connection, the system enters into a fault state. The related module and all downstream
modules remain inactive until the overall system is restarted (fault state).
Interlocking modules with the conguration BR are hot pluggable. It is therefore not necessary to restart the overall system.
8.2. Mounting submodules
CAUTION
Risk of damage to equipment or malfunction as a result of incorrect connection or a conguration
change.
ÌOnly submodules of connection types P, K and N can be used. Check the compatibility before in-
stallation. For information on the related connection type of a submodule, refer to the data sheet
for the related submodule. This is included with each submodule.
ÌPay attention to the alignment of the submodule. See marking (a) in Fig. 10: Mounting submodule.
Submodules can also be installed rotated by 180°. The marking (a) always indicates the rst posi-
tion to be equipped. This is the emergency stop S1 position in the example below.
ÌMake sure the pins on the submodule slide straight into the guide. Tighten the cover screws to 0.5
Nm.
ÌIf you use a submodule, pay attention to the correct alignment of the modules in relation to the
labeling elds on the connection module. Incorrect assignments can cause serious malfunctions in
your installation.
ÌMake sure no foreign bodies, e.g. swarf or wires, enter the open submodule slots. These can
cause short circuits or contact problems.
ÌAvoid touching the contacts on the underside of the submodule. Risk of ESD damage and contact
problems due to soiling.
ÌUnused submodule slots must be tted with a cover (e.g. order number 126372).
Pos. 1
Pos. 2
Pos.
3
a
Fig. 10: Mounting submodule

Operating Instructions Safety Systems
MGB2-I-BP.-… / MGB2-I-BR.-…
18 (translation of the original operating instructions) 2530674-02-03/21
8.3. Replacing submodules
CAUTION
ÌThe communication between submodule and interlocking module is interrupted by the replacement
of a submodule. The submodule ceases to function. The function of the interlocking module, e.g.
the safety outputs FO1A / FO1B, is not affected. If a process is running, the removal/replacement
of a submodule can result in an uncontrolled stop and damage to the installation or the product.
Before replacement, make sure the installation is in a suitable operating status.
NOTICE
Pay attention to the information on the replacement of a submodule in the operating instructions for
the related module. Correct function must be tested after replacement before the system enters
normal operation again.
The replacement of submodules MSM while in operation is also possible (pay attention to safety note above). As soon as
the system detects a compatible submodule, the submodule is ready for operation.
If an incompatible submodule is installed, the Slot1 LED illuminates red.
8.3.1. Replacing submodule with a submodule with a different function (changing conguration)
The use of a different submodule will change the function and as a result the terminal assignment (see data sheet for the
submodule). Take into account the changes in your wiring and control system.
8.3.2. Fitting and removing lenses and labels for controls and indicators
1 2
23
90°
Click!
1
Fitting
Removing
Lens

19
2530674-02-03/21 (translation of the original operating instructions)
Operating Instructions Safety Systems
MGB2-I-BP.-… / MGB2-I-BR.-…
EN
8.4. Changing direction of connection
CAUTION
Risk of damage to equipment or malfunction as a result of uncontrolled machine stop.
ÌThe direction of connection can be changed by removing the covers and mounting rotated by
180°.
ÌThe communication within the system is interrupted if the internal wiring is changed. If a process is
running, this situation can result in an uncontrolled stop and damage to the installation or the prod-
uct. Before replacement, make sure the installation is in a suitable operating status.
Fig. 11: Changing direction of connection

Operating Instructions Safety Systems
MGB2-I-BP.-… / MGB2-I-BR.-…
20 (translation of the original operating instructions) 2530674-02-03/21
9. Changing the door hinge position
9.1. Changing the interlocking module to a different door hinge position
To change the interlocking module for doors with a different door hinge position, the module only needs to be rotated by
180°. Submodules installed in the module can also be rotated by 180° (see section 8.1. Replacing modules on page 17).
9.2. Changing actuating direction of the handle module
(here: from right to left)
Important!
It is possible to make this change only when the bolt tongue is not extended and an escape release
is not yet mounted.
In the delivery state, the handle module is set either for doors hinged on the right or for doors hinged on the left.
Based on the example of a handle module for doors hinged on the right this means:
ÌThe guard opens by pressing down the door handle.
ÌThe system is mounted the other way up for doors hinged on the left. In other words, the guard opens by pressing up
the door handle (see Fig. 12). For this reason the actuating direction of the door handle must be changed (see Fig. 12
to Fig. 21).
(Similarly on handle modules for doors hinged on the left)
CLOSED
OPEN
1
1Press door handle up.
Fig. 12: Changing actuating direction, step 1
3
2
2Unscrew locking screws.
3Push cover aside.
Fig. 13: Changing actuating direction, steps 2and 3
