V-fit HG1 Manual

Assembly & User Manual
Herculean Home Gym Trainers
HG1 & HG2

Contents
Section Page
General Information . . . . . . 4
Before you start . . . . . . . . . 5
Safety . . . . . . . . . . . . . . . . . 6
Exercise Information . . . . . . 7
Assembly . . . . . . . . . . . . . . 14

General Information
Page 4 Herculean Home Gym Trainer
Quality
This V-fit exercise product has been designed and
manufactured to comply with the latest (BS EN
957) British and European Safety Standards.
Questions
Should you encounter any difficulty with the
assembly, operation or use of your V-fit exercise
product or if you think that you may have parts
missing, please DO NOT return it to your retailer
but contact us first for help and advice, asking for
CUSTOMER SUPPORT, by any of the following
means.
Tel:- 0871 222 0881 or
Fax:- 01535 637722 or
Email:- [e-mail]
CUSTOMER SUPPORT is open from 9.00am to
5.00pm from Monday to Friday
Beny Sports Co. UK Ltd.
Queries
If you do have any queries, please ensure that
you have the following information ready for our
Customer Support Staff:
YOUR NAME
YOUR ADDRESS
YOUR PHONE NUMBER
PRODUCT MAKE OR BRAND
PRODUCT MODEL
PRODUCT SERIAL NUMBER
DATE OF PURCHASE
NAME OF RETAILER
PART NUMBERS REQUIRED
Guarantee
Beny Sports Co. UK Ltd. guaranteeÕs its V-fit
product range for DOMESTIC USE only for a
period of 2 years from certified date of purchase.
During this period we have the right to: -
a). provide parts for the purchaser to effect repair.
b). repair the product returned (at the purchaserÕs
cost) to our warehouse.
c). replace the product if it is deemed economical
to do so.
This guarantee applies to the original purchaser
only and is not transferable.
This guarantee does not cover wear and tear on
upholstery or consumables.
This guarantee does not cover abuse or defects
caused by storage or use outside those intended.
If you need to advise us of a defect with your
product, we may ask for proof of purchase. To
enable us to service your requirement for
replacement parts, you must return the enclosed
Guarantee Registration Card within 14 days of
purchase. Failure to do so may result in any claim
for replacement parts or repairs being refused.
This does not affect your statutory rights as a
consumer.
Customer Support
Tel:- 0871 222 0881 or
Fax:- 01535 637722 or
Email:- [e-mail]
CUSTOMER SUPPORT is open from 9.00am to
5.00pm from Monday to Friday
Beny Sports Co. UK Ltd.
Unit 8, Riparian Way,
The Crossings, Cross Hills
West Yorkshire.
BD20 7BW
Unit 8, Riparian Way,
The Crossings, Cross Hills
West Yorkshire.
BD20 7BW

Before You Start
Page 5Herculean Home Gym Trainer
Tools
All V-fit products are supplied with basic tools, which will enable you to successfully assemble your
product. However, you may find it beneficial to have a soft-headed hammer and perhaps an adjustable
spanner handy as this may help.
Prepare the Work Area
It is important that you assemble your product in a clean, clear, uncluttered area. This will enable you to
move around the product while you are fitting components and will reduce the possibility of injury
during assembly.
Work with a Friend
You may find it quicker, safer and easier to assemble this product with the help of a friend as some of
the components may be large, heavy or awkward to handle alone.
Open the Carton.
Carefully open the carton that contains your product, taking note of the warnings printed on the carton
to ensure that the risk of injury is reduced. Be aware of sharp staples that may be used to fasten the
flaps as these may cause injury. Be sure to open the carton the right way up, as this will be the easiest
and safest way to remove all the components.
Unpack the Components
Carefully unpack each component, checking against the parts list that you have all the necessary parts
to complete the assembly of your product.
Please note that some of the parts may be pre-fitted to major components, so please check carefully
before contacting our CUSTOMER SUPPORT team.
In any event, please do not return the product to your retailer before contacting us first.

Safety
Page 6 Herculean Home Gym Trainer
Before you undertake any programme of exercise that will increase cardiovascular activity please be
sure to consult with your doctor. Frequent strenuous exercise should be approved your doctor and
proper use of your V-fit product is essential. Please read this manual carefully before commencing
assembly of your product or starting to exercise.
• Please keep all children away from exercise products when in use. Do not allow children to climb or
play on them when they are not in use.
• For your own safety, always ensure that there is at least 1 Metre of free space in all directions
around your product while you are exercising.
• Regularly check to see that all nuts, bolts and fittings are securely tightened. Periodically checking
all moving parts for obvious signs of wear or damage.
• Clean only with a damp cloth, do not use solvent cleaners. If you are in any doubt, do not use your
V-fit product, but contact CUSTOMER SUPPORT by any of the means listed on the
opposite page.
• Before use, always ensure that your V-fit product is positioned on a solid, flat surface. If necessary,
use a rubber mat underneath to reduce the possibility of slipping in use.
• Always wear appropriate clothing and footwear such as training shoes when exercising. Do not wear
loose clothing that could become caught or trapped during exercise.
Storage and Use
Your V-fit product is intended for use in clean dry conditions. You should avoid storage in excessively
cold or damp places as this may lead to corrosion and other related problems that are outside our
control.
Weight Limit
Your V-fit product is suitable for users weighing:
275LBS / 19.6 Stones / 125KG or less.
Conformity
This V-fit product conforms to:
(BS EN 957) - PARTS 1 and 2Class (H) - HOME USE - Class (C).
It is NOT suitable for therapeutic purposes.

Page 7Herculean Home Gym Trainer
Exercising Information
Beginning
How you begin to exercise will vary from person to person. If you
have not exercised for a long period of time, have been inactive for a
while, or are severely overweight you MUST start slowly, increasing
your exercise time gradually, by perhaps only a few minutes for each
session per week.
Combine a carefully structured nutritious diet with a simple but
effective exercise routine and this can help make you feel better, look
better and will almost certainly enable you to enjoy life more.
Aerobic Fitness
Aerobic exercise is simply defined as any sustained activity that
increases the supply of oxygen to your muscles via the blood pumped
by your heart. With regular exercise, your cardiovascular system will
become stronger and more efficient. Your recovery rate i.e. the time
taken for your heart to reach its normal resting level, will also
decrease.
Initially you may only be able to exercise for a few minutes each day.
Do not hesitate to breathe through your mouth should you need more
oxygen. Use the "talk test". If you cannot carry on a conversation
while exercising, you are working too hard! However, aerobic fitness
will be gradually built up with regular exercise, over the next six to
eight weeks.
Do not be discouraged if it takes longer than this to begin to feel less
lethargic, everyone is different and some will achieve their targets
quicker than others. Work at your own, comfortable pace and the
results will come. The better your aerobic fitness the harder you will
have to work to stay in your target zone.

Exercising Information
Page 8 Herculean Home Gym Trainer
Warm Up
A successful exercise programme consists of three parts, Warm Up, Aerobic Exercise and Cool Down.
Never start a training session without warming up. Never finish one without cooling down correctly.
Perform between five and ten minutes of stretching before starting your workout to prevent muscle
strains, pulls and cramps.
Aerobic Exercise Session
Those new to exercise should exercise no more than every other day to start with.
As your fitness level increases, increase this to 2 in every 3 days.
When you are comfortable with your routine, exercise for 6 days per week. Always take at least one day
off per week.
Exercising in your Target Zone
To ensure that your heart is working in its exercise target zone, you need to be able to take your pulse.
If you do not have a pulse monitor (either from the product you are using or a proprietary independent
unit) you will need to locate the pulse in your carotid artery. This is situated in the side of the neck and
can be felt by using the index and middle fingers. Simply count the number of beats you feel in 10
seconds and then multiply by six to get your pulse rate. This should be taken before you start to
exercise for easy reference.
People who have a greater aerobic fitness, have a lower resting pulse level and will also be able to
exercise with a higher pulse level.
Target Zone
To determine your target zone, see the chart opposite. If you are new to exercise and by definition unfit,
refer to the left column. If you exercise regularly and have good aerobic fitness, refer to the right
column.
USERS
AGE
(Years)
20-24
25-29
30-34
35-39
40-44
45-49
50-54
55-59
60 and over
UNCONDITIONED
TARGET ZONE - A
(Beats per Minute)
145 - 165
140 - 160
135 - 155
130 - 150
125 - 145
120 - 140
115 - 135
110 - 130
105 - 125
CONDITIONED
TARGET ZONE - B
(Beats per Minute)
155 - 175
150 - 170
145 - 165
140 - 160
135 - 155
130 - 150
125 - 145
120 - 140
115 - 135

Page 9Herculean Home Gym Trainer
Exercising Information
Hamstring Stretch
Sit on the floor with your right leg extended and
place your left foot flat against the right inner
thigh. Stretch forward toward the right foot and
hold for 10 seconds. Relax and then repeat with
the left leg extended.
Repeat 2 - 3 times.
Cool Down
To decrease fatigue and muscle soreness, you should also cool down by walking at a slow relaxed pace
for a minute or so, to allow your heart rate to return to normal.
Warm Up and Cool Down Exercises
Hold each stretch for a minimum of ten seconds and then relax. Repeat each stretch two or three
times. Do this before your Aerobic Exercise session and also after you have finished.
Head Roll
Rotate your head to the right for one count,
feeling a slight pull on the left side of your neck.
Next, rotate your head back for one count,
stretching your chin. Then rotate your head to the
left for one count, feeling a slight pull on the right
side of your neck. Lastly, drop your head to your
chest for one count. Repeat 2 to 3 times.
Toe Touch
Slowly bend forward from your waist, letting your
back and shoulders relax as you lower your trunk.
Gently stretch down as far as is comfortable and
hold for 10 seconds.
Shoulder Lift
Rotate and lift your right shoulder up towards
your ear for one count. Relax then repeat for the
left shoulder.
Repeat 3 - 4 times.
Calf / Achilles Stretch
Turn towards the wall and place both hands on it.
Support yourself with one leg while the other is
placed behind you with the sole flat on the floor.
Bend the front leg and lean towards the wall,
keeping the rear leg straight so that the calf and
Achilles tendon are stretched hold for 5 seconds.
Repeat with the other leg.
Repeat 2 - 3 times.
Side Stretch
Open both arms to the side and gently lift them
above your head. Reach your right arm as high as
you can for one count, gently stretching the
muscles of the stomach and lower back. Repeat
the action with your left arm.
Repeat 3 - 4 times.
Inner Thigh Stretch
Sit on the floor and pull your legs toward your
groin, the soles of your feet together. Hold your
back straight and lean forward over your feet.
Tighten the thigh muscles and hold for 5
seconds. Release and repeat 3 - 4 times.

Exercising Information
Page 10 Herculean Home Gym Trainer
Basic Aerobic Training Programme
For your basic Aerobic Exercise routine we suggest that you try the
following. Remember, breathe correctly, exercise at your own pace
and do not over-train as injury may result.
Week 1 & 2
Warm Up 5 - 10 Minutes
Cool Down 5 Minutes
Week 3 & 4
Warm Up 5 - 10 Minutes
Cool Down 5 Minutes
Week 5 & 6
Warm Up 5 - 10 Minutes
Cool Down 5 Minutes
Week 7 & 8
Warm Up 5 - 10 Minutes
Cool Down 5 Minutes
Week 9 & beyond
Warm Up 5 - 10 Minutes
Cool Down 5 Minutes
Exercise 4 minutes at 'A'
Rest 1 minute
Exercise 2 minutes at 'A'
Exercise slowly 1 minute
Exercise 5 minutes at 'A'
Rest 1 minute
Exercise 3 minutes at 'A'
Exercise slowly 2 minutes
Exercise 6 minutes at 'A'
Rest 1 minute
Exercise 4 minutes at 'A'
Exercise slowly 3 minute
Exercise 5 minutes at 'A'
Exercise 3 minutes at 'B'
Exercise 2 minutes at 'A'
Exercise slowly 1 minute
Exercise 4 minutes at 'A'
Exercise slowly 3 minutes
Exercise 5 minutes at 'A'
Exercise 3 minutes at 'B'
Exercise 2 minutes at 'A'
Exercise slowly 1 minute
Repeat entire cycle 2 or 3
times
This is only a suggested programme and may not suit every
individual’s needs.

Page 11Herculean Home Gym Trainer
Exercising Information
GETTING STARTED
You will often read about terms referring to exercise that may be confusing. Below are some of the
definitions that are regularly used.
Repetition - Commonly referred to as 'REPS'.
This is a complete movement from start to finish.
Set - This is a complete number of consecutive repetitions.
i.e. 1 set of 10 reps.
Speed of Motion - This is the relative speed of movement for each rep.
Fast is considered as 1 rep / second. Medium is 1 rep / 2 seconds. Slow is 1 rep /
4 seconds.
Intensity - How 'hard' the exercise feels.
Low Intensity = easy exercise. High Intensity = hard exercise.
TRAINING PROGRAMMES
You will achieve fast results, gaining a trimmer, fitter body if you follow these general rules.
• Exercise regularly - do not skip workouts as consistency is the first key to success.
• Do not be afraid perspire a little. This is a sign that you are working your body hard enough to give
fast results. You will find 'hard' exercise enjoyable.
• Set yourself realistic goals. Do not be over-ambitious. Plan your workouts to concentrate on
specific body areas. Start slowly and gradually increase the intensity, reps and sets.
BEGINNERS PROGRAMME
This is a short suggested programme which we suggest you use for no more than 3 weeks, to be
ideally performed every other day, but certainly not more than 4 times during the week.
This suggested routine is specifically for beginners or those who have not exercised for a considerable
time. The programme is designed to provide general improvement in muscle tone, strength, flexibility
and co-ordination.
As a beginner, you should start with no more than 2 sets of 6 exercises for the following reps on each
of the Gym’s training stations.
10 REPS - BENCH PRESS followed by LAT PULLDOWNS
5 REPS - PEC DEC
10 REPS - SHOULDER PRESS
10 REPS - LEG EXTENSIONS followed by LEG CURLS
• Your rest interval between each set of reps should be 1 minute.
• You should perform 2 SETS of each exercise.
• Your exercise pace should be SLOW to MEDIUM.
• The resistance (weight) settings should be in positions 1 - 3.
• This exercise programme should take you approximately 20 minutes.
• Follow this exercise programme with 5 minutes of proper cool down exercises.

Exercising Information
Page 12 Herculean Home Gym Trainer
INTERMEDIATE EXERCISE
This is a slightly longer programme which we suggest you use for the next 6 – 8 weeks, to be ideally
performed not more than 5 times during the week.
This suggested routine is specifically for intermediate users or those that are familiar with exercise
routines. The programme is designed to increase muscle definition, build strength, aid flexibility and co-
ordination.
The increase in exercise intensity and speed of repetitions is key to your success at this stage.
For intermediate exercise we recommend 3 - 4 sets of 8 exercises for the following reps on each of the
Gym’s training stations.
15 REPS - BENCH PRESS followed by LAT PULLDOWNS
10 REPS - PEC DEC
15 REPS - SHOULDER PRESS
15 REPS - LEG CURLS
15 REPS - LEG EXTENSIONS followed by ARM CURLS
• Your rest interval between each set of reps should be 1 minute.
• You should perform 3 - 4 SETS of each exercise.
• Your exercise pace should be MEDIUM to FAST.
• The resistance (weight) settings should be in positions 3 - 6.
• This exercise programme should take you approximately 35 - 40 minutes.
• Follow this exercise programme with 5 minutes of proper cool down exercises.
ADVANCED TRAINING
This is an open-ended programme, ideally performed not more than 4 times during the week, preferably
on alternate days.
This suggested routine is specifically for advanced users or those that are familiar with exercise
routines. The programme is designed to increase muscle mass and build strength.
The increase in exercise intensity, resistance levels and speed of repetitions is key to your on going
success.
For advanced training we recommend 4 sets of the 9 exercises for the following reps on each of the
Gym’s training stations. However at this stage you may want to concentrate on specific body parts, so
as you are now fully familiar with the workings of your Gym you should be able to structure an exercise
programme to suit your own individual needs. Any specific advice should be sought through specialist
books.
20 REPS - BENCH PRESS followed by LAT PULLDOWNS
15 REPS - PEC DEC
15 REPS - SHOULDER PRESS
15 REPS - LEG CURLS
20 REPS - LEG EXTENSIONS followed by ARM CURLS
15 REPS - LEG PRESS
10 SLOW REPS - 2 SETS - SIT UPS
• Your rest interval between each set of reps should be 1 minute.
• You should perform 4 SETS of each exercise.
• Your exercise pace should be MEDIUM to FAST.
• The resistance (weight) settings should be in positions 4 - 8.
• This exercise programme should take you approximately 40 - 50 minutes.
• Follow this exercise programme with 5 minutes of proper cool down exercises.

Exercise Notes
Page 13Herculean Home Gym Trainer

Assembly
Page 14 Herculean Home Gym Trainer
x 4
x 9
30
14
37
48
37
48
39
87
22
18
36
52
31
37 48
48 19
254
1
88
88
54
4
43
56
42
93
94
94
28
7
47
52
44
88
34
12
57
49
92
16
45
5
46
15
33
32
88
85
91
95
29
28
45 52 89
48
85
22
36
20
52 57A
87
43 92
92
17
90
85
38
50
11
51
35
13
37
48
48
49
52
10
52
86

Assembly
Page 15Herculean Home Gym Trainer
PART No. DESCRIPTION QTY
MAIN COMPONENTS . . . . . . . . . . . .
1 MAIN FLOOR FRAME . . . . . . . . . . . . . . . . . . . . .1
2 FRAME STABILISER (F) . . . . . . . . . . . . . . . . . . .1
3 FRAME STABILISER (R) . . . . . . . . . . . . . . . . . . .1
4 FRAME EXTENSION . . . . . . . . . . . . . . . . . . . . . .1
5 FRONT UPRIGHT . . . . . . . . . . . . . . . . . . . . . . . .1
6 Not Applicable . . . . . . . . . . . . . . . . . . . . . . . . . .
7 TOP FRAME . . . . . . . . . . . . . . . . . . . . . . . . . . .1
8 Not Applicable . . . . . . . . . . . . . . . . . . . . . . . . . .
9 Not Applicable . . . . . . . . . . . . . . . . . . . . . . . . . .
10 PRESS FRAME . . . . . . . . . . . . . . . . . . . . . . . . .1
11 PRESS FRAME STOP . . . . . . . . . . . . . . . . . . . .1
12 PEC ARM MOUNT . . . . . . . . . . . . . . . . . . . . . . .1
13 PEC ARM (L) . . . . . . . . . . . . . . . . . . . . . . . . . .1
14 PEC ARM (R) . . . . . . . . . . . . . . . . . . . . . . . . . .1
15 PEC SWIVEL BKT (L) . . . . . . . . . . . . . . . . . . . .1
16 PEC SWIVEL BKT (R) . . . . . . . . . . . . . . . . . . . .1
17 PRESS HANDLE . . . . . . . . . . . . . . . . . . . . . . . .2
18 SEAT SUPPORT FRAME . . . . . . . . . . . . . . . . . . .1
19 SEAT BRACE . . . . . . . . . . . . . . . . . . . . . . . . . .1
20 LEG UNIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
21 LEG UNIT STABILISER PLATE . . . . . . . . . . . . . . .1
22 LEG UNIT ROLLER BAR . . . . . . . . . . . . . . . . . . .2
23 Not Applicable . . . . . . . . . . . . . . . . . . . . . . . . . .
24 Not Applicable . . . . . . . . . . . . . . . . . . . . . . . . . .
25 Not Applicable . . . . . . . . . . . . . . . . . . . . . . . . . .
26 Not Applicable . . . . . . . . . . . . . . . . . . . . . . . . . .
27 Not Applicable . . . . . . . . . . . . . . . . . . . . . . . . . .
28 WEIGHT GUIDE TUBE . . . . . . . . . . . . . . . . . . . .2
29 WEIGHT SELECTOR TUBE . . . . . . . . . . . . . . . . .1
30 LAT PULLDOWN BAR . . . . . . . . . . . . . . . . . . . .1
31 TRICEPS BAR . . . . . . . . . . . . . . . . . . . . . . . . . .1
32 DOUBLE PULLEY BKT . . . . . . . . . . . . . . . . . . . .1
33 PULLEY MOUNT BKT . . . . . . . . . . . . . . . . . . . . .2
34 JOCKEY PULLEY BKT . . . . . . . . . . . . . . . . . . . .2
FOAM ROLLERS / GRIPS . . . . . . .
35 PEC ARM FOAM ROLLER . . . . . . . . . . . . . . . . .2
36 LEG UNIT FOAM ROLLER . . . . . . . . . . . . . . . . . .4
37 PRESS / BAR FOAM GRIP . . . . . . . . . . . . . . . . .8
SEATS / PADS . . . . . . . . . . . . . . . . . . .
38 GYM BACKREST . . . . . . . . . . . . . . . . . . . . . . . .1
39 GYM SEAT . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
40 Not Applicable . . . . . . . . . . . . . . . . . . . . . . . . . .
41 Not Applicable . . . . . . . . . . . . . . . . . . . . . . . . . .
CHAINS / CABLES . . . . . . . . . . . . . . .
42 LINK CHAIN (SHORT – 7 Link) . . . . . . . . . . . . . .1
43 LINK CHAIN (LONG – 12 Link) . . . . . . . . . . . . . .1
44 TOP (LAT) CABLE . . . . . . . . . . . . . . . . . . . . . . .1
45 LOWER (LEG) CABLE . . . . . . . . . . . . . . . . . . . .1
46 CENTRE (PEC) CABLE . . . . . . . . . . . . . . . . . . . .1
47 REAR (WEIGHT) CABLE . . . . . . . . . . . . . . . . . . .1
MASTER PARTS & ACCESSORY LIST
PART No. DESCRIPTION QTY
CAPS / BUMPERS . . . . . . . . . . . . . . .
48 1" ROUND CAP . . . . . . . . . . . . . . . . . . . . . . . .15
49 1 1/2” INT SQUARE CAP . . . . . . . . . . . . . . . . . .3
50 1 1/2” EXT RUBBER SQUARE CAP . . . . . . . . . . .1
51 1 1/2” EXT SQUARE TRIM . . . . . . . . . . . . . . . . .2
52 2” INT SQUARE CAP . . . . . . . . . . . . . . . . . . . . .8
53 Not Applicable . . . . . . . . . . . . . . . . . . . . . . . . . .
54 2" EXT RUBBER CAP . . . . . . . . . . . . . . . . . . . . .6
55 Not Applicable . . . . . . . . . . . . . . . . . . . . . . . . . .
56 2” RUBBER WEIGHT BUMPER . . . . . . . . . . . . . .2
57 SMALL SQUARE RUBBER PAD . . . . . . . . . . . . .2
57A LARGE SQUARE RUBBER PAD . . . . . . . . . . . . . .1
BOLTS / NUTS / WASHERS . . . . .
58 Not Applicable . . . . . . . . . . . . . . . . . . . . . . . . . .
59 Not Applicable . . . . . . . . . . . . . . . . . . . . . . . . . .
60 Not Applicable . . . . . . . . . . . . . . . . . . . . . . . . . .
61 M8 x 50mm HEX BOLT. . . . . . . . . . . . . . . . . . .2
62 M10 x 25mm HEX BOLT . . . . . . . . . . . . . . . . . .4
63 M10 x 50mm HEX BOLT . . . . . . . . . . . . . . . . . .10
64 M10 x 65mm HEX BOLT . . . . . . . . . . . . . . . . . .10
65 M10 x 70mm HEX BOLT. . . . . . . . . . . . . . . . . .8
66 M10 x 75mm HEX BOLT..................8
67 M12 x 70mm HEX BOLT . . . . . . . . . . . . . . . . . .2
68 M12 x 80mm HEX BOLT . . . . . . . . . . . . . . . . . .3
69 M12 x 125mm HEX BOLT . . . . . . . . . . . . . . . . .1
70 Not Applicable . . . . . . . . . . . . . . . . . . . . . . . . . .
71 M8 x 19mm od FLAT WASHER . . . . . . . . . . . . .4
72 Not Applicable . . . . . . . . . . . . . . . . . . . . . . . . . .
73 M10 x 20mm od FLAT WASHER . . . . . . . . . . . .70
74 M10 x 38mm od FLAT WASHER . . . . . . . . . . . .2
75 M12 x 24mm od FLAT WASHER . . . . . . . . . . . .12
76 Not Applicable . . . . . . . . . . . . . . . . . . . . . . . . . .
77 Not Applicable . . . . . . . . . . . . . . . . . . . . . . . . . .
78 M8 NYLON LOCKNUT . . . . . . . . . . . . . . . . . . . .2
79 M10 NYLON LOCKNUT . . . . . . . . . . . . . . . . . . .36
80 M12 NYLON LOCKNUT . . . . . . . . . . . . . . . . . . .6
MISC COMPONENTS / FITTINGS
81 Not Applicable . . . . . . . . . . . . . . . . . . . . . . . . . .
82 Not Applicable . . . . . . . . . . . . . . . . . . . . . . . . . .
83 Not Applicable . . . . . . . . . . . . . . . . . . . . . . . . . .
84 M10 x 18mm od METAL BUSH . . . . . . . . . . . . .6
85 M12 x 29mm od METAL BUSH . . . . . . . . . . . . .8
86 PRESS ARM LOCKING KNOB . . . . . . . . . . . . . . .1
PULLEYS / PINS / CLIPS . . . . . .
87 22mm WIDE PULLEY . . . . . . . . . . . . . . . . . . . .3
88 32mm WIDE PULLEY . . . . . . . . . . . . . . . . . . . .10
89 STABILISER LOCK PIN . . . . . . . . . . . . . . . . . . . .1
90 PEC ARM LOCK PIN . . . . . . . . . . . . . . . . . . . . .2
91 WEIGHT SELECTOR PIN . . . . . . . . . . . . . . . . . .1
92 CARABINA LOCK CLIP . . . . . . . . . . . . . . . . . . . .5
WEIGHTS . . . . . . . . . . . . . . . . . . . . . . . . .
93 CROWN PLATE . . . . . . . . . . . . . . . . . . . . . . . . .1
94 WEIGHT PLATE . . . . . . . . . . . . . . . . . . . . . . .4 or 9
95 CROWN PLATE PIN . . . . . . . . . . . . . . . . . . . . . .1

Part No. 64
Part No. 65
Part No. 66
Part No. 73 Part No. 79
*Part No. 56
*Part No. 54
Assembly
Page 16 Herculean Home Gym Trainer
INSTRUCTIONS:- STAGE A
TOOLS REQUIRED
1 x Soft Headed Hammer – 1 x Adjustable Spanner – 1 x 13mm (1/2”) Spanner – 1 x 14mm (9/16”)
Spanner
ASSEMBLY OF THIS GYM WILL BE EASIER WITH 2 PEOPLE
Securely attach the Front Frame Stabiliser (2) to the front end of the Main Floor Frame (1) using 2 x
M10 x 75mm Hex Bolts (66), 4 x M10 x 20mm od Flat Washers (73) and 2 x M10 Nylon Locknuts (79).
Connect the Frame Extension (4) to the rear of the Main Floor Frame (1) using 2 x M10 x 70mm Hex
Bolts (65), 4 x M10 x 20mm od Flat Washers (73) and 2 x M10 Nylon Locknuts (79).
Attach the Rear Frame Stabiliser (3) to the back end of the Frame Extension (4) using 2 x M10 x 70mm
Hex Bolts (65), 4 x M10 x 20mm od Flat Washers (73) and 2 x M10 Nylon Locknuts (79).
Cap both Frame Stabilisers (2 and 3) and the central Main Floor Frame Support (1) with 6 x 2” Ext
Rubber Caps (54) securing in place using a small amount of household adhesive if desired.
Loosely attach the Front Upright (5) to the Main Frame (1) from the side with 2 x M10 x 75mm Hex
Bolts (66), 4 x M10 x 20mm od Flat Washers (73) and 2 x M10 Nylon Locknuts (79).
Pass both Weight Guide Tubes (28) into the holes in the central Main Floor Frame Support (1), and
secure in place with 2 x M10 x 65mm Hex Bolts (64), 4 x M10 x 20mm od Flat Washers (73) and 2 x
M10 Nylon Locknuts (79). Slide the 2 x Rubber Weight Bumpers (56) down the Weight Guide Tubes
and then lay the 4 Large Weight Plates (94) supplied for the STARTER GYM or the 9 Large Weight Plates
(94) for the IMPROVER GYM on top.
Slide the Weight Selector Tube (29), which has 5 holes for the STARTER GYM or 10 holes for the
IMPROVER GYM into the central hole in the top Weight Plate. Fit the Crown Plate Pin (95) into the
Weight Selector Tube and finally lay the Crown Weight Plate (93) on top.
1
2
3
4
5
6
7
ASSEMBLY ACCESSORIES
PART No. DESCRIPTION QTY
54 2” Ext Rubber Cap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
56 Rubber Weight Bumper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
64 M10 x 65mm Hex Bolt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
65 M10 x 70mm Hex Bolt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
66 M10 x 75mm Hex Bolt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
73 M10 x 20mm od Flat Washer . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
79 M10 Nylon Locknut . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
* Drawn 1/2 scale

Assembly
Page 17Herculean Home Gym Trainer
73
66
3
73
5
65 65
73
73 65 65 73 73
91
93
29
94
56
73
2
66
66
73
73 73 79
73
79
54
54
54
73
79
64
73 79
79 1
4
28
79

Assembly
Page 18 Herculean Home Gym Trainer
INSTRUCTIONS:- STAGE B
Attach the Top Frame (7) to the Front Upright (5) ensuring that the tops of the Weight Guide Tubes (28)
are located in the round holes in the underside of the Top Frame, using 2 x M10 x 70mm Hex Bolts
(65), 2 x M10 x 20mm od Flat Washers Flat Washers (73) to the UNDER side and 2 x M10 x 38mm od
Flat Washers (74) to the TOP side, securing in place with 2 x M10 Nylon Locknut Nuts (79).
Secure the Weight Guide Tubes (28) to the Top Frame (7) using 2 x M10 x 65mm Hex Bolts (64), 4 x
M10 x 20mm od Flat Washers (73) and 2 x M10 Nylon Locknuts Nuts (79).
Cap the exposed open ends of the Top Frame with 3 x 2” Int Square Caps (52), securing in place using
a small amount of household adhesive if desired.
8
9
10
ASSEMBLY ACCESSORIES
PART No. DESCRIPTION QTY
52 2” Int Square Cap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
64 M10 x 65mm Hex Bolt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
65M10 x 70mm Hex Bolt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
73 M10 x 20mm od Flat Washer . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
74 M10 x 38mm od Flat Washer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
79 M10 Nylon Locknut . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
*Part No. 52
Part No. 79
Part No. 73
Part No. 74
Part No. 65
Part No. 64
* Drawn 1/2 scale

Assembly
Page 19Herculean Home Gym Trainer
28
52
73
79
64
73
64
73
7
73 73
65
65
52
52
74
79 74
79

Assembly
Page 20 Herculean Home Gym Trainer
INSTRUCTIONS:- STAGE C
Fit 2 x M12 x 29mm od Metal Bushes (85) to the holes on either side of the Top Frame (7) and then
assemble the Press Frame (10) to the Top Frame (7) with 1 x M12 x 125mm Hex Bolt (69) 2 x M12 x
24mm od Flat Washers (75) and 1 x M12 Nylon Locknut (80).
Fit 2 x M12 x 29mm od Metal Bushes (85) to the large holes in each Pec Arm (13 and 14) and
assemble each Pec Arm to the Press Frame (7) using 1 x M12 x 70mm Hex Bolt (67), 2 x M12 x 24mm
od Flat Washers (75) and 1 x M12 Nylon Locknut (80). Align the Pec Arms by fitting a Pec Arm Lock Pin
(90) to the inner hole in each Pec Arm and then fully tighten both Hex Bolts.
Slide 1 x Pec Arm Foam Roller (35) onto each Pec Arm (13 and 14) and then fit 1 x Press Handle (17)
to each Pec Arm using 1 x M8 x 50mm Hex Bolt (61), 2 x M8 x 19mm od Flat Washers (71) and 1 x
M8 Nylon Locknut (78) for each Press Handle.
Slide 1 x Press / Bar Foam Grip (37) onto each of the 2 Press Handles on each Pec Arm (13 and 14)
and cap the exposed ends of the Press Handles with a 1” Round Insert Cap (48). Slide a Press / Bar
Foam Grip (37) onto the welded Press Tube of each Pec Arm (13 and 14) and again cap the exposed
ends of the tube with a 1” Round Insert Cap (48) for each.
Cap both exposed Pec Arm inner tube ends with 1 x 1 1/2” Square Insert Cap (49) and the lower end
with 1 x 1 1/2” Ext Square Trim (51) to each Pec Arm (13 and 14), securing in place using a small
amount of household adhesive if desired.
Remove the backing paper and fit 2 x Small Square Rubber Pads (57) to the back face of the Press
Frame where the Pec Arms touch the Press Frame.
Fit the Press Arm Locking Knob (86) into the tube inside the Press Frame with the metal lock facing UP
and cap the tube with the 1 x 2” Int Square Cap (52) securing in place using a small amount of
household adhesive if desired.
Assemble the Press Frame Stop (11) to the FRONT FACE of the Front Upright (5) and the Pec Arm
Mount (12) to the REAR FACE of the Front Upright (5) using 2 x M10 x 75mm Hex Bolts (66), 4 x M10 x
20mm od Flat Washers (73) and 2 x M10 Nylon Locknuts (79). Cap the FRONT open end of the Press
Frame Stop (11) with the 1 1/2” Ext Rubber Square Cap (50) and the TOP open tube with 1 x 1 1/2” Int
Square Cap (49) securing in place using a small amount of household adhesive if desired.
Fit the left and right Pec Swivel Brackets (15 and 16) to the Pec Arm Mount (12) using 2 x M12 x
80mm Hex Bolts (68), 4 x M12 x 24mm od Flat Washers (75) and 2 x M12 Nylon Locknuts (80).
11
12
13
14
15
16
17
18
19
Fully tighten the Hex Bolt to
remove any existing freeplay
from the Press Frame.
Note
Fitment of the Foam Grips will
be easier with a small amount
of washing up liquid smeared
on the bar first.
Note
The Pec Swivel Brackets (15
and 16) are marked L and R
with stickers. These should be
fitted to the Pec Arm Mount
(12) viewed from the REAR.
When fitted, fully tighten the
bolts so that all freeplay is
removed from the brackets but
that it is still possible for them
to rotate. These may need to be
re-tightened after a few days
when the frame coating has
worn flat.
Note
PART No. DESCRIPTION QTY
48 1” Round Insert Cap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
49 1 1/2” Square Insert Cap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
50 1 1/2” Ext Rubber Square Cap . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
51 1 1/2” Ext Square Trim . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
52 2” Int Square Cap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
57 Square Rubber Pad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
61 M8 x 50mm Hex Bolt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
66 M10 x 75mm Hex Bolt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
67 M12 x 70mm Hex Bolt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
68 M12 x 80mm Hex Bolt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
69 M12 x 125mm Hex Bolt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
71 M8 x 19mm od Flat Washer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
73 M10 x 20mm od Flat Washer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
75 M12 x 24mm od Flat Washer . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
78 M8 Nylon Locknut . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
79 M10 Nylon Locknut . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
80 M12 Nylon Locknut . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
85 M12 x 29mm Metal Bush . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
86 Press Arm Locking Knob . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
90 Pec Arm Lock Pin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
ASSEMBLY ACCESSORIES
Part No.78 Part No.79
Part No.71 Part No.73
Part No.80
Part No.75
Part No.85
