V-Show S718 Elf User manual

S718 Elf
User Manual

1. Safety Instructions
Please read the instruction carefully which includes important
information about the installation, usage and maintenance.
Please keep this User Guide for future consultation. If you sell the unit to
another user, be sure that they also receive this instruction manual.
Important:
Damages caused by the disregard of this user manual are not subject to
warranty. The dealer will not accept liability for any resulting defects or
problems.
Unpack and check carefully to ensure that there is no transportation damage
before using the unit.
This product is for indoor use only. Use only in a dry location.
DO install and operate by qualified operator.
DO NOT allow children to operate the fixture.
Use safety chain when fixing the unit. Handle the unit by carrying its base
instead of head only.
The unit must be installed in a location with adequate ventilation, at least 50cm
from adjacent surfaces.
Be sure that no ventilation slots is blocked, otherwise the unit will be
overheated.
Before operation, ensure that you are connecting this product to the proper
voltage in accordance with the specifications in this manual or on the product’s
specification label.
It’s important to ground the yellow/green conductor to earth in order to avoid
electric shock.
Minimum ambient temperature TA: 0℃. Maximum ambient temperature TA:
40℃. Do not operate this product at a lower or higher temperature.
DO NOT connect the device to any dimmer pack.
Avoid any flammable liquids, water or metal from entering the unit. Once it
happens, cut off the mains power immediately.
DO NOT operate in a dirty or dusty environment. DO clean the fixture regularly.
DO NOT touch any wire during operation as there might be a hazard of electric
shock.
Avoid entanglement of the power cord with other wires.
The minimum distance to objects/surface must be more than 1 meters.
Disconnect mains power before fuse/lamp replacement or servicing.
Replace fuse/lamp only with the same type.

In the event of serious operating problem, stop using the unit immediately.
Never turn on and off the unit time after time.
The housing, the lenses, or the ultraviolet filter must be replaced if they are
visibly damaged.
DO NOT attempt to operate this unit if it becomes damaged. DO NOT attempt
any repairs
yourself. Repairs carried out by unskilled people can lead to damage or
malfunction. Please contact the nearest authorized technical assistance center
if needed.
Disconnect this product from its power source before servicing.
DO use the original packaging if the device is to be transported.
Avoid direct eye exposure to the light source while the product is on.
Never touch bulb with bare fingers, as it is very hot after using.
DO NOT operate this product if you see damage on the housing, shields, or
cables. Have the damaged parts replaced by an authorized technician at once
Installation:
The fixture should be fixed on the clamp. Always ensure that the unit is firmly
fixed to avoid vibration and slipping off during operation. Ensure that the
trussing or area of installation must be able to hold 10 times the weight without
any deformation. Always install a safety cable that can hold at least 12 times
the weight of the fixture when installing.DO install and operate by qualified
operator. It must be installed in a place where there is out of the reach of
people.
2.INSTALLATIONS
installations Note: In order to increase protection, please install the lamp on
the sidewalk, outside the seating area, or an area where unauthorized persons
may touch the lamp
Before installing the fixture on any surface, make sure that the installation area
can bear the minimum point load above 10 points of the weight of the
equipment. The installation of the fixing device must always be fixed with
auxiliary safety accessories (such as a suitable safety rope)
Do not stand directly under the equipment when installing, removing, or
servicing fixtures
From the ceiling or set on a flat surface (see the picture below). Ensure that
this fixture is kept at least 0.5m (1.5 feet) away from any flammable materials
(decorations, etc.)
Be sure to use and install the supplied safety rope to ensure safety and
prevent accidental damage and/or injury in case the fixture is damaged

Installation point: Overhead installation requires a wealth of experience,
including calculation of working load limits, in-depth understanding of the
installation materials used, and regular safety inspections of all installation
materials and fixtures. If you do not have these qualifications, please do not try
to install it yourself. Improper installation can cause personal injury
Before connecting the main power cord to an appropriate wall outlet, make
sure to complete all assembly and installation procedures
Lamp installation: LED shaking head provides a unique mounting bracket
assembly, which integrates the bottom of the base and the fixing point of the
safety cable into one unit (see the figure below). When installing the fixture to
the truss, make sure to use the appropriate tools to fix it on the attached
bracket, and use the M10 screw that passes through the center hole of the
"bracket" to fix it. As an additional safety measure, make sure to use at least
one safety cable integrated in the base assembly to connect at least one
appropriately rated safety cable to the fixture.
3. DMX-512 control connections
Connect the provided XLR cable to the female 3-pin XLR output of your
controller and the other side to the male 3-pin XLR input of the moving head.
You can chain multiple
Moving heads be connected together through serial linking. The cable needed
should be two core, screened cable with XLR input and output connectors.
For installations where the DMX cable has to run a long distance or is in an
electrically noisy environment, such as in a discotheque, it is recommended to
use a DMX terminator. This helps in preventing corruption of the digital control
signal by electrical noise. The DMX terminator is simply an XLR plug with a 120
Ω resistor connected between pins 2 and 3,which is then plugged into the
output XLR socket of the last fixture in the chain. Please see illustrations below

1
2
3
PIN 3
PIN 2
120Ω
4.Address code setting
If you use a universal DMX controller to control the units, you have to set DMX
address from 1 to 512 so that the units can receive DMX signal.
Press the MENU button to enter menu mode, select DMX Settings, press the
ENTER button to confirm, use the UP/DOWN button to select DMX Address,
press the ENTER button to confirm, the present address will blink in the display,
use the UP/DOWN button to adjust the address from 001 to 512, press the
ENTER button to store. Press the MENU button back to the last menu or let the
unit idle 30 seconds to exit menu mode.Please refer to the following diagram to
address your DMX512 channel for the first 4 units.

Channel
MODE
UNIT1
ADDERSS
UNIT2
ADDERSS
UNIT3
ADDERSS
UNIT4
ADDERSS
17CH
1
18
35
52
5.Fixture size
6.Illuminance chart:

7. Effect Wheels
STATIC GOBO WHEEL
COLOR WHLLE
Rotation GOBO

8. LED technical parameters
Input Voltage: 100-240V, 50/60Hz
Output Voltage: V1:29V(Master board+LED driver), V2:12V(cooling fan+Displa
y)
Power consumption: 180W
Power supply: 250W
Light source: 150W Osram LED Chip (24-27V,6A)
Color temperature: 8000K
Diameter of optic lens: 65mm
Beam angle: 15-17°
Color wheel: 1 color wheel, 7fixed colors plus white, two-way rainbow effect
Static gobo: 7 gobos plus 1 white circle
Rotation Gobo: 6 Gobo plus 1 white circle
Prism: 5 prism,can be rotated in both directions
Frost filter: with smooth wash effect
DMX Channel: 17CH
Operate mode: DMX512, self-propelled, master/slave,Sound active, RDM
Fixture size: 303*226*394mm
Net weight: 14 KG
Features:
1. Electric focuing system with 0-100% smooth dimming
2. Overheating self-energy protection can extending lamp life
3.Three phase Motor with SY Brand ( XY axis magnetic coding positioning is m
ore accurate)
4. With two angle lens 15°and 17°can change the gobo size
5. High quality LCD touch screen
6. Power in & Out connector,3 or 5pin XLR inout & output can optional
7. Folding clamp can optional
8. Housing material: PA6 Nylon( Solid,high temperature resistance up to 200°
flame retardance)

9. Touch key description
Up and down keys to select edit
Confirm key: execute function, start editing, exit editing
menu key: return to the previous interface
The following takes "Modify DMX Address Code" as an example to describe the
use of buttons:
1. If it is not the main interface, press the menu key (one or more times) to
return to the main interface
2. In the main interface, press the "Up" key or the "Down" key to select the
"Settings" button
3. Press the "OK" button to enter the "Settings" interface
4. In the "Settings" interface, press the "Up" key or the "Down" key to select
"DMX Address"
5. Press the "OK" key to enter the editing state
6. Press the "Up" key or "Down" key to modify the DMX address code
7. Press "OK" to exit the editing state
10.menu description
Main menu diagram

10.1set up
Option
Description
operating
mode
DMX
Slave state: receive DMX signal from console
or host
AUTO
Master status: self-propelled and send DMX
signal to slave
voice
control
DMX address
1~512
Press the "OK" key to enter the editing state. At
this time, the hundreds digit is selected, and the
"up" and "down" keys are pressed to change
the address code. Press the "OK" key again to
select ten edits. Press the "OK" key again to
select the one digit editing. Press again to exit
the editing state
Motor reset
close
open
Lamp reset
channel mode
Standard
17CH
Standard 17-channel mode
X reverse
close
open
Y reversal
close
open
XY swap
close
open
Swap the channels of the XY axes (including
fine-tuning)
XY encoder
open
Use the encoder (optical coupler) to judge the
out-of-step and automatically correct the
position
close
Correct position without encoder (optocoupler)
DMX signal
Keep
Continue to operate as it is
clear
The motor returns and stops running
restore default
settings
Press the "OK" button to see the confirmation
dialog box, press the "OK" button again to
restore the default settings
10.2MANU
Option
Description
1
X
2
X fine-tuning
3
Y
4
Y fine-tuning

5
XY velocity
6
Dimming
7
Strobe
8
color
9
pattern
10
glass pattern
11
glass pattern rotation
12
atomization
13
Prism
14
Prism rotation
15
focusing
16
enlarge
17
reset
10.3factory
Sensor
detection
X Hall
Y Hall
color hall
Pattern
Hall
glass
pattern hall
Focus Hall
X-coded
step value
Y-coded
step value
reset calibration
X axis
After entering the sub-interface, you can
adjust the reset position of the X-axis, Y-axis
and other motors to make up for the error in
the hardware installation. The adjustment
range is -128~+127, and +0 means no
adjustment.
Y axis
color
pattern
glass
pattern
focusing
enlarge
Prism
frost
10.4system
Option
Description
DIS
Dashboard software version
MT
Motor board software version
system error
If the red ERR indicator is on, it means that

the lamp is running incorrectly, and the details
can be viewed from this sub-interface. After
viewing, you can press the "Clear" button to
clear the error record
total usage time
This time of use
temperature
Display the current temperature of the lamp
bead
Common error
messages
illustrate
MT board
connection
failed
The motor board is not responding. There is a problem with
the serial communication line connecting the display board
and the motor board, or there is a problem with the motor
board.
X axis reset
failed
There is a problem with the X-axis photoelectric switch, or
the X-axis motor or motor board
Y axis reset
failed
There is a problem with the Y-axis photoelectric switch, or
the Y-axis motor or motor board
X axis Hall error
X-axis Hall, or there is a problem with the motor board
Y axis Hall error
Y-axis Hall, or there is a problem with the motor board
Color wheel
reset failed
The color wheel Hall, or the color wheel motor has a
problem
Pattern disk
reset failed
Gobo Hall, or gobo motor is faulty
Focus reset
failed
Focusing Hall, or there is a problem with the focusing motor
11.Channel
17CH
CH
Function
CH Value
Effect
1
X
000-255
Horizontal 540 degree scan
2
X fine
000-255
Horizontal 1.2 degree fine-tuning
3
Y
000-255
Vertical 270 degree scan
4
Y fine
000-255
Vertical 1.2 degree fine-tuning
5
XY speed
000-255
Speed from fast to slow
6
Dimming
000-255
from dark to light
7
000-003
004-103
Shutter open
Strobe from slow to fast

Strobe
104-107
108-207
208-212
213-251
252-255
Shutter open
Pulse strobe from slow to fast
Shutter open
Random strobe from slow to fast
Shutter open
8
color
000 - 007
008 - 015
016 - 023
024 - 031
032 - 039
040 - 047
048 - 055
056 - 063
064 - 071
072 - 079
080 - 087
088 - 095
096 - 103
104 - 111
112 - 119
120 - 127
128 - 191
192 - 255
white light
white light + color 1
color 1
color 1+color 2
color 2
color 2+color 3
color 3
color 3+color 4
color 4
color 4+color 5
color 5
color 5+color 6
color 6
color 6+color 7
color 7
Color 7+ White Light
Reverse flow (from fast to slow)
Forward flow (from slow to fast)
9
Static Gobo
000 - 007
008 - 015
016 - 023
024 - 031
032 - 039
040 - 047
048 - 055
056 - 063
064 - 071
072 - 079
080 - 087
088 - 095
096 - 103
104 - 111
112 - 119
120 - 127
128 - 191
192 - 255
Static Gobo1(white light)
Static Gobo2
Static Gobo3
Static Gobo4
Static Gobo5
Static Gobo6
Static Gobo7
Static Gobo8
Static Gobo1shock (from slow to fast)
Static Gobo2shock (from slow to fast)
Static Gobo3shock (from slow to fast)
Static Gobo4shock (from slow to fast)
Static Gobo5shock (from slow to fast)
Static Gobo6shock (from slow to fast)
Static Gobo7shock (from slow to fast)
Static Gobo8shock (from slow to fast)
Forward flow (from fast to slow)
Reverse flow (slow to fast)
10
000 - 009
010 - 019
020 - 029
Rotation Gobo1（white light）
Rotation Gobo2
Rotation Gobo3

Rotation
Gobo
030 - 039
040 - 049
050 - 059
060 - 069
070 - 079
080 - 089
090 - 099
100 - 109
110 - 119
120 - 129
130 - 192
193 - 255
Rotation Gobo4
Rotation Gobo5
Rotation Gobo6
Rotation Gobo7
Static Gobo2shock (from slow to fast)
Static Gobo3shock (from slow to fast)
Static Gobo4shock (from slow to fast)
Static Gobo5shock (from slow to fast)
Static Gobo6shock (from slow to fast)
Static Gobo7shock (from slow to fast)
Forward flow (from fast to slow)
Reverse flow (slow to fast)
11
Gobo
Rotation
000-127
128-191
192-255
gobo angle adjustment
gobo forward rotation
gobo reverse rotation
12
frost
000-127
128-255
no effect
frost cut in
13
Prism
000-127
128-255
Prism pops up
Prism cut
14
Prism
rotation
000-127
128-191
192-255
Prism angle adjustment
Prism rotating forward flow
Prism rotation reverse flow
15
focusing
000-255
gobo clarity from far to near
16
enlarge
000-127
128-255
no effect
zoom in
17
reset
000-127
128-255
None, there is no action for the area
without the specified function
Reset all motors
11. Common malfunctions
1. After the lamp is reset normally, it will not accept the control of the
console
Check whether the digital start address value and function options of the
lamps are correct;
Check whether the connection of the communication control line is correct,
the communication line is too long or has been interrupted;
Check whether the control equipment is invalid, and check whether the
signal amplifier connected in series is invalid;
Check whether the communication line is too long or other devices interfere
with each other;
Optimize wiring, shorten the length of control signal lines, separate
high-voltage and low-voltage lines;

Add a signal amplifier;
The signal line adopts high-quality shielded twisted pair;
Connect a signal terminating resistor (120 ohms) at the end of the fixture.
2. The lamps cannot be started
Check that the lamps have poor contact or fall off due to extrusion
deformation, vibration of internal parts, moisture and other reasons during
long-distance transportation.
Please check whether the wires and connectors inside the lamp are
detached or loose.
Check whether the electronic components of lamps (such as electronic
transformers, PCB boards, motor control boards, etc.) are loose,
short-circuited and burned out.
3. When working, the X-axis or Y-axis of the lamp does not move normally
Check whether the transmission belt corresponding to the X and Y axis
directions in the lamp is off and broken;
Check whether the data feedback receiver (optical coupler) corresponding
to the X and Y directions in the lamp is damaged;
Reboot to reset once.
