Sony VPL-VW1100ES User manual

Experience Sony’s most immersive, awe-inspiring home theater
with the Sony 4K projector featuring SXRD™ 4K movie theater
projector technology. Delivering greater than four times 1080p
resolution, anamorphic 3D, and HD to 4K upscaling, nothing else
comes close to the Sony®VPL-VW1100ES Projector. No detail was
le out—including easy installation and control.
• 4K resolution—4096x2160. That’s greater than 4
times 1080p
• HD to 4K upscaling turns your HD content into a
4K experience
• 1,000,000:1 dynamic contrast ratio with SXRD™
technology
• Brightness of 2,000 ANSI lumens
• Control over RS232 or IP with feedback
• Flexible installation—2.1 motorized zoom,
80%(v)/30%
• (h) motorized shi and 1.27-2.73 throw ratio
• HDMI® 2.0 compatible for 4K resolution at up to 60
frames per second
• 3-year limited warranty
• Picture position feature for lens-less anamorphic
(2.35:1)
• Whisper-quiet fan
Features
An astonishingly immersive home theater experience
Features the same technology and resolution found in high-end, professional 4K movie theaters, providing an astonishingly
immersive home theater experience. 4K resolution is 4096x2160. That’s more than 4 times 1080p. Add a 1,000,000:1
dynamic contrast ratio, 2,000 ANSI lumen brightness, and wide color gamut and the VPL-VW1100ES pulls you into your
favorite movies like no home theater projector you’ve ever experienced.
Recommended for up to a 200" screen
Because the VPL-VW1100ES has such high resolution and brightness, you can install a 200" screen and still experience an
astonishingly crisp and bright picture in 2D. (Up to 150" if you want to use 3D.)
Enjoy your favorite 1080p HD movies and shows in 4K
Watch your favorite HD movies and television shows in 4K with Super Resolution upscaling. Sony’s proprietary Reality
Creation algorithm makes your best video content look better than ever before. And Sony’s proprietary “Mastered in 4K”
algorithm faithfully reproduces specially prepared movies to match the original 4K images.
Get the most out of your Sony 4K projector
The included 4K Ultra HD Media Player allows you to enjoy 4K video shorts, and Sony’s Video Unlimited 4K network video
service provides access to a library of 4K movies and TV shows.3Control it all with a Sony Tablet, both of which are
optional.
Integrate into virtually any home automation system
Seamlessly integrate the VPL-VW1100ES into virtually any major automation system through the bi-directional, industry-
standard RS232 or IP connections.
Simple installation
Installing the VPL-VW1100ES is easy with its motorized 2.1x zoom, 80%(v)/30%(h) motorized shi and exible throw
distance—1.27-2.73 throw distance for 1.78:1 and 1.68-2.73 for 2.35:1 anamorphic zoom using the picture position feature.
No anamorphic lens required
When using a cinema scope screen, enjoy 2.35:1 content without the need for an external anamorphic lens using the
Picture Position function.
Immersive, vibrant picture for any environment
VPL-VW1100ES
Sony 4K Home Theater ES Projector
Bullets

3D Features
3D Features
2D to 3D Conversion Yes
3D Glasses Brightness Adjustment 2 Modes, Standard and High
Digitally Driven Panel Yes
Eect Adjustment(s) Yes
Format(s) Frame Packing/ Side by Side/ Over-Under/Simulated
3D/ESPN 3D format/ 720p / 60 SBS
Signal (HDMI inputs only) 1080:24p/60p/50p/60i/50i ;
720:60p/50p
Simulated 3D Yes
Transmitter Built-in with the option for external
Convenience Features
By simply choosing the appropriate preset, the VPL-VW1100ES’s 2,000 ANSI lm brightness and color gamut can be adjusted
for the ideal picture quality in any environment—whether gaming or watching sports in a lit room, or enjoying movies in a
dark theater.
Watch 2D high-denition content in 3D
Add a new dimension to your favorite movies, shows or videos with Sony’s unique 2D to 3D upconversion algorithm,
allowing high denition 2D content connected via HDMI® to be viewed in immersive Sony 3D.2
Whisper-quiet fan
Forget that the projector is even in the room. Due to the VPL-VW1100ES’s advanced air discharge system.
Powerful picture calibration features
Quickly calibrate your picture to the type of content you’re enjoying with nine unique modes including a variety of
cinema, gaming, photo and user customizable pre-sets.
Automatic motorized lens protector
The lens cover of the VPL-VW1100ES opens automatically when the projector powers on, then closes when the projector is
turned o to prevent dust build-up on the lens.
Integrated IR 3D Sync Transmitter
No need to wire an external transmitter. The built in IR transmitter can adequately cover home theaters with up to 130"
screens at 0.85 gain.
153 Zone Panel Alignment
153 zone, 1/10th pixel step, panel alignment ensures a sharp image.
Smoother, sharper motion
Enjoy smooth, sharp motion with Sony’s Motionow™ technology with Dark Frame Insertion and 24p True Cinema
technologies.
3-year limited warranty
Rest assured that Sony has you covered. All Sony Elevated Standard (ES) projectors enjoy 3-year limited warranties,
including a special tech support hotline in case you run into any problems.
Specications

Convenience Features
Auto Input Search Yes
BRAVIA® Sync™ Yes
Image Flip HV, H, V, O
IR Receiver Front & Rear, Front, Rear
Multiple Language Display 15 languages (including English, French, Spanish,
German and Chinese)
Power Save Mode Yes
Remote Control Yes (RM-PJ22)
Test Pattern Yes
Display
Display
Native Resolution 4K - 4096 x 2160
Screen Size 60"-200" recommended
Aspect Ratio 17:9
Display Resolution 4096 × 2160 (Full 4K)
Display Features
Display Features Display Technology SXRD™ Technology
General
General
Integration Partner
Yes (Control4 Certied, AMX Device Discovery,
Crestron Integrated Partner, Savant Partner in
Excellence, RTI & URC)
Lens 4K All Range Crisp Focus (ARC-F)
Projection Picture Size 60" to 300" measured diagonally
General Features
General Features
Acceptable Computer Signals fH: 19 to 72 kHz, fV: 48 to 92 Hz, fV: 60 Hz
Information Menu Horizontal and Vertical frequency display
Input A D-sub 15 Pin, Analog RGB/Component
Lens Control Motorized focus, shi and zoom with servo/memory
Standby Mode Yes
Inputs and Outputs
Inputs and Outputs
12V Trigger Output(s)
Mini Jack - Power On: DC 12V, output impedance:
4.7 kilohms Power O: 0V (Two, selectable power /
anamorphic zoom.)
3D Sync 1 (Side) RJ45
Component Video (Y/Pb/Pr)
Input(s) 2 (Side): 1 (RCAx3), 1 (15 Pin HD)
HDMI™ Connection(s) (Total) 2 (Side) Digital RGB/Y/Cb(Pb)Cr(Pr) with PC timing
support1
IR Input(s) 1 (Side) Mini Jack
PC Video Input(s) D-sub 15-pin
Remote Network Connection(s) 1 (Side) RJ-45, 10 base-T/100base-T
RS-232C Input(s) D-sub 9-pin (female)
RS232 Control Yes
Optional Accessories
Optional Accessories Optional Accessories Ultra High Pressure Replacement Lamp (LMP-H330)
Accessories

1. Requires 3D content, 3D player, 3D glasses, and HDMI® cable (at least 10.2 Gbps).
2. Simulated 3D image will vary based on source content.
3. Ethernet connection required. Fees may apply for 4K networked video service.
4. Lamp in this product contains mercury. Disposal of these materials may be regulated due to environmental considerations. For disposal or recycling information, please contact your
local authorities or the Telecommunications Industry Association (www.eiae.org).
© 2013 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without written permission is prohibited. Features and specications are subject to change without notice.
Accessories Supplied Accessories
Remote Control (RM-PJ22)
Instruction Manual
AC Cord
Size AA batteries x 2
(2) 3D Glasses: TDG-PJ1
Service and Warranty Information
Service and Warranty Information Limited Warranty Term
Product Warranty - Limited 3 Years Parts and Labor
except the lamp. Lamp Warranty - 90 Days from date
of purchase.
TV System
TV System Color System Auto, NTSC, PAL, SECAM
Video
Video
Brightness 2000 Lumens
Contrast Ratio 1,000,000:1 Dynamic Contrast
Deep Color Yes
Picture Modes 9 modes
Video Calibration Settings 11 Gamma Modes
Independent settings for 2D & 3D viewing
Video Features
Video Features
3D Anamorphic Yes, via picture position or external lens
4K resolution upscaling Yes - 3840 x 2160 (QFHD)
Acceptable Video Signals
480/60i, 576/50i, 480/60p, 576/50p,720/60p, 720/50p,
1080/60i, 1080/50i
The following items are available for HDMI input only:
1080/60p, 1080/50p, 1080/24p,3840 x 2160/24p, 3840
x 2160/25p,
3840 x 2160/30p, 3840 x 2160/60p, 4096 x 2160/24p,
4096 x 2160/60p
Anamorphic Yes, lens-less anamorphic via picture position
Deep Color Yes
Film Mode Yes
Lens Shi Function Yes 80(v), 30(h)
Motionow™ Technology Yes (120 Hz with Dark Frame Insertion)
Picture Position Yes, 5 Modes (including lens-less anamorphic)
Pixel Alignment Yes, 0.1 Pixel increments, 153 zones
Title Area Control Yes
Vertical Position Yes
Video Processing Optional
Wide Mode Yes
x.v.Color™ Technology Yes
Color Space Supports sRGB (Rec 709), DCI, Adobe RGB
