V-tech ErisTerminal VSP608A User manual

ErisTerminalTM SIP DECT Cordless Deskset
VSP608A
Quick Start Guide

2
Important Safety Information
This symbol is to alert you to important operating or servicing
instructions that may appear on the product or in this user’s manual.
Always follow basic safety precautions when using this product to
reduce the risk of injury, re, or electric shock.
Important Safety Instructions
When using your telephone equipment, basic safety precautions should always be
followed to reduce the risk of re, electric shock and injury, including the following:
1. This product should be installed by a qualied technician.
2. This product should only be connected to the host equipment and never
directly to the network such as Public Switch Telephone Network (PSTN) or
Plain Old Telephone Services (POTS).
3. Read and understand all instructions.
4. Follow all warnings and instructions marked on the product.
5. Unplug this product from the wall outlet before cleaning. Do not use liquid or
aerosol cleaners. Use a damp cloth for cleaning.
6. Do not use this product near water such as near a bath tub, wash bowl,
kitchen sink, laundry tub or swimming pool, or in a wet basement or shower.
7. Do not place this product on an unstable table, shelf, stand or other unstable
surfaces.
8. Slots and openings in the back or bottom of the handset are provided for
ventilation. To protect them from overheating, these openings must not be
blocked by placing the product on a soft surface such as a bed, sofa or rug.
This product should never be placed near or over a radiator or heat register.
This product should not be placed in any area where proper ventilation is not
provided.
9. This product should be operated only from the type of power source indicated
on the marking label. If you are not sure of the type of power supplied at the
premises, consult your dealer or local power company.
10. Do not allow anything to rest on the power cord. Do not install this product
where the cord may be walked on.
11. Never push objects of any kind into this product through the slots in the
handset because they may touch dangerous voltage points or create a short
circuit. Never spill liquid of any kind on the product.

3
12. To reduce the risk of electric shock, do not disassemble this product, but take
it to an authorised service facility. Opening or removing parts of the handset
other than specied access doors may expose you to dangerous voltages or
other risks. Incorrect reassembling can cause electric shock when the product
is subsequently used.
13. Do not overload wall outlets and extension cords.
14. Unplug this product from the wall outlet and refer servicing to an authorised
service facility under the following conditions:
A. When the power supply cord or plug is damaged or frayed.
B. If liquid has been spilled onto the product.
C. If the product has been exposed to rain or water.
D. If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the
operation instructions. Improper adjustment of other controls may
result in damage and often requires extensive work by an authorised
technician to restore the product to normal operation.
E. If the product has been dropped and the telephone base and/or
handset has been damaged.
F. If the product exhibits a distinct change in performance.
15. Avoid using a telephone (other than cordless) during an electrical storm.
There is a remote risk of electric shock from lightning.
16. Do not use the telephone to report a gas leak in the vicinity of the leak. Under
certain circumstances, a spark may be created when the adapter is plugged
into the power outlet, or when the handset is replaced in its cradle. This is a
common event associated with the closing of any electrical circuit. The user
should not plug the phone into a power outlet, and should not put a charged
handset into the cradle, if the phone is located in an environment containing
concentrations of ammable or ame-supporting gases, unless there is
adequate ventilation. A spark in such an environment could create a re or
explosion. Such environments might include: medical use of oxygen without
adequate ventilation; industrial gases (cleaning solvents; gasoline vapours;
etc.); a leak of natural gas; etc.
17. Only put the handset of your telephone next to your ear when it is in normal
talk mode.
18. The power adapters are intended to be correctly oriented in a vertical or oor
mount position. The prongs are not designed to hold the plug in place if it is
plugged into a ceiling, under-the-table or cabinet outlet.
19. Use only the power cord indicated in this manual.
Power adapter rating: 6.0 Vdc @ 600 mA

4
20. For pluggable equipment, the socket-outlet shall be installed near the equipment
and shall be easily accessible.
21. In wall mounting position, make sure to mount the telephone base on the wall
by aligning the eyelets with the mounting studs of the wall plate. Then slide the
telephone base down on both mounting studs until it locks into place. Refer to
the full installation instructions in the User Guide.
22. CAUTION: Keep small metallic objects such as pins and staples away from the
handset receiver.
SAVE THESE INSTRUCTIONS
Declaration of Conformity
Hereby, VTech declares that this VSP608A is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC.

5
Parts Checklist
Your telephone package contains the following items. Save your sales receipt and
original packaging in the event warranty service is necessary.
About this Guide
This quick start guide provides a reference for the external features of the
VSP608A SIP DECT cordless deskset and installation instructions.
The VSP608A SIP DECT cordless deskset is for use with the VSP610A SIP DECT
base station. Please refer to the VSP610A/VSP608A SIP DECT Base Station and
Cordless Deskset User Guide for complete operation instructions.
For customer service or warranty service, please contact our regional ofces or
distributors in your country or region where you purchased your product.
Quick Start Guide Power adapter Directory card
Deskset base Deskset stand
Handset and cord
Backup battery
Quick start guide

6
Quick Reference Guide
Deskset overview
MESSAGE WAITING
Flashes when a line has a new
voice message.
LINE
Displays the Dialling Line menu.
MESSAGE
Displays the Message menu.
HOLD
Puts the active call on hold.
TRANSFER
Starts the transfer process.
FLASH
Press to answer a call after a call
waiting alert.
CONFERENCE
Starts the conference process.
NAVIGATION KEY
While in menus, press qor pto
scroll through the menu, highlight
items or change settings. While
entering names, numbers or other
text, press tor uto move the
cursor left or right.
DIRECTORY
Press to view
directory information.
CALL HISTORY
Press to view caller
ID information.
DND
Press to enter do-not-
disturb mode.
REDIAL
Press to view list of
previously dialled
numbers.
MENU/FUNC.
Press to display the
deskset menu.
DELETE
Press to delete a
selected item.
SELECT
Press to select a menu
item or save a setting.
CANCEL
While in a menu, press
to cancel an operation
and exit the menu.
LOWER
VSP608

7
Quick Reference Guide
Deskset overview
SPEED DIAL KEYS
Press to dial the desired speed dial
number.
LOWER
When assigning or dialling a speed
dial number, press to switch to
the lower lcation (the second 16
locations) of a speed dial key.
MIC
INTERCOM
Press to display the intercom list.
INT. ALL
Press to start an intercom call to all other
cordless desksets and handsets.
MUTE
During a call, press to mute the microphone.
HEADSET
When a corded headset is connected, press
to make, answer or hang up a call.
VOL pq
• During a call, press to adjust the
listening volume.
• During message playback, press to
adjust the playback volume.
• When the phone is idle, press to
adjust the ringer volume.
SPEAKER
Press to turn the speakerphone on or off.
LOWER
VSP608

8
Deskset Installation
This section assumes that your network infrastructure is established and that your
IP PBX phone service has been ordered and congured for your location.
Deskset installation involves both the backup battery and the deskset. The deskset
is powered using the supplied power adapter. The deskset can be placed on a at
surface or mounted on a wall.
Avoid placing the deskset too close to:
• Communication devices such as television sets, DVD players, or other cordless
telephones
• Excessive heat sources
• Noise sources such as a window with trafc outside, motors, microwave ovens,
refrigerators, or uorescent lighting
• Excessive dust sources such as a workshop or garage
• Excessive moisture
• Extremely low temperature
• Mechanical vibration or shock such as on top of a washing machine or work bench
Installing the backup battery
Install the backup battery as shown below. In the event of a power failure, the
charged backup battery allows the deskset to operate. The backup battery will be
charged when you connect the AC power adapter to a wall outlet not controlled by a
wall switch.
1. Press down on the tab to open the battery compartment cover.

9
2. Place the battery in the compartment. Make sure the supplied battery with the
label THIS SIDE UP faces up, as indicated.
3. Align the cover at against the battery compartment, then press down until it
clicks into place.
IMPORTANT INFORMATION
• Use only the supplied rechargeable battery or replacement battery.
• If you do not use the deskset for a long time, disconnect and remove the battery
to prevent possible leakage.
Battery charging
Once you have installed the battery, the screen indicates the battery status (see
the table below). The backup battery is fully charged after 16 hours of continuous
charging.
The following table summarises the battery charge indicators and actions to take.
Battery indicators Battery Status Action
The screen shows Low
battery and ashes.
Battery has enough
charge to be used for a
short time.
Charge without
interruption (at least 30
minutes).
Full battery icon ( )
appears.
Battery is charged. To keep the battery
charged, place it in the
charger when not in use.
BatteryPack BT166342/BT263342 2.4V300mAh Ni-MH WARNING:DONOT BURN OR PUNCTUREBATTERIES
MADEIN CHINA GY1224
Battery Pack
BT166342/BT263342
2.4V 300mAh Ni-MH
WARNING:DO NOT BURN OR
PUNCTURE BATTERIES
MADE IN CHINA GY1224

10
Installing the deskset
1. Install the mounting bracket for tabletop use.
Low tabletop position: Insert the xed tabs of the mounting bracket into slots A
and B. Press the exible tabs into slots Cand Duntil they click into place.
High tabletop position: Insert the xed tabs of the mounting bracket into slots A
and B. Press the exible tabs into slots Cand Duntil they click into place.
CD
A B
B A
CD
Low tabletop position
D
B
B A
CD
High tabletop position
D
B

11
2. Connect the coiled handset and the power cord to the deskset.
IMPORTANT INFORMATION
1. Use only the power adapter supplied with this product.
2. The power adapter is intended to be correctly oriented in a vertical or oor
mount position. The prongs are not designed to hold the plug in place if it is
plugged into a ceiling, under-the-table or cabinet outlet.
Plug the large end of the
power adapter into a power
outlet not controlled by a
wall switch.
Raise the antenna for
optimum wireless range
and performance.
Plug the small end of the
power adapter into the
power jack at the bottom of
the deskset.
Route the power adapter
cord through the slot at the
bottom of the deskset.
Plug the end of the
coiled handset cord into
the jack at the bottom of
the deskset.

12
Wall mounting the deskset
The deskset is ready for tabletop use. If you want to mount the deskset on a wall,
make sure you rst unplug the power adapter from the electrical outlet.
To mount the deskset on the wall:
1. Place your corded handset aside. Use a coin to rotate the handset tab 180
degrees. The protruding edge holds the corded handset when the deskset is
mounted on the wall.
2. Press in the direction indicated by the arrows to release and remove the
mounting bracket from the deskset.
3. Place the corded handset back to the deskset. Plug the small end of the power
adapter cord into the power jack on the back of the deskset.
4. Align the wall mounting holes on the back of the deskset with the tabs of the
standard wall plate. Push the deskset down until it clicks securely in place.
5. Plug the large end of the power adapter into an electrical outlet not controlled by
a wall switch.
Protruding edge
Handset tab
Low tabletop position High tabletop position

13
Adding a corded headset
You can use this deskset hands-free when you install any industry-standard 2.5 mm
corded telephone headset (purchased separately).
Registering the deskset to the base
The deskset must be registered to the base station in order to make and receive calls.
To register the deskset:
1. Make sure both the deskset and the base station is connected to power.
2. On the base station, press the HANDSET LOCATOR button for at least four
seconds, then release the button. Both LEDs on the
base station begin to ash slowly.
3. Press the #key on the deskset to begin registration. The
process takes up to 10 seconds to complete.
When the rst deskset registers, it beeps and the screen
displays DESKSET n(the number ndepends on how many devices are already
registered to the base).The deskset is ready to use.
If the deskset fails to register, it displays Registration failed. Try again. Wait for a
few seconds and repeat the registration procedure.
Deregistering the deskset
Before using the deskset with a different base station, you must deregister the
deskset from the base station to which it is currently registered.
To deregister the deskset:
1. Press MENU on the deskset. The Main Menu appears.
2. Press qto scroll to User settings and then press SELECT.
3. Press qto scroll to Registration and then press SELECT.
4. Press qto highlight Deregistration and then press SELECT.
The deskset screen displays a list of devices registered to the base.
Plug a 2.5 mm headset into
the HEADSET jack on the side
of the deskset.

14
5. Highlight the name of the deskset you want to deregister, and then press SELECT.
6. On the deskset, enter the System PIN and then press SELECT to begin
deregistration. The default PIN is 0000.
The deregistration process takes up to 10 seconds to complete. When the
deskset deregisters, it beeps and the screen displays Handset is deregistered,
followed by the registration instructions.
Note: The deskset enters an energy-saving charging mode after being deregistered.
All cordless telephone functions except deskset-battery charging are disabled.
Energy-saving charging mode is deactivated after the deskset registers to the base
station.
Screen icons
The following screen icons indicate your phone’s current status:
Icon Status
Indicates signal strength, from one bar (weak) to four bars (strong).
Flashes when out of range.
Indicates battery strength from 1/3 to 3/3. Flashes when empty.
The ringer is off.
Headset—audio is coming through a headset after the HEADSET key
was pressed.
Speakerphone—the speakerphone is active.
Microphone is muted.
FWD Call Forward All is on.
DND Do Not Disturb is on.

15
Maintenance
Taking care of your telephone
• Your base station and cordless deskset contain sophisticated electronic parts,
so you must treat them with care.
• Avoid rough treatment.
• Place the handset down gently.
• Save the original packing materials to protect your products if you ever need to
ship them.
Avoid water
• You can damage your cordless telephone if it gets wet. Do not use the handset
in the rain, or handle it with wet hands. Do not install the base station and
deskset near a sink, bathtub or shower.
Electrical storms
• Electrical storms can sometimes cause power surges harmful to electronic
equipment. For your own safety, take caution when using electric appliances
during storms.
Cleaning your telephone
• Your products have a durable plastic casing that should retain its luster for
many years. Clean it only with a soft cloth slightly dampened with water or a
mild soap.
• Do not use excess water or cleaning solvents of any kind.
Remember that electrical appliances can cause serious injury if used when you
are wet or standing in water. If the telephone base should fall into water, DO NOT
RETRIEVE IT UNTIL YOU UNPLUG THE POWER CORD FROM THE WALL, then
pull the unit out by the unplugged cord.
Technical Specications
RF frequency band 1881.792–1897.344 MHz
Channels 10
Operating temperature 32–122 °F (0–50 °C)
Power requirements Power adapter: 6.0 Vdc @ 600 mA
Cordless Deskset: 2.4 V 750 mAh, Ni-MH battery pack

VTech Telecommunications Ltd.
A member of THE VTECH GROUP OF COMPANIES.
VTech is a registered trademark of VTech Holdings Limited.
ErisTerminalTM is a trademark of VTech Communications Inc.
Specications are subject to change without notice.
Copyright © 2018 for VTech Telecommunications Ltd. All rights reserved.
Printed in China. Version 2, 05/18
United Kingdom
Tel: [phone]
Email: [email protected]
Website: www.ukbusinessphones.vtech.com
Middle East
Tel: [phone]
Email: [email protected]
Website: www.mebusinessphones.vtech.com
