V-ZUG CombiCooler V4000 178KNI User manual

Operating instructions
CombiCooler V4000 178KNI
Refrigerator/freezer
V-ZUG-Home
Install the app, network your appliances and
benefit from a wide range of useful functions.

Thank you for choosing to buy one of our products. Your appliance is made to high
standards and is easy to use. Nevertheless, please take the time to read these operating
instructions in order to familiarize yourself with the appliance and get the best use out of
it.
Please follow the safety precautions.
Modifications
Text, diagrams and data correspond to the technical standard of the appliance at the
time these operating instructions went to press. The right to make technical modifications
for the purpose of the further development of the appliances is reserved.
Validity
These operating instructions apply to:
Model designation Type Model number Size system
CombiCooler V4000 178KNI CCO4T-51114 51114 Euro 60
Variations depending on the model are noted in the text.
© V-ZUG Ltd, CH-6302 Zug, 2022
2

3
Table of contents
1 Safety precautions 4
1.1 Symbols used......................................................... 4
1.2 General safety precautions.................................. 4
1.3 Appliance-specific safety precautions ............... 5
1.4 Appliance installation............................................ 5
1.5 Instructions for use................................................ 5
2 Using for the first time 8
3 Appliance description 8
3.1 Construction ........................................................... 8
3.2 Operating and display elements......................... 9
4 Operation 10
4.1 Switching the appliance on ...............................10
4.2 Setting the temperature......................................10
4.3 Selecting appliance functions ...........................11
4.4 Cancelling settings..............................................11
4.5 Switching the appliance off................................11
5 Appliance functions 12
5.1 Activating/Deactivating appliance functions ..12
5.2 Description of functions......................................19
6 V-ZUG-Home 21
6.1 Conditions .............................................................21
6.2 Initial set-up...........................................................21
7 Interior fittings 22
7.1 Glass shelves and door trays ...........................22
7.2 Divider shelf..........................................................22
7.3 Drawers and covers............................................22
8 Storing food 22
8.1 How to arrange food in the appliance.............22
8.2 Shelf life of food...................................................23
8.3 Packaging and containers .................................23
8.4 ColdFresh..............................................................23
8.5 Freezing food .......................................................24
8.6 Defrosting food ....................................................24
9 Care and maintenance 25
9.1 Divider shelf..........................................................25
9.2 Drawers and glass shelves.................................26
9.3 Covers.....................................................................26
9.4 Interior.....................................................................27
9.5 Operating and display elements........................27
9.6 Door seals..............................................................27
9.7 Defrosting...............................................................27
9.8 When the appliance is not in use......................27
10 Noises and warnings 28
10.1 Operating noise ....................................................28
10.2 Warnings ................................................................28
11 Trouble-shooting 29
12 Tips and tricks 32
12.1 General information on using the appliance ...32
12.2 Notes on saving energy ......................................33
13 Technical data 33
14 Disposal 34
15 Index 36
16 Notes 38
17 Service & Support 39

4
1 Safety precautions
1.1 Symbols used
Denotes important safety precau-
tions.
Failure to observe said precautions
can result in injury or in damage to
the appliance or fittings!
Information and precautions that
should be observed.
Information on disposal
Information about the Operating In-
structions
Remove plug from mains socket /
disconnect power supply
Insert plug into mains socket / con-
nect power supply
Do not cut off or modify mains plug
Wear protective gloves
Symbol ISO 7010 W021
WARNING: Risk of fire / flammable
materials
▸ Indicates step-by-step instructions.
–Describes how the appliance reacts
to the steps taken.
▪Indicates a list.
1.2 General safety precautions
▪Read the operating instruc-
tions before using the appli-
ance for the first time.
▪This appliance can be used
by children aged 8 and above
and by persons with reduced
physical, sensory or mental
capabilities, or lack of experi-
ence and/or knowledge,
provided they are supervised
or have been instructed on
the safe use of the appliance
and have understood the haz-
ards involved. Children shall
not play with the appliance.
Cleaning and user mainten-
ance shall not be undertaken
by children without supervi-
sion.
▪If an appliance is not
equipped with a mains cable
and a plug or other means for
disconnecting from the mains
with a contact opening on
each pole complying with the
conditions of overvoltage cat-
egory III for full isolation, an
isolating device must be in-
corporated into the perman-
ently installed electrical install-
ation in accordance with the
installation regulations.
▪If the mains cable of this ap-
pliance is damaged, it must
be replaced by the manufac-

1 Safety precautions
5
turer or its Customer Services
or a similarly qualified person
in order to avoid hazard.
1.3 Appliance-specific safety
precautions
▪Children aged from 3 to 8
years are allowed to load and
unload refrigerating appli-
ances.
1.4 Appliance installation
▪The appliance must be installed by
qualified personnel only.
▪Each step must be carried out and
checked in full in the order specified.
▪Electrical connections must be carried
out by qualified personnel in accord-
ance with the guidelines and standards
for low-voltage installations and the spe-
cifications of the local electricity supply
companies.
▪A plug-in appliance may only be con-
nected to a socket outlet with earthing
contact, installed according to specifica-
tions. An all-pole mains isolating device
with 3 mm contact opening should be
provided in the house wiring system.
Switches, plug and socket devices, cir-
cuit breakers and fusible cut-outs which
are accessible after installation and
which have all-poles switching are per-
missible as isolating devices. Effective
earthing and separately installed neutral
and earth conductors ensure safe and
fault-free operation. After installation,
live parts and cables with basic insula-
tion must not be accessible. Check old
installations.
▪Refer to the identification plate for in-
formation on the required mains
voltage, current type and fuse protec-
tion.
▪All plastering, plasterboarding, wall pa-
pering and painting work is to be car-
ried out prior to installing the appliance.
▪Efficient repairs can only be guaranteed
if it is possible to de-install the complete
appliance at any time without causing
any damage.
▪Allow a 200cm² ventilation opening/
niche both top and bottom to ensure
ideal ventilation.
▪The direction of the door opening can
be changed. This requires the corres-
ponding hinge and panel covers (de-
pending on model). Thickness of wood
of door leaf: 16–20mm. Use the hinge
bolts supplied if the door leaf thickness
>19mm. This restricts the opening
angle to 90°.
1.5 Instructions for use
Before using for the first time
▪The appliance must be installed and
connected to the electricity supply in
accordance with the separate installa-
tion instructions. Have a qualified fitter/
electrician carry out the necessary
work.
▪Electrical safety (protection against con-
tact) must be ensured by the installa-
tion.
▪If the appliance is visibly damaged, do
not use it. Contact our Customer Ser-
vices. Do not use the appliance if the
cold circuit is damaged.
▪WARNING: The required room volume
for the appliance is at least 1m3per
8g refrigerant (isobutane R600a). In
rooms that are too small, a leak can
produce a flammable air-gas mixture.
The filled volume of the refrigerant is
shown on the identification plate.
▪WARNING: When installing the appli-
ance, ensure the mains cable is not
trapped or damaged.

1 Safety precautions
6
▪WARNING: Do not locate multiple port-
able socket-outlets or portable power
supplies at the rear of the appliance.
▪Avoid using extension cables.
▪When installed, it is important to ensure
that the air inlets and vent openings are
not covered or blocked.
▪Retain these operating instructions for
future reference.
▪Operating instructions for the appliance
can be downloaded from
www.vzug.com.
▪Dispose of the packaging material in
accordance with local regulations.
Correct use
▪The appliance is designed for use in
the home for cooling and storing food.
The appliance must only be used as de-
scribed in the operating instructions.
▪This appliance is intended for use in the
home and similar settings such as: in
staff kitchens; in shops or offices; in ag-
ricultural establishments; by guests in
hotels, motels and other accommoda-
tion establishments; in bed and break-
fast establishments. This appliance is
not intended for use in the commercial
sector.
▪The appliance corresponds to recog-
nized technology standards and the rel-
evant safety regulations. Proper use of
the appliance is essential to avoid dam-
age and accidents. Please therefore fol-
low the precautions given in these oper-
ating instructions.
▪No liability is assumed for any damage
caused by improper or incorrect use or
by repairs carried out by an unqualified
person. In this case any warranty or
other liability claims are deemed null
and void.
▪Any repairs, modifications or manipula-
tions to the appliance, especially any
electrically live parts, may only be car-
ried out by the manufacturer, its Cus-
tomer Services or a similarly qualified
person. Repairs if carried out incorrectly
may cause serious injury, damage to
the appliance and fittings, as well as af-
fect the functioning of the appliance. If
the appliance is not working properly or
in case a repair is needed, follow the in-
structions given in the «Service & Sup-
port» section. Contact our Customer
Services if necessary.
▪Use original spare parts only.
Climate class
This appliance is intended for use in a lim-
ited ambient temperature range to ensure
proper operation. Information for the ap-
plicable climate class can be found on the
identification plate.
Climate class Ambient temperature
SN +10 °C to +32 °C
N +16 °C to +32 °C
ST +16 °C to +38 °C
T +16 °C to +43 °C
SN-ST +10 °C to +38 °C
SN-T +10 °C to +43 °C
Note on use
▪Do not operate any electrical devices
inside the refrigerator compartment
and/or freezer compartment.
▪High-proof alcohol should only be
stored tightly sealed and standing up-
right. Do not store explosive materials
or aerosol cans in the appliance.
Danger of explosion!
▪This appliance is CFC- and FC-free and
contains small quantities of the environ-
mentally friendly, but flammable refriger-
ant isobutane (R600a). When handling
the appliance take care not to damage
the cooling circuit. Any refrigerant that
escapes can ignite. If it were to become
damaged, avoid open flames and other
ignition sources as isobutane is flam-
mable. Ventilate the room well for a few
minutes. Switch the appliance off and
disconnect from the power supply. Do
not turn on any power supplies. Notify
our Customer Services.

1 Safety precautions
7
Caution: Risk of injury!
▪Be careful not to put fingers in the door
hinges. as there is otherwise a risk of
injury if the appliance door is moved.
Particular care should be taken when
children are around.
▪Cut the power going to the appliance
before cleaning. Pull out the mains plug
or switch off the fuse. Never pull the
mains plug out of the mains socket by
the cable or with wet hands. Hold the
mains plug and pull it straight out of the
mains socket.
▪Avoid prolonged skin contact with
frozen food. Never consume frozen
food or ice cubes that are straight out
of the freezer compartment or too cold.
Risk of burns from freezing!
▪Do not remove the evaporation tray on
the compressor. Fire hazard!
▪Do not place bottles or cans of drink in
the freezer compartment. Especially
those containing carbonated drinks can
burst during freezing.
Caution: Risk to life!
▪Packaging materials, e.g. plastic film
and polystyrene, can be dangerous for
children. Danger of suffocation! Keep
packaging material away from children.
▪When carrying out maintenance work
on the appliance, including replacing
light bulbs (if how to remove them is
described in the Operating instructions),
cut off the electricity supply to the appli-
ance: remove the screw fuse from the
holder or switch the circuit breaker off,
or unplug from the mains socket.
How to avoid damaging the appliance
▪Clean the appliance just with water or a
mild soapy solution (water and washing-
up liquid).
▪Do not use pointed or sharp objects to
remove layers of ice or frozen-on food.
▪No mechanical or chemical aids other
than those recommended may be used
to speed up defrosting.
▪Store oils and fats upright in closed
containers. They must not come into
contact with the plastic parts or the
door seal.
Transport
Transport the appliance in an up-
right position only! Transporting it in
any other position will result in dam-
age to the appliance!

2 Using for the first time
Before operating the newly installed appliance for the first time, the following steps
should be taken:
▸ Remove packaging and transport materials as well as any protective film from the in-
terior.
▸ Clean the interior and accessories with lukewarm water or a mild soapy solution (wa-
ter and washing-up liquid) and dry thoroughly.
▸ Check that all appliance door seals are completely dry and dry them if necessary.
▸ Wait for 2 hours before switching the appliance on.
3 Appliance description
3.1 Construction
The direction in which the door opens can be changed. Please contact our Cus-
tomer Services if necessary.
6
D
12
4
4
3
2
4
5
1
13
C
B
8
7
A
11
8
9
8
10
Temperature zones
ARefrigerator compartment
BUnfrozen compartment
CColdFresh
DFreezer compartment / Second re-
frigerator compartment
Equipment
1Door tray with cover
2Door trays
3Door tray with bottle holder
(bottles up to max. 1.5litres)
4Temperature sensor
5Refrigerator compartment door
6Freezer compartment door
7Freezer compartment drawers
8LED illumination
9Humidity control on cover of Cold-
Fresh temperature zone
10 Divider shelf
11 Glass shelves
12 Split glass shelf
13 Operating and display elements
Identification plate with serial num-
ber (SN)
8

3 Appliance description
3.2 Operating and display elements
Buttons
Function buttons
Settings
Fast cooling/freezing
Timer
Temperature setting
Navigation buttons
Navigation arrow pointing up/left; adjust value
Navigation arrow pointing down/right; adjust value
Confirm entry
BACK: Cancel or discard entry; ON/OFF (hold depressed for 3 seconds)
Display elements
Functions User settings
MonoFridge Display brightness
SilentPlus Switch off button tone
PartyCooling V-ZUG-Home
Holiday function Temperature unit
Sabbath mode
Value and status display
Unfrozen compartment / ColdFresh / Freezer compartment
Freezing zone active
Fast cooling/freezing active
9

4 Operation
4 Operation
4.1 Switching the appliance on
▸ Plug in the appliance at the mains socket.
–«OF» appears on the left- and right-hand side of the display for 30 seconds.
▸ Hold the button depressed for 3 seconds.
–The appliance is switched on.
A newly installed appliance takes around 13 hours (empty state / without any food
inside) to reach normal operating temperatures. The corresponding zones con-
tinue to flash in the display until the temperatures are reached.
4.2 Setting the temperature
Setting range
The required temperature for each zone is entered one after the other.
Temperature zone Degrees Celsius [°C] Fahrenheit [°F]
Unfrozen compartment Setting range 3 to 8 38 to 46
Recommended setting 5 41
ColdFresh Setting range 0 to 3 32 to 37
Recommended setting 1 34
Freezer compartment Setting range -24 to -14 -11 to 6
Recommended setting -18 0
Second refrigerator com-
partment (MonoFridge
is activated)
Setting range 2 to 14 36 to 57
If the freezer compartment is used as a second refrigerator compartment (MonoFridge
is activated), the temperature in the unfrozen compartment and in the ColdFresh temper-
ature zone is set at 5°C (41°F) and 1°C (34°F) respectively.
If the temperature in the ColdFresh temperature zone is set at 0°C (32°F), de-
pending on what is being stored, cold damage can occur.
Procedure
▸ Open the refrigerator compartment door.
–The selected set temperature values are displayed for 5 seconds: the temperature
of the unfrozen compartment alternates with that of the ColdFresh temperature
zone on the left-hand side of the display
–and then the actual temperature values are displayed.
▸ Touch the , or button.
–The temperature display for the unfrozen compartment flashes on the left-hand side
of the display.
▸ Touch the or button and select the desired temperature for the unfrozen com-
partment.
10

4 Operation
▸ Confirm with the button to accept the entry.
–The temperature display for the ColdFresh temperature zone flashes on the left-
hand side of the display.
▸ Touch the or button and select the desired temperature for the ColdFresh tem-
perature zone.
▸ Confirm with the button to accept the entry.
–The temperature display for the freezer compartment flashes on the right-hand side
of the display.
▸ Touch the or button and select the desired temperature for the freezer com-
partment.
▸ Confirm with the button to accept the entry.
–The temperature setting has been entered successfully.
–The temperature will be reached in a few hours, depending on the setting.
The effective temperature may at times be different from the selected set value if
the door is open for an extended period of time or if warm food has been placed
inside.
4.3 Selecting appliance functions
▸ Touch the / / / function button.
–The corresponding settings level is called up.
▸ Select appliance functions using the and navigation arrows (see page 12).
If a button is touched that has no function in the particular context, a double
acoustic signal is emitted and «- -» is shown on the left-/right-hand side of the dis-
play.
4.4 Cancelling settings
Settings can be cancelled or discarded in one of four ways, such that any changed val-
ues are not accepted.
▸ To cancel or discard a setting, the following options are available:
▪Wait 30 seconds without interaction.
▪Touch the active function button / / / again.
▪Touch the button.
▪Close the refrigerator compartment door.
4.5 Switching the appliance off
▸ Hold the button depressed for 3 seconds.
–The appliance is switched off.
–«OF» is shown on the left- and right-hand side of the display for 30 seconds.
If the appliance is being taken out of operation, e.g. for repair work or disposal:
▸ Remove the mains plug from the mains socket.
▸ When not in use for an extended period of time: Empty and and clean the appliance.
Leave the refrigerator and freezer compartment doors open.
11

5 Appliance functions
5 Appliance functions
5.1 Activating/Deactivating appliance functions
Function Description
Temperature set-
ting
Temperature selection for the zones
▸ Follow the instructions in the «Setting the tem-
perature» section (see page 10).
Timer Acoustic alarm emitted when the selected duration (from 0 hours
05 minutes to 9 hours 55 minutes) is up.
Activating ▸ Touch the button.
▸ Adjust the hours on the left-hand side of the dis-
play using the / buttons.
▸ Confirm with the button.
▸ Adjust the minutes on the right-hand side of the
display using the / buttons.
▸ Confirm with the button.
–The timer starts.
–The countdown to the duration remaining is
shown in the display.
Acknowledge
alarm
–An acoustic alarm is emitted when the timer
is up.
▸ Touch any button.
–The alarm stops.
Deactivating
before time
▸ Touch the button.
–The timer is deactivated.
or
▸ Touch the button.
▸ Touch the button repeatedly until «0h» is
shown on the left-hand side of the display.
▸ Confirm with the button.
▸ Touch the button repeatedly until «00» is
shown on the right-hand side of the display.
▸ Confirm with the button.
–The timer is deactivated.
12

5 Appliance functions
Function Description
Fast cooling/
freezing
Preparing the refrigerating zones ideally for loading food and food
items after a shopping trip.
Activating ▸ Touch the button.
▸ Select the refrigerator or freezer compartment
using the / buttons.
▸ Confirm with the button.
–The function is activated.
– is shown in the display.
Deactivating ▸ Touch the button.
▸ Select the refrigerator or freezer compartment
using the / buttons.
▸ Confirm with the button.
–The function is deactivated.
– is no longer shown in the display.
Setting Accessing the functions and
user settings
For more information: Description of functions (see page 19).
Selecting ▸ Touch the button.
▸ Select the desired function or user setting
(flashing) using the / buttons.
▸ Confirm with the button.
–The selection is accepted or additional set-
tings are required.
▸ See the following detailed description for the in-
dividual functions and user settings.
13

5 Appliance functions
Function Description
MonoFridge The freezer compartment operates as a second refrigerator com-
partment, a cold storage compartment (2 °C) or a cellar compart-
ment.
Activating ▸ Touch the button.
– flashes in the display.
▸ Confirm with the button.
▸ Confirm the temperature for the unfrozen com-
partment of 5°C (41°F) using the button if
necessary.
▸ Confirm the temperature for the ColdFresh tem-
perature zone of 1°C (34°F) using the
button if necessary.
▸ Adjust the temperature for the freezer compart-
ment or now newly defined as a second refri-
gerator compartment using the / but-
tons.
▸ Confirm with the button.
–The function is activated and shown in the
display.
– is no longer shown in the display.
Deactivating ▸ Touch the button.
– flashes in the display.
▸ Confirm with the button.
▸ Adjust the temperature for the freezer compart-
ment using the / buttons.
▸ Confirm with the button.
–The function is deactivated and no longer
shown.
– is shown in the display.
14

5 Appliance functions
Function Description
SilentPlus Noise-reduced operation
Activating ▸ Touch the button.
▸ Touch the button repeatedly until flashes
in the display.
▸ Confirm with the button.
▸ Adjust the temperature for the freezer compart-
ment using the / buttons if necessary.
▸ Confirm with the button.
–The function is activated and shown in
the display.
Deactivating ▸ Touch the button.
▸ Touch the button repeatedly until is
shown in the display.
▸ Confirm with the button.
–The function is deactivated and no longer
shown in the display.
PartyCooling Operation with increased cooling capacity
Activating ▸ Touch the button.
▸ Touch the button repeatedly until flashes
in the display.
▸ Confirm with the button.
▸ Select the desired duration (12, 24 or 48 hours)
using the / buttons.
▸ Confirm with the button.
–The function is activated and shown in
the display.
Deactivating ▸ Touch the button.
▸ Touch the button repeatedly until is
shown in the display.
▸ Confirm with the button.
–«OF» is shown in the display.
▸ Confirm with the button.
–The function is deactivated and no longer
shown in the display.
15

5 Appliance functions
Function Description
Holiday function Reduced cooling capacity for the refrigerator compartment (14
°C). The freezer compartment remains at the set temperature
value.
Activating ▸ Touch the button.
▸ Touch the button repeatedly until flashes
in the display.
▸ Confirm with the button.
–The function is activated and «- -» is
shown in the display instead of the refriger-
ator compartment temperature.
Deactivating ▸ Touch the button.
▸ Touch the button repeatedly until is
shown in the display.
▸ Confirm with the button.
–The function is deactivated and no longer
shown in the display.
Sabbath mode The illumination does not change when the door is opened, the
timer and alarms are temporarily deactivated.
Activating ▸ Before the Sabbath begins, touch the button.
▸ Touch the button repeatedly until flashes
in the display.
▸ Confirm with the button.
▸ Select the desired duration (30, 54 or 78 hours)
using the / buttons.
▸ Confirm with the button.
–The function is activated. The display,
visual and acoustic warnings are turned off.
– is no longer shown in the display after a
minute or after the refrigerator compartment
door is closed.
Deactivating ▸ Hold the button depressed for 3 seconds.
–The function is deactivated; the illumina-
tion and display are switched on.
16

5 Appliance functions
Function Description
V-ZUG-Home Interaction with the appliance via the app (see page 21).
Activating ▸ Touch the button.
▸ Touch the button repeatedly until flashes
in the display.
▸ Confirm with the button.
▸ Touch the / button repeatedly until «On»
appears in the display.
▸ Confirm with the button.
–The connection to is activated and shown
in the display.
▸ Follow the instructions in the app.
Resetting the
connection ▸ Touch the / button repeatedly until «rS»
(reset) appears in the display.
▸ Confirm with the button.
Deactivating ▸ Touch the button.
▸ Touch the button until appears in the dis-
play.
▸ Confirm with the button.
▸ Touch the / button repeatedly until «OF»
appears in the display.
▸ Confirm with the button.
–The function is deactivated and no longer
shown in the display.
Display bright-
ness
Adjusting the level of brightness for the display
Selection ▸ Touch the button.
▸ Touch the button repeatedly until flashes
in the display.
▸ Confirm with the button.
▸ Select the desired level of brightness (1/2/3)
using the / buttons.
▸ Confirm with the button.
–The setting is accepted.
17

5 Appliance functions
Function Description
Switch off button
tone
Switching the button tone on/off
Activating ▸ Touch the button.
▸ Touch the button repeatedly until flashes
in the display.
▸ Confirm with the button.
–The setting is activated and shown in the
display.
–The button tone is switched off.
Deactivating ▸ Touch the button.
▸ Touch the button repeatedly until is
shown in the display.
▸ Confirm with the button.
–The setting is deactivated and no longer
shown in the display.
–The button tone is switched on.
Temperature unit Switching the unit of temperature.
°C / °F ▸ Touch the button.
▸ Touch the button repeatedly until
flashes in the display.
▸ Confirm with the button.
Demo mode* This setting enables specialist retailers to put the appliance into
the showroom mode for demonstration purposes. The demo
mode enables functions to be demonstrated without the appli-
ance being switched on.
Note(*): This setting is not recommended for private use because
no cooling takes place in the refrigerator.
Activating The demo mode can only be turned on when the
appliance is switched off.
▸ Hold the button depressed and at the
same time long press the button.
–The demo mode is activated.
– is shown in the display.
Deactivating The demo mode can only be turned off when the
appliance is switched off.
▸ Hold the button depressed and at the
same time short press the button.
–The demo mode is deactivated.
– is no longer shown in the display.
18

5 Appliance functions
5.2 Description of functions
MonoFridge
In the MonoFridge mode, the freezer compartment is operated as a second refrigerator
compartment with a setting range of 2–14°C.
Prior to activating the MonoFridge, relocate food and food items that by changing the op-
erating mode can be spoiled through freezing or defrosting. It takes several hours to
reach the newly set temperature. Leave the door of the second refrigerator compartment
closed during this time. For the second refrigerator compartment, the fast freezing func-
tion changes to fast cooling.
At a setting temperature of 2 °C, the conditions for a cold storage compartment are sat-
isfied. Suitable foods can be stored in it for up to three times longer than in a standard
refrigerator compartment.
Since food spoils quicker through the transmission of germs, animal and vegetable
foodstuffs should be stored separately from each other. If such foodstuffs have to
be stored together in a drawer for reasons of space, it is recommended they be
stored covered or packaged.
At a setting temperature of between 10°C and 14°C, beverages can be chilled at
a pleasant drinking temperature. The temperatures are also ideal for storing trop-
ical fruits (e.g. pineapples, mangoes), potatoes and fruit vegetables (e.g. cucum-
bers, aubergines, tomatoes, courgettes, sweet peppers).
SilentPlus
This operating mode is designed to produce low noise emissions. The energy consump-
tion of the appliance may be slightly increased. Since the appliance is quiet during nor-
mal operation, the effect of SilentPlus is particularly perceptible at higher ambient tem-
peratures. In addition, the appliance reacts to the door being frequently opened or warm
food being loaded in a particularly noise-optimized way in the SilentPlus mode compared
to normal operation. SilentPlus is temporarily interrupted while PartyCooling and fast
cooling/freezing are running. The setting range of the temperature zones is limited
through SilentPlus.
PartyCooling
PartyCooling temporarily provides generally increased cooling capacity whereby the tem-
perature of the unfrozen compartment is lowered to the coldest value. This also applies
to the second refrigerator compartment when in the MonoFridge mode. The appliance
can thus react better to the effect of opening the door frequently and loading warm food.
This increases the noise emissions and energy consumption of the appliance. PartyCool-
ing can be set to run 12, 24 or 48 hours. SilentPlus is interrupted for the duration for ap-
plication-related reasons.
Fast cooling/freezing
The fast cooling/freezing functions allow larger quantities of food, e.g. after a shopping
trip or freezing pre-cooked meals, to be cooled more quickly. The temperature of the un-
frozen compartment is lowered to the coldest value for 24 hours and similarly the tem-
perature of the freezer compartment is lowered to the coldest value for 54 hours. The
ColdFresh temperature zone continues to operate at the selected set temperature. The
SilentPlus function is interrupted for the duration for application-related reasons.
19

5 Appliance functions
During fast cooling/freezing, the appliance operates at higher power, which increases the
noise level above the normal operating noise level. Both functions switch off automatic-
ally. The fast freezing function is turned off when the MonoFridge mode is activated and
can be reactivated as fast cooling in the second refrigerator compartment for 24 hours.
To prevent food that is already being stored from warming up: activate fast cooling/freez-
ing several hours beforehand (e.g. before going shopping).
To achieve maximum freezing capacity, the following must be observed: To freeze the
maximum quantity (see the identification plate), use the bottom freezer compartment
drawer and activate fast freezing at least 24hours before storing the fresh food (pre-
freezing). Transfer already frozen food to the upper freezer compartment drawers. Distrib-
ute the food to be frozen evenly in the bottom freezer compartment drawer. Do not place
any more food for freezing in the freezer compartment for the next 24 hours during the
freezing process.
When a smaller quantity of food is to be frozen, the pre-freezing time may be
shortened.
Fast freezing does not need to be activated if storing food that is already frozen or
freezing up to about 1kg of fresh food a day.
Holiday function
With the holiday function, only the freezer compartment is operated at the selected set
temperature. For hygiene reasons, the refrigerator compartment operates at a temperat-
ure of about 14°C. Close the refrigerator compartment door.
The holiday function is not intended to be used for the purpose of storing food in the un-
frozen compartment or the ColdFresh temperature zone.
Sabbath mode
When the Sabbath mode is activated, all visual and acoustic warnings as well as operat-
ing and display elements are turned off for the selected duration (30, 54 or 78 hours).
Opening the appliance door will not affect the illumination or the behaviour of the appli-
ance. The illumination in the refrigerator compartment can be automatically activated if
the ambient temperature is low. Any timer running when the Sabbath mode is activ-
ated is ended, no acoustic signal is emitted.
The appliance doors must be closed firmly as the visual and acoustic warnings are
turned off!
When the Sabbath mode is activated, no error messages are displayed and no
warnings are given. In certain circumstances, the appliance switches to the emer-
gency mode or cannot maintain the refrigerating temperatures for other reasons.
Check the quality of the food. Do not eat food that has thawed!
Risk of food poisoning.
V-ZUG-Home
This function is available for specific countries.
With V-ZUG-Home, you can access your appliances over the V-ZUG App to, for instance:
▪query the appliance status
▪receive push notifications
▪change appliance settings
▪receive software updates.
20
