VACOM WIRELESS VS-5L User manual

1
USER MANUAL
VS-5L
Version 0.1
VACOM WIRELESS, INC.

2
CONTENTS
IMPORTANT SAFETY INFORMATION
GETTING TO KNOW YOUR PHONE
DISPLAY INDICATORS
BATTERY INFORMATION
BASIC FUNCTIONS
1. Making Calls
2. Ending Calls
3. Answering Calls
4. Correcting Entry Errors
5. Storing Phone Numbers
6. Adjusting In-Call Mic Volume
7. Volume
8. Using Caller ID
9. Redialing Last Dialed, Received, or Missed Number
10. Speed Dial
11. Keypad Lock
12. Etiquette Mode
13. Silence Mode
14. Shortcut
MENUS
I. PHONEBOOK
1. Phone Book Search
2. Phone Number Addition
3. Call List
4. My Number
5. Delete Phone Book

3
II. PHONE SETTINGS MENU
1. Wallpaper
2. Languages
3. Selecting Font
4. Backlight
5. LCD Contrast
6. Screen Saver
7. Auto Keylock
III. VOLUME & ALERT
1. Ring Type
2. Selecting Bell
3. Roam Ringer
4. Volume
5. Alert Setting
6. Beep Length
IV. PERSONAL INFORMATION MANAGEMENT
1. Alarm
2. Schedule
3. Calendar View
4. Calculator
5. Memo
6. World Time View
V. SECURITY FUNCTIONS
1. Phone Lock
2. Changing Password
3. Restricting
4. Privacy Information
5. Initialization
VI. CALL INFORMATION
1. AutoAnswer
2. Call Answer
3. Auto Redial
4. Call Time

4
VII. GAMES
1. Black Jack
2. Othello
3. Game Sound
MESSAGE SERVICES
I. TEXT MESSAGE SERVICES (SMS)
1. Reading Text Messages
2. Sending Text Messages
II. VOICE MAIL SERVICE
III. SMS Settings
1. Alert
2. Save Message
3. Direct View
4. DeliveryACK
5. Priority
6. Delete All
USING MENU DURING CALLS
1. Phone Book Search
2. Mute
3. DTMF Mute
4. Volume
5. Mic Volume
6. Voice Privacy

5
IMPORTANT SAFETY INFORMATION
Some of the following information may not apply specifically to your phone. However, as with
any electronic product, these safety precautions should be observed when using this product.
?Please keep this manual in a safe place, for it contains important safety information and
operating instructions.
?Please follow and adhere to all warning, safety, and operating instructions indicated on both
the phone and in this manual before use.
?Do Not expose the phone to water or moisture.
?Do Not expose the phone to extreme heat or cold.
?Do Not expose the phone to open flame.
?Do Not allow objects to fall or liquids to spill on the product.
?Use Original Accessories only. Any damage incurred from the use of non-approved
accessories will void the warranty.
?Use approved chargers only and connect to a power source designated on the product.
?To reduce the risk of injury, remove the electrical cord from an outlet by pulling on the
charger, rather than the cord.
?Ensure that the electrical cord is positioned accordingly so that it will not be vulnerable to
damage.
?To reduce the risk of electrical shock, unplug the phone from the power source before
cleaning. Once unplugged, use a soft cloth dampened with water to clean.
?DANGER: Do Not modify the cord or the plug. If the plug does not fit into an outlet,
have a proper outlet installed by a qualified electrician. Improper connection can result in
electrical shock.
?Do Not attempt to disassemble the product –doing so will void the warranty. This product
does not contain consumer-serviceable components. Service should be performed only by
authorized service centers.
?Do Not remove the antenna. A detached antenna can be a choking hazard for children.
?Do Not place the battery inside the mouth. The battery contains toxic electrolytes that are
harmful for your health.

6
GETTING TO KNOW YOUR PHONE
LED Indicator
: Flashes to indicate an incoming call or message. It also lights
up (flashes) when you turn on the phone.
Backlit LCD Screen
: The LCD screen contains three areas;
-The top line displays indication about your phone’s
operating mode.
-Two lines in the middle are the display areas for numbers
and characters.
-The bottom line displays menus.
Menu Keys ( / )
: This key performs several useful functions.
-During incoming calls, press it to answer the incoming
call.
-In Standby mode, press it briefly to access Main Menu
and Select Menu.
-When navigating a menu, press it to select the highlighted
selection.
SMS Key ( )
: When in Standby Mode, press this key to access Message
Menu items.
Navigation Key (??)
: This key allows you to navigate the phone’s variable
functionality and useful shortcut.
Microphone
: Your typical voice microphone for conversation and you can
also mute the microphone during conversation by pressing
“MENU”“2”.
DC Jack
: The location where you connect your charging device.
CLR Key
: This key is used to erase numbers or characters you may have
entered incorrectly, or to return to a previous screen.
-To erase one character from the display screen, briefly
press it once.
-To erase all of them, hold it for one second.
-To back up one menu level, press it once.
-To return to Standby Mode, hold it for one second.
-During a call, press it to controlearpiece volume.

7
END( ) Key
: Press this key to disconnect a call or to return to Standby
Mode from any menu. Press and hold this key to turn the
phone On or Off.
SEND( ) Key
: This key performs several useful functions.
-Dial a number and press it to connect.
-Press it once to redial the last outgoing number.
Numeric Keys
: These keys are to dial and to input numbers and characters.
?*
: This key performs several useful functions.
-Change bells to vibration
-Use as navigation key.
# ?
: This key performs several useful functions.
-Use as instance phone lock.
-Use as navigation key.
Antenna

8
DISPLAY INDICATORS
Display indicators appear across the bottom of your phone’s LCD screen. These display
indicators (or icons) will vary based on your phone’s operating modes.
Signal strength : This icon shows your current signal strength. More lines
indicate more signal strength. Five lines indicate maximum strength, and one
line indicates least strength.
No service indicator : This icon indicates your phone cannot find a signal
because you’re outside a service area. When this is displayed, you cannot make
or receive calls. Wait a little while for a signal or move into an open area.
Roaming : This icon indicates you are “roaming”on to other carrier’s service
area. But you must register the roaming service.
Vibrator on : This icon means that an incoming call will vibrate the phone rather
than ring it or before/after the phone ring.
It also means that your phone is on Etiquette mode. An incoming call will
vibrate the phone rather than ring it. This feature is good for quiet situations
where you don’t want your ringer to disturb anyone.
Message indicator : This icon indicates you have message(s) waiting.
Press SMS Menu button to see the message menu, or press and hold to be
connected to voicemail.
Alarm on : This icon means that you set the alarm On.
Battery strength : This icon shows the level of your battery charge. The more
black bars you see the greater the charge. When the battery becomes very low,
an empty box appears and the phone flashes an alert.
DThis icon shows that you are in CDMA coverage area. (Cellular only)

9
BATTERY INFORMATION
The rechargeable Lithium-polymer battery included in your kit is partially charged so that you
can use the phone immediately once it has been activated.
Attaching the Battery
To attach the battery to your phone:
1. Lineup the metallic contacts on the base of the battery to the base of the phone.
2. Place the battery on the back of the phone, with the top of the battery about a quarter of
an inch from the latch.
3. Gently slide the battery towards the top of the phone until it snaps into place.
Charging the Battery
You can tell whether your battery needs to be recharged or not by checking the upper-right
corner of your phone’s display.
When the battery charge level becomes low, the battery sensor will alert you by blinking the
battery icon and making an audible warning tone. The phone will automatically power itself
off if the battery level becomes critically low, and any incoming or outgoing call will disconnect.
To avoid such disconnection, be mindful of the battery strength indicator and make sure your
battery is sufficiently charged.
Charging with a Travel Charger
Using an unauthorized accessory may be dangerous and will void the warranty if it causes
damage to the phone.
To charge the Battery using a Travel Charger:
-Plug the power cord of the charger into a wall outlet.
-Insert the charger’s connector to the DC jack of the phone.
Note) Ensure a proper connection of the charger and the phone. Incomplete connection may
cause damage to the phone.

10
A completely discharged standard sized battery charges full in approximately tbd hours.
Leaving your phone powered on during charging or charging two batteries simultaneously will
increase charge times. Leaving the battery connected to the charger after it has been fully
charged will not harm the battery.
?WARNING
After the battery is fully charged, the battery can be discharged. If the charger is
connected to your phone for over 3hrs, please pull the plug from the phone and recharge
the battery even if the battery is fully charged.
Turning your phone onand off.
When you’re ready to turn on your phone, press and hold “END( )”until the display is turned
on and the phone makes the sound. When the phone has found a signal, the “ ” icon appears.
Once the phone is turned on, it enters Standby mode and you are able to make and receive calls.
To turn your phone off, press and hold “END( )”until the display is turned off and the phone
makes the sounds. Then the display will go blank. When the phone is turned off, nothing is
displayed on screen.
Note:If “END( )”is pressed for less than one second, the phone will not be turned off. This
function prevents your phone from being turned off accidentally.
Standby Mode.
Standby is the most basic state of your phone. The phone goes into standby mode soon after you
turn it on, or whenever you briefly press “END( )”. When your phone is in Standby Mode,
you will typically see the banner (that’s the message displayed when you turn on your phone). If
you enter a phone number, you press “SEND( )”to complete the call, or press “STO ( )”to
save it in the internal phone book.
Power Save Mode
Your phone comes with a Power Save feature that will automatically be activated if your phone
is unable to find a signal after 15 minutes of searching. While this feature is active, the phone’s
battery power is conserved.

11
The phone will automatically recheck for a signal periodically. To manually force the phone to
recheck for a signal, press any key. A message on the display will let you know when the phone
is operating in Power Save Mode.
Conversation Mode.
You can place and answer calls only when your phone is turned on. During a call, the phone is
in Conversation Mode.

12
BASIC FUNCTIONS
1. Making Calls
In standby mode, enter the phone number (up to 32 digits) by pressing the digit keys. The phone
number is displayed from left to right. Press “SEND( )”. The phone places the call to the
entered phone number (if service is available).
2. Ending Calls
To end a call, press “END( )”. The call time (length of the call) will be displayed along with
the name or number of the called party (if available). The phone returns to Standby Mode
automatically.
3. Answering Calls
To answer an incoming call, press any key if “Any Key Answer”is set. (Please refer to “2. Call
Answer”in “VI. Call Information”). If your phone is registered in Caller ID, a caller’s phone
number will be displayed on screen. If caller’s number is stored in Phone Book, the caller’s
name will be displayed.
4. Correcting Entry Errors
To correct a misdialed digit, press “CLR”to erase one digit at a time. You can erase all the digits
at once by pressing “CLR”and holding it down over one second.
5. Storing Phone Numbers
Phone numbers for frequently used services are pre-programmed into your phone. To store a
number,
-Enter a phone number and press “STO ( )”. Or in standby mode, press “Menu ( )”,
“1. Phone Book”and “3. Phone NumberAddition”.
-Enter the location number you want to store in.
-Press “?”and enter the name.
-Press “?”and enter the phone number.
-Press “?”and scroll “?”or “?(*)”/ “(#)?”to choose Group type.
-Press “Sto ( )”to store.
6.AdjustingIn-Call Mic Volume
To adjust the in-call mic volume:
-Press MENU ( ) and “5.MIC Volume”.

13
-Press “?” to increase and “?” to decrease the mic volume.
Once a call has ended, the mic volume reverts back to factory set level.
7. Volume
You can adjust volume of the earpiece by using the volume keys on the side of the phone.
Briefly press the volume key once to display your current earpiece volume setting. Repeatedly
press the volume key to adjust.
To adjust earpiece volume during a call, press “??”to increase or decrease earpiece volume.
8. Using Caller ID
This feature informs you of the caller’s identification by displaying their number when the
phone rings.
If the corresponding caller’s information is already available in your Phone Book, that caller’s
name will appear on screen. Conversely, calling someone who has this feature will disclose your
number on their phone. To access the call log, press “SEND( )”.
9. Redialing Last Dialed, Received, or Missed Number
Up to 30 dialed, received, or missed can be redialed directly. Simply press “SEND( )” to:
-Access the call log of 30 call entries in chronological order.
-Then, press the “VIEW ( )”key to see the time and number of the selected call.
-Simply press “SEND( )” to redial that number.
10. Speed Dialing
Once a phone number is stored in your Phone Book, you can access and dial that number using
assigned speed dial keys.Press the location number of a stored number and hold the last digit.
The phone will then automatically connect to that number.
11. Keypad Lock
You can lock the keypad to prevent the keys being accidentally pressed, for example, when your
phone is in your pocket. You can do it by pressing “(#)?”for a second in standby mode.
12. Etiquette Mode
In social situations where audible rings, bells, or tones are inappropriate, such as in a movie
theater, at a museum, play, etc, your phone can be set on Etiquette mode. All incoming calls
under this mode will be notified by inaudible vibration. Press and hold “?*”to set the Etiquette
mode and once more to cancel.

14
13. Silence Mode
If you want to silence an incoming ring, for example, when you are in a meeting, press
“END( )”. Then the incoming ring will be silenced. Then the caller will be noticed that you
are not available to answer.
Note 1) Although the incoming ring is silenced, the call is still coming. If you want to answer,
press any keys.
Note 2) When you press “END( )” to silence the incoming ring, the caller may be able to
leave a voice message or the call may be forwarded to others, which depends on your service
provider. Please contact your service provider for available options, such as Voice mail, Call
forwarding, etc.
14. Short Cut
i. Keypad Lock : Press and hold “(#)?”for a second when it’s in Standby Mode, and the
keypad will be locked. To unlock the keypad, press “ ” and “(#)?”orderly.
ii. Etiquette Mode : Press and hold ?(*)”for a second. Then the phone will turn to
vibration m
iii. Phone Book Entry : Press “?” of navigation keys. Then all the phone numbers you
stored will be shown alphabetically.ode. To release etiquette mode, press and hold “?
(*)”again.
iv. Phone Book Entry : Press “?”of navigation keys. Then all the phone numbers you
stored will be shown alphabetically.
v. Alarm : Press “?”. Then you can set an alarm.

15
MENUS
I. PHONE BOOK
1. Phone Book Search
You can go to Phone Book list by pressing “?”to see all the phone number list you stored
alphabetically. Also you can fine a phone number according to Name, Location Number, Phone
Number or Group.
a. Search by name
You can find a number you stored in Phone Book by entering a name.
-Press “Menu ( )”, “1. Phone Book”, “1. Search” and select “1. Name”.
-Enter the name you want to call.
-If you don’t remember the full name, just enter the first letter of the name. Your phone
will show you all similar names.
-Press “SEND( )”to dial.
-Or press “View ( )”to edit or “Del( )”to delete.
b. Search by location
You can find a number you stored in Phone Book by locations.
-Press “Menu ( )”, “1. Phone Book”, “1. Search” and select “2. Speed Key”.
-Enter the location number you want to find and press “Ok”.
-Press “SEND( )”to dial. Or press “View( )”to edit or “Del( )”to delete.
-If a number is not stored in the location, “Empty Location”is shown on the display.
c. Search by Number
You can find a number’s information you stored in Phone Book by entering a phone number.
-Press “Menu ( )”, “1. Phone Book”, “1. Search” and select “3. Phone Number”.
-Enter the number you want to see and press “OK”. Then you will see the name and
location.
-Press “SEND( )”to dial. Or press “View ( )”to edit or “Del( )”to delete.
-If the number is not stored in the location, a warning tone is sounded and “No Number
Matches”is shown on the display.
d. Search by group
You can find a number you stored in Phone Book.
-Press “Menu ( )”, “1. Phone Book”, “1. Search” and select “4. Group”.
-Scroll “?(*)”or “(#)?”to select “No Group”, “Family”, “Friends”, “Business”or
“Company”.
-Once you select “No Group”, “Family”, “Friends”, “Business”or “Company”, you can

16
see the numbers you stored and defined only as “No Group”, “Family”, “Friends”,
“Business”or “Company”.
-Place the cursor on the number you want to dial by scrolling “?”and “?”.
Press “SEND( )”to dial. Or press “View ( )”to edit or “Del( )”to delete.
2. Phone Number Addition
Phone numbers for frequently used services are pre-programmed into your phone. To store a
number,
-Press “Menu ( )”, “1. Phone Book”and “2. Phone # Store”. Or you can press “STO
( )”.
-Enter the location number you want to store in.
-Press “?”and enter the name.
-Press “?”and enter the phone number.
-Press “?”and scroll “?”or “?(*)”/ “(#)?”to choose Group type.
-Press “STO( )”to store.
3. Call List
Call history, including number, time, and duration, can be referenced by:
-Pressing “MENU ( )”, “1. Phone Book”, and “3. Call List”.
A log of dialed, received, and missed calls will be displayed.
4. My Phone Number
To see your phone number, Press “Menu ( )”, “1. Phone Book”and “4: My Phone Num.”.
Then your phone number will appear on screen.
5. Delete Phone Book
If you want to clear call lists, which you missed, called, received and stored, or all in Phone
Book.
-Press “Menu ( )”, “1. Phone Book”and choose “5. Delete All”.
-Scroll “??”and choose call list you want to delete by press “OK ( )”.
-Press “OK( )”to erase.
II. PHONE SETTING
1. Wallpaper
You can have the phone display various welcome greeting on stand-by mode. To edit the

17
greeting for the display on stand-by mode:
a. Set Wallpaper Type
-Press “Menu ( )”, “2. Phone Setting”, “1. Wallpaper”and “1. Set Wallpaper”.
-Scroll “??”to selecta wallpaper and press “OK ( )”to save.
b. Greeting Edit
-Press “Menu ( )”, “2. Settings”, “1. Wallpaper”, “2. Greeting Edit”.
-Edit the banner and press “OK ( )”to set.
2. Languages
You can set the phone to 2 different languages. (Spanish, Portuguese and English).
-Press “Menu ( )”, “2. Phone Setting”and “2. Language”.
-Select “Spanish”, “Portuguese”or “English”, and press “OK ( )”to save.
3. Selecting Font
You can select a font for the display among 4 fonts
-Press “Menu ( )”, “2. Phone Setting”and “3. Font Select”.
-Scroll “??”to select a font and press “OK ( )”to save.
4. Backlight
You can set backlighting of LCD display and the keypad automatically turned off in 10, 20 and
30 seconds or set always off. To set back light;
-Press “Menu ( )”, “2. Phone Setting”and “4. Backlight”and choose “1. LCD Light”
or “2. Keypad Light”
-Select “10 seconds”, “20 seconds”, “30 seconds”or “Always Off”and press “OK
( )”to save.
5. LCD Contrast
You can adjust LCD contrast.
-Press “Menu ( )”, “2. Phone Setting”and “5. Contrast”.
-Scroll “?”and “?”to adjust LCD contrast and press “OK( )”to set.
6. Screen Saver
You can set Screen Saver of Standby mode.
-Press “Menu ( )”, “2. Phone Setting”and “6. Screen Saver”
-Scroll “??”to select a Screen Saver type.
-Press “?”and Select “After 10 seconds”, “After 30 seconds”or “After 1 minute”and
press “OK( )”to store.

18
7. Auto Keypad Lock
If you set “Auto Keypad Lock”as “Auto”, the keypad will automatically locked after 30
seconds when you don’t use.
-Press “Menu ( )”, “2. Phone Setting”and “7. Auto Keypad Lock”.
-Select “Auto”or “off”and press “OK ( )”to set.
-If you want to release the keypad lock, press “MENU ”and “(#)?”on a standby
mode.
III. VOLUME / ALERT
1. Ring Type
You can set the alert for incoming calls in 5 different ways. (Bell, Vibration, BellàVibration,
VibrationàBell, Vibration+Bell ).
-Press “Menu ( )”, “3 Vol/Alert”and “1. Ring Type
-Select “Bell”, “Vibrator”“BellàVib”, “VibàBell”or “Vib+Bell”by scrolling “??”
-Press “OK ( )”to set.
2. Selecting Bell
This option enables you to set the sound of ringing among 10 bells,10 melodies and 32 midi
sounds.
-Press “Menu ( )”, “3. Vol/Alert”and “2. Bell Select”and choose “1. Bell”,“2.
Melody”or “3. MIDI.
-Scroll “??”or “??”to select. While you scroll, you can hear bells and melodies.
-Press “OK ( )”to set.
3. Roam Ringer
This option allows you to hear a distinctive ringing when you receive a call in other carriers’
service area, which you registered for a roaming service.
-Press “Menu ( )”, “3. Vol/Alert”and “3. Roam Ringer”.
-Choose “on”or “off”and press “OK ( )”to set.
4. Volume Control
a. Bell Volume
This option allows you to set the bell volume level.
-Press “MENU ( )”, “3. Vol/Alert”, “4. Volume”, and “1. Bell Volume”.

19
-Scroll “?/?”to increase or decrease the volume level.
-Press “OK ( )”to set.
b. Key Volume
This option allows you to set the key volume level.
-Press “MENU ( )”, “3. Vol/Alert”, “4. Volume”, and “2. Key Volume”.
-Scroll “?/?”to increase or decrease the volume level.
-Press “OK ( )”to set.
c. Call Volume
This option allows you to set the earpiece volume level.
-Press “MENU ( )”, “3. Vol/Alert”, “4. Volume”, and “3. Call Volume”.
-Scroll “?/?”to increase or decrease the volume level.
-Press “OK ( )”to set.
5.Alert Setting
a. Connection Beep
This option allows you to be audibly notified when a call is connected.
-Press “MENU ( )”, “3. Vol/Alert”, “4. Alert Setting”, and “1. Connection”.
-Select between On and Off and press “OK ( )” to set.
b. Call Drop
This option allows you to be audibly notified when a call is disconnected or the other party
hangs up the phone.
-Press “MENU ( )”, “3. Vol/Alert”, “4. Alert Setting”, and “2. Drop”.
-Select between On and Off and press “OK ( )” to set.
c. 1 Minute Alert
This option allows you to be audibly warned when a call reaches the 1 minute mark.
-Press “MENU ( )”, “3. Vol/Alert”, “4. Alert Setting”, and “3. Minute”.
-Select between On and Off and press “OK ( )” to set.
d. Service
This option allows you to be audibly warned when you move into other base stations during a
call.
-Press “MENU ( )”, “3. Vol/Alert”, “4. Alert Setting”, and “4. Service”.
-Select between On or Off and press “OK ( )” to set.
6. Beep Length
DTMF tone length can be set at normal or long.
-Press “MENU ( )”, “3. Vol/Alert”, and “6. Beep Length”.
Set the beep length “Normal”or “Long”and press “OK ( )”to set.

20
IV. PERSONAL INFORMATION MANAGEMENT
Your phone supports various additional functions, including Alarm, Schedule, Calendar,
Calculator, Memo and World Time.
1. Alarm
The 24-hour alarm can be set to go off at a set time while your phone is on. If the phone is
powered off at the set time, the alarm will not sound. To set the alarm, press “MENU ( )”, “4.
PIM”, and “1. Alarm”.
-Choose “Alarm 1”or “Alarm 2”and press “OK ( )”.
-Choose from Off, Everyday, Mon~Sat, Mon~Fri, and Once Alarm by scrolling “??”.
-Press “?”and choose a Bell type by scrolling “??”.
-Press “?”and enter the time, and then select AM or PM by pressing “( )”
-Press “STO ( )”to set.
Note 1) You can set up to 2 different alarms.
Note 2)
-Disable: Once you’ve chosen Disable, the alarm will not sound even if you’ve set a
time for it.
-Everyday: Once you’ve chosen Daily, the alarm will sound at the set time everyday.
-Mon~Sat: Once you’ve chosen Mon~Sat, the alarm will sound at the set time from
Monday to Saturday.
-Mon~Fri: Once you’ve chosen Mon~Fri, the alarm will sound at the set time from
Monday to Friday.
-Once Alarm: Once you’ve chosen Once, the alarm will only sound at the set time once.
2. Schedule
The Schedule Manager option helps to manage your schedule using the phone. To set or edit a
schedule, press “MENU (?)”, “4. PIM”, and “2. Schedule”.
a. Add Schedule :
-Select “1. Add”. Calendar of the current month will then appear on the display.
-Use “??”and “??”to scroll through the days and select the date by pressing
“OK( )”
-Enter the time (hour, minute and AM/PM) and press “OK( )”
-Enter a memo under “Input Schedule”. Once you finish entering a memo, press “OK
