Apogee Jam X User manual

Jam XUser’s Guide
Version 1.0
1

Apogee Jam X User’s Guide
Contents
Contents 2
In the Box 3
System Requirements 3
Register your Product 3
Jam X Product Tour 4
Connecting Your Studio 5
Connect your instrument 5
Connect headphones or speakers 5
Connecting to a Mac or Windows computer 6
Connecting to an iPad Pro (USB-C connector) 6
Connecting to an iOS Device (Lightning connector) 7
Jam X Lights and Getting Sound 8
Installing Jam X Software 9
Windows 10 Installer 9
Configure the Computer’s OS to use Jam X for Audio I/O 10
macOS 10
Windows 11 11
Apple iOS 11
Working with Jam X 12
Blend Mode 12
Blend Off - Software Monitoring 12
Minimize Latency with Software Monitoring 13
Blend On - Direct Monitoring 13
Configuring Neural Archetype:Tim Hensen - Standalone 14
Configuring Your DAW 15
Apple Logic Pro 15
Avid Pro Tools 16
Ableton Live 17
Troubleshooting 18
Warranty Information and Legal Notices 19
Declarations of Conformity 19
2

Apogee Jam X User’s Guide
In the Box
● Jam X
● Micro-USB B to USB-A cable, 1 meter
● Micro-USB B to USB-C cable, 1 meter
● Warranty Booklet
● Product Registration Link Card
System Requirements
● macOS 10.15 or greater
● Windows 10 Anniversary update or later
● iOS 13 or greater
● Mac & Windows: 4GB minimum RAM, 8GB Recommended
Register your Product
● Receive links to free software!
○ Ableton Live Lite
○ Neural Archetype: Tim Henson Plugin Extended Trial
● Access Apogee’s expert Technical Support for free
● Receive important product update information by email
● Take the Customer Satisfaction Survey for a chance to win Apogee gear!
Register Now: https://apogeedigital.com/my-account
3

Apogee Jam X User’s Guide
Jam X Product Tour
4

Apogee Jam X User’s Guide
Connecting Your Studio
A wide range of devices, including dynamic microphones, electric instruments and keyboards,
speakers and headphones may be connected to Jam X.
Connect your instrument
Connect Hi-Z instruments such as guitar, bass, keyboards, and synthesizers to the Jam X using a ¼”
instrument cable.
● Dynamic mics with XLR plug can be connected using a Hi-Z to Low-Z transformer converter.
● Condenser microphones require a separate external 48V phantom power supply.
Connect headphones or speakers
Connect headphones to the ⅛” stereo connector.
Powered speakers can also be connected to this jack.
● Adjust the output level using the volume controls on the computer or iOS device.
5

Apogee Jam X User’s Guide
Connecting to a Mac or Windows computer
Using one of the supplied cables, connect Jam X’s Micro-USB B port to any USB-A or USB-C port on
your Mac or Windows computer.
Connecting to an iPad Pro (USB-C connector)
Using the supplied Micro-USB B to USB-C cable, connect Jam X’s to your iPad Pro’s USB-C
connector.
6

Apogee Jam X User’s Guide
Connecting to an iOS Device (Lightning connector)
Using the micro-USB B to Lightning Cable (sold separately), connect to the Lighting port on your
iPhone or iPad:
Connecting Jam X to an iPhone with Lightning connector
Connecting Jam X to an iPad with Lightning connector
7

Apogee Jam X User’s Guide
Installing Jam X Software
For Windows 10 & 11 users, download the Apogee ASIO Driver from the link below:
https://apogeedigital.com/installer-downloads
For macOS and iOS users, no software is required to connect Jam to your Mac, iPhone or iPad.
After registering your Jam X at the link below, you’ll receive links to download accessory software:
● Ableton Live Lite, a digital audio workstation;
● Neural Archetype: Tim Henson, a virtual guitar amp/FX plugin.
https://apogeedigital.com/my-account
Windows 10 Installer
1. In your Downloads folder, double-click the .zip file
to extract it, then double-click the .exe file to start
the installation process.
2. Click Next through all steps, then click Finish at
the final step.
3. You should restart your computer immediately.
8

Apogee Jam X User’s Guide
Configure the Computer’s OS to use Jam X for Audio I/O
macOS
To choose Jam X as the audio interface for Mac applications that don’t have specific audio hardware
preferences, such as Safari, Spotify, Voice Memos and others:
1. Open System Settings by choosing Apple menu > System
Settings.
2. Click the Sound icon to open the Sound Settings panel.
3. Click the Output tab, then click Jam X in the devices list.
4. Click the Input tab, then click Jam X in the devices list.
9

Apogee Jam X User’s Guide
Windows 11
To choose Jam X as the audio interface for Windows applications that don’t have specific audio
hardware preferences, such as Google Chrome, Spotify, and others:
1. Type Control Panel in the Windows search bar to open the Control Panel. Double-click the Sound
icon.
2. Click the Output section and select Speakers-Apogee Jam X.
3. Click Speakers to show the Properties of the device.
4. Ensure the Audio - “Allow apps and Windows to use this device for audio” is Allowed. When using
a DAW and apps like Spotify simultaneously, match the Default Format sample rate with the rate
of the DAW session.
5. Go back to the main System > Sound window.
6. Click the Input Section and repeat steps 2-5 for Input.
Apple iOS
Apple iOS (iPhone and iPad) automatically chooses the most recently connected audio interface as
the audio I/O device for all applications. Simply connect Jam X to your iOS device’s Lightning or
USB-C port as described on page 6-7.
10

Apogee Jam X User’s Guide
Working with Jam X
Jam X LED Functionality
Use the Jam X’s multi-color LED lights, buttons, and knob to adjust your audio signal level, monitor
settings, and compressor presets.
Jam X will display a blue LED when first connected via USB.
No sound will pass when in this standby mode.
Audio input and outputs will activate when an audio application plays through the Jam
X (such as playing Apple Music or Spotify), or attempts to record from Jam X’s ¼”
instrument input (like Garageband or Ableton Live).
When the LED is green, it will pulse with the signal level.
Use the Input Level adjustment controls to change the input settings.
Push the Blend button to toggle Blend (direct monitoring) on/off.
When Blend is on, the ¼” input signal is blended with playback from your audio app
and routed directly to the headphone/speaker output. Use this for a low-latency direct
signal that does not rely on the monitoring functions of your recording software. See
here for more about low-latency direct monitoring.
Turn the Input Level adjustment knob to change the input recording level.
A good rule of thumb is to adjust this knob so that your strongest playing occasionally
triggers the right LEDs to turn orange.
When compression is engaged, increasing the Input Level results in more
compression rather than an increased input level. Use the Input Gain knob to control
the amount of compression applied to the input signal.
Push the Input Level adjustment knob to toggle between Compressor presets.
A Blue LED displays for 1 second to indicate the compressor preset selected.
The Compressor has three presets:
Left LED: Smooth Leveler - Gentle and smooth compression
Center LED: Purple Squeeze - Medium compression
Right LED: Vintage Blue Stomp - Fast and Heavy compression
No LED: Compression is Off
The Orange LED indicates the input signal is engaging the Soft Limit analog circuit.
Soft Limit engages when the input level reaches -4dBfs; this setting is fixed and
permanent.
11

Apogee Jam X User’s Guide
Blend Mode
The Blend mode button toggles Jam X’s signal path between two workflows, Software monitoring and
Direct monitoring. These workflows affect how you hear your instrument while recording.
Blend Off - Software Monitoring
When Blend is off, you hear your instrument AFTER it’s been routed through your Amp Sim app or
DAW, as shown below.
● Pros
○ Software monitoring is the simplest workflow, where most settings are made in the
DAW window.
○ If you’re using an amp sim plugin or app, you hear your instrument through the amp
sim while recording.
● Cons
○ Depending on your system, you may encounter latency - a delay of your Instrument’s
audio in your headphones.
To configure your system for software monitoring:
1. Press the Jam X Blend button to turn Blend off.
2. Configure your DAW for software monitoring, as described here.
3. Set up a DAW channel for recording, then use the DAW mixer to create the desired balance
between the track being recorded and tracks being played back.
12

Apogee Jam X User’s Guide
Minimize Latency with Software Monitoring
Here are a few ways to minimize the latency through your system:
1. Set your Amp sim or DAW software to a sample rate of 96kHz - this divides latency in half.
2. Lower the buffer setting on your software as low as possible while avoiding audio dropouts or
glitches. If you have a powerful computer and your sessions use a moderate amount of plugin
processing, you may be able to find a buffer setting that works.
3. If latency is still too high, turn Blend on to engage Direct monitoring.
Blend On - Direct Monitoring
When Blend is on, you hear your instrument BEFORE it’s been routed through your Amp Sim app or
DAW, as shown below.
● Pros - Low latency and maximum plugin power - the DAW IO Buffer may be set to its
maximum value for the greatest number of native plugins without an effect on latency. Latency
remains virtually non-existent to the headphone/speaker output.
● Cons - If you’re using an amp sim app or plugin, monitoring options are the following:
○ Leave software monitoring on in the app, so you hear the unprocessed direct signal
AND the delayed amp sim audio.
○ Turn software monitoring off in the app, so you hear ONLY the unprocessed direct
signal.
To configure your system for direct monitoring:
4. Press the Blend button to turn the Blend LED on.
5. Configure your DAW for direct monitoring or software monitoring, as described here,
6. Set up a DAW channel for recording.
13

Apogee Jam X User’s Guide
Configuring Neural Archetype:Tim Hensen - Standalone
The best way to get started quickly with Jam X is with the supplied Archetype: Tim Hensen guitar amp
plugin running in Standalone mode on your Mac or Windows computer.
1. No DAW needed - After installing the Archetype:Tim Hensen plugin, go to the Applications
folder (on Mac), find the Neural DSP folder, open it and click on the Archetype Tim Hensen
icon to launch the application in Standalone mode.
2. Click on the Setting gear in the lower left corner of the app window.
a. Set Audio Output Device and Audio Input Device to Jam X
b. Set Sample Rate to 96000 Hz
c. Set Audio Buffer Size to 192 samples, for a latency of 2.0ms
3. Start with the Input and Output knobs set to 0.0.
4. Adjust Jam’s headphone/speaker output level with your computer or iOS device’s output level
control.
14

Apogee Jam X User’s Guide
Configuring Your DAW
Find below detailed information to configure Jam X with popular DAWs:
● Configure the DAW to use Jam X
● Configure the DAW for Direct or Software monitoring
● Access Jam X inputs & outputs in the DAW
● Additional DAW-specific notes
Apple Logic Pro
To configure Apple Logic Pro to use Jam X:
1. In the Logic Pro menu bar, choose Logic Pro >
Preferences > Audio in the menu bar, then click the
Device tab.
2. Check the Core Audio checkbox; set Output Device and
Input Device to Jam X.
3. Set I/O Buffer Size
4. Click Apply.
To configure Logic Pro for Direct or Software Monitoring Workflow:
1. In the Logic Pro menu bar, choose Logic Pro >
Preferences > Audio, then click the General tab.
● Check the Software Monitoring box to monitor through
Logic while recording.
● Leave the Software Monitoring box unchecked for
Direct monitoring through the Blend function of the
Jam X
2. On the Jam X, press the Blend button:
● Turn Blend off for Software monitoring.
● Turn Blend on for Direct monitoring through the Jam
X.
15

Apogee Jam X User’s Guide
Avid Pro Tools
To configure Avid Pro Tools to use Jam X:
1. Open Pro Tools, then choose Setup > Playback
Engine in the menu bar.
2. Set Playback Engine to Jam X.
3. Set H/W Buffer Size to 128 to start, adjust for
lower latency or more plugin power.
To configure Pro Tools for Direct or Software Monitoring
Workflow:
1. In the Pro Tools menu bar, set Options > Low Latency Monitoring.
● Uncheck Low Latency Monitoring for Software monitoring.
● Check Low Latency Monitoring for Direct monitoring.
2. On the Jam X, press the Blend button:
● Turn Blend off for Software monitoring..
● Turn Blend on for Direct monitoring through the Jam X.
16

Apogee Jam X User’s Guide
Ableton Live
To configure Ableton Live:
1. In the Live menu bar, choose Live >
Preferences and click the Audio tab.
2. Mac - set Driver Type to CoreAudio;
Windows - set Driver Type to Apogee
ASIO Driver.
3. Set Audio Input Device and Audio
Output Device to Jam X.
4. Set Buffer Size. Adjust for lower latency
or more plugin power.
To configure Ableton Live for Direct or Software Monitoring Workflow:
1. Monitor settings in Ableton Live are
configured for each channel individually.
2. In the Ableton menu bar, choose View
and verify that In/Out is checked.
3. In each channel, set Monitor to Auto for
Software monitoring or Off for Direct
monitoring.
4. On the Jam X, press the Blend button:
● Turn Blend off for Software
monitoring..
● Turn Blend on for Direct monitoring
through the Jam X.
17

Apogee Jam X User’s Guide
Troubleshooting
Q: The LED light stays blue and I can’t turn it green
A1: Check if Jam X is recognized by the computer or iOS device. If it isn’t, Your USB cable may be
faulty and should be swapped out.
A2: The LED will not turn green until an audio application plays through the Jam X (such as playing
Apple Music or Spotify), or attempts to record from Jam X’s ¼” instrument input (like Garageband or
Ableton Live). Some apps will not do this until you actually start recording so make sure you check for
this.
Q: Low sound through headphone/speakers, even though the input signal is peaking red.
A: The output volume may be turned down. This is a separate control from the input adjustment knob.
To adjust output level, use the volume buttons on the side of your iPhone or iPad, or the volume
controls on your Mac or PC computer.
Q: The input signal is noisy or has a hum or buzz
A1: This could be a bad cable. Try swapping out your instrument cable, output cable, or USB cable to
see if there’s improvement.
A2: Hi-Z (high impedance) input sources such as electric guitar pickups are notoriously noisy and
susceptible to picking up interference from lights, radio transmissions, and other electronic devices.
Turn your instrument to face another direction, or move to a different area away from electromagnetic
sources to reduce the interference being picked up.
Q: Will Jam X work with my Android device?
A: Jam X was designed to work with standard drivers that are part of Windows and Mac PC’s, and
Apple iOS devices. You may try using Jam X with your Android device, but we cannot guarantee that
it will work.
For more information
● Apogee KnowledgeBase and FAQs
● Informational Videos
● Apogee Product Registration
● How to contact Apogee Technical Support
Please visit:
www.apogeedigital.com/support
18

Apogee Jam X User’s Guide
Warranty Information and Legal Notices
APOGEE ELECTRONICS CORPORATION warrants this product to be free of defects in material and
manufacture under normal use for a period of 12 months. The term of this warranty begins on the date
of sale to the purchaser from an authorized Apogee dealer (proof of purchase in the form of a receipt
may be required). Units returned for warranty repair to Apogee or an authorized Apogee warranty
repair facility will be repaired or replaced with a functional equivalent product that is new or
refurbished at the manufacturer’s option, free of charge. Please note this guarantee may be subject to
other conditions as dictated by the customer’s legal warranty rights under the applicable national
legislation governing the sale of consumer goods.
Apogee reserves the right to change or improve design at any time without prior notification. Design
changes are not implemented retroactively, and the incorporation of design changes into future units
does not imply the availability of an upgrade to existing units. This warranty is void if Apogee
determines, in its sole business judgment, the defect to be the result of abuse, neglect, alteration or
attempted repair by unauthorized personnel. The buyer acknowledges and agrees that in no event
shall the company be held liable for any special, indirect, incidental or consequential damages, or for
injury, loss or damage sustained by any person or property, that may result from this product failing to
operate correctly at any time.
Warranty details are subject to change. For the latest warranty information please visit
www.apogeedigital.com.
Declarations of Conformity
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference and (2) This device must accept any interference
received, including interference that may cause undesired operation. This equipment has been tested
and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules.
CAUTION: Changes or modifications not expressly approved by Apogee Electronics Corporation
compliance could void the user’s authority to operate the equipment.
Rating: 3.3-5V 100mA USB 2.0
Industry Canada Notice
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing
Equipment Regulations. Cet appareil numérique de la classe B respecte toutes les exigences du
Règlement sur le matérial brouilleur du Canada.
19

Apogee Jam X User’s Guide
Declaration of Conformity – CE
Apogee Electronics Corporation hereby declares that the product, Jam X, to which this declaration
relates, is in material conformity with the following standards or other normative documents:
(EN50081-1/EN55022; 1995) and (EN50082-1/IEC 801-2, 3, 4; 1992)
following the provisions of: (73/23/EEC – Low Voltage Directive)and (89/336/EEC – EMC Directive)
Declaration of Conformity – CE
Apogee Electronics Corporation hereby declares that the product, Jam X, to which this declaration
relates, is in material conformity with the following standards or other normative documents:
(EN50081-1/EN55022; 1995) and (EN50082-1/IEC 801-2, 3, 4; 1992)
following the provisions of: (73/23/EEC – Low Voltage Directive) and (89/336/EEC – EMC Directive)
Declaration of Conformity – Japan
Apogee Electronics Corporation hereby declares that Jam X, to which this declaration relates, is in
material conformity with the VCCI Class A standard.
Declaration of Conformity – Australia
Apogee Electronics Corporation hereby declares that the Jam X is in material conformity with AN/NZS
standard requirements.
Use of the “Made for iPhone”, “Made for iPad”, and “Made for iPod” badge means that an accessory
has been designed to connect specifically to the Apple product(s) identified in the badge, and has
been certified by the developer to meet Apple performance standards. Apple is not responsible for the
operation of this device or its compliance with safety and regulatory standards. Please note that the
use of this accessory with an Apple product may affect wireless performance.
User’s Guide Version 1.0b
20
