VALBERG WF 612 D DS701T User manual

ELECTRO DEPOT
1 route de Vendeville
59155 FACHES-THUMESNIL - FRANCE
EN
WARRANTY CONDITION
This product is guaranteed for a period of 2 years from the date of purchase* against any failure resulting
from a manufacturing or material defect. This warranty does not cover defects or damage resulting from
incorrect installation, improper use or abnormal wear of the product.
*as shown on the sales receipt.
FR
CONDITION DE GARANTIE
Ce produit est garanti pour une période de 2 ans à partir de la date d’achat*, contre toute défaillance
résultant d’un vice de fabrication ou de matériau. Cette garantie ne couvre pas les vices ou les dommages
résultant d’une mauvaise installation, d’une utilisation incorrecte ou de l’usure anormale du produit.
*sur présentation du ticket de caisse.
NL
GARANTIEVOORWAARDEN
Dit product wordt gegarandeerd voor een periode van 2 jaar vanaf de aankoopdatum*, voor elke storing
die het gevolg is van een fabricagefout of het materiaal. Gebreken of schade door slechte installatie, onjuist
gebruik of abnormale slijtage van het product worden niet gedekt door deze garantie.
*op vertoon van kassabon.
ES
CONDICIONES DE GARANTÍA
El certicado de garantía de este producto tiene una duración de 2 años a partir de la fecha de compra*
que se limita a los defectos de fabricación y averías del material. Se excluyen de la garantía deciencias o
daños originados por una mala instalación, errores en la manipulación o por un uso inadecuado.
*previa presentación del comprobante de compra.

971314 - WF 612 D DS701T
INSTRUCTIONS FOR USE ....................02
CONSIGNES D'UTILISATION ....................38
GEBRUIKSAANWIJZINGEN ....................74
INSTRUCCIONES DE USO ...................110
2/2 08/2021-V1
Washing machine
Machine à laver
Wasmachine
Lavadora

123
4
5
6
7
8
9
10

2 EN
Thanks!
Thank you for choosing this VALBERG product.
Chosen, tested and recommended by ELECTRO DEPOT,
the products of the VALBERG brand are easy to use,
reliable and of an impeccable standard.
Thanks to this appliance, you can be sure that each use
will bring you satisfaction.
Welcome to ELECTRO DEPOT.
Visit our website: www.electrodepot.fr
www.electrodepot.be

3 EN
Table of contents
APreview of the
appliance
CUseful information
BUsing the appliance Installation
Use
Cleaning and care
Troubleshooting
Description of the appliance

4EN
Preview of the appliance
A
Description of the appliance
1Electronic display
2Program selector
3Work top
4Dispenser drawer
5Drum
6Access hatch to the drain pump lter
7Water inlet valve
8Power Cord
9Drain hose
10 Transit bolt

5EN
Using the appliance
B
Installation
Removing the transit bolts
X4
X4
1
3
X4
2
4
Before using the washing machine, remove the 4 transit bolts and rubber washers located
at the rear of the machine. Failure to comply with this instruction may cause strong vibrations, a
high level of noise and damage to the machine, rendering the warranty null and void.
Loosen the transit bolts by turning them anticlockwise with a suitable spanner.
Remove the transit bolts by pulling them straight out.
Fit the plastic blanking plugs supplied with the accessory kit on the holes left once the transit
bolts have been removed. Keep the transit bolts for later use.
NOTE
Remove the transit bolts before using the machine for
the first time. Faults resulting from a machine used
with the transit bolts still attached are not covered
by the warranty.

6EN
Using the appliance
B
Adjusting the feet/adjusting the adjustable housings
Electrical connection
To increase the height of the machine, turn the feet clockwise. To reduce the height of the
machine, turn the feet anticlockwise.
• Once the machine is level, re-tighten the lock nuts by turning them clockwise.
Never place blocks made of cardboard, wood or any other similar material under the machine
to level it.
• When cleaning the oor around the machine, be careful not to change the levelling.
Do not install the machine on a surface that could prevent air from owing underneath (e.g.
a carpet).
• For quiet and vibration-free operation, install the machine on a rm surface.
• The machine can be levelled using the adjustable feet.
• Loosen the plastic lock nut.
1
X4
2
3

7EN
Using the appliance
B
• Your washing machine requires a mains power supply of 220-240 V, 50 Hz.
• The power cord of your washing machine is tted with an earthed plug. This plug should always
be inserted into a 10 amp earthed outlet.
• This plug should always be inserted into a 10 amp earthed outlet. The fuse rating of the outlet
must also be 10 amps.
• If the plug or fuse does not meet these requirements, call a qualied electrician.
• We disclaim all liability for any damage resulting from the use of unearthed facilities.
NOTE
Using the machine at low voltage will shorten its
lifetime and it will not perform as well.
Connecting the water inlet hose
Depending on its technical specications, your machine can be tted with either a single
water inlet hose connection (cold water) or a double connection (hot and cold water). The hose
with a white cap should be connected to the cold water inlet and the hose with a red cap to the
hot water inlet (if applicable).
• To prevent water leaking from the joints, 1 or 2 nuts (depending on the technical specications
of your machine) are delivered in the hose packaging. Fit these nuts to the end of the water
inlet pipe(s) to be connected to the water supply.
1
2
34

8EN
Using the appliance
B
Connect the new water inlet hoses to a ¾" threaded tap.
• Connect the white end of the water inlet hose to the white water inlet valve located at the rear
of the machine and the red end of the hose to the red water inlet valve (if available).
• Tighten the connections by hand. If in doubt, consult a qualied plumber.
• A water pressure between 0.1 and 1 MPa is required for optimum operating eciency (a pressure
of 0.1 MPa corresponds to a ow rate of more than 8 L of water per minute with a fully open
tap).
Once all the connections have been made, carefully turn on the water supply and check for
any leaks.
Make sure that the new water inlet hose is not pinched, twisted, bent, kinked or crushed.
• If the machine is tted with a hot water inlet connection, the temperature of the water supplied
must not exceed 70°C.
NOTE
The appliance must be connected to the water supply
network using the new connection sets supplied with
the appliance; used connection sets must not be
reused.
~ 95 cm
~ 145 cm
~ 95 cm
~ 140 cm
~ 95 cm
~ 150 cm
0 – max. 100 cm

9EN
Using the appliance
B
Connecting the drain hose
• Connect the drain hose to a drain pipe or to the washing machine waste pipe of a sink using
additional hardware.
• Never attempt to lengthen the drain hose.
• Do not place the end of the machine's drain hose in a container, bucket or bathtub.
• Make sure that the drain hose is not kinked, twisted, crushed or stretched excessively.
• Fit the drain pipe no higher than 100 cm from the ground.
1Dispenser drawer
2Program selector
3Electronic display
4Additional functions
5Start/Pause button
Presentation of the control panel
1 2 3 4 5

10 EN
Using the appliance
B
Dispenser drawer
1
2
3
4
5
6
1Accessories for washing liquids
2Washing product compartment, main wash cycle
3Fabric softener compartment
4Washing product compartment, pre-wash cycle
5Washing powder levels
6Washing powder scoop (*)
(*) The technical specications may vary depending on the model of machine.

11 EN
Using the appliance
B
Compartments
• Laundry compartment, main wash cycle:
• Softener, starch or washing product compartment:
• Washing powder compartment, pre-wash cycle:
This compartment is intended for washing powder or liquid, or anti-limescale products. The
graduated rule (optional) for washing liquid is provided inside the machine.(*)
This compartment is for fabric softeners, conditioners or starch. Follow the instructions on the
packaging. If the fabric softener leaves a residue after use, try diluting it or use a liquid fabric
softener.

12 EN
Using the appliance
B
Program selector
Electronic display
(*) The technical specications may vary depending on the model of machine.
• To select a program, turn the program selector clockwise or anticlockwise until the indicator
points towards the desired program.
• Make sure that the program selector is pointing precisely at the desired program
Only use this compartment when the Prewash function has been selected. Only select this function
with heavily soiled laundry.
°C - x100/min
WM912A+++W701T
1
2 3 4 5
6
7

13 EN
Using the appliance
B
1Electronic display
2Digital display
3Water temperature adjustment button
4Spin speed adjustment button (rpm)
5Delay start
6Start/Pause button
7On/o indicator
Using the machine
Preparing the laundry
12
3 4
56
7

14 EN
Using the appliance
B
1Follow the instructions on the garment care labels.
2Never wash white laundry with coloured laundry.
3Remove any metallic materials that may be present in the laundry or in the pockets.
• Sort the laundry according to the type of fabric (cotton, synthetic, delicate, wool, etc.), the
washing temperature (cold, 30°C, 40°C, 60°C or 90°C) and how dirty it is (slightly dirty, dirty, very
dirty).
• Dark clothing may contain an excessive amount of dye and should be washed separately
several times.
CAUTION
Any malfunction resulting from damage caused by
the presence of foreign objects in the machine is not
covered by the warranty.
4Close the zip, hooks and buttons
5Remove metal or plastic curtain hooks or place them in a mesh or laundry bag.
6Some clothing, such as trousers, blouses, T-shirts and sweatshirts, must be turned inside out.
7Wash socks, handkerchiefs and other small items in a washing bag.

15 EN
Using the appliance
B
FFA
Putting the laundry into the machine
Bleach when
needed
Do not bleach Machine wash,
normal/moderate
cycle
Iron medium heat
(150°C)
Dry clean
Line dry without
spinning
Dry clean with
petroleum solvents
Dry clean with
common solvents
Dry clean with
solvents
Dry at without
spinning
Do not tumble dry
Do not dry clean Dry at
Iron high heat (200°C) Do not iron
• Open the machine door.
• Spread the laundry evenly inside the machine.

16 EN
Using the appliance
B
Click
NOTE
Exceeding the maximum load of the drum can lead to
poor washing results and creased clothing. Refer to
the program table to find out the loading capacities
for the different programs.
The following table shows the approximate weight of the most common laundry items:
Type of laundry
Towel
Sheet
Bathrobe
Duvet cover
Pillowcase
Underwear
Tablecloth
200
500
1200
700
200
100
250
Weight (g)
• Add each article separately.
• Check that no items are trapped between the rubber seal and the door.
• Gently push the door until you hear a click.
• Make sure the door is properly closed. Otherwise, the program will not start.

17 EN
Using the appliance
B
Adding the washing product to the machine
The amount of washing product used in the machine will depend on the following factors:
• Do not select a prewash if the laundry is only very lightly soiled. Pour a small quantity of
washing product (according to the manufacturer's instructions) into compartment II of the
dispenser drawer.
• If the laundry is extremely soiled, select a program with prewash and pour ¼ of the amount of
washing product to be used in compartment I of the dispenser drawer and the rest in compartment
II.
• Only use washing products for washing machines. Follow the manufacturer's instructions
regarding the amount of washing product required.
• In areas with hard water, more washing product should be used.
• The larger the load of laundry, the more washing product you will need.
• Pour the softener in the central compartment of the dispenser drawer. Do not exceed the
MAX level.
• Thick softeners can clog the drawer and should be diluted.
• Washing liquids can be used with all programs without prewash. To do this, slide the graduated
ruler for washing liquid (*) into the guide rails of compartment II of the dispenser drawer. To ll
the compartment with the required amount of washing product, use the graduations on the ruler.
(*) The technical specications may vary depending on the model of machine
