VALBERG WF 714 A W701T User manual

MADE IN TÜRKIYE
ELECTRO DEPOT
1route de Vendeville
59155FACHES-THUMESNIL
FRANCE
EN
WARRANTY CONDITION
This product is guaranteed for a period of 2 years from the date of purchase* against
any failure resulting from a manufacturing or material defect. This warranty does not
cover defects or damage resulting from incorrect installation, improper use or abnormal
wear of the product.
*as shown on the sales receipt.
FR
CONDITION DE GARANTIE
Ce produit est garanti pour une période de 2 ans à partir de la date d’achat*, contre
toute défaillance résultant d’un vice de fabrication ou de matériau. Cette garantie ne
couvre pas les vices ou les dommages résultant d’une mauvaise installation, d’une
utilisation incorrecte ou de l’usure anormale du produit.
*sur présentation du ticket de caisse.

10/2022 - V1
INSTRUCTIONS FOR USE ....................02
CONSIGNES D'UTILISATION ....................46
975768 WF 714 A W701T
975770 WF 814 A S701T
975772 WF 1014 A W701T
Washing Machine
Lave-linge
2/2

123
4
5
6
7
8
9
10

Thanks!
Thank you for choosing this VALBERG product.
Chosen, tested and recommended by ELECTRO DEPOT,
the products of the VALBERG brand are easy to use,
reliable and of an impeccable standard.
Thanks to this appliance, you can be sure that each
use will bring you satisfaction.
Welcome to ELECTRO DEPOT.
Visit our website: www.electrodepot.fr
www.electrodepot.be
2 FR
A
2
Thanks!
Thank you for choosing this VALBERG product.
Chosen, tested and recommended by ELECTRO DEPOT,
VALBERG branded products are easy to use, reliable,
and of an impeccable standard.
With every use of this appliance, you can be sure of
complete satisfaction.
Welcome to ELECTRO DEPOT.
Visit our website: www.electrodepot.fr
EN

Table of contents
A
AOverview of the
appliance
CUseful information
BUsing the appliance Installation
Control panel overview
Using your washing machine
Programme table
Cleaning and maintenance
Troubleshooting
Technical specications
3 FR
Aperçu de l’appareil
A
3
Table of contents
EN

4EN
Preview of the appliance
A
Technical specications
1Electronic Display
2Programme Dial
3Upper Tray
4Detergent Drawer
5Drum
6Pump Filter Cover
7Water Inlet Valve
8Power Cable
9Discharging Hose
10 Transit Bolts

5EN
Using the appliance
B
Installation
Removing the Transit Bolts
X X4 4
X4
1
3
2
4
1. Before operating the washing machine, remove the 4 transit bolts and rubber spacers
from the rear of the machine. If the bolts are not removed, they may cause heavy
vibration, noise and malfunction of the machine and void the warranty.
2. Loosen the transit bolts by turning them anticlockwise with an appropriate spanner.
3. Remove the transit bolts with a straight pull.
4. Fit the plastic blanking caps supplied in the accessories bag into the gaps left by the
removal of the transit bolts. The transit bolts should be stored for future use.
NOTE
Remove the transit bolts before using the machine for
the first time. Faults occurring due to the machine being
operated with transit bolts fitted are out ofthe scope of
the warranty.

6EN
Using the appliance
B
Adjusting the Feet / Adjusting Adjustable Stays
1
1. Do not install your machine on a surface (such as carpet) that would prevent ventilation
at the base. To ensure silent and vibration-free operation of your machine, install it on
a firm surface. You can level your machine using the adjustable feet. Loosen the plastic
locking nut.
X4
2 3
2. To increase the height of the machine, turn the feet clockwise. To decrease the height of
the machine, turn the feet anticlockwise. Once the machine is level, tighten the locking
nuts by turning them clockwise.
3. Never insert cardboard, wood or other similar materials under the machine to level it.
When cleaning the ground on which the machine is located, take care not to disturb the
level of the machine.

7EN
Using the appliance
B
Electrical Connection
• Your Washing Machine requires a 220- 240V, 50 mains supply.
• The mains cord of your washing machine is equipped with an earthed plug. This plug
should always be inserted to an earthed socket of 10 amps.
• If you do not have a suitable socket and fuse conforming with this, please ensure the
work is carried out by a qualified electrician.
• We do not take responsibility for damage that occurs due to the use of ungrounded
equipment.
NOTE
Operating your machine with low voltage will cause the life
cycle of your machine to be reduced and its performance
to be restricted.

8EN
Using the appliance
B
Water Inlet Hose Connection
3/4”
10 mm
1
3
2
4
1. Your machine may have either a single water inlet connection (cold) or double water inlet
connection (hot and cold) depending on the machine specifications. The white capped
hose and red capped hose to the hot water inlet (if applicable). To prevent water leaks at
the joints, either 1 or 2 nuts (depending on your machine’s specifications) are supplied
in the packaging with the hose. Fit these nuts to the end(s) of the water inlet hose that
connect to the water supply.
2. Connect new water inlet hoses to a ¾ ˝, threaded tap. Connect the white capped end of
the water inlet hose to the white water inlet valve on the rear side of the machine and
the red capped end of the hose to the red water inlet valve (if applicable). Hand tighten
the connections. If in any doubt, consult a qualified plumber. Water flow with pressure of
0. 1-1 Mpa will allow your machine to operate at optimum efficiency (pressure of 0. 1 Mpa
means that more than 8 litres of water per minute will flow through a fully opened tap).
3. Once you have made all of the connections, carefully turn the water supply on and
check for leaks.
4. Ensure that the new water inlet hoses are not trapped, kinked, twisted, folded or crushed.
If your machine has a hot water inlet connection, the temperature of the hot water
supply should not be higher than 70°C.

9EN
Using the appliance
B
NOTE
Your Washing Machine must only be connected to your
water supply using the supplied new fill hose. Old hoses
must not be reused.
~ 95 cm ~ 140 cm
~ 145 cm ~ 95 cm
0 – max. 100 cm
95 cm 150 cm
Water Discharge Connection
• Connect the water drain hose to a standpipe or to the outlet elbow of a household sink,
using additional equipment.
• Never attempt to extend the water drain hose.
• Do not put the water drain hose from your machine into a container, bucket or bathtub.
• Make sure that the water drain hose is not bent, buckled, crushed or extended.
• The water drain hose must be installed at a maximum height of 100 cm from the ground.

10 EN
Using the appliance
B
Control panel overview
1 2 3
1Detergent Drawer
2Programme Dial
3Electronic Display
Detergent Drawer (*)
1
2
3
4
5
6

11 EN
Using the appliance
B
1Liquid Detergent Attachments (*)
2Main Wash Detergent Compartment
3Softener Compartment
4Pre-Wash Detergent Compartment
5Powder Detergent Levels (*)
6Powder Detergent Scoop (*)
(*) Specications may vary depending on the machine purchased.
Sections
Main wash detergent compartment:
This compartment is for liquid or powder detergents or limescale remover. The uid detergent
level plate will be supplied inside your machine. (*)
Fabric conditioner, starch, detergent compartment:

12 EN
Using the appliance
B
This compartment is for softeners, conditioners or starch. Follow the instructions on the
packaging. If softeners leave residue after use, try diluting them or using a liquid softener.
Pre-wash detergent compartment:
This compartment should be used only when the pre-wash feature is selected. We recommend
that the pre-wash feature is used only for very dirty laundry.
(*) Specications may vary depending on the machine purchased.
Program Dial
• To select the desired programme, turn the programme dial either clockwise or anti-
clockwise until the marker on the programme dial points to the chosen programme.
• Make sure that the programme dial is set exactly to the programme you want.

13 EN
Using the appliance
B
Electronic Display
12 3 4 5 6 7
89
1Delayed start auxiliary function
2Selecting the level of soiling
3Stain selection
4Selecting the washing water temperature
5Spin speed selection
6Options
7Save+ / Speed (Eco washing, Quick Wash auxiliary function)
8Start Pause Button
9Energy/Water Efficiency Bar

14 EN
Using the appliance
B
Using your washing machine
Preparing Your Laundry
1
2
3
4
5
6
D
G
V
D
S
H
D
GV
D
S
7
1. Follow the instructions given in the care labels on the clothing. Separate your laundry
according to type (cotton, synthetic, sensitive, wool etc.), washing temperature (cold,
30°, 40°, 60°, 90°) and the degree of dirtiness (slightly stained, stained, highly stained).
2. Never wash coloured and white laundry together. Dark textiles may contain excess dye
and should be washed separately several times.
3. Ensure that there are no metallic materials on your laundry or in the pockets; if so,
remove them.
CAUTION
Any malfunctions which occur due to foreign materials
damaging your machine are not covered by the warranty.
4. Close zips and fasten any hooks and eyes.
5. Remove the metallic or plastic hooks of curtains or place them in a washing net or bag.
6. Reverse textiles such as pants, knitwear, t-shirts and sweat shirts.
7. Wash socks, handkerchiefs and other small items in a washing net.

15 EN
Using the appliance
B
Can be bleached
Do not bleach
Normal washing
Maximum ironing temperature 150°C
Maximum ironing temperature 200°C
Do not iron
Can be dry cleaned
No dry cleaning
Dry at
Drip dry
Hang to dry
Do not tumble dry
FDry cleaning in gas oil, pure alcohol and R113 is allowed
PPerchloroethylene R11, R13, Petroleum
A
Perchlorinetyhlene R11, R113, Gas oil

16 EN
Using the appliance
B
Putting Laundry in the Machine
• Open the door of your machine.
• Spread your laundry evenly in the machine.
NOTE
Take care not to exceed the maximum load of the drum
as this will give poor wash results and cause creasing.
Refer to the washing programme tables for information
on load capacities.
The following table shows approximate weights of typical laundry items:
LAUNDRY TYPE WEIGHT (gr)
Towel 200
Linen 500
Bathrobe 1200
Quilt cover 700
Pillow slip 200
Underwear 100
Tablecloth 250
• Load each item of laundry separately.
• Check that no items of laundry are trapped between the rubber seal and the door.
• Gently push the door until it clicks shut.

17 EN
Using the appliance
B
Click
• Make sure the door is fully closed, otherwise the programme will not start.
Adding Detergent to the Machine
The amount of detergent you will need to put in your machine will depend on the following
criteria:
• If your clothes are only slightly soiled, do not pre-wash. Put a small amount of detergent
(as specied by the manufacturer) into compartment II of the detergent drawer.
• If your clothes are excessively soiled, select a programme with pre-wash and put ¼ of
the detergent to be used into compartment I of the detergent drawer and the rest in
compartment II.
• Use detergents produced for automatic washing machines. Follow the manufacturer’s
instructions on the amount of detergent to use.
• In areas of hard water, more detergent will be required.
• The amount of the detergent required will increase with higher washing loads.
• Put softener in the middle compartment of the detergent drawer. Do not exceed the
MAX level.
• Thick softeners may cause clogging of the drawer and should be diluted.
• It is possible to use uid detergents in all programmes without a pre-wash. To do this,
slide the uid detergent level plate (*) into the guides in compartment II of the detergent
drawer. Use the lines on the plate as a guide to ll the drawer to the required level.
(*) Specications may vary depending on the machine purchased.
