Valcom VL580 User manual

Issue 2
1 947600
CAUTION: To reduce the risk of electric shock,
Do not remove cover (or back).
No user serviceable parts inside.
Refer servicing to qualified service personnel.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous
voltage constituting a risk of electric
shock is present within this unit.
This symbol indicates that there are
important operating and maintenance
instructions in the literature accompanying
this unit.
VL580
IP LARGE DISPLAY
INTRODUCTION
The VL580 IP Large Display provides highly
visible message output over an Ethernet
network. Text messages are created and
delivered from a Valcom Application Server.
SPECIFICATIONS
Features
Easy to read, high visibility
Font and color options
Power over Ethernet (PoE+) 802.3at
compatible
Display can operate as a clock or provide
other message during idle periods
Relay connection for optional equipment
Audio Line-level output connection
Dimensions / Weight
80.75” W x 12.13” H x 3.0” D
(205.10cm W x 30.81cm H x 7.62cm D)
Weight: 42 lbs (19.05kg)
Nominal Power Requirements
802.3at (PoE+) Class 4
Environment
Temperature: - 20° to +50° C
Humidity: Direct rain,
10ft max distance power washing
2000 to 3100 psi, 25 degree nozzle
These products are intended for use with a UL
Listed power source marked “Class 2” or “LPS”
rated 24VDC, or 48VDC (PoE).
PoE and all interconnected ITE are intended for
intra-building.
Precautionary Designations
WARNING: To Reduce The Risk Of Fire
Or Electric Shock. Do Not Expose This
Apparatus To Rain Or Moisture.
AVERTISSEMENT: Afin de réduire les
risques d'incendie ou de décharge
électrique, évitez d'exposer le système
à la pluie ou à l'humidité.
Apparatus shall not be exposed to
dripping or splashing and no objects
filled with liquids, such as vases, shall
be placed on the apparatus.
L’appareil ne doit pas être exposé à des
égouttements et éclaboussures et
aucun Objet Rempli de liquide, comme
vase, ne doit être placé sur l’appareil.
FCC Information
This equipment has been tested and found
to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference when the equipment is operated
in a commercial environment. This
equipment generates, uses and can radiate
radio frequency energy and if not installed
and used in accordance with the instruction
manual, may cause harmful interference to
radio communications. Operation of this
equipment in a residential area may cause
harmful interference in which case the user
will be required to correct the interference at
one’s own expense.

2 947600
INSTALLATION
Mounting
The VL580 message display should be mounted
with appropriate hardware (not included) for the
structure to which it is attached. All building
codes and requirements must be followed. It is
recommended to attach the mounting base into
wall studs. A vial level is included to assist with
leveling the mounting base. (Figure 2)
CONNECTIONS
Network Connection / Power
The VL580 has one RJ-45 network connector.
Connect a standard patch cable to the VL580
from an Ethernet switch supporting the Power
over Ethernet specification 802.3at (PoE+).
If a PoE+ switch is not available, a mid-span
injector may be used to supply power to the
display, or an optional Valcom 24 Vdc power
adapter may be connected to the barrel
connector on the circuit board (see Figure 1).
If using external power, the recommended
power supply is a VP-2124D.
Relay Connection
One relay output is provided through three
screw terminals labeled Normally Open (NO)
and Normally Closed (NC). The center screw
terminal is common to both NO and NC. The
relay contacts are rated 1 amp @ 24Vdc.
Line Out Connection
The Line Out connection provides line level
output sufficient to drive up to 40 Valcom
self-amplified speakers.
Status / Demo / Reset
A multifunction button is provided to display
information and/or reset the VL580
configuration. The button is located on the edge
of the circuit board as shown in Figure 2. The
button provides different functions depending on
the duration the button is pressed.
Status Mode
Press the button for approximately 1 second
and release and the Status display will show the
current IP Address, Power Source status and
the last four digits of the MAC address.
Figure 1. Network Connections
Demo Mode
While the VL580 is in Status Mode, pressing the
button again will enable Demo Mode. In this
mode, the VL580 will display a scrolling sample
message. Demo Mode will display for about 30
seconds then the VL580 returns to normal
operation.
Reset Modes
Pressing the button continuously for greater
than 10 seconds, but less than 20 seconds, will
perform a soft reset on the VL580. The IP
address will be reset to the factory default
setting. Other configuration items will not be
affected.
IMPORTANT SAFETY INFORMATION
CONSIGNES DE SÉCURITÉ IMPORTANTES
1. Read these instructions.
Lisez ces instructions.
2. Keep these instructions.
Conservez ces instructions.
3. Heed all warnings.
Respecteztous les avertissements.
4. Follow all instructions.
Suivez toutes les instructions.
5. Do not use this apparatus near water.
Ne pas utiliser cet appareil près de l'eau.
6. Clean only with dry cloth.
Nettoyer avec un chiffon sec.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
Ne pas bloquer les ouvertures de ventilation. Installer formément aux instructions du
fabricant.
8. Do not install near any heat sources such as radiators, heat registers, stoves or other
apparatus (including amplifiers) that produce heat.
Ne pas installer à proximité de sources de chaleur telles que radiateurs, registres de
chaleur, poêles ou autres appareils (y compris les amplificateurs) produisant de la chaleur.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and a
third grounding prong. The wide blade and the third prong are provided for your safety. If
the provided plug does not fit into your outlet consult an electrician for replacement of the
obsolete outlet.
Ne pas contourner le dispositif de sécurité de la fiche polarisée ou de mise à la terre. Une
fiche polarisée possède deux lames dont une plus large que l'autre. Une fiche de terre a
deux lames et une troisième broche de mise à la terre. La lame large et la troisième
broche sont fournies pour votre sécurité. Si la fiche fournie ne rentre pas dans votre prise,
veuillez consulter un électricien pour le remplacement de la prise obsolète.
10.Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles and the point where they exit from the apparatus.
11.Only use attachments/accessories specified by the manufacturer.
N'utilisez que des fixations / accessoires spécifiés par le fabricant.
12. Use only with the cart, stand, tripod, bracket or table specified
by the manufacturer or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
Utilisez uniquement avec le chariot, stand, trépied, support ou table spécifié par le
fabricant ou vendu avec l'appareil. Quand un chariot est utilisé, Soyez prudent lorsque
vous déplacez l'ensemble chariot / appareil pour éviter des blessures dues au
renversement.
13. Unplug this apparatus during lightning storms or when unused for a long period of time.
Débranchez cet appareil pendant les orages ou lorsqu'il n'est pas utilisé pendant une
longue période de temps.
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way. Such as when the power supply cord or plug is
damaged, liquid has been spilled, objects have fallen into the apparatus or the
apparatus has been exposed to rain or moisture and does not operate normally or has
been dropped.
Confiez toute réparation à un personnel qualifié. Une réparation est nécessaire lorsque
l'appareil a été endommagé de quelque façon. Parexemple lorsque le cordon
d'alimentation oula fiche est endommagé, du liquide a été renversé, si des objets sont
tombés dans l'appareil ou le appareil a été exposé à la pluie ou à l'humidité et ne
fonctionne pas normalement ou s'il est tombé.

3 947600
Pressing the button continuously for greater
than 20 seconds will perform a hard reset on the
VL580. All of the configuration items (including
the password) will be reset to factory default
settings.
Setup
Information specific to your application will need
to be programmed into the VL580 using a
computer. The PC used for programming
should be connected to the same subnet as the
VL580. Setup will be done using the IP
Solutions Setup Tool. Download the latest
version of the free IP Solutions Setup Tool from
the Valcom website at
www.valcom.com/vipsetuptool
TECHNICAL ASSISTANCE
Assistance is available from the factory when
problems are encountered. Call [phone]
and press 1 for Technical Support or visit our
website at http://www.valcom.com
Valcom, Inc. equipment is not field repairable.
Valcom maintains service facilities in Roanoke,
VA.
Should repairs be necessary, attach a tag to the
unit clearly stating company name, address,
phone number, contact person, and the nature
of the problem.
Send the unit to:
Valcom, Inc.
Repair and Return Dept.
5614 Hollins Road
Roanoke, VA 24019-5056
WARRANTY
Warranty information may be found on our
website at www.valcom.com/warranty.
Figure 2. Mounting Diagram
