Valcom Vm-srly User manual

1 947487

CAUTION: To reduce the risk of electric shock,

Do not remove cover.

No user serviceable parts inside.

Refer servicing to qualified service personnel.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates that dangerous

voltage constituting a risk of electric

shock is present within this unit.

This symbol indicates that there are

important operating and maintenance

instructions in the literature accompanying

this unit.

ISSUE 1

VM-SRLY Smart Relay

INTRODUCTION

The VM-SRLY Smart Relay module is designed

for use with Valcom SIP Intercoms. The Smart

Relay provides both a Normally Open and

Normally Closed (Form C) output connection for

use with auxiliary equipment such as electric door

strikes, gate openers, etc.

SPECIFICATIONS

Access Methods

Valcom SIP Intercoms

Features

Smart signaling reduces possibility of

tampering

1 Form C relay

Dimensions/Weight:

2.5” H x 1.25" W x 1.25" D

(6.4 cm H x 3.2 cm W x 3.2 cm D)

Weight: 1 oz. (28 g)

Nominal Specifications

Relay Current: 1 AMP @ 24VDC

Environment

Temperature: 0 to +40° C

Humidity: 0 to 85% non-precipitating

Compatibility

The VM-SRLY is compatible with the following

Valcom SIP Products:

VIP-176

VIP-180

Precautionary Designations

FCC Information

This equipment has been tested and found to

comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide

reasonable protection against harmful

interference when the equipment is operated

in a commercial environment. This

equipment generates uses and can radiate

radio frequency energy and if not installed

and used in accordance with the instruction

manual, may cause harmful interference to

radio communications. Operation of this

equipment in a residential area may cause

harmful interference in which case the user

will be required to correct the interference at

his own expense.

2 947487

INSTALLATION

Operation

The VM-SRLY provides one Normally Open and

one Normally Closed (Form C) relay connection

for use with Valcom SIP Doorphone/Intercom

devices. The relay is activated by pressing a digit

on the calling telephone. The relay is typically

used to activate door entry equipment, gates, etc.

Mounting

The VM-SRLY can be mounted to a solid surface

using the double-sided tape affixed to the back of

the module, or can be attached using the #4 x ¾”

screw included with the module. See Figure 1.

Figure 1. Mounting

Power / Signal Connections

The power and signal connections are provided

to the VM-SRLY by a four wire connector. The

recommended wiring uses two pairs from a

standard Category 3 (or better) twisted-pair

cable. The screw terminal block is removable for

ease of installation. Make the connection from

the Valcom SIP Doorphone/Intercom device to

the VM-SRLY following the diagram shown in

Figure 2.

Relay Connections

Access to the form C relay is provided via a three

pin screw terminal block on the VM-SRLY. The

screw terminal block is removable for making

connections. The Common contact is the middle

terminal. The normally open contact is labeled

“NO” and the normally closed contact is labeled

“NC”. Make connections between NO and

Common, or NC and Common, as necessary.

See Figure 2.

SETUP

No setup is necessary for the VM-SRLY.

Information related to activating the VM-SRLY

from a Valcom SIP Doorphone/Intercom device

will need to be programmed into the SIP

Doorphone using a computer. The PC used for

programming should be connected to the same

subnet as the Doorphone. Setup will be done

using the IP Solution Setup Tool. Download the

latest version of the free IP Solutions Setup Tool

from the Valcom web site at

www.valcom.com/vipsetuptool

3 947487

TECHNICAL ASSISTANCE

Assistance in troubleshooting is available from

the factory. Call (540) 563-2000 and press 1 for

Technical Support or via email at

support@valcom.com.

When requesting assistance, you should include

all available information. General information and

troubleshooting procedures are available on the

Valcom website at www.valcom.com.Valcom

equipment is not field repairable. Valcom, Inc.

maintains service facilities in Roanoke, VA.

Should repairs be necessary, attach a tag to the

unit clearly stating your company name, address,

phone number, contact person and the nature of

the problem.

Send the unit to: Valcom, Inc.

Repair & Return Dept.

5614 Hollins Road

Roanoke, Va. 24019-5056

VALCOM LIMITED WARRANTY

Valcom, Inc. warrants its products only to the original purchaser, for its own use, to be free from defects in materials and workmanship under conditions of

normal use and service for a period of one year from the date of shipment. This Limited Warranty obligation shall be limited to the replacement, repair or refund

of any such defective device within the warranty period, provided that:

1. inspection by Valcom, Inc. indicates the validity of the claim;

2. the defect is not the result of damage, misuse or negligence after the original shipment;

3. the product has not been altered in any way or repaired by others and that factory sealed units are unopened (a service charge plus parts

and labor will be applied to units defaced or physically damaged);

4. freight charges for the return of products to Valcom are prepaid;

5. all units 'out of warranty' are subject to a service charge. The service charge will cover minor repairs (major repairs will be subject to

additional charges for parts and labor).

This Limited Warranty is in lieu of and excludes all other warranties, expressed or implied and in no event shall Valcom, Inc. be liable for any

anticipated profits, consequential damages, loss of time or other losses incurred by the buyer in connection with the purchase, operation,

maintenance, installation, removal or use of the product. The maximum liability of Valcom under this warranty is limited to the purchase price of the

specific Product covered by the warranty.

Disclaimer. Except for the Limited Warranty provided herein, the product is provided “as-is” without any warranty of any kind whatsoever including, without

limitation, any WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT.

This warranty specifically excludes damage incurred in shipment. In the event a product is received in damaged condition, the carrier should be notified
