Valdesta Classico 750 User manual

Classico 750

CAUTION
Please take a few minutes to read the following pages of instruction and precaution.
1. Please use AC 110V power cord.
2. Use the AC power cord correctly.
3. Avoid injecting water into keyboard or cabinet.
——Don’t place containers with liquid on or near the piano. For example vase, cup, wine, etc..
——If a liquid is dispersed into keyboard or cabinet, please turn the power switch off and call the
local music dealer or repair technician immediately.
4. Take care in maintaining your cabinet. Avoid direct sunlight and other heat sources.
ASSEMBLY
Make sure that your package contains the following items:
Side panel(Left)
Real panel
Hand screws PCS
4
Pedal board
Main unit
Real panel screws PCS 5
Side panel(Right)
Main unit
Real panel
Side p an el (Le ft)
Side p anei(Rig ht)
8
6
7
6
6
8
7
7
7
OPERATION
1、Power
Simply slide the key cover open and the power will come on automatically. To turn the power
off, simply slide the key cover closed.

2、Master volume
DO WN UP
MA STER VOLUME
This sliding control button simply adjusts the overall volume
of the selected keyboard voice(s)
3、Demo
DEMO
Press the Demo button the LED will begin to flash and the different demonstrations
songs can be selected by pressing the individual instrument voice buttons.
4、Midi
MIDI
MIDI allows your instrument to communicate with other MIDI-enabled devices.
5、Timbre
V O ICE
There are fourteen different instrument sounds that can be selected by pressing the
individual instruments voice buttons.
6、Dual
DUAL
The Dual button allows the user to mix any two of the fourteen instrument voices.
Press the instrument button and the voice is selected, pressing any two instrument voices, the
voice becomes layered (dual),the proportion of mixing is 50:50.
7、Split
S PLI T
The split function allows the player the opportunity to divide the keyboard into two
instrument voice sections.
Press the split button (the LED above the button will blink)
The 88 note piano will be divided, into left and right sections.
The left section is the originally selected instrument voice, the right section is the secondary
selected voice. If the instrument voice of right section is not selected, the voice will be the same as
original voice. Press the button again to turn the function off.

8、Transpose
TRANSPOSE
The transposition feature allows the user to transpose or change the overall pitch of
the piano to the key of your choice. Use the up and down value buttons to adjust the transposition
desired.
9、Tune
TUNE
The tune function allows you to adjust slightly the tune of the instrument when it
plays with other musical instruments. To adjust, press up or down value button to increase or
decrease the tuning by 1 cent. The range of adjustment is –99~+99cent
Press the button again to turn the function off.
10、Metronome
The tempo range is from 40 to 240 BPM and adjusted via the value buttons. The measure
button selects the Meter of your choice. (4/4,4/2,42,6/8 or fixed).
+ -
VALUE
4 3 2 6
11、Recorder
PLAY
RECO RD
This allows the user to record up to two musical passages and then
listen to the play back simultaneously.
Press the record 1 button (the LED above the button will turn on) and begin playing;
Press the record 1button again to stop recording.
Press the play 1button, the musical passage that you just entered into the musical recorder will
playback just as it was preformed.
Press the record button, (the metronome will turn on automatically).
Press the Metronome button to stop the function of Metronome.
To erase track 1 or track 2 simply press the record button and then press the play button.
PEDALS
There are three pedals from left to right: the soft pedal, the sostenuto pedal and the sustain pedal.
a). The soft pedal (left): when engaged the keyboard volume is reduced and the timbre slightly
altered.
b) The sostenuto pedal (middle): when engaged the keyboard sustains any key to the left of the

middle C piano key that is depressed immediately before the pedal is engaged.
c) The sustain pedal (right): when the sustain pedal is engaged there is a gradual decay for as long
as you hold down the pedal.
INPUT/OUTPUT JACKS
1. HEADPHONE JACK
P HO NE
Disconnects internal speakers so you can play in total silence without disturbing
others.
2. AUDIO IN/OUT
ON
OFF
AUD I O J A CK
These jacks connect the output of other electronic instruments to the internal
amplifier and speakers within this piano.
3. MIDI JACK
IN
OUT
MID I J AC K
Midi jack allow communication with other products equipped with MIDI interfaces
ABOUT MIDI
1. What is MIDI?
Midi stands for musical instrument digital interface. This is a worldwide standard communication
interface that enables musical instruments (of all brands) and computers to communicate so that
instructions and other data can pass between them.
2. Midi terminals
A. MIDI IN connector receives MIDI data from an external MIDI device which can be used
to control this piano.
B. The MIDI out connector transmits MIDI data generated by this piano. Therefore note and
velocity data produced by playing the keyboard.
3. MIDI (implemention chart)
Function Receive data. Transmit data Others
Default 1 1-16Basic
Channel Channel 1-16 1-16
Default Mode 3 Mode 1
Messages Omni
ON/OFF,Poly
Omni
ON/OFF,Poly
Mode
Altered Mono
15-113 15-113Note
Number True Voice 15-113

Note ON O=9n,V=1-27 O=9n,V=1-27
Velocity Note OFF
Key’s ××After
Touch Ch’s ××
Pich Bender ××
64(40H) ООDamper
67(43H) ООSoft
7(07H) ООVolumc
11(OBH) ×ОExperession
10 ××Panpot
32 ××Vibrato
Control
Change
92 ××Tremolo
Prog
Chage True О(1-127)
System
Exclusive ОО
Song Pos ××
Song Sel ××
System
Common Tune ××
Clock ××Stystem
Real Time Commands ××
Local ON/OFF ОО
All Note’s OFF ×О(0-127)
Active Sense ОО
Aux
Messages
Reset ××
Mode1 : OMNION,POLY Mode2 : OMNI ON.MONO О : YES
Mode3 : OMNI OFF,POLY Mode4 : OMNI OFF.MONO ×: NO
TROUBLESHOOTING
1. The LED does not work
Examine if the socket and play is connected correctly
AC 110V power cord.
Turn the power switch on.
2. The keyboard makes no sound
Examine the master volume
Make sure headphones are not connected
3. Noise
Too close to radio or television receivers, can be interference.
The noise from refrigerator or washing machine.
Avoid plugging the AC adaptor into the same AC outlet with the above appliance.

TAKING CARE OF YOUR PIANO
Never apply excessive force to the controls, connectors or other parts of the instrument.
Avoid direct sunlight and humidity.
Avoid strong vibrations and movements.
Avoid excessive dust in and near the keyboard
Wipe the piano with a soft dry cloth.
Move the piano away from large electrical appliances
Avoid contact with liquids
Avoid placing heavy objects on the instrument.
DIMENSION OF PRODUCT
VBB PCM(44.1KHz Sample)
Keyboard 88 Full weighted keys
Voice Piano1, Piano2, Harpsichord, Glockspiel, Organ, Guitar, Violin, Guitar, Voice,
Trumpet, Saxo, Voice of animal, Drum
Adjusting Volume, Voice, Dual, Split, Transpose, Tune, Touch, Metronome, Value,
Recorder/Play, Midi, Demo
Pedal Output : L/R 250Mv
Headphone : 32Ω-7dB
Automatic
output
Soft pedal, Sostenuto pedal, Sustain pedal
Maximal
power
30W+30W
Other fittings MIDI Jack, Headphone Jack
Dimension 1387×435×841
Weight 45Kg
PERCUSSION VOICES SFX
Cattle Keyboard 68
House 69
Dog 70
Lion 71
Cock 72
Frog 73
Cat 74
Bird 75
Wind 76
Thunder 77
Friction sounds of car 78
Tinkling of bell 79

The sound of car 80
Pig 81
Goat 82
Sheep 83
Sound of running 84
Goose 85
Cuckoo 86
Hen 87
Duck 88
DRUM VOICES
Keyboard Scale Standard Keyboard Scale Standard
7 D#0 High Q 40 C 3 High Bongo
8 E 0 Slap 41 C#3 Low Bongo
9 F 0 Scrath Push 42 D 3 Mute Conga
0 F#0 Scrath Pul 43 D#3 Open Conga
11 G 0 Sticks 44 E 3 Low Conga
12 G#0 Square Click 45 F 3 Hi Timbale
13 A 0 Metronome Click 46 F#3 Low Timbale
14 A#0 Metronome Bell 47 G 3 High Agog o
15 B 0 Kick Drum 2 48 G#3 Cabasa
16 C 1 Kick Drum 1 49 A 3 Maracas
17 C#1 Side Stick 50 A#3 Short Whistle

18 D 1 Snare Drum 1 51 B 3 Long Whistle
19 D#1 Hand Clap 52 C 4 Short Guica
20 F 1 Snare Drum 2 53 C#4 Long Guica
21 F 1 Low Tom 2 54 D 4 Claves
22 F#1 Close Hi Hat 1 55 D#4 High Block
23 G 1 Low Tom 1 56 E 4 Low Block
24 G#1 Pedal Hi Hat 1 57 F 4 Open Block
25 A 1 Mid Tom 2 58 F#4 Mute Cuica
26 A#1 Open Hi Hat 1 59 G 4 Open Cuica
27 B 1 Mid Tom 2 60 G#4 Mute Triangle
28 C 2 High Tom 2 61 A 4 Open Triangle
29 C#2 Crash Cymbal 1 62 A#4 Shaker
30 D 2 Hight Tom 2 63 B 4 Jingle
31 D#2 Ride Cymbal 1 64 C 5 Bell Tree
32 E 2 Chinese Cymbal 65 C#5 Castanets
33 F 2 Ride Bell 66 D 5 Mute Surdo
34 F#2 Tambourine 67 D#5 Open Surdo
35 G 2 Splash Cymbal
36 G#2 Cow Bell
37 A 2 Crash Cymbal 2
38 A#2 Vibraslap
39 B 2 Ride Cymbal 2
