Valeo SC1000 IVECO User manual

Rev. 07.06.2019
Id.No. DOK31004
BUS BODY ELECTRONICS
SC1000 IVECO
Operating Instructions
–BusDriver

BUS BODY ELECTRONICS
1
Contents
List of figures 2
List of Tables 2
1. Introduction 3
1.1 Intended Use 3
1.2 Symbols used 5
1.3 Description of the control panel 6
1.4 Description of the control panel HVAC version 7
1.5 Display description 8
2. Usage 9
2.1 Turn ON 9
2.2 Turn OFF 9
2.3 Driver’s workplace functions 9
2.3.1 Adjust Temperature 9
2.3.2 Adjust blower speed 10
2.3.3 Adjust air flow direction /defrost function 10
2.3.4 Toggle between fresh air and air recirculation 11
2.4 Passenger compartment functions 12
2.4.1 AUTO mode 12
2.4.2 Set temperature 12
2.4.3 Adjust blower speed level (HVAC version only) 13
2.4.4 Toggle between fresh air / air recirculation (HVAC version only) 14
2.5 Preheating 15
2.5.1 Set date and time 15
2.5.2 Activate heating (without start time delay) 16
2.5.3 Programming the timer 16
2.6 Reheat (HVAC version only) 18
2.6.1 Activate 18
2.6.2 Terminate 18
2.7 Errors 18
2.7.1 Error display 18
2.7.2 Error read out 18

BUS BODY ELECTRONICS
2
List of figures
Figure 1 - SC1000 Control Panel Basic Version..............................................................3
Figure 2 - SC1000 Control Panel HVAC Version.............................................................4
Figure 3 - SC1000 Substation...................................................................................4
Figure 4 - SC1000 Control Panel Basic Version..............................................................6
Figure 5 - SC1000 Control Panel HVAC Version.............................................................7
Figure 6 - SC1000 Display Screen..............................................................................8
Figure 7 - SC1000 Release......................................................................................9
Figure 8 - SC1000 Standard Screen ...........................................................................9
Figure 9 - SC1000 Current Blower Speed Level ...........................................................10
Figure 10 - SC1000 Air Recirculation Mode Driver’s Seat Active........................................11
Figure 11 - SC1000 AUTO Mode Active.....................................................................12
Figure 12 - SC1000 Current Room Temperature ..........................................................13
Figure 13 - SC1000 Blower Speed Level....................................................................13
Figure 14 - SC1000 Air Recirculation Mode Active ........................................................14
Figure 15 - SC1000 Preheat...................................................................................15
Figure 16 - SC1000 Number of Hours .......................................................................15
Figure 17 - SC1000 Week Day................................................................................15
Figure 18 - SC1000 Heating Icon.............................................................................16
Figure 19 - SC1000 PrE........................................................................................16
Figure 20 - SC1000 Memory location ........................................................................16
Figure 21 - SC1000 Hour Display.............................................................................17
Figure 22 - SC1000 Display Week Day......................................................................17
Figure 23 - SC1000 Operation Time..........................................................................17
Figure 24 - SC1000 Entfeuchten aktiv .......................................................................18
Figure 25 - SC1000 Error Display.............................................................................18
Figure 26 - SC1000 Error read out ...........................................................................19
Figure 27 - SC1000 Current Error ............................................................................19
List of Tables
Table 1 - SC1000 Error Messages ...........................................................................21

BUS BODY ELECTRONICS
3
1. Introduction
1.1 Intended Use
The SC1000 is a device designed to control HVAC components (heating, ventilation, air-condi-
tioning) for buses, e.g. roof-top air-conditioning systems, heaters etc. It comprises always of a
control panel (control device with human-to-machine interface) which is integrated into the
dashboard, and of one or more substations, which are controlled by means of the control panel.
The communication between control panel and the respective substation is done via CAN bus.
Figure 1 - SC1000 Control Panel Basic Version

BUS BODY ELECTRONICS
4
Figure 2 - SC1000 Control Panel HVAC Version
A substation is a control device with power outputs for the control of all the components inte-
grated in the AC unit.
Figure 3 - SC1000 Substation

BUS BODY ELECTRONICS
5
1.2 Symbols used
Note

BUS BODY ELECTRONICS
6
1.3 Description of the control panel
7.
Driver’s seat
Passenger compartment
1. Fresh air / air recirculation
button
7. Heater button
11. Temperature button
2. Air direction control
8. Timer button heater
12.UP/DOWN button
3. Blower speed control
10. AUTO button
13.Display
4. Temperature control
Figure 4 - SC1000 Control Panel Basic Version

BUS BODY ELECTRONICS
7
1.4 Description of the control panel HVAC version
Figure 5 - SC1000 Control Panel HVAC Version
Driver’s seat
Passenger Compartment
1. Fresh air / air recirculation but-
ton
5. Fresh air / air recirculation
button (optional)
9. Reheat (dehumidify)
button (optional)
2. Air direction control
6. Blower speed button
(optional)
10. AUTO mode button
3. Blower speed control
7. Heater button
11. Temperature button
4. Temperature control
8. Timer button heater
12. UP/DOWN button
13. Display

BUS BODY ELECTRONICS
8
1.5 Display description
Figure 6 - SC1000 Display Screen
A. Indicated value
J. Heater is on
B. Appears if the lowest adjustable room
temperature is reached
K. Fresh air flaps open
C. Is indicated with the setpoint tempera-
ture (passenger compartment)
L. Air recirculation is on (HVAC version
only)
D. Time
M. Is indicated with the current room tem-
perature
E. Blower speed level
N. Is indicated with the current outside
temperature
F. Error icon
O. Is displayed during blower speed ad-
justment at the driver’s seat
G. Reheat (dehumidification) active
(HVAC version only)
P. AUTO mode active
H. Blower is on (HVAC Version only)
Q. Is displayed during start time adjust-
ment of the preheater
I. Cooling is activated

BUS BODY ELECTRONICS
9
2. Usage
2.1 Turn ON
➔Switch on the ignition.
➔The control panel starts automatically.
➔The current software version (1.0) and the current re-
lease appear on the display (Fig.7).
➔After four seconds the default screen is displayed. (Fig.8).
2.2 Turn OFF
➔Switch off the ignition.
➔The system powers down.
2.3 Driver’s workplace functions
2.3.1 Adjust Temperature
2.3.1.1 Cooling (if the roof-top air-conditioning unit is in cooling mode only)
Rotate the knob (Fig.5, No.4) counterclockwise into the blue area.
Note
Neither the current temperature, nor the setpoint
temperature for the driver's workplace, are shown in
the display. The temperature can be adjusted in nine
steps. At level 0 (the knob is in the left-most position)
there is no regulation of temperature, at level nine
(the knob is in the right-most position) the heater
operates at maximum power.
If a climate evaporator is installed in the front box, the
cooling is always on at the driver's seat whenever the
compressor is on. In order to achieve a warmer tempera-
ture, the driver must heat it up to counteract the cooling.
Figure 7 - SC1000 Release
Figure 8 - SC1000 Standard Screen
Note

BUS BODY ELECTRONICS
10
2.3.1.2 Heating
Rotate the knob clockwise into the red area.
2.3.2 Adjust blower speed
2.3.2.1 Increase blower speed
Turn the knob (Fig.5, No.3) clockwise to 5 o’clock position.
➔Blower speed increases incrementally by 10.
➔The current blower speed level is shown in the display
(Fig. 9).
2.3.2.2 Reduce blower speed
Turn the knob counterclockwise to 7 o’clock position to decrease blower speed level.
➔Blower speed decreases incrementally by 10
➔The current blower speed level is shown in the display
(Fig. 9).
2.3.3 Adjust air flow direction /defrost function
2.3.3.1 Adjust air flow direction
Rotate knob (Fig.5, No.2) counterclockwise into 7 o’clock position
➔air flow onto the floor
Rotate knob clockwise into 12 o’clock position
➔air flow against the wind screen and the floor
Rotate knob clockwise into 2 o’clock position
Note
The blower can be set from 20 to 100 in steps of
10. 20 is the smallest blower speed, on level 100
the blower runs at full speed. If the knob is turned
counterclockwise to its most left position, on the
screen displays “OFF” and the blower is switched
off.
Figure 9 - SC1000 Current Blower Speed
Level

BUS BODY ELECTRONICS
11
➔air flow against the wind screen
Rotate knob clockwise into 4 o’clock position
➔air flow against the wind screen.
2.3.3.2 Defrost function
Rotate knob clockwise into 5 o’clock position
➔air flow is directed against the wind screen. The water valve opens to generate
heated air and the blower runs with maximum speed.
2.3.4 Toggle between fresh air and air recirculation
Press button (Fig.5, No.1), to toggle between fresh
air and air recirculation modes.
➔Fresh air: the LED next to the fresh air / air recirculation
button is not lit.
➔Air recirculation: the LED next to the fresh air / air
recirculation button lights up.
Note
The air recirculation mode is not limited in time. The
air recirculation mode for the driver’s seat starts au-
tomatically whenever the air recirculation mode for
the passenger compartment is turned on. If the air re-
circulation mode for the passenger compartment is
active, it cannot be deactivated for the driver’s seat.
Figure 10 - SC1000 Air Recirculation
Mode Driver’s Seat Active

BUS BODY ELECTRONICS
12
2.4 Passenger compartment functions
2.4.1 AUTO mode
2.4.1.1 Activate
Press button (Fig.5, No.10) shortly.
➔Mode is activated.
➔the LED next to the button lights up, “AUTO” appears
on the display.
2.4.1.2 Terminate
Press button shortly.
➔Mode deactivated.
➔the LED next to the button goes out, “AUTO” disap-
pears from the display.
2.4.2 Set temperature
2.4.2.1 Adjust temperature
Press button.
➔Temperature +1˚C.
Note
Air-conditioning system and heater are activated only
in the AUTO mode!
To use all modes in full, activate the AUTO mode after
turning on the control panel and make sure that the
doors are closed.
To save energy, you can switch to manual mode
(simply deactivate the AUTO mode), here the temper-
ature can be manually changed by adjusting the
blower speed.
Note
The AUTO mode can be activated only when the en-
gine is running.
Figure 11 - SC1000 AUTO Mode Active

BUS BODY ELECTRONICS
13
Press button.
➔Temperature -1˚C.
2.4.2.2 Display the current room or outside temperature
Press button.
➔“INT” and the current room temperature are shown on
the display (Fig.12).
Press button again.
➔“EXT” and the current outside temperature are shown
on the display.
2.4.2.3 Terminate
➔Terminate the display by pressing the button or by
timeout automatically after 3 seconds.
➔Standard display screen appears.
2.4.3 Adjust blower speed level (HVAC version only)
2.4.3.1 Activate
press button (Fig. 5, No.6).
➔Manual blower speed level adjustment active.
➔The LED next to the button lights up and the current blower
speed level can be read on the display (Fig.13).
➔Blower speed can be changed.
2.4.3.2 Change blower speed level
Press button.
Note
The temperature can be varied between the values
15°C and 28°C.
Note
The blower can be set from 10 to 100 in steps of 10.
10 is the smallest blower speed, on level 100 the
blower runs at full speed. The adjustment can only be
made if the engine is running.
Figure 12 - SC1000 Current Room
Temperature
Figure 13 - SC1000 Blower Speed Level

BUS BODY ELECTRONICS
14
➔Blower speed level is increased.
➔The current blower speed level can be read on the dis-
play
Press button.
➔Blower speed level is decreased.
➔The current blower speed level can be read on the dis-
play.
2.4.3.3 Exit
By pressing the button or automatically after 3 seconds of inactivity.
2.4.4 Toggle between fresh air / air recirculation (HVAC version only)
2.4.4.1 Manual operation of the fresh air flaps
Press button (Fig 5, No.5) when the automatic air
recirculation is active.
➔The LED next to the button lights up and the air recircu-
lation icon (Fig.14) appears on the display.
Press the button when the manual operation of the fresh
air flaps is active.
➔The fresh air flaps are operated automatically again.
➔The LED next to the button lights up and the air recircu-
lation icon disappears from the display.
Note
It is not possible to check the setting again. If after
leaving the mode the blower button is pressed again,
the set value is displayed, then deleted and the
blower is controlled automatically again.
Note
The air recirculation mode is limited to 10 minutes. After
this time the fresh air ducts are automatically regulated.
Figure 14 - SC1000 Air Recirculation
Mode Active

BUS BODY ELECTRONICS
15
2.5 Preheating
2.5.1 Set date and time
Press button (Fig.5, No.8) for 3 second.
➔“Pre“ appears on the display (Fig. 15).
Press button or (Fig.5, No.12) once.
➔”hour“ appears on the screen (Fig. 17) and the hour
digits flash.
Press button to increase the number of hours (0-23 h).
Press button to decrease the number of hours (0-23 h).
Press button to confirm value.
➔Minute digits flash.
Now proceed exactly as described for setting the number of
hours to set the number of minutes.
➔Now the week days are displayed (Fig. 18).
Note
Programming, operating the heater and setting up the
timer of the heater is the responsibility of the driver.
He must ensure that at the start time the circumstances
and the parking situation are suitable.
For security reasons it is only possible to program the
timer for the same and the next working day. The Start
time delay for Monday is already possible on Friday.
To activate the preheating function the engine must be
off.
The pre-heating function will only be executed if no low
voltage (<22V) is present. Otherwise, the function is au-
tomatically terminated after 10 seconds.
Note
Day and time are set in the following order:
hours –minutes –day of the week.
The position to be set is flashing.
Figure 15 - SC1000 Preheat
Figure 16 - SC1000 ti-A
Figure 16 - SC1000 Number of Hours
Figure 17 - SC1000 Week Day

BUS BODY ELECTRONICS
16
Set the week day (Mo, Tu, We, Th, Sa, Su) using the buttons.
Press button to confirm the day.
➔The default screen appears.
2.5.2 Activate heating (without start time delay)
Press button (Fig 5. No 7.).
➔The button’s LED lights up and the heating icon ap-
pears on the screen (Fig.19).
2.5.3 Programming the timer
Press button 3 seconds.
➔“PrE“ appears on the screen (Fig.20).
2.5.3.1 Choose start time
Press button to display the memory locations.
➔“PrE1“ appears on the display (Fig.21).
Press buttons to scroll through memory locations
PrE1-7 and select one of them.
Press button to confirm selection.
Note
Prior to using the timer, the correct time must be set.
The timer allows you to heat up the passenger compart-
ment without having to start the engine.
By using the timer, the starting and operating time can
be selected individually.
Up to 7 start times can be set in parallel (PRE1-7).
Note
You have seven memory locations (PrE 1-7) available
for storing different start times. The system starts the
pre-heating mode at the respective times.
Figure 18 - SC1000 Heating Icon
Figure 19 - SC1000 PrE
Figure 20 - SC1000 Memory location

BUS BODY ELECTRONICS
17
➔“00:00“ and “hour“ appear on the screen (Fig. 22).
➔If the start time was already programmed before, it ap-
pears instead of ”00:00“.
➔The hour digits flash.
Press button to increase number of hours.
Press button to decrease number of hours.
Press button to confirm value.
➔Minute digits flash.
Now proceed exactly as described for setting the number of
hours to set the number of minutes.
➔Now the weekdays are displayed (Fig. 18).
Set the week day (Mo, Tu, We, Th, Sa, Su) using the
buttons.
Press button to confirm the day.
“0´”appears on the screen (Fig.24).
2.5.3.2 Laufzeit einstellen
Press buttons to set operating time.
Press button to confirm operating time.
2.5.3.3 Activate pre-heating mode
Press button to activate the pre-heating mode with the chosen start and operation time.
2.5.3.4 Terminate
Press button to exit the menu.
Note
The operation time can be set in steps of 5 between
5 and 60 minutes.
Note
If more than one preheating time is programmed, pre-
heating is done at all programmed starting times.
Figure 21 - SC1000 Hour Display
Figure 22 - SC1000 Display Week Day
Figure 23 - SC1000 Operation Time

BUS BODY ELECTRONICS
18
2.6 Reheat (HVAC version only)
2.6.1 Activate
Press button (Fig. 5, No.9).
➔The button’s LED lights up and the heating icon ap-
pears on the screen (Fig.25).
2.6.2 Terminate
Press button.
➔The button’s LED turns off and the heating icon disap-
pears on the screen (Fig.19).
2.7 Errors
2.7.1 Error display
Wenn ein Systemfehler vorhanden ist, blinkt das Warnsymbol
für die Fehlermeldung in der Anzeige (Figure 26).
2.7.2 Error read out
2.7.2.1 Activate
Press button (Fig.5, No.1) at driver’s workplace for 2 sec-
onds until “E1:XY”appears on the display.
➔The menu for system fault analysis opens.
Note
The reheat mode can only be activated in the AUTO
mode (when the engine is running) and at at least 8°C
outside temperature.
After 10 minutes the reheat mode is terminated automat-
ically.
Note
If an error occurred, the error icon (Fig.6, F) appears on
the display. You can see which kinds of error exist in the
error code table in the section „Error description“.
Figure 24 - SC1000 Entfeuchten aktiv
Figure 25 - SC1000 Error Display

BUS BODY ELECTRONICS
19
➔The count (Fig.27) shows the current frequency of oc-
currence of the error.
2.7.2.2 Error messages
Press buttons to scroll through error messages.
2.7.2.3 Terminate
Press button (Fig.5, No.1) at the drivers’s seat until the standard screen appears.
2.7.2.4 Erase error
Press the button 6 seconds.
➔The error stops being displayed.
➔If the error has not been corrected, itappears again with
a dot between the third and fourth digit of the error code
within the error messages (Fig.28).
2.7.3 Error message overview
Error message dis-
played
Description
Cause/remedy
00
No error message
-
01
Hot water valve fail-
ure in the frontbox
1. Check plug connections
- Electrical and visual check of all
plug connections
2. Replace component
3. Replace control unit
02
The air distribution
flap actuator (foot
area) of the frontbox
has failed
Note
If it is a currently existing error, this is indicated by a dot
between the third and fourth digitof the error code on the
display (Fig.26). If the error is corrected, the point dis-
appears and the count increases.
Note
Servo/ Motor 0 -> Floor water valve
Servo/ Motor 1 -> Foot area flap
Servo/ Motor 2 -> Wind screen flap
Servo/ Motor 3 -> Fresh air flap
Figure 26 - SC1000 Error read out
Figure 27 - SC1000 Current Error
