Pfeiffer Vacuum TPG 366 MAXIGAUGE User manual

OPERATING INSTRUCTIONS
EN
Translation of the Original
TPG 366 MAXIGAUGE
Total pressure measuring and control unit

Dear Customer,
Thank you for choosing a Pfeiffer Vacuum product. Your new total pressure measuring and
control unit should support you in your individual application with full performance and without
malfunctions. The name Pfeiffer Vacuum stands for high-quality vacuum technology, a
comprehensive and complete range of top-quality products and first-class service. From this
extensive, practical experience we have gained a large volume of information that can
contribute to efficient deployment and to your personal safety.
In the knowledge that our product must avoid consuming work output, we trust that our
product can offer you a solution that supports you in the effective and trouble-free
implementation of your individual application.
Please read these operating instructions before putting your product into operation for the
first time. If you have any questions or suggestions, please feel free to contact info@pfeiffer-
vacuum.de.
Further operating instructions from Pfeiffer Vacuum can be found in the Download Center on
our website.
Disclaimer of liability
These operating instructions describe all models and variants of your product. Note that your
product may not be equipped with all features described in this document. Pfeiffer Vacuum
constantly adapts its products to the latest state of the art without prior notice. Please take
into account that online operating instructions can deviate from the printed operating
instructions supplied with your product.
Furthermore, Pfeiffer Vacuum assumes no responsibility or liability for damage resulting from
the use of the product that contradicts its proper use or is explicitly defined as foreseeable
misuse.
Copyright
This document is the intellectual property of Pfeiffer Vacuum and all contents of this
document are protected by copyright. They may not be copied, altered, reproduced or
published without the prior written permission of Pfeiffer Vacuum.
We reserve the right to make changes to the technical data and information in this document.
2/72

Table of contents
1 About this manual 7
1.1 Validity 7
1.1.1 Applicable documents 7
1.1.2 Variants 7
1.1.3 Firmware versions 7
1.2 Target group 7
1.3 Conventions 8
1.3.1 Instructions in the text 8
1.3.2 Pictographs 8
1.3.3 Stickers on the product 8
1.3.4 Abbreviations 8
1.4 Trademarks 9
2 Safety 10
2.1 General safety instructions 10
2.2 Safety instructions 10
2.3 Safety precautions 14
2.4 Proper use 15
2.5 Foreseeable improper use 15
2.6 Responsibilities and warranty 15
2.7 Owner requirements 15
2.8 Personnel qualification 15
2.8.1 Ensuring personnel qualification 16
2.8.2 Personnel qualification for maintenance and repair 16
2.8.3 Advanced training with Pfeiffer Vacuum 16
2.9 Operator requirements 16
3 Transportation and storage 18
4 Product description 19
4.1 Identifying the product 19
4.2 Scope of delivery 19
4.3 Structure 19
4.4 Display elements 21
4.5 Controls 22
4.6 Interfaces 23
4.6.1 Mains power supply 23
4.6.2 Ground terminal 23
4.6.3 "sensor" connection 24
4.6.4 "control" connection 24
4.6.5 "relay" connection 25
4.6.6 "RS-485" connection 25
4.6.7 "USB" connection (type B) 26
4.6.8 "USB" connection (type A) 26
4.6.9 "Ethernet" (LAN) connection 26
5 Installation 28
5.1 Installing the device in a 19” rack 28
5.2 Installing the device in a switchboard 29
5.3 Using the device as a desktop device 30
6 Commissioning 31
6.1 Switch on the device 31
6.2 Updating the firmware 31
6.3 Configuring Ethernet 33
7 Operation 36
Table of contents
3/72

7.1 Basic operation 36
7.2 Operating modes 36
7.3 Measuring mode 36
7.4 Parameter mode 38
7.4.1 Switching function parameters 40
7.4.2 Gauge parameters 42
7.4.3 Gauge control 43
7.4.4 General parameters 45
7.4.5 Test parameters 49
7.5 Data logger mode 52
7.6 Setup mode 53
8 Decommissioning 55
9 Maintenance 56
9.1 Cleaning the device 56
9.2 Replacing the battery 57
10 Errors 58
11 Shipping 59
12 Disposal 60
13 Service solutions from Pfeiffer Vacuum 61
14 Technical data and dimensions 63
14.1 Technical data 63
14.2 Dimensions 67
15 Appendix 68
15.1 Units of pressure 68
15.2 Gas throughputs 68
ETL Listed 69
Declaration of conformity 70
Table of contents
4/72

List of tables
Tbl. 1: Applicable documents 7
Tbl. 2: Variants 7
Tbl. 3: Abbreviations used 9
Tbl. 4: Danger to life due to electric voltage 11
Tbl. 5: Controls 22
Tbl. 6: Switching functions 25
Tbl. 7: Status of the Ethernet connection 27
Tbl. 8: Description of the controls 36
Tbl. 9: Switching function parameters 40
Tbl. 10: Examples of switching function displays 40
Tbl. 11: Upper and lower threshold values 41
Tbl. 12: Gauge parameters 42
Tbl. 13: Available parameters (gauge parameters) 42
Tbl. 14: Gauge control 44
Tbl. 15: Available parameters (gauge control) 44
Tbl. 16: Switch-on type (SENSOR ON) 44
Tbl. 17: Switch-off type (SENSOR OFF) 44
Tbl. 18: Switch on/off thresholds 45
Tbl. 19: General parameters 45
Tbl. 20: Available parameters (general parameters) 46
Tbl. 21: Test parameters 49
Tbl. 22: Parameters in data logger mode 52
Tbl. 23: Parameters in setup mode 53
Tbl. 24: Errors 58
Tbl. 25: Technical data (general) 63
Tbl. 26: Technical data (mains connection) 63
Tbl. 27: Technical data (ambient conditions) 63
Tbl. 28: Technical data (gauge connections) 64
Tbl. 29: Technical data (gauge supply) 64
Tbl. 30: Technical data (operation) 64
Tbl. 31: Technical data (measured values) 64
Tbl. 32: Technical data (switching functions) 64
Tbl. 33: Technical data (switching function relay) 65
Tbl. 34: Technical data (error signal (error)) 65
Tbl. 35: Technical data (error signal relay) 65
Tbl. 36: Technical data (gauge control) 65
Tbl. 37: Technical data (analog outputs) 66
Tbl. 38: Technical data (RS-485 interface) 66
Tbl. 39: Technical data (USB interface (type A)) 66
Tbl. 40: Technical data (USB interface (type B)) 66
Tbl. 41: Technical data (Ethernet interface) 66
Tbl. 42: Units of pressure and their conversion 68
Tbl. 43: Gas throughputs and their conversion 68
List of tables
5/72

List of figures
Fig. 1: Disconnect device in accordance with EN 61010-1 11
Fig. 2: Front panel 20
Fig. 3: Connections on the rear side 20
Fig. 4: Display 21
Fig. 5: Parameter or bar graph 21
Fig. 6: Switch-points, parameter mode and input lock 22
Fig. 7: Measurement channel status 22
Fig. 8: Mains connection with IEC 320 C13 socket 23
Fig. 9: Gauge connection (6-pin Amphenol C 091 B socket) 24
Fig. 10: "control" connection (15-pole D-Sub socket) 24
Fig. 11: "relay" connection (25-pole D-Sub socket) 25
Fig. 12: "RS-485" connection (5-pole Binder M12 socket) 26
Fig. 13: "USB" connection (type B) 26
Fig. 14: "USB" connection (type A) 26
Fig. 15: "Ethernet" (LAN) connection 26
Fig. 16: Guide rails 28
Fig. 17: Rack module adapter (3 height units) 28
Fig. 18: Device installation 29
Fig. 19: Required control panel cut-out 29
Fig. 20: Fastening the rubber feet and rubber strip 30
Fig. 21: USB Update Tool 32
Fig. 22: Ethernet Configuration Tool 34
Fig. 23: Change measurement channel 37
Fig. 24: Switching gauges on and off 37
Fig. 25: Measuring range 37
Fig. 26: Identifying the gauge 37
Fig. 27: Change from measuring mode to parameter mode 38
Fig. 28: Select parameter group 38
Fig. 29: Read/write parameter groups and parameters 39
Fig. 30: Switching functions and threshold values 41
Fig. 31: Fast, normal and slow (from left to right) 43
Fig. 32: Press the arrow keys simultaneously > 2 seconds 48
Fig. 33: Program memory test 50
Fig. 34: Parameter memory test 50
Fig. 35: Display test 51
Fig. 36: Test of relays in the device 51
Fig. 37: Start/stop measured data recording 53
Fig. 38: Delete files 53
Fig. 39: Formatting the USB memory stick 54
Fig. 40: Delete parameter files from the USB memory stick 54
Fig. 41: Dimensions TPG 366 (in mm) 67
List of figures
6/72

1 About this manual
IMPORTANT
Read carefully before use.
Keep the manual for future consultation.
1.1 Validity
This document describes the function of the products listed in the following and provides the most im-
portant information for safe use. The description is written in accordance with the valid directives. The
information in this document refers to the current development status of the products. The document
retains its validity assuming that the customer does not make any changes to the product.
1.1.1 Applicable documents
Designation Document
“Measuring and control unit” communication instructions
TPG 366
BG 5511
“Gauges” operating instructions
ActiveLine gauge
(depending on the gauge used)
Declaration of conformity (Part of this document)
Tbl. 1: Applicable documents
1.1.2 Variants
This document applies for the product with the following part number:
Part number Designation
PT G28 770 TPG 366 MaxiGauge
Tbl. 2: Variants
The part number is found on the rating plate of the product.
Pfeiffer Vacuum reserves the right to make technical changes without prior notification.
The figures in this document are not to scale (dimensions in mm).
1.1.3 Firmware versions
This document is based on firmware version V010100.
Older firmware versions do not have the full functionality described in these operating instructions.
Checking the firmware version
1. If the device is not functioning as it did before, check whether the correct firmware version is in-
stalled.
2. If you have any questions about the firmware, contact Pfeiffer Vacuum.
1.2 Target group
These operating instructions are aimed at all persons performing the following activities on the product:
●Transportation
●Setup (Installation)
●Usage and operation
●Decommissioning
●Maintenance and cleaning
●Storage or disposal
About this manual
7/72

The work described in this document is only permitted to be performed by persons with the appropriate
technical qualifications (expert personnel) or who have received the relevant training from Pfeiffer Vac-
uum.
1.3 Conventions
1.3.1 Instructions in the text
Usage instructions in the document follow a general structure that is complete in itself. The required ac-
tion is indicated by an individual step or multi-part action steps.
Individual action step
A horizontal, solid triangle indicates the only step in an action.
►This is an individual action step.
Sequence of multi-part action steps
The numerical list indicates an action with multiple necessary steps.
1. Step 1
2. Step 2
3. ...
1.3.2 Pictographs
Pictographs used in the document indicate useful information.
Note
Tip
1.3.3 Stickers on the product
This section describes all the stickers on the product along with their meaning.
S/N
Made in Romania 2017/02
44990000
Mod.
P/N
Input 100-240 V~ 50-60 Hz 200 W
PT G28 770
TPG 366
D-35614 Asslar
4010094
Rating plate
The rating plate is located on the back of the de-
vice.
1.3.4 Abbreviations
Abbreviation Explanation
A/D Analog/Digital
F.S. Full Scale (limit value)
FSR Full Scale Range (upper range value)
About this manual
8/72

Abbreviation Explanation
SP Switch-point (setpoint)
UART Universal Asynchronous Receiver Transmitter
Tbl. 3: Abbreviations used
1.4 Trademarks
●FullRange® is a trademark of Pfeiffer Vacuum GmbH.
●MaxiGauge® is a trademark of Pfeiffer Vacuum GmbH.
About this manual
9/72

2 Safety
2.1 General safety instructions
This document includes the following 4 risk levels and 1 information level.
DANGER
Imminent danger
Indicates a hazardous situation which, if not avoided, will result in death or serious injury.
►Instructions on avoiding the hazardous situation
WARNING
Possibly imminent danger
Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
►Instructions on avoiding the hazardous situation
CAUTION
Possibly imminent danger
Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
►Instructions on avoiding the hazardous situation
NOTICE
Danger of property damage
Notice is used to address practices not related to physical injury.
►Instructions on avoiding property damage
Notes, tips or examples indicate important information on the product or on this document.
2.2 Safety instructions
Safety instructions according to product’s life stages
All safety instructions in this document are based on the results of a risk assessment.
Pfeiffer Vacuum has taken into account all the relevant life stages of the product.
Safety
10/72

Danger to life due to electric voltage
DANGER
Danger to life due to electric voltage
High voltages are present inside the device. When touching parts that are live, there is a risk of
death. If there is visible damage, there is a risk of death when commissioning the device.
►Work on the open device must only be carried out by trained specialist personnel.
►Before carrying out any installation and maintenance work, switch the device off and disconnect
it from the current supply.
–After switching off, wait about 60 seconds and then disconnect all cables (power cable at the
end).
►Never open the device with the current supply connected.
►Secure the current supply against unauthorized or unintentional reactivation.
►Do not insert any objects into the vent openings.
►Never open an external power supply unit.
►Never operate an open or defective device.
►Secure a defective device against accidental operation.
►Protect the device against moisture.
Do not insert any objects into the vent openings.
Protect the device against moisture.
Tbl. 4: Danger to life due to electric voltage
Disconnect device
The disconnect device must be clearly recognizable by the user and within easy reach.
1
Fig. 1: Disconnect device in accordance with EN 61010-1
1 Disconnect device
Risks during transport
NOTICE
Damage caused by incorrect transportation
Transportation in unsuitable packaging, or failure to install all transport locks, can damage the prod-
uct.
►Comply with the instructions for safe transportation.
Safety
11/72

Risks during storage
NOTICE
Damage caused by improper storage
Improper storage will lead to damage to the product.
Static charging, moisture, etc. lead to defects on the electronic components.
►Comply with the instructions for safe storage.
Risks during installation
DANGER
Danger to life from electric shock
The internal earthed conductor is fastened to the housing by a screw. A device without an earthed
conductor attached can be life-threatening in the event of a malfunction.
►Do not rotate or loosen the screw on the internal earthed conductor.
DANGER
Danger to life due to dangerous contact voltage
Voltages above 30 V (AC) or 60 V (DC) are considered dangerous in accordance with IEC 61010. If
you come into contact with dangerous contact voltage, this can result in injury through electric shocks
or even death.
►Only apply protected extra-low voltage (PELV).
DANGER
Danger to life from electric shock
Inadequate or incorrect grounding of the unit leads to contact-sensitive voltage on the housing. When
making contact, increased leakage currents will cause a life-threatening electric shock.
►Before the installation, check that the connection leads are voltage-free.
►Conduct the electrical connection in accordance with locally applicable regulations.
►Make sure that the local mains voltage and frequency match rating plate specifications.
►Make sure that the mains cable and extension cable meet the requirements for double isolation
between input voltage and output voltage, in accordance with IEC 61010 and IEC 60950.
►Use only a 3-pin mains cable and extension cable with properly connected protective earthing
(earthed conductor).
►Plug the mains plug into a socket with earthing contact only.
►Always connect the mains cable prior to all other cables, to ensure continuous protective earth-
ing.
NOTICE
Loss of control cabinet protection class
As a built-in unit, the device can negate the required protection class (protection against foreign mat-
ter and water) of control cabinets according to IEC 60204-1, for example.
►Take suitable measures to reestablish the required protection class.
NOTICE
Damage caused by penetrating moisture
Penetrating moisture, e.g. through condensation or dripping water, damages the device.
►Protect the device against moisture penetrating.
►Only operate the device in a clean and dry environment.
►Operate the device away from fluids and humidity sources.
►Take special precautions if there is a risk of dripping water.
►Do not switch on the device if fluid has penetrated into it, instead contact the Pfeiffer Vacuum
Service Center.
Safety
12/72

NOTICE
Damage caused by overheating
The ambient temperature must not exceed the permissible operating temperature of the device.
►Make sure there is unobstructed circulation of air when installing the device.
►Make sure that air can enter and exit through the ventilation openings without obstruction.
►Do not cover the ventilation openings.
►Periodically check and clean the installed air filter.
Risks during operation
DANGER
Electric shocks due to moisture penetrating into the device
Moisture that has penetrated into the device results in personal injury through electric shocks.
►Only operate the device in a dry environment.
►Operate the device away from fluids and humidity sources.
►Do not switch on the device if fluid has penetrated into it, instead contact Pfeiffer Vacuum Serv-
ice.
►Always disconnect the current supply before cleaning the device.
NOTICE
Unintentional results with controller connected
Switch relay not dependent on pressure. Values below the intended measuring range, or starting the
test program, can result in unintentional results at the connected controller, if the relay switches.
►Unplug the connected measuring and control cable.
►Prevent triggering of incorrect control commands or messages.
Risks during maintenance
DANGER
Danger to life due to electric voltage
High voltages are present inside the device. When touching parts that are live, there is a risk of
death. If there is visible damage, there is a risk of death when commissioning the device.
►Work on the open device must only be carried out by trained specialist personnel.
►Before carrying out any installation and maintenance work, switch the device off and disconnect
it from the current supply.
–After switching off, wait about 60 seconds and then disconnect all cables (power cable at the
end).
►Never open the device with the current supply connected.
►Secure the current supply against unauthorized or unintentional reactivation.
►Do not insert any objects into the vent openings.
►Never open an external power supply unit.
►Never operate an open or defective device.
►Secure a defective device against accidental operation.
►Protect the device against moisture.
WARNING
Health hazard through poisoning from toxic contaminated components or devices
Toxic process media result in contamination of devices or parts of them. During maintenance work,
there is a risk to health from contact with these poisonous substances. Illegal disposal of toxic sub-
stances causes environmental damage.
►Take suitable safety precautions and prevent health hazards or environmental pollution by toxic
process media.
►Decontaminate affected parts before carrying out maintenance work.
►Wear protective equipment.
Safety
13/72

WARNING
Health hazards due to cleaning agent
The cleaning agents used cause health hazards.
►When handling cleaning agents, observe the applicable regulations.
►Adhere to safety measures regarding handling and disposal of cleaning agents.
►Be aware of potential reactions with product materials.
NOTICE
Damage caused by unsuitable cleaning agents
Unsuitable cleaning agents damage the product.
►Do not use solvents as they attack the surface.
►Do not use any aggressive or abrasive cleaning agents.
Risks when shipping
WARNING
Risk of poisoning from contaminated products
Where products that contain harmful substances are shipped for maintenance or repair purposes, the
safety of service personnel is at risk.
►Comply with the instructions for safe shipping.
Risks during disposal
CAUTION
Health hazard caused by environmentally hazardous substances
Products, operating fluid, electric components, calibration gas residues (for example from test leaks)
or similar pose health hazards.
►Dispose of the environmentally hazardous substances in accordance with local regulations.
►Dispose of calibration gas and test leaks in accordance with local regulations.
2.3 Safety precautions
The product is designed according to the latest technology and recognized safety engineering rules.
Nevertheless, improper use can result in danger to operator all third party life and limb, and product
damage and additional property damage.
Duty to provide information on potential dangers
The product holder or user is obliged to make all operating personnel aware of dangers
posed by this product.
Every person who is involved in the installation, operation or maintenance of the product
must read, understand and adhere to the safety-related parts of this document.
Infringement of conformity due to modifications to the product
The Declaration of Conformity from the manufacturer is no longer valid if the operator
changes the original product or installs additional equipment.
●Following the installation into a system, the operator is required to check and re-evalu-
ate the conformity of the overall system in the context of the relevant European Direc-
tives, before commissioning that system.
Meet fundamental safety measures
1. When handling the gases and contaminated parts used, observe the applicable guidelines.
2. Observe the protective measures.
3. Observe the safety guidelines specified in this document.
–All work is only permissible when observing the relevant guidelines and adhering to the pro-
tective measures.
Safety
14/72

4. Inform yourself about any contamination before starting work.
5. Pass on safety instructions to all other users.
2.4 Proper use
The total pressure measuring gauge and control unit are used together with the Pfeiffer Vacuum Active-
Line gauges to measure total pressures. Typical applications are measurement, monitoring and process
control tasks in vacuum systems.
Using the product according to its intended purpose
1. Install, operate and maintain the product only in accordance with these operating instructions.
2. Comply with the application limits.
3. Observe the technical data.
2.5 Foreseeable improper use
Improper use of the product invalidates all warranty and liability claims. Any use that is counter to the
purpose of the product, whether intentional or unintentional, is regarded as misuse, in particular:
●Use outside the mechanical and electrical application limits (technical data)
●Use with corrosive or explosive media, if this is not explicitly permitted
●Use outdoors
●Use after technical changes (on the inside or the outside of the product)
●Use with replacement or accessory parts that are unsuitable or are not approved
2.6 Responsibilities and warranty
Pfeiffer Vacuum shall assume no responsibilities and warranty if the operating company or a third party:
●disregards this document.
●does not use the product for its intended purpose.
●carries out any modifications to the product (conversions, changes, maintenance work, etc.) that
are not listed in the corresponding operating instructions.
●operates the product with accessories that are not listed in the corresponding operating instruc-
tions.
The operator is responsible for the process media used.
2.7 Owner requirements
Safety-conscious working
1. Only operate the product in a technically flawless state.
2. Operate the product in line with its intended purpose, safety and hazard-conscious and only in
compliance with these operating instructions.
3. Fulfill the following instructions and monitor the observation of the following instructions:
–Proper use
–Generally applicable safety instructions and accident prevention regulations
–International, national and locally applicable standards and guidelines
–Additional product-related guidelines and regulations
4. Only use original parts or parts approved by Pfeiffer Vacuum.
5. Keep the operating instructions available at the place of installation.
6. Ensure personnel qualification.
2.8 Personnel qualification
The work described in this document may only be carried out by persons who have appropriate profes-
sional qualifications and the necessary experience or who have completed the necessary training as
provided by Pfeiffer Vacuum.
Training people
1. Train the technical personnel on the product.
2. Only let personnel to be trained work with and on the product when under the supervision of
trained personnel.
Safety
15/72

3. Only allow trained technical personnel to work with the product.
4. Before starting work, make sure that the commissioned personnel have read and understood
these operating instructions and all applicable documents, in particular the safety, maintenance
and repair information.
2.8.1 Ensuring personnel qualification
Specialist for mechanical work
Only a trained specialist may carry out mechanical work. Within the meaning of this document, special-
ists are people responsible for construction, mechanical installation, troubleshooting and maintenance
of the product, and who have the following qualifications:
●Qualification in the mechanical field in accordance with nationally applicable regulations
●Knowledge of this documentation
Specialist for electrotechnical work
Only a trained electrician may carry out electrical engineering work. Within the meaning of this docu-
ment, electricians are people responsible for electrical installation, commissioning, troubleshooting, and
maintenance of the product, and who have the following qualifications:
●Qualification in the electrical engineering field in accordance with nationally applicable regulations
●Knowledge of this documentation
In addition, these individuals must be familiar with applicable safety regulations and laws, as well as the
other standards, guidelines, and laws referred to in this documentation. The above individuals must
have an explicitly granted operational authorization to commission, program, configure, mark, and earth
devices, systems, and circuits in accordance with safety technology standards.
Trained individuals
Only adequately trained individuals may carry out all works in other transport, storage, operation and
disposal fields. Such training must ensure that individuals are capable of carrying out the required activi-
ties and work steps safely and properly.
2.8.2 Personnel qualification for maintenance and repair
Advanced training courses
Pfeiffer Vacuum offers advanced training courses to maintenance levels 2 and 3.
Adequately trained individuals are:
●Maintenance level 1
─Customer (trained specialist)
●Maintenance level 2
─Customer with technical education
─Pfeiffer Vacuum service technician
●Maintenance level 3
─Customer with Pfeiffer Vacuum service training
─Pfeiffer Vacuum service technician
2.8.3 Advanced training with Pfeiffer Vacuum
For optimal and trouble-free use of this product, Pfeiffer Vacuum offers a comprehensive range of
courses and technical trainings.
For more information, please contact Pfeiffer Vacuum technical training.
2.9 Operator requirements
Observing relevant documents and data
1. Read, observe and follow this operating instruction and the work instructions prepared by the op-
erating company, in particular the safety and warning instructions.
2. Install, operate and maintain the product only in accordance with these operating instructions.
3. Carry out all work only on the basis of the complete operating instructions and applicable docu-
ments.
Safety
16/72

4. Comply with the application limits.
5. Observe the technical data.
6. Please contact the Pfeiffer Vacuum Service Center if your questions on operation or maintenance
of the product are not answered by these operating instructions.
–You can find information in the Pfeiffer Vacuum service area.
Safety
17/72

3 Transportation and storage
NOTICE
Damage caused by incorrect transportation
Transportation in unsuitable packaging, or failure to install all transport locks, can damage the prod-
uct.
►Comply with the instructions for safe transportation.
NOTICE
Damage caused by improper storage
Improper storage will lead to damage to the product.
Static charging, moisture, etc. lead to defects on the electronic components.
►Comply with the instructions for safe storage.
Transporting the product safely
1. Observe the weight of the product.
2. Where possible, always transport or ship the product in the original packaging.
3. Always use dense and impact-proof packaging for the product.
4. Remove the existing protective cover and transport protections only immediately prior to installa-
tion.
5. Reattach transport locks and transport protections prior to each transport.
Storing the product safely
1. Store the product in a cool, dry, dust-free place, where it is protected against impacts and me-
chanical vibration.
2. Always use dense and impact-proof packaging for the product.
3. Where possible, store the product in the original packaging.
4. Store electronic components in antistatic packaging.
5. Maintain the permissible storage temperature.
6. Avoid extreme fluctuations of the ambient temperature.
7. Avoid high air humidity.
8. Seal connections with the original protective caps.
9. Protect the product with the original transport protections (where available).
Transportation and storage
18/72

4 Product description
4.1 Identifying the product
You will need all the data from the rating plate to safely identify the product when communicating with
Pfeiffer Vacuum.
Recording rating plate data
1. Read the data on the product rating plate.
2. Record this data.
3. Always have all rating plate specifications to hand.
4.2 Scope of delivery
The shipment includes the following parts:
●1 × total pressure measuring and control unit
●1 × network cable
●4 × collar screws with synthetic nipple
●2 × rubber feet
●1 × rubber strip
●1 × installation instructions
●1 × operating instructions
Unpacking the product and checking completeness of the shipment
1. Unpack the product.
2. Remove the transport fasteners, transport protection etc.
3. Store the transport fasteners, transport protection etc. in a safe place.
4. Check that the shipment is complete.
5. Ensure that no parts are damaged.
4.3 Structure
DANGER
Danger to life from electric shock
The internal earthed conductor is fastened to the housing by a screw. A device without an earthed
conductor attached can be life-threatening in the event of a malfunction.
►Do not rotate or loosen the screw on the internal earthed conductor.
Product description
19/72

MaxiGauge
x
®
1 32
Fig. 2: Front panel
1 USB connection (type A) 3 Controls
2 Display
3
1 2
4
56
7
8
Fig. 3: Connections on the rear side
1 Connections "sensor 1" to "sensor 6" for gauges 5 Ground terminal
2 "control" connection for control functions 6 Mains power supply
3 "relay" connection with relay contacts 7 USB connection (type B)
4 "RS 485" connection as a serial interface 8 Ethernet interface
Product description
20/72
