Valley CSB001-1 User manual

website: www.valleyacrylic.com • E-mail: [email protected] • customer service call Toll Free: 1.877.398.8827 • Fax: [phone]
CSB001-1
VALLEY BIDET
INSTALLATION GUIDE
1

website: www.valleyacrylic.com • E-mail: [email protected] • customer service call Toll Free: 1.877.398.8827 • Fax: [phone]
CSB001-1
VALLEY BIDET
INSTALLATION GUIDE
2
Thank you for choosing Valley Acrylic Products. This installation manual provides general
information on the installation of our products.
• Read the instructions carefully before beginning the installation.
• Consult local building codes to make sure the installation complies with standards.
• Remove the unit from its packaging. Before disposing, packaging and taking unit from your sales
person, inspect the unit to make sure it is in good shape.
• Should inspection reveal any damage or defect in the nish, Contact Us. The warranty does not
cover damages or defects in the nish once the unit has been installed. Valley’s responsibility for
shipping damages ceases upon delivery of the product in good order to the carrier. All complaints
regarding damage due to transport must be made directly to the carrier.
• It is recommended that you place the unit in the bathroom before you start. Sectional units
should be disassembled if necessary. Conserve all nuts and bolts.
BEFORE YOU BEGIN
REQUIRED TOOLS
INCLUDED PARTS
WRENCH SCREWDRIVER
ADAPTER LOCK NUTS HOSEPIPE

website: www.valleyacrylic.com • E-mail: [email protected] • customer service call Toll Free: 1.877.398.8827 • Fax: [phone]
CSB001-1
VALLEY BIDET
INSTALLATION GUIDE
3
Measurements may vary ¼”
(Diagram Not to scale)
+
-
DISCLAIMER:
7.125” / 181mm
SEAT BRAKETS
NOZZLE
PRESSURE
CONTROL
NOZZLE
ADJUSTER
3.25” / 83mm
7” / 178mm1.75” / 44mm
2.25” / 57mm
9.75” / 248mm
16.75” / 425mm
Valley Bidets are warrantied for residential use for a period of 1 year from the original
purchase date, against any failure from improper manufacturing defects.

website: www.valleyacrylic.com • E-mail: [email protected] • customer service call Toll Free: 1.877.398.8827 • Fax: [phone]
CSB001-1
VALLEY BIDET
INSTALLATION GUIDE
4
01 Turn o the water valve near the toilet.
Flip up the screw caps behind the seat with
a screwdriver to access the screws. You may
need to hold the bolt beneath the screw with
your other hand while unscrewing. Remove
the seat and set aside.
Disconnect the existing exible hose from
your toilet tank. To unscrew the connection,
turn left.
03
Flush your toilet to drain the tank completely.
Hold down that usher until it empties!
(A couple inches of water is okay.)
02
04

website: www.valleyacrylic.com • E-mail: [email protected] • customer service call Toll Free: 1.877.398.8827 • Fax: [phone]
CSB001-1
VALLEY BIDET
INSTALLATION GUIDE
5
Attach the transparent hosepipe into the
adapter and secure with the lock nut.
06
Connect the other end of the transparent
hosepipe to the port under your CSB001-1
Bidet and secure with the lock nut. Make
sure all the connections are secure and
turnon the water supply.
07
Place the rubber washer in the adapter.
Screw the adapter onto the tank connection
and then attach the exible hose to the
bottom of the adapter. Do not over tighten
05
WASHER
LOCK NUT
HOSEPIPE

website: www.valleyacrylic.com • E-mail: [email protected] • customer service call Toll Free: 1.877.398.8827 • Fax: [phone]
CSB001-1
VALLEY BIDET
INSTALLATION GUIDE
6
Congratulations! You are now a part of the Valley Acrylic family.
0908
Secure the toilet seat on top of the CSB001-1 bidet
by threading the toilet seat bolts through the seat
fasteners and the mounting holes.
10 04
Once all water connections have been
made, check for possible leaks.
Place your CSB001-1 bidet on top of your
toilet and align the seat brackets with your
toilet seat mounting holes.
Make sure the nozzle is centered to your
toilet bowl for that precise spray of water.
Adjust your CSB001-1 bidet if nessesary
5
min.
Valley Bidets are warrantied for residential use for a period of 1 year from the
original purchase date, against any failure from improper manufacturing defects.
