Vallox Vallox 245 MV VKL User manual

Installation instructions
Document
D5037
Valid from
01.01.2018
Updated
26.11.2018
Model
Vallox 245 MV
Vallox 245 MV VKL
Sound-dampening part
SOUND-DAMPENING PART
VALLOX 245
INSTALLATION INSTRUCTIONS

2
SOUND-DAMPENING PART VALLOX 245
INSTALLATION INSTRUCTIONS
756
1038
ø 250 4 kpl
2320-2335
1226-1241 1093
The sound-dampening part is designed to be installed
on top of the Vallox 245 ventilation unit to reduce duct
noises. The sound-dampening part has a cover that can
be opened. The cover allows for cleaning the ducts and
the sound-dampening part without disconnecting the
ducts. Where required, the dampening elements can be
removed for cleaning.
INSTALLATION
The sound-dampening part has sound-dampening
elements for supply and extract air ducts, which have
been installed ready at the factory.
There are four Ø 250 mm female duct outlets at the top
of the sound-dampening part. There are feedthroughs
at the top and in the base of the sound-dampening part
for VKL radiator pipes.
1
3A
6
3B
8
5
2A
2B
4
3C
1. Remove the door of the sound-dampening part.
2. When the part is to be installed in a VKL model unit,
make holes in the radiator’s rubber feedthroughs
and in the section that will be mounted against the
wall (2A in the R model and 2B in the L model) and
remove insulation at the feedthroughs.
3. You can remove the sound-dampening elements to
reduce weight (see changing handedness on page
3).
4. Install the extensions delivered with the sound-
dampening element (D) and the related insulation
(E) in the sound-dampening part.
5. Move the cables of the ventilation unit so that
they leave from the feedthrough at the top of the
ventilation unit towards the door.
6. Lift the sound-dampening part on top of the
ventilation unit. Ensure that the extensions (D)
and related insulation (E) are firmly in place.
7. When the part is to be installed in a VKL model
unit, install the VKL radiator pipes (2A/2B).
8. Feed the cables of the ventilation unit into
the cable conduit in the middle of the sound-
dampening part.
9. If you have removed the sound-dampening
elements, install them back in place (see
changing handedness on page 3).
4
E
D

3© Vallox Oy - All rights reserved
SOUND-DAMPENING PART VALLOX 245
INSTALLATION INSTRUCTIONS
756
1038
ø 250 4 kpl
2320-2335
1226-1241 1093
DIMENSIONS AND DUCT OUTLETS
Product title
Vallox 245 sound-dampening part
Product number
4101502
HVAC code
7912129
Enclosure protection class IP34
Weight 110 kg (88 kg without the door)
Dimensions (width x height x depth) 1038 x 1093 x 756 mm
TECHNICAL SPECIFICATIONS
3D
3A 3C
3A
3B
Remove the door of the sound-dampening
part. Remove the locking screw (3D) and then
the foremost sound-dampening element (3A)
of the supply air duct by lifting it. The sound-
dampening element of the extract air duct (3B),
located behind the supply air duct, has been
fastened onto the intermediate wall with eight
cross-slot headed screws.
The sound-dampening elements have been
installed in the left side at the factory (for an R
model unit). When the sound-dampening part is
to be installed in an L-model unit, the dampening
elements must be moved to the ducts on the
right side. Remove the maintenance door (3C)
from the wall between the right-side ducts.
Move the dampening element (3B) to the right
side. Next, turn the dampening element (3A)
upside down and move it to the right side so
that it is in the middle of the duct outlet. The
element is now installed correctly. Mount the
maintenance door (3C) on the sidewall of the
left-side ducts.
CHANGING HANDEDNESS
R model L model

© Vallox - All rights reserved
Vallox Oy | Myllykyläntie 9-11 | 32200 LOIMAA | FINLAND
www.vallox.com | Customer service [phone] | Aftersales [phone]
SOUND-DAMPENING PART VALLOX 245
0
50
40 60 80 100 120 140 160 180 200 220 240 260 280 300 (l/s)
dm³/s
100
200
250
300
350
150
100%
60%
50%
40%
30%
D5037 | 26.11.2018 | PDF
Fan input power
Power (W)
Volume flow rate (dm³/s)
0
50
100
200
250
300
350
150
40 60 80 100 120 140 160 180 200 220 240 260 280 300 (l/s)
dm³/s
100%
60%
50%
40%
30%
Pressure loss in ducts. Total pressure (Pa)
Volume flow rate (dm³/s)
INSTALLATION INSTRUCTIONS
Supply/extract air volumes
Sound power level in the supply air duct
by octave band Lw, dB
Sound power level in the extract air duct
by octave band Lw, dB
Adjustment position 30% 40% 50% 60% 100% 30% 40% 50% 60% 100%
Air flow dm3/s 109 137 174 203 238 121 146 186 212 250
Medium
frequency
of the
octave
band Hz
63 61 65 67 70 72 51 55 60 61 65
125 58 59 63 65 68 50 49 51 53 57
250 47 54 59 57 59 40 45 51 53 54
500 27 32 35 39 42 19 24 29 33 38
1000 14 17 21 24 29 12 14 17 21 27
2000 16 20 24 27 31 13 13 14 15 18
4000 16 16 17 18 21 16 16 16 16 17
8000 20 21 21 21 21 20 20 20 20 20
LW, dB
LWA, dB(A)
63 66 69 71 73 54 56 61 62 66
45 47 52 52 54 38 38 43 46 48
Sound pressure level, in decibels (A) coming through the envelope from the room in which the unit is installed
(10m2sound absorption)
ADJUSTMENT POSITION / AIR FLOWS (supply/extract)
Adjustment position 30% 40% 50% 60% 100%
Air flow dm3/s 119 / 132 145 / 162 173 / 191 197 / 216 228 / 245
LpA, dB (A) 36 38 40 43 48
SOUND VALUES
Extract air
Supply air
