Vapo Smini User manual

!
!
USER MANUAL
SMINI
By
available at vapo.co.nz

!
©!2014!JTBD!Limited.!All!rights!reserved.!
2!
Contents.
Disclaimer 3
Introduction 4
Assembly 4
Changing the Atomiser 5
Charging 5
Filling 6
Cleaning 7
Storage
Miscellaneous 8
IMPORTANT:
Read the disclaimer.
Keep out of reach of children.
Not intended for persons under 18.
Replace the cartridge WEEKLY to avoid leaking.
Unscrew the battery from the middle disc and atomiser casing when not in
use.

!
©!2014!JTBD!Limited.!All!rights!reserved.!
3!
Disclaimer
General
!Vapo products are intended for adults over the age of 18
!Our products are not intended for children, pregnant women, women who may
become pregnant, non-smokers, or smokers seeking a smoking cessation product
!Our products are not being marketed as smoking cessation devices and have not
been approved as such. If you’re seeking a smoking cessation method, please
consult your healthcare providers or organisations that deal specifically with quitting
smoking, such as Quitline – 0800 778 778.
!VAPO’s products may contain nicotine. This is a highly addictive and poisonous
substance that can be harmful to your health
!Do not use nicotine products if you are pregnant or breast feeding. Nicotine is a
chemical known to produce birth defects and reproductive harm.
!Do not use nicotine products if you have any of the following medical conditions:
Heart disease, diabetes, high blood pressure, or asthma
!VAPO’s products have not been evaluated by the Food and Drug Administration nor
is it intended to treat, prevent or cure any disease or condition
!If you experience any symptoms of nicotine poisoning stop using the product
immediately and consult your healthcare provider. Symptoms may include but are not
limited to vomiting, nausea, headache, difficulty breathing, sweating, palpatations,
lisps, stomache ache or pain, siezures or weakness
!Nicotine based liquids may be toxic if orally ingested or in contact with skin. VAPO’s
products may contain small parts. Keep out of reach of children and pets
!Nicotine based liquids are toxic to the environment. Do not flush or pour down the
drain. Please dispose of containers properly.
!eLiquid is flammable. Keep away from open flame and excessive heat.
!Use products only as intended and only with liquids designed for the products sold.
Battery Safety
Warning: All batteries have an inherent safety risk. Risks include but are not limited to fire,
explosion, electrical shock or exposure to harmful chemicals. Misuse or abuse dramatically
increases these risks. VAPO assumes no liability for damages.
!Only use Steamoon chargers or chargers purchased from the VAPO website when
charging the battery.
!Use a dedicated power source capable of supplying adequate power for charging.
Note some USB ports may not be designated to supply power and should not be
used.
!Excessive heat produced during charging can lead to failure
!Do not overcharge
!Always keep batteries in cool, dry surroundings
!Do not store in hot or humid places
!Do not carry in purse or pocket with other sharp or bulky items. Such items may
damage the battery or cause accidental misfire of the atomiser
!Never leave your battery in a place that it could become excessively hot such as
direct sunlight or inside a parked car
!Do not leave a battery where children may have access to it
!Never use a battery in damp or wet conditions
!Never submerge the battery in any liquid
!Do not drop the battery
!Do not puncture the battery housing
!Do not force the battery
!Do not dismantle the battery
!If the model of the battery has an on/off toggle feature please ensure the battery is off
when not in use. This will help prevent misfire and possible overheating.

!
©!2014!JTBD!Limited.!All!rights!reserved.!
4!
Introduction.
The Box*
1x Smini battery
1x Smini atomiser casing and middle disc
2x atomiser
2x refillable cartridge
1x USB charger
* x2 for twin pack, except charger
Parts
1. Cartridge
2. Atomiser casing
3. Atomiser
4. Middle disc
5. Battery
6. Light indicator
7. Atomiser unit
Assembly.
1. Remove an atomiser from the black plastic atomiser container and
drop 2 – 3 drops of liquid onto the spike and let it soak in to the
atomiser – this is called “priming” the atomiser.
2. Unscrew the middle disc from the atomiser casing and insert the
atomiser as below:

!
©!2014!JTBD!Limited.!All!rights!reserved.!
5!
3. Replace the middle disc and screw the atomiser unit onto the battery
4. Add fluid to the cartridge till it is two thirds full (pg. 6) and, if it is the first
time using the cartridge, make a small hole in the rubber plug with a
pin. It is recommended that you stretch the hole out to around twice the
diameter of the pin:
Note: If the hole is not large enough the atomiser spike will not
enter the cartridge. If the atomiser is not inside the cartridge the
user will experience a burnt taste and the unit will produce little,
if any, vapour.
5. While keeping the cartridge upright, insert the cartridge into the
atomiser casing.
Changing the Atomiser.
An atomiser will generally last between 1 - 2 months if used correctly.
1. Remove the atomiser from the black plastic casing and drop 2 – 3
drops of liquid onto the spike and let it soak in to the atomiser (pg. 4).
2. Remove the cartridge from the unit
3. Remove the atomiser unit and untwist the middle disc from the
atomiser casing

!
©!2014!JTBD!Limited.!All!rights!reserved.!
6!
4. Push, or tap, the atomiser out of the atomiser casing and discard
5. Insert a new atomiser into the atomiser casing and twist the middle disc
back into the casing
6. Reattach the atomiser unit to the battery and insert the cartridge.
Note that a new atomiser will take some time for the fluid to soak into the
vaporising unit. We recommend allowing the fluid to be absorbed into the
atomiser by standing the Smini on the light indicator for a few minutes.
Charging.
1. Unscrew the Smini battery atomiser casing. Note that the middle disc
should remain attached to the atomiser casing:
2. Screw the Smini battery into the USB charger provided and plug the
charger into a USB point or the wall charger (available from
vapo.co.nz):
3. The light on the charger will change from RED to GREEN once the
Smini battery is fully charged. Remove the battery from the charger and
reassemble the unit.
Note: The light indicator on the Smini battery will flash when the unit requires
charging.
Filling.
The Smini is designed as a refillable vaporising unit.
1. Pull the cartridge from the rear of the unit:
2. Remove the rubber plug at the atomiser end of the cartridge (not the
end you draw from).

!
©!2014!JTBD!Limited.!All!rights!reserved.!
7!
3. Refill two thirds (if you overfill the cartridge the atomiser spike will be
trapped in an air bubble and the device will not work) of the cartridge
with your favourite fluid and replace the rubber cap. Now slide the
cartridge back into the unit, twisting to ensure it is sealed.
Note: The first time you fill your Smini (or change the atomiser pg 4) it will
take a few draws for the liquid to soak through to the vaporising atomiser. We
recommend leaving the Smini standing on the light indicator for a few minutes
to allow the fluid to soak into the atomiser.
Cleaning.
The Steamoon Smini is a quality product that uses intricate technology. In
order to maintain the performance of the unit you must clean the individual
parts regularly.
We recommend the Smini is cleaned at least once every three days.
Dismantle the Smini and wipe down all internal and external surfaces. Ensure
any liquid is removed from the surfaces of the product.
Cartridge Replacement.
Although the cartridge can be broken up to clean it should be replaced at least
every week.
Note: The rubber cartridge caps are designed for very limited use. With care,
the caps can be used repeatedly. If you begin to experience leaking around
the atomiser you will need to replace the cartridge.

!
©!2014!JTBD!Limited.!All!rights!reserved.!
8!
Storage
When not in use we strongly recommend unscrewing the battery from the
centre disc and atomiser casing. This will prevent any fluid from leaking
through the atomiser and into the battery.
Troubleshooting.
Burnt taste
•Check that the cartridge has not been overfilled. If it has empty the
cartridge till it is one third full.
•If the cartridge has not been overfilled you may have burnt your
atomiser. This can occur by trying to use the device with an over-filled
cartridge or with an empty cartridge. The atomiser may be black in
colour if it has been burnt.
•A burnt atomiser requires replacement. You can purchase replacement
atomisers on VAPO.co.nz
•An atomiser should last around 1 month if used correctly. If the
atomiser has been overused it can also give off a burnt taste. If this
happens please replace the atomiser.
Leaking
•The most common cause of leaking is when the cartridge is not
changed frequently enough
•Take the unit apart, clean all parts and replace the cartridge
•Leaking is important to avoid as the liquid can flow into the battery
where it can short the unit
•Ensure that the hole made in the cartridge cap is not too big to allow
leaking but not too small that the atomiser spike will not fit through to
allow access to the liquid in the cartridge.
Battery Problems
•Overheating is generally caused by fluid getting into the battery and
shorting the unit. If this occurs immediately cease use of the unit and
replace it
•If the battery is not functioning at all this is also a sign that fluid has
made its way into the battery. Cease using the product immediately
and replace it. This outlines the importance of replacing the cartridge
regularly to ensure a tight seal over the atomiser.
Any further questions relating to this product or any other product in the VAPO
range can be directed to [email protected]
