VARO POWERplus POW1010 User manual

POW1010 EN
Copyright © 2013 VARO P a g e | 1www.varo.com
1APPLICATION..................................................................................2
2DESCRIPTION .................................................................................2
3PACKAGE CONTENT LIST.............................................................2
4SYMBOLS........................................................................................3
5GENERAL POWER TOOL SAFETY WARNINGS ..........................3
5.1 Work area ................................................................................................................3
5.2 Electrical safety.......................................................................................................3
5.3 Personal safety .......................................................................................................4
5.4 Power tool use and care.........................................................................................4
5.5 Service.....................................................................................................................4
6SPECIAL SAFETY INSTRUCTIONS FOR JIG SAWS....................5
7OPERATING INSTRUCTIONS ........................................................5
7.1 Fitting the Inspector guard.....................................................................................5
7.2 Changing the saw blade.........................................................................................5
7.3Switching ON/OFF...................................................................................................6
7.4 Adjusting the base..................................................................................................6
7.5 Sawing tips..............................................................................................................6
7.6 Dust extraction........................................................................................................6
8TECHNICAL DATA..........................................................................6
9NOISE...............................................................................................7
10 WARRANTY.....................................................................................7
11 ENVIRONMENT ...............................................................................8
12 DECLARATION OF CONFORMITY ................................................8

POW1010 EN
Copyright © 2013 VARO P a g e | 2www.varo.com
JIG SAW 450W
POW1010
1 APPLICATION
The power tool is intended for sawing wood, metal and plastics. It is not designed for
commercial use.
WARNING! Please read and understand this operating manual before use
and keep it for your future reference. Your power tool should only be
passed on together with these instructions.
2 DESCRIPTION
1. Power cable
2. Locking button
3. On/Off switch
4. Inspection guard
5. Saw blade
6. Guide roller
7. Adjustable base
8. Hex key
9. Dust extractor socket
3 PACKAGE CONTENT LIST
Remove all packing materials
Remove remaining packaging and transit supports (if existing)
Check the completeness of the packing content
Check the appliance, the power cord, the power plug and all accessories for transportation
damages.
Keep the packaging materials as far as possible till the end of the warranty period.
Dispose it into your local waste disposal system afterwards.
WARNING Packing materials are no toys! Children must not play with
plastic bags! Danger of suffocation!
Machine
Manual
Hex key
1pc blade for wood
When parts are missing or damaged, please contact your dealer.

POW1010 EN
Copyright © 2013 VARO P a g e | 3www.varo.com
4 SYMBOLS
The following symbols are used in this manual and/or on the machine:
In accordance with essential requirements of the European directive(s).
Class II - The machine is double insulated; earthing wire is therefore not
necessary.
Read manual before use.
Wear a mask In dusty conditions.
Wear eye protection.
Wear noise protection.
5 GENERAL POWER TOOL SAFETY WARNINGS
Read all safety warnings and all instructions. Failure to follow all warnings and instructions
may result in electric shock, fire and/or serious injury. Save all warnings and instructions for
future reference. The term "power tool" in the warnings refers to your mains operated (corded)
power tool or battery operated (cordless) power tool.
5.1 Work area
Keep work area clean and well lit. Cluttered and dark areas invite accidents.
Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or
fumes.
Keep children and bystanders away while operating a power tool. Distractions can cause
you to lose control.
5.2 Electrical safety
Always check that the power supply corresponds to the voltage on the
rating plate.
Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching
outlets will reduce risk of electric shock.
Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges
and refrigerators. There is an increased risk of electric shock if your body is earthed or
grounded.
Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.

POW1010 EN
Copyright © 2013 VARO P a g e | 4www.varo.com
When operating a power tool outdoors, use an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the risk of electric shock.
If operating a power tool in a damp location is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces the risk of electric shock.
5.3 Personal safety
Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or
medication. A moment of inattention while operating power tools may result in serious
personal injury.
Use safety equipment. Always wear eye protection. Safety equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection used whenever conditions require
will reduce personal injuries.
Avoid accidental starting. Ensure the switch is in the off position before plugging in.
Carrying power tools with your finger on the switch or plugging in power tools that have
the switch on invites accidents.
Remove any adjusting key or wrench before turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool may result in personal injury.
Do not overreach. Keep proper footing and balance at all times. This enables better
control of the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and
gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in
moving parts.
If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of these devices can reduce dust related
hazards.
5.4 Power tool use and care
Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
Do not use the power tool if the switch does not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
Disconnect the plug from the power source before making any adjustments, changing
accessories, or storing power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
Store idle power tools out of the reach of children and do not allow persons unfamiliar with
the power tool or these instructions to operate the power tool. Power tools are dangerous
in the hands of untrained users.
Maintain power tools. Check for misalignment or sticking of moving parts, breakage of
parts and any other condition that may affect the power tool’s operation. If damaged, have
the power tool repaired before use. Many accidents are caused by poorly maintained
power tools.
Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to stick and are easier to control.
Use the power tool, accessories and tool bits etc., in accordance with these instructions
and in the manner intended for the particular type of power tool, taking into account the
working conditions and the work to be performed. Use of the power tool for operations
different from intended could lead to a hazardous situation.
5.5 Service
Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.

POW1010 EN
Copyright © 2013 VARO P a g e | 5www.varo.com
6 SPECIAL SAFETY INSTRUCTIONS FOR JIG SAWS
Important! Use of any accessories or attachments other than those
supplied or recommended in these operating instructions can mean the risk
of injury.
When using jig saws ear protectors and a face mask should be worn. Exposure to noise
can cause damage to hearing.
Do not use the jig saw to cut asbestos or materials containing asbestos.
Do not leave power tools running unattended. Always switch off and do not put down or
leave until it has stopped completely.
Long hair must be covered. Do not work in loose fitting clothing.
Be careful when working on walls. Damage to power supply lines, gas or water pipes can
lead to dangerous situations. Use appropriate detectors to establish whether there are
concealed wires or pipes in the working area.
Always check that the mains voltage corresponds to the voltage on the device's rating
plate.
Secure the work piece. The work piece is only secure if it is held by work-holding devices
or in a vice.
Use of extension cables. Only use extension cables which are designed for the machine's
power. The minimum conductor cross section must be 1.5 mm². When using cable reels
the cable must always be completely unrolled.
Always remove the mains plug before replacing saw blades.
Caution: saw blades can get very hot.
Saw blades must be kept sharp and in good condition. Replace partially fractured and
broken saw blades immediately.
Work calmly and evenly with the jig saw. You will thus avoid accidents and the saw blades
and the jig saw will last longer.
7 OPERATING INSTRUCTIONS
7.1 Fitting the Inspector guard
A : Inspector guard
Important : wear safety goggles
7.2 Changing the saw blade
Releasing the saw blade.
Turn the screws anticlockwise
Insert the saw blade in the ram up to the stop and
tighten the two screws of the retention clip.
Important ! : Make sure the saw blade sits
properly in the slot of the roller and ram.

POW1010 EN
Copyright © 2013 VARO P a g e | 6www.varo.com
7.3 Switching ON/OFF
Switching ON : Press the On/Off switch.
Continuous operation. Lock the On/Off switch with
the locking button.
Switching Off : Press the On/Off switch and
release.
A : locking button
B : ON/Off switch
7.4 Adjusting the base
Undo the 2 screws to set the base to an angle
up to 45° on the right or left side.
7.5 Sawing tips
Cutting veneered chipboard:
Use a fine saw blade
Position the base on the uncovered area
Advance the saw with little force.
A : support
Cutting holes : Possible only in chipboard and wood
unless you drill a hole first. Press the jig saw firmly
against the support and move slowly in cutting
direction.
7.6 Dust extraction
The jigsaw is equipped with a dust extractor socket. You can connect your vacuum cleaner to
the socket at the rear of the jigsaw. If you require a special adapter, please contact the
manufacturer of your vacuum cleaner.
8 TECHNICAL DATA
Nominal voltage
230 V - 50 Hz
Power consumption
450W
Cutting rate
2800 min-1
Cutting depth in wood
60 mm
Cutting depth in plastic
12 mm
Cutting depth in steel
8 mm
Mitre cuts
Up to 45° (left and right)

POW1010 EN
Copyright © 2013 VARO P a g e | 7www.varo.com
9 NOISE
Noise values measured according to relevant standard. (K = 3)
Acoustic pressure level LpA
81 dB(A)
Acoustic power level LwA
92 dB(A)
ATTENTION! The sound power level may exceed 85 dB(A), in this case
individual hearing protection shall be worn.
aw (Vibration)
6.4 m/s²
K = 1.5 m/s²
10 WARRANTY
This product is warranted for a 24-month period effective from the date of purchase by the
first user.
This warranty covers all material or production flaws excluding : batteries, chargers,
defective parts subject to normal wear & tear such as bearings, brushes, cables, and
plugs, or accessories such as drills, drill bits, saw blades, etc. ; damage or defects
resulting from maltreatment, accidents or alterations; nor the cost of transportation.
Damage and/or defects resulting from inappropriate use also do not fall under the
warranty provisions.
We also disclaim all liability for any bodily injury resulting from inappropriate use of the
tool.
Repairs may only be carried out by an authorised customer service centre for Powerplus
tools.
You can always obtain more information at the number 00 32 3 292 92 90.
Any transportation costs shall always be borne by the customer, unless agreed otherwise
in writing.
At the same time, no claim can be made on the warranty if the damage of the device is the
result of negligent maintenance or overload.
Definitely excluded from the warranty is damage resulting from fluid permeation, excessive
dust penetration, intentional damage (on purpose or by gross carelessness), inappropriate
usage (use for purposes for which the device is not suitable), incompetent usage (e.g. not
following the instructions given in the manual), inexpert assembly, lightning strike,
erroneus net voltage. This list is not exhaustive.
Acceptance of claims under warranty can never lead to the prolongation of the warranty
period nor commencement of a new warranty period in case of a device replacement.
Devices or parts which are replaced under the warranty therefore remain the property of
Varo NV.
We reserve the right to reject a claim whenever the purchase cannot be verified or when it
is clear that the product has not been properly maintained. (Clean ventilation slots, carbon
brushes serviced regularly, etc.).
Your purchase receipt must be kept as proof of date of purchase.
Your appliance must be returned undismantled to your dealer in an acceptably clean state,
(in its original blow-moulded case if applicable to the unit), accompanied by proof of
purchase.

POW1010 EN
Copyright © 2013 VARO P a g e | 8www.varo.com
11 ENVIRONMENT
Should your appliance need replacement after extended use, do not discard it
with the household rubbish but dispose of it in an environmentally safe way.
Waste produced by electrical machine items should not be handled like normal
household rubbish. Please recycle where recycle facilities exist. Check with your
Local Authority or retailer for recycling advice.
12 DECLARATION OF CONFORMITY
VARO N.V. –Joseph Van Instraat 9 –BE2500 Lier –Belgium, declares that,
product Jig saw
trade mark PowerPlus
model POW1010
is in conformity with the essential requirements and other relevant provisions of the applicable
European Directives, based on the application of European harmonized standards. Any
unauthorized modification of the apparatus voids this declaration.
European Directives (including, if applicable, their amendments up to the date of signature);
2011/65/EU
2006/42/EC
2004/108/EC
European harmonized standards (including, if applicable, their amendments up to the date of
signature);
EN60745-1 : 2009
EN60745-2-11 : 2010
EN55014-1 : 2006
EN55014-2 : 1997
EN61000-3-2 : 2006
EN61000-3-3 : 2008
Keeper of the Technical Documentation : Philippe Vankerkhove, VARO –Vic. Van Rompuy
N.V.
The undersigned acts on behalf of the company CEO,
Philippe Vankerkhove
Regulatory Affairs –Compliance Manager
13/05/2013
