Vauth-Sagel IRONING BOARD User manual
IRONING BOARD
Cabinet dimensions
Width min. I.D. : 400 mm - 547 mm
Depth min. I.D. : 510 mm
Height min. I.D. : 120 mm
Description
Fitting: RAL 9010 white
Ironing Board Full Extension
06 / 2007 / HS
400 to 547
(15.75 to 21.50 )
min. 120
(4.72 )
mm (in.)
1. Left Slide
2. Right Slide
3. Support Bracket
4. Drawer Front Bracket
5. Support Bracket
SYSTEMTECHNIK
page 1 of 3
We reserve the right to change and/or improve the technical specificationswithout notice. For the most current technical information please call us.
1Assembling the cabinet
guide slide “left / right“
The guide slides are to be
positioned in such a way that
there are 34 mm between the
cabinet front edge and the
middle hole of the slide; and
from the cabinet upper edge
to the middle hole of the slides,
there should be 74 mm with a
countertop thickness of 30 mm
(thickness 40 mm =
64 mm) (see diagram A).
Fasteners:
countersunk screws 4.5 x 15
2Assembling guide slide
“left / right“
Push the guide with the
support bracket across the
mounted cabinet slide.
3Assembling Ironing Board
on the Support Bracket
The board is placed in the
middle of the support bracket.
Place the angle support on the
front support bracket. Screw
the Ironing board and the
angle support bracket from
underneath on the support
bracket in the front and back.
Fasteners:
Cylinder head screws M 6.0
Washers
Screw nut M 6.0
Note:
Make sure the slide
movement in smooth
before firmly tightening
all screws.
41634
32 X
2h
(h)
30er
40er
X
74
64
countersunk screws
4.5 x 15
cabinet guide slide
cabinet guide slide
guide with slide with support bracket
Countertop thickness diagram A
cabinet side left / right
screw to drawer front
support bracket
ironing board
Cylinder head screws M 6.0
guide side
Cylinder head
screws M 6.0
support bracket
angle support
bracket
SYSTEMTECHNIK
page 2 of 3
4Assembling the drawer front
Attach the front as
indicated in diagram B.
Fasteners:
panhead screws 4.0 x 16
5Assembling angle support
bracket with the board to
the drawer front
screw the angle support
bracket as indicated.
Fasteners:
panhead screws 4.0 x 16
400 (450 / 500 / 600)
304 (354 / 404 / 504)
Y
11
32 X
diagram B
Drawer Front
Drawer Front
Drawer Front
X = 44 + overlay
Y = 32 + overlay
guide side
support bracket
support bracket
angle
support bracket
guide side
support arm
SYSTEMTECHNIK
page 3 of 3
