Vax VCS-01 User manual
COMMERCIAL
VCS-01
VCS-01
User Guide
Vax Commercial Careline: (UK) 0844 375 4275
vaxcommercial.co.uk
Performance is everything.
8
9
1
2
4
9
5
3
6
7
Machine Overview
2 vaxcommercial.co.uk
1 Upper metal handle
2 Lower metal tube
3 Handle position dials
4 Dirt container
5 Brush height adjust dial
6 Dirt container handle
7 Dirt container release button
8 Sweeper brushes
9 Wall guides
Assembly
3Vax Careline: (UK) 0844 375 4275
Slide metal handle (A) over lower
metal tubes (B). Press button and
slide lower tube into upper handle
until the button snaps into place.
There are 5 height settings.
Assembling your sweeper
PLEASE READ SAFETY INFORMATION BEFORE USE (PAGE 8)
A
B
Remove tape from the caster
wheel on the bottom of unit.
Unscrew the dial located on each
side of the machine.
Reattach dials and screw
until secure.
Align holes in the lower tube to
the screw posts.
Operation
4 vaxcommercial.co.uk
The brushes rotate and sweep
up debris when the sweeper is
pushed forward. The brushes do
not rotate when the machine is
pulled backwards.
For use on atter surfaces and
smaller debris.
c30,2&#&#'%&2"(312"'*rs
towards ‘LOW’
c�#0-$2##.#05'**0'1#
For use on rougher surfaces and
larger debris.
c30,2&#&#'%&2"(312"'*rs
towards ‘HIGH’
c�#0-$2##.#05'***-5#0
Wall guides are provided to
aid sweeping close to edges by
guiding either side of the sweeper
along walls.
NOTE: For best results,
push the sweeper at a
normal walking pace.
(circa 5kph)
NOTE: If the sweeper
is dicult to push on a
surface, turn the height
adjustment towards ‘HIGH’.
CAUTION: The sweeper
is designed for use on
hard, at surfaces. It is not
intended to be used for wet
pick up, on lawns or carpet.
!
!
!
Low brush position High brush position
Brushes and wall guides
BRUSH HEIGHT
MEDIUM
A
BRUSH HEIGHT
MEDIUM
BRUSH HEIGHT
MEDIUM
Adjusting the brush height
Maintenance
5Vax Careline: (UK) 0844 375 4275
Push handle forward so it is no
longer resting on the container.
To replace container, align indent
over the height adjust dial.
Lower container onto the
sweeper until it snaps into place.
The sweeper can be stored
upright or hanging in a dry place,
out of direct sunlight.
Emptying and storing
NOTE: It is advised that you empty and clean the bin with warm water (40°C) and mild detergent
before storage.
Slide container release (A)
towards the rear of the sweeper.
Lift handle (B), remove the
container and empty.
A
B
!
Maintenance
6 vaxcommercial.co.uk
Brushes can be cleaned with warm water (40°C) and mild detergent.
To maintain peak performance, it is advised you regularly clean the sweeper brushes.
Cleaning sweeper brushes
WARNING: Do not use high pressure water spray to clean the brushes.
NOTE: For spare or replacement parts, please call the Vax Commercial careline (0844 375 4275)
or visit vaxcommercial.co.uk
Front Back Inside
BRUSH HEIGHT
MEDIUM
!
!
Clean the top side of the brushes
with a damp cloth.
Turn the unit over and clean the
under side of the brushes.
Remove the dirt container and
clean the inside of the brushes.
FAQs
7Vax Careline: (UK) 0844 375 4275
Why is debris being swept back onto surface during use?
c'%&2"# 0'1+7&4#!-**#!2#"',2&#$0-,2-$2&#"'02!-,2',#0I2�#$-0#2'.2##.#0 !)2-**-52&#
debris to move to the back of the dirt container.
Why does the sweeper leave a line of debris?
c##.#0'1 #',%.31&#"2--1*-5*7I207.31&',%2##.#01*'%&2*7$12#0G
c07.02'**7-4#0*..',%15##.',%.2&1G
Why is the sweeper dicult to push?
c30$!#'10-3%&-03,#4#,G
c30,2&# 031&&#'%&2"(312+#,2"'*2-50"1&'%#22',%G
Why is the sweeper not picking up debris?
c-5#02##.#0&#'%&2$-01+**"# 0'1G
c'1#2##.#0&#'%&2$-0*0%#"# 0'1G
Why won’t the brushes turn?
c$2‚$!#'13,#4#,I230,2&# 031&&#'%&2"(312+#,2"'*2-50"&'%#22',%G
c$'2'1&'%&$0'!2'-,130$!##G%G!0.#2I2##.#05'**,-2$3,!2'-,.0-.#0*7G
What do I do if the unit becomes damaged or broken?
c#U0#�#2-&#*.G'+.*7!**0844 375 4275 or visit vaxcommercial.co.uk
General Safety Information
8 vaxcommercial.co.uk
When using the sweeper, basic safety precautions should always be observed, including the following:
1. This appliance should be stored in dry and dark environments only.
2. Empty this appliance after each use.
3. Do not use this appliance for sweeping up liquids.
4. This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, unless they have been given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
5. Do not use this appliance if it has been dropped or damaged.
Call 0844 375 4275 for advice and assistance.
6. Ensure airways remain clear of blockages during use for best performance.
7. Keep hair, loose clothing, ngers and all parts of the body away from openings and moving parts. Do not
operate this appliance in bare feet or when wearing open toe shoes or sandals.
8. Do not pick up hot, smoking, burning, ammable, hazardous or combustible materials or use in the
presence of explosive liquids or vapours.
9. Do not sweep up harmful or toxic material (chlorine bleach, ammonia, drain cleaner, etc).
10. Do not use this appliance to sweep steps.
11. To avoid injury, wear safety gloves when removing glass, metal or similar material from dirt container.
12. Do not use the sweeper near heat sources such as re, fan heaters, or other heat dissipating devices.
13. Do not use this appliance to sweep over electrical cords.
14. Use only this appliance as described in this manual.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Machine Overview
9Vax Careline: (UK) 0844 375 4275
Service & Help
Vax Commercial Careline:
(UK) 0844 375 4275
Monday-Friday 8.30am to 6.30pm
Saturday-Sunday 9.00am to 5.00pm
Any queries or concerns about using your Vax, call the Vax Commercial Careline. Calls are charged at the UK
local rate. Please make a note of the serial number and model number of the sweeper before calling. For the
nearest Service Agent, please call the Vax Commercial Careline or visit vaxcommercial.co.uk
Technical Specication
Capacity: 25L
Weight: 7.3kg
Cleaning path: 46cm
Subject to technical change without notice.
Disposal
This product should not be disposed of with the house-hold waste. Please recycle where facilities exist.
Check with your Local Authority or retailer for recycling advice.
