Vax SWEEPER VAC V-036 Product information sheet

UK SERVICE & HELP - VAX CARE 0870 6061248
Monday to Frday 9.00am to 5.00pm. An answer phone is available out of these hours. If you have queries or concerns about using your VAX, call the HELPLINE. Calls are charged at the UK national rate.
Please make a note of the serial number and model number of your VAX before calling. There are over 400 approved VAX Service Agents in the UK . For your nearest Service Agent, please call VAX Care.
V-036 Easy Guide

2
1. Hanging loop
2. On/off switch
3. Upper handle
4. Lower handle
5. Dust canister release button
6.See-through dust canister
7. Dry cloth head
8. Cleaner nozzle
9. Dry cloths
10.Charger
11. Charging indicator
12. Charger input
Parts checklist
11
1
2
3
4
5
6
7
8
10
9
12

Putting your cleaner together
Insert the lower handle into the body of the unit and firmly push in until it locks
into place. Be sure to line up the 2 notches to help guide the lower handle into the
body properly.
Insert the upper handle into the lower handle of the unit and firmly push into
place. Use the alignment tabs to help guide the upper handle in properly.
1234
3
Notches
Top view of cleaner

4
Charging Storage
NOTE: Only use the charger supplied.
CHARGE 24 HOURS BEFORE FIRST USE.
Connect the charger to a wall socket. Plug the charger end into the back of the unit. Use the storage hook to hang the cleaner up.
NOTE: Hang in a place convenient for charging.
12 1

5
Operating the vacuum cleaner
FOR ADVICE ON ELECTROSTATIC DRY CLOTHS, PLEASE CALL VAX CARE ON 0870 6061248.
NOTE: This product is intended for dry pick up only. Do not attempt to vacuum up any liquids with this cleaner.
Lift the vacuum nozzle. It should lock into position. Place one electrostatic cloth on the dry cloth head of
the unit. Secure by pushing the edge of the cloth into
the tabs.
Pull the vacuum nozzle back to the floor cleaning
position.
123

6
Operating the vacuum cleaner
Use the dry electrostatic cloth to pick up fine debris like dirt, dust and pet hair.
Use the vacuum to suck up any left-over debris. For best results, replace the dry
cloth as needed.
To turn the vacuum on: hold down the on/off button located on the handle.
Release the button to turn the vacuum off.
45

Dust canister and filter
IMPORTANT: FOR BEST RESULTS, CLEAN THE FILTER AFTER EACH USE.
For advice on filter replacement, please call VAX Care on 0870 6061248.
Removing the dust canister
Press the dust canister release button located above
the container on the body of the unit. Tip the dust
canister out to remove.
Grasp the centre tab on the filter and pull out of the
dust canister.
IMPORTANT: Do not wash the filter.
Empty the contents into a waste bin. For best
results, shake and lightly tap the filter against the
waste bin to remove remaining dirt.
123
7

8
Dust canister and filter
Replacing the dust canister
Return the filter to the dust canister. Re-attach by aligning the tab on the dust canister with
the slot on the body of the unit.
Tilt and push the dust canister until it locks into place.
456
Slot
Tab

Troubleshooting
PROBLEM
Cleaner won’t run
Cleaner won’t pick-up/loss of suction
Dust escaping from cleaner
POSSIBLE REASONS
1. Battery not charged.
2. Handle is not pushed into housing.
3. Battery dead - won’t hold a charge.
4. Needs service.
1. Dust canister is full.
2. Filter is dirty.
3. Battery charge is getting weak.
1. Dust canister is full.
2. Filter is dirty.
POSSIBLE CAUSES
1. Charge battery. For first use, charge for at
least 24 hours.
2. Make sure handle is pushed firmly all the
way into housing.
3. Call VAX Care on 0870 6061248.
4. Call VAX Care on 0870 6061248.
1. Empty dust canister
2. Remove filter and clean.
3. Charge battery.
1. Empty dust canister.
2. Clean or replace filter.
9
WARNING: TO REDUCE RISK OF PERSONAL INJURY, UNPLUG CLEANER BEFORE SERVICING.
VAX CARE: 0870 6061248

Safety
• Use only dry dusting cloths. Do not use wet cloths.
• To prevent electric shock, do not use outdoors or on wet surfaces.
• Do not charge the unit outdoors.
• Not to be used as a toy. Close attention is necessary when used by or near children.
• Use only as described in this user guide.
• Use only the manufacturer’s recommended attachments.
• Do not use the charger with a damaged cord or plug.
• Do not pull or carry by the cord, use the cord as a handle, allow the cord to come into contact with hot or sharp surfaces or close a door on the cord.
• Do not unplug by pulling on the cord.
• Do not handle the plug or appliance with wet hands.
• This product includes rechargeable nickel cadmium batteries. Do not incinerate the batteries or expose them to high temperatures, as they may explode.
• Unplug the charger from the outlet before performing any routine cleaning or maintenance.
• Keep hair, loose clothing, fingers and all parts of body away from openings and moving parts.
• Do not vacuum any glowing, burning or smoking particles.
• Do not use without the dust canister and filters in place.
• Turn off all controls before unplugging.
• Use extra care when cleaning on stairs.
• Do not use to pick up flammable or combustible liquids such as petrol, or use in areas where they may be present.
• Leaks from battery cells can occur under extreme conditions. If the liquid, which is 20-35% solution of potassium hydroxide, gets on the skin, (1) wash
quickly with soap and water or (2) neutralise with a mild acid such as lemon juice or vinegar. If the liquid gets into the eyes, flush them immediately with
clean water for a minimum of 10 minutes. Seek medical attention.
• Use only the charger supplied by the manufacturer to recharge.
• Store the vacuum cleaner indoors. Put the vacuum cleaner away after use to prevent tripping accidents.
• Keep cloths out of reach of toddlers and pets to avoid accidental ingestion.
• If your VAX fails to operate, never attempt to repair it yourself, as repairs carried out by an unauthorised or inexperienced person may cause injury to you or
damage to your VAX. Never alter the specification or modify your VAX in any way.
For further information in the UK, call the VAX HELPLINE: 0870 6061248
10

11 (This page has been left intentionally blank)

EEC STATEMENT OF COMPLIANCE
Manufacturer/EEC importer: VAX Limited, hereby on our own responsibility declare that the product Sweeper Vac is manufactured in compliance with the following:
Safety: 72/23/EEC Low Voltage Directive as modified by 93/68/EEC
EMC: 89/336/EEC Electromagnetic compatibility Directive as modified by 93/68/EEC
VAX Ltd., Kingswood Road, Hampton Lovett, Droitwich, Worcestershire, WR9 0QH, UK
email: [email protected] - website: www.vax.co.uk
Version 1
