Vax MACH PET Installation instructions

vax.co.uk
C85-MQ-Pe
Mach
Pet
Let’s get started

Let’s talk safety
Basic
safety
precautions
Don’ts
Do’s
This vacuum cleaner is intended for household use only and
NOT for commercial or industrial use.
• Only use the vacuum cleaner indoors on dry surfaces and
keep the area you’re cleaning well lit.
• Keep ngers, hair and loose clothing away from moving parts
and openings whilst using the vacuum cleaner.
• Only Vax recommend tools and accessories should be used
with this vacuum cleaner.
• Don’t use this vacuum cleaner if it has been dropped, damaged
or left outdoors or the lters not in their original place.
• Don’t run over the power cord or use vacuum cleaner if the
power cord or plug is damaged. Please contact our Customer
Care Line on: 0330 026 8455 (Mon-Fri 8:30am to 6:30pm,
Sat 9:00am to 5:00pm).
• Don’t handle the plug or use the vacuum cleaner with wet hands.
• Don’t pull or carry this vacuum cleaner by the power cord.
Don’t use the power cord as a handle, pull the power cord
around corners, sharp edges or close a door over the power
cord. Don’t unplug vacuum cleaner by pulling on the power cord.
• Don’t lift or carry the vacuum cleaner by the dirt container handle.
• Turn o all controls on the vacuum cleaner before
disconnecting or connecting the power cord.
• Always make sure both the pre-motor/post-motor lters are
in place before use.
• Always switch o the vacuum cleaner before disconnecting
or connecting the hose and accessories.
• Keep all openings clear and free from debris as this may aect
the airow/suction.
• Always replace the fuse in the plug with a British 13amp fuse.
• Always protect the power cable from heated surfaces and
open ames.

• This vacuum cleaner can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the vacuum cleaner in a safe way and understand the
hazards involved. Children shall not play with the vacuum cleaner. Cleaning
and user maintenance shall not be made by children without supervision.
• Don’t vacuum up any ammable or combustible materials (lighter uid, petrol,
kerosene etc.) or use the vacuum cleaner in an area with explosive vapours
or liquid.
• Don’t vacuum up hot coals, cigarette butts, matches or smoking hot burning
items or use in an area where there may be harmful uids (chlorine, bleach,
and ammonia drain cleaner).
• Don’t attempt to remove blockages with sharp objects as this may cause
damage to your vacuum cleaner.
• Don’t vacuum up hard or sharp objects such as glass, nails, screws or coins etc.
• Don’t use the vacuum cleaner with incorrect voltage as this may result in
damage or injury to the user. The correct voltage is listed on the ratings label.
• Take extra care when positioning and using the vacuum cleaner on the stairs.
• Use only CE approved 13amp extension cords, non-approved extension cords
may overheat. Care should be taken to arrange the extension cord as it can
be a trip hazard.
• Store your vacuum cleaner in a cool, dry area. If lters have been cleaned
as per user guide instructions ensure they are thoroughly dry before
storing away.
PLEASE KEEP INSTRUCTIONS FOR FURTHER USE.

Let us know what you think @VaxUK
Taking care of you
We’re here if you need us. Instead of taking me back
to the shop, simply visit:
vax.co.uk/support or call:
(UK) 0330 026 8455 (ROI) 1-800 928 308
Monday-Friday 8:30am to 6:30pm, Saturday 9:00am to 5:00pm
Calls are charged at the UK local rate. Please make a note of the serial number and model number
of the product before calling.
Alternatively, you can write to us at:
Vax Ltd., Plot 302, Stonebridge Cross Business Park, Hampton Lovett, Droitwich, WR9 0LW, UK
This user guide can be found online at: vax.co.uk/support
Thank you for buying this Mach Pet.
Taking care of your carpets and hard oors
The Mach Pet is designed to make vacuuming carpets and hard oors regularly, as eective
and ecient as possible and this user guide will help you get the most out of your machine.
Maintaining your carpets and hard oors will ensure they keep their appearance for longer.
You’ve chosen the carpets and hard oors for your home for a reason and Vax will help you
take good care of them.
Taking care of your Mach Pet
Also inside this guide are instructions on maintaining your new machine, so that it’s always
ready when you are to tackle your carpets and hard oors.

Contents
Let’s talk safety
Getting to know your machine
Getting started
Using your machine
Taking care of your machine
Let’s talk technical
Accessories
Notes
What to do if it goes wrong
Getting in touch
Mach Pet
Included with
your machine
Telescopic extension tube
Initial Setup for normal operation
1. Use the base accessories.
– Shortest hose.
– Extension tube set to shortest practicable length.
2. Clean lters installed.
3. Dust receptacle empty.
4. All Bleeds must be closed.
5. Floor heads/tools set to Carpet Mode for carpet cleaning.
6. Mechanical Agitation turned ON for carpet cleaning.
7. Floor heads/tools set to Hard Floor Mode for hard oor cleaning.
8. Mechanical Agitation turned OFF for hard oor cleaning.
Combination oorhead
Accessory hose and handle
TurboTool
Tool connector
3-in-1 tool

Getting to know your machine
Name Mach Pet
Voltage See rating label on machine for details
Wattage See rating label on machine for details
Cord length 6m
Weight 5.5kg
Technical Specication
Subject to technical change without notice.
Accessories & Consumables
*To purchase consumables and accessories, please visit vax.co.uk
Filter kit (Type 95)*
1-1-134231-00
2-in-1 tool (Type 2)*
1-1-132115-00
Upholstery tool (Type 6)*
1-9-132116-00
TurboTool (Type 6)*
1-1-134419-00
Hard oor tool (Type 3)*
1-1-135705-00
Cord rewind button
Bin release button
Carry handle
Power On/O button
Hose inlet
Dirt container
Dirt container lid
Inner cyclone
Inner wheel and
lter housing
Floorhead parking slot

Assembling your machine
Insert the end of the hose
into the unit. Ensure the
hose has clicked into place.
Insert handle into
telescopic extension tube.
Press button on telescopic
extension tube and adjust
to required length.
Insert the other end of
the telescopic tube into
the oorhead until it clicks
into place.
PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE
Getting started
IMPORTANT: The condition of the lters aects the performance of your machine. Please check and clean lters
periodically (depending on the level of use). For full cleaning instructions, see ‘Taking care of your machine’.
Before you begin cleaning
• Always switch o and unplug the vacuum cleaner before connecting or disconnecting the hose/attachments, or removing
and emptying the dirt container.
• The vacuum cleaner is equipped with a thermal cut-out. If for any reason the vacuum cleaner does overheat the thermostat
will automatically turn the vacuum cleaner o. If this happens, switch the vacuum cleaner o and unplug from electrical
socket. Remove and empty the dirt container also check the vacuum cleaner for blockages. Allow the vacuum cleaner to
cool for approximately 1 hour (if you have cleaned the lters please wait 24 hours for the lters to fully dry before putting
back into the vacuum).
• Pre-motor lter requires cleaning at least every 3 months.
• If the vacuum cleaner is blocked, switch o and unplug before removing the blockage.
• When using the accessories always make sure the brushbar is switched to the o position.
IMPORTANT: The base of the vacuum cleaner should always be positioned at on the oor when starting and in use.
The dirt container should be locked into place before lifting the vacuum cleaner by the carry handle.

Using your machine
How to use
Choose an accessory and
push onto the telescopic
extension tube or hose.
The tool connector must be tted on the handle or extension
tube when using the TurboTool (some models only).
Using accessories
Fully unwind the power
cord. A yellow mark on
the cord indicates the
recommended cord
length. Do not exceed
the cord beyond the
yellow mark.
Plug in and switch the
unit on by pressing the
power button.
Use the vacuum by moving
the oorhead backwards
and forwards for an
eective clean.
Remove the oorhead
to use the hose in harder
to reach places.

Emptying and cleaning the dirt container
Taking care of your machine
Don’t over ll the dirt
container to avoid blocking
the air ow through the
vacuum cleaner.
TIP
IMPORTANT: Always switch o and unplug the vacuum cleaner from the electrical socket before assembling, opening
or emptying the dirt container, or before connecting/disconnecting the attachments.
The motor is equipped with a thermal cut-out. If for any reason the unit should overheat, the thermostat will
automatically turn the unit o.
Press dirt container release
button to remove the
dirt container.
Hold dirt container over a
bin and press dirt release
button to open, allowing
dirt to fall out.
To remove the inner shroud,
hold the container and rotate
the shroud clockwise.
Hold the container and
turn the inner separator
anti-clockwise.
Dislodge any excess dirt
by gently tapping the inner
separator over the bin.

Taking care of your machine
!
40˚C
MAX
24hr
Cleaning the pre-motor lter
Twist the dirt container
lid anti-clockwise and
lift to remove.
Tap the lter over a
bin to remove any dirt
and debris.
Lift out the pre-motor lter. Rinse the lter under water
(40°C Max). Leave to dry
for 24 hours before placing
back in the machine.
Post-motor lter maintenance
Post-motor lter is located
in the right side wheel.
Hold the centre of the
wheel and twist wheel
cover anti-clockwise.
Check the post-motor
lter for discolouration.
With the wheel cover o
the post-motor lter is
easily removed.
Clean the pre-motor
lter every time the dirt
container is emptied and
replace the post-motor
lter every 12 months.
!
40˚C
MAX
24hr
IMPORTANT: The exhaust lter is designed to oer long life with no maintenance. The lter should be checked
periodically and when heavily discoloured it should be replaced. Please do not wash, scrub or brush the lter as
this will damage the delicate lter media.
TIP
Cable rewind button is
located at the rear of the
machine. After unplugging
press the cable rewind until
the cord is fully retracted.
For convenience there is a parking slot located
at the rear of the vacuum cleaner where the
oorhead and tubes can be attached for storage
and carrying.
Storing your machine

Removing blockages from the TurboTool
IMPORTANT: Remove accessory from hose or telescopic extension tube before performing maintenance or trouble
shooting checks.
Remove the hose from the vacuum cleaner and
telescopic extension tube. Remove any blockage
by inserting a wire coat hanger into the hose.
Removing blockages from the hose
Let’s talk technical
Slide the locking ring
to remove.
Using a pair of scissors,
cut any hair or debris free
from around the brushes.
Lift and separate
the housing.
Line up the tabs on front of
housing and push together
to ret. Slide locking ring
into groove to secure.
Tabs
To test for a blockage in
the hose, drop a small ball
of paper into the hose. The
paper will drop through if
the hose is clear.
TIP

Pro Cleaning Kit (Type 2)
1-1-133326-00
All our best tools all in one kit that makes cleaning
your home quicker, easier and with even better
results. We’ve taken care of cleaning all of the hard
to reach areas such as on top of cupboards and in
between blinds to the dust that collates behind and
within the radiator.
Don’t forget your accessories!
Order at: www.vax.co.uk/spares-and-solutions
TurboTool (Type 6)
1-1-134419-00
Use the TurboTool for vacuuming your stairs,
upholstery and car interiors. It’s great for picking
up stubborn pet hair.
Accessories

Notes

• Check the ‘This pack contains’ panel on the box to make sure the part
is included with your machine.
• The plug may not be fully pushed into the electrical socket.
• Check the fuse in the plug if this needs replacing, always replace with a British
13amp fuse.
• The motor thermostat may have tripped. If this has happened, unplug the vacuum
cleaner. Remove and empty the dirt container and check the hose for blockages.
Clean the lters and allow the vacuum cleaner to cool for approximately 1 hour
(if you have washed the lters you will need to wait 24 hours for the lters to
fully dry before putting them back into the vacuum cleaner).
• The lters may be clogged, clean the lter. Go to ‘Taking care of your machine’.
• The dirt container may not be correctly tted, remove the dirt container from
the vacuum cleaner and check it’s assembled correctly, ret ensuring it’s locked
into place.
• The lter may be clogged, clean the lter. Go to ‘Taking care of your machine’.
• The dirt container may be blocked, empty the dirt container. Go to ‘Taking care
of your machine’.
• There may be a blockage in the hose/tube. Disconnect from the vacuum cleaner
and carefully remove any blockages. Go to ‘Let’s talk technical’.
SolutionProblem
IMPORTANT: To reduce the risk of personal injury, unplug the vacuum before performing maintenance/
troubleshooting checks.
What to do if it goes wrong
There is an
accessory missing
Why does my vacuum
cleaner have no power?
Why won’t the vacuum
cleaner pick up?
Why is dust escaping
from the vacuum?

†
Getting in touch
* Calls are charged at the UK local rate. Please make a note of the serial number and model number of the product before calling.
†Registration required. Terms and conditions apply, see vax.co.uk for details.

Vax Ltd., 5th Floor 2 Colmore Square, 38 Colmore Circus, Queensway, Birmingham, B4 6BN, UK
email: [email protected]o.uk website: vax.co.uk
EEC Statement of Compliance: Manufacturer/EEC importer: Vax Limited, hereby on our own responsibility,
declare that the C85-MQ-Pe is manufactured in compliance with the following Directives:
Safety: 2006/95/EC Low Voltage Directive. EMC: 2004/108/EC Electromagnetic Compatibility Directive.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
Check with your Local Authority or retailer for recycling advice.
@VaxUK
© 2015 All rights reserved. VAX®, VAX Lozenge are trade marks or registered trade marks of Techtronic Floor Care Technology Ltd.
