Vaxcel T0102 Instruction manual

ASSEMBLY AND INSTALLATION
INSTRUCTIONS
NOTES: 1. Before installing, consult local electrical codes for wiring and grounding requirements.
2. READ AND SAVE THESE INSTRUCTIONS.
T0101 / T0102
WARNING:
TO AVOID RISK OF ELECTRICAL SHOCK, BE SURE TO SHUT OFF
POWER WHILE INSTALLING OR SERVICING THIS FIXTURE.
T0101 / T0102 --- Page 1 / 2
Mounting Screw (A) Mounting Screw (B) Mounting Bracket Screw (D) Fixture Mounting Screw (G)Decorative Cover(F)
Mounting Strap (E)Mounting Screw (C) Wire Nut (H)
140919
Hardware Package (included):
IMPORTANT:
The fixture features a photocell sensor which enables the light to turn on at dusk and off at dawn automatically.
Note: Fixture can be wall mounted or eave mounted.
Wall Mounted Eave Mounted
Light fixture should be mounted as shown above when installed (depending upon type of installation)
FRONT
Turn off the power at fuse or circuit box.
1. The mounting bracket is pre-assembled on the light fixture, unscrew the decorative cover, fixture mounting screw and
remove the mounting bracket.
Mounting Strap (E)
Mounting Bracket
Outlet Box
Wire Nut (H) Back Plate
Mounting Screw (A)
Light Head
Fixture Mounting Screw (G)
Mounting Bracket Screw (D)
Decorative cover (F)

140919
T0101 / T0102 --- Page 2 / 2
Mounting Screw (A) Mounting Screw (B) Mounting Bracket Screw (D) Fixture Mounting Screw (G)Decorative Cover(F)
Mounting Strap (E)Mounting Screw (C) Wire Nut (H)
Turn on the power at the main fuse or circuit breaker box.
2. Install the mounting strap with the stamped word “FRONT” facing
away from the outlet box, using two mounting screws that best fit the
outlet box.
3. Pull out the source wires from the outlet box. Make wire connections
using wire nuts as follows:
---Connect the black wire from the fixture to the black wire from the
power source.
---Connect the white wire from the fixture to the white wire from the
power source.
---Connect the grounding wire from the fixture to the grounding wire
from the power source. (usually green / yellow insulation)
Carefully tuck the wires back into the outlet box.
4. Place mounting bracket against the outlet box, insert the mounting
bracket screw through the mounting bracket hole, thread mounting
bracket screw into the center hole of the mounting strap. Tighten the
mounting bracket screw securely.
▲ When mounting to a wall, the “UP” arrow must point upward.
(See Fig. 1)
▲ When mounting to an eave, the “UP” arrow must point toward
the building.
5. Attach the back plate of the light fixture to the mounting bracket, secure it with the fixture mounting screw.
6. Push the decorative cover firmly into the fixture mounting screw hole on the light fixture.
7. With silicone caulking compound, caulk completely around where the mounting bracket meets the wall surface.
CAUTION: Be sure to caulk completely where the mounting bracket meets the wall surface to prevent water
from seeping into the outlet box.
8. Gently grasp the light heads and move them up or down, left or right to adjust the light coverage area. (See Fig. 2)
9. Keep the light heads 30˚ below horizontal to avoid water damage and electrical shock.
Fig. 2
Note: When power is first applied, the light will turn on immediately. Wait for 15 seconds to allow the sensor to
warm up.
Assembly Kit
5076MM
(1 SET)
The following parts are available for re-order if damaged or missing.
Fig. 1
A: 9-3/8"
B: 5-1/4"
C: 5-1/4"
