CD 2803
RDS Tuner / CD MP3 Player
So t-Take-In CD Player
CD-Changer Control
4-Channel 4V Preamp Out
3D Surround Sound
Preset Buttons
Bass Boost System (BBS)
Hands ree Phone In
Speed Dependent Volume Control (SDVC)
So tware Access Menu (SAM)
Credit Card Remote Control included
4 x 55 Watts

VDO Dayton. The Car Brand.
Car Multimedia Systems.
www.vdodayton.com
CD 2803
RDS Tuner / CD MP3 Player
So t-Take-In CD Player / CD-Changer Control
Product Design
• Silver-grey Metallic Finish
• Flipdown Front, detachable
• Multicolour Display
• Protection-LED
• Pilot Light
Tuner
• RDS Tuner
• FM with RDS TRAFFIC, NEWS
• MW, LW
• Preset Buttons
12 FM / 12 MW / 6 LW
• RDS Clock
CD Player
• CD MP3 Player
• High End CD-Drive
• Soft-Take-In CD-Drive
• CD-R & CD-RW compatible
Internal Amplifier
• Max. Power: 4 x 55 Watts
• RMS Power: 4 x 27 Watts
• 4-Channel 4V Preamp Out
• 3D Surround Sound
• Bass Boost System (BBS)
• 5 Sound Presets
• CD-Changer Control
(Analog)
• Aux In (optional cable
AC 1108 required)
General
• Speed Dependent
Volume Control (SDVC)
• Handsfree Phone In
• Telephone In
• Telephone Mute
• Navigation Mute
• Software Access Menu
(SAM)
• Credit Card Remote
Control included
• Dimensions (w x h x t):
180 x 51 x 150 mm
• DIN + JIN Mounting
Options
• Handsfree Phone Kit
C1
E
CD 2803
B
F
A
C1 C2 C3
D1
G
02/03, CD 2803,
subject to modification
4 x 55 Watts
4-Channel 4V Preamp Out
The 4-channel line out multiplies the sound power combinations and
pre-amplifier connections. In order to optimize at its maximum the signal
to noise ratio and increase the dynamic, outputs are supplied at 4V.
Preset Buttons
Each model of the new 2003 VDO Dayton radios posesses three buttons
which make 12 FM, 12 MW and 6 LW preset stations available. Those pro-
vide you with more comfort and easy access to your most favourite radio
stations.
3D Surround Sound
Brings ultimate "3-dimensional" sound into your car, engulfing the
listeners in a sea of sound - listening pleasure at its highest! By a tricky
electronic network the interior of your car is enlarged.
Bass Boost System (BBS)
Boosts the bass out of the set!! This function is selected via a direct key
access. 3 levels of effect can be chosen according to your preference.
Handsfree Phone In
With the Handsfree Phone In function you have a Plug & Play solution, to
connect the VDO Dayton Handsfree Phone Kit. Using the high sound
quality of your In-Car HiFi, phone sound is processed through your loud-
speakers, enabling a relaxed telephone call. The VDO Dayton Handsfree
Phone Kit includes a microphone and is available for the most popular
mobile phones on the market. In addition, the car radio provides the
power supply to keep the battery of your mobile fully charged.
Speed Dependent Volume Control (SDVC)
When connected to the speedometer signal of the car, the volume is
automatically adjusted to always get the best of the sound.
Software Access Menu (SAM)
"Software Access Menu" is an easy way to personalise your VDO Dayton
car radio according to your choice and install all possible options. You can
adjust the level of the Traffic Announcement volume, as well as other
sound effects. Navigation and Handsfree mute signal level is selectable to
suit your equipment. You are able to choose which SDVC curve is most
efficient for your car, adjust the Clock settings plus many other options.
Credit Card
Remote Control included
Connections
A: General + Power Supply (ISO)
B: Loudspeakers (ISO)
C1: Line Out (Cinch)
C2: Wire Remote Control / Telephone Mute
Navigation Mute
C3: CD-Changer
D1: Handsfree Phone In / Telephone In / Telephone Mute
E: Aerial Plug (ISO)
F: Fuse
G: Telephone Mute
