VDO CD 4626 X Manual

CD / MP3 / WMA-Player
CD 4626 X Product Information
• 4 x 50 Watts max. Power
• CD/MP3/WMA-Player
• USB & iPod ready
• Service Interval Computer
• Changer Control
• Detachable Front Panel
• Infrared Remote Control
• Switchable Key Illumination
• External Display Interface (EDI)
• Aux In
• Telephone In
• ECE 21 Compliant
CD/MP3/WMA-Player
Ensures 100% music enjoyment. You can put together your
favourite music without changing the CD. Simply press a
button to play most audio CDs - and enjoy maximum music
backed by exceptional ease of use.
USB & iPod ready
USB & iPod ready allows you to listen to music from your
external device over your car radio system. Main functions
(such as display of ID3 Tags, next and previous track, fast
forward or backward) of USB device & iPod can be operated
direcly by the radio keys. The USB device & iPod can easliy be
connected via the Changer Input of the radio.*
Service Interval Computer
Performs all functions usually associated with an on-board
computer, such as displaying inspection schedule and distance.
It also warns the driver when a predefined maximum speed
is exceeded - making every journey a little bit safer and more
relaxed.
Changer Control
For stereo preamp input connection possibilities for analogue
VDO Dayton CD/DVD changers.
Detachable Front
For theft protection, the complete front of this car radio is
detachable.
Infrared Remote Control
Enables easy handling of most functions of the VDO Dayton
CD 4626 X. This boosts driving safty and comfort by allowing
to stay in control of the vehicle at all times.
Additionally an original steering wheel remote control can be
connected directly to the device or by using an adaptor.*
Switchable Key Illumination
For better car integration. The user can choose between two
different key illuminations (orange/green).
External Display Interface (EDI)*
EDI is the ability to connect the standard display in the cockpit
when installing a VDO Dayton Smart Line car radio.
Aux In
With the Aux In you can connect additional audio sources to
your car‘s Hi-Fi system.
Telephone In
Connection of a hands-free kit‘s audio output to the radio.
Playback of thr current source is automatically interrupted and
the incoming call is played through the car‘s speakers.
ECE 21 Compliant
The finishing of the radio complies with the interior safety
requirements according to the European regulations related to
crash testing.
* Additional adapter necessary
SWITCHABLE
ILLUMINATION
INFRARED
CONTROL
SWITCHABLE
ILLUMINATION
INFRARED
CONTROL
LINUX
CD4626x_uk.indd 1 18.05.2006 8:53:09 Uhr

Connections
A: Car Interface
B: Speakers
C1: Preamp Out
C2: RC3 interface (SWRC-In)
C3: CD/DVD Changer In/Aux In/USB In/
iPod In
D1: Telephone In
D3: External Display Interface (EDI)
E: Aerial Plug (ISO)
Item Number
CD 4626 X
EAN Code
4025515255710
Product Design
• Silver Front
• Fully Detachable Front
(Anti-Theft-Protection)
• Multicolur Display Illumination
• Switchable Key Illumination
(orange/green)
• Pilot Light
Tuner
• RDS Tuner
• FM/MW/LW
• RDS Evaluation/EON/PTY-31
• Traffic Announcement
• RDS Clock
• 30 Presets (15 FM, 10 MW, 5 LW)
CD/MP3/WMA-Player
• ID3 Tags (Artist, Album, Source, Title)
• Plays CD Audio, CD-R, CD-RW, MP3,
WMA
• High-speed forward and reverse scanning
• Track Search
• Random CD Playback
• The unit can play up to maximum 300
tracks and supports 50 directories per disc
• WMA specification: Version 9.0 or lower
• MP3 specification: MPEG 1/2 & 2.5
layer 3 at bit rate up to 320 kbps,
Variable Bit Rate (VBR) or ID3 Tag
version 1 and 2 are both supported
Internal Amplifier
• Max. Power: 4 x 50 Watts
• RMS Power: 4 x 22 Watts
• 4-Channel Preamp Out
• 6 Sound Presets
• Loudness:
4 freely selectable levels
• Speed Dependent Volume Control (SDVC)
General
• Service Interval Computer/
Speed Warning
• Telephone In
• Dimensions: 179 mm x 50 mm x 150 mm
• DIN + JIN mounting
• ECE 21 Compliant
• Current consumption: approx. 1 A
(ca. 0.1 mA in off state)
• Power Supply: 12 V, DC at GND
• Voltage: 10,5 V ... 16 V
• Temperature Range: -20°C ... +75°C
Options
• Amplifier
• Speakers
• CD/DVD Changer
• Handsfree Kit
• Activation of OEM Displays*
• IR Credit Card Remote Control (CA 1103)
or IR Steering Wheel Remote Control
(RCS 5100)*
• OEM Steering Wheel Remote Control
(SWRC)
• iPod / USB devices *
* Additional adapter necessary
CD / MP3 / WMA-Player
CD 4626 X
Technical Information
01/2006 • CD 4626 X • subject to modification • VU26-0013-0035502
