OWNER'S MANUAL
CD7326U-OR / CD PLAYBACK
24V DC

1
预防措施
•
只能在24V直流供电负极接地的系统中使用。
• 安装和连接时，要切断汽车电池的负端。
•
更换保险丝时，要确保使用相同规格的保险
丝。如果使用规格不同的保险丝，会对机器
产生严重损害。
•
不要试图拆卸机器，因为光头中的激光束会
对眼睛产生伤害。
•
要确保尖针等外部物体不会进入机器内部，
否则将会引起故障，或者危及设备安全。
例如：电击或激光束曝露。
•
如果你的汽车在过冷或过热的环境中放置一
段较长的时间，那么可能要等到车内的温度
恢复正常时才能操作。
•
把音量调节到能听到外部警报声的位置(例
如：喇叭声等)。
CD注意事项
•
播放有缺陷或是有灰尘的CD碟会导致声音
不连贯。
•
照图示拿、放CD碟。
•
不要触摸光碟没有标识的一面。
•
不要把任何封条、标签及数据保护片贴于光
碟的任何一面。
•
不要把CD碟直接曝露在阳光下或是过热环境中。
•
要用一块干净的软布擦拭脏污的碟片，擦拭
时要从中心向外擦。
不要用酒精或是汽油之类的溶剂擦拭。
安全须知..........................................................1
目录.................................................................1
面板功能..........................................................2
播放说明..........................................................3
USB MP3/WMA概述........................................4
电气连接..........................................................5
故障排除指南...................................................6
规格.................................................................7
.
安全须知 目录
操作前
不要把音量调得太大，因为声音过大会妨碍
外界声音，以致发生交通事故。
在进行较复杂操作时，要先将车停靠。
不要擅自打开外壳进行修理，请咨询您的经
销商或是有经验的技术人员。
* 可播放普通CD，包括CD-R或CD-RW，MP3
等碟片。
•
该机器不能播放3英寸(8cm)的CD碟。
不要插入3英寸CD或是形状不规则的 CD，
光碟可能不能退出，导致故障。
•碟片不能带有异物,由碟片带入异物产生的
机器 损坏,不属于保修范围。
注:本系统只支持英文和数字显示,其他文字可能
造成无法显示或显示*

2
面板功能
1. - 出碟按钮
2. - 在收音状态短按为静音
- CD/MP3播放时短按为暂停
- 旋转为调节音量
- 长按关机
3. - 音效选择
4. - 短按,1-6预置频道浏览播放
- 长按,自动搜索并存储电台
5. - 数字键1/随机播放
6. - 数字键2/曲目扫描：
依次扫描播放每首曲目前10秒
7. - 数字键3/重复播放
8. - 数字键4
9. - 数字键5/MP3文件夹向后
10. - 数字键6/MP3文件夹向前
11. - CD状态下显示播放时间及系统时间
- MP3文件播放时依次显示文件夹名/
文件名/ID3信息/系统时间
- 收音状态下显示PTY信息及系统时间
12. - FM/AM收音波段切换
13. - USB插槽（插入USB）
14. -CD/MP3播放时向上选曲
15. - CD/MP3播放时向下选曲
16. - 碟片插槽
17. - 选择播放源
收音
光碟播放
USB(当插入USB时)
AUX IN
18. - 复位键
19. - 短按进入选择VOL/BAS/ TRE/BAL/FAD/
LOUD/AF/TA/PTY,配合VOL钮进行调整.
- 收音状态，旋转搜索电台
- 在CD/MP3模式,旋转调节播放曲目
20. - 按钮1～6收音预置频道:
按一下可收听已存电台，按2秒以上可存
入当前电台。

3
曲目搜索
CD/MP3播放时，按[AST]键,选择"TRACK
SCH"模式。
按旋钮[TUNE]，显示屏将显示出"000"。
搜索曲目：
旋转[VOL]旋钮选择个位数字并按[TUNE]键确
认，按[TUNE]键切换到十位数字,旋转[VOL]旋
转设置十位数字并按[TUNE]键确认，按[TUNE]
键切换到百位数字,旋转[VOL]旋转设置百位数
字并按[TUNE]键确认。
操作说明
时钟设置
在收音模式下:
短按[DSP]键,可查看PTY信息/时钟显示。
在时钟显示画面:
长按[DSP]键进入时钟设定模式,此时分钟在
屏幕上跳动,按[TUNE]键选择分钟或小时,旋转
[VOL]调整分钟或小时,调整完成按[DSP]键或隔
5秒钟系统自动退出时钟设定模式。
当播放MP3文件时:
按[DSP]键一次或多次可查看"文件夹/文件名和
ID3标签"信息。
系统设置
在非时钟显示画面时:
长按[DSP]键进入系统设置菜单，旋转VOL钮进
行自定义调节。
BEEP TAVOL RETURN
BEEP音设置,设置为"ON”,按键时发出BEEP
声,设置为"OFF”按键时不会发出声音。
TA VOL设置,设置当接收到RDS电台的TA信息
时的主机音量值.旋转VOL钮进行自定义调节。
RETURN：FM收音状态下,RDS自动搜索TA信
息的时间间隔,当设定为L时，TA自动搜索时间
间隔为180秒, 当设定S时, TA自动搜索时间间
隔为45秒。
POP CLASSIC ROCK JAZZ EQ OFF
音效设置
按[EQ]键进入音效设置,旋转[VOL]钮选择。
进碟与出碟
进碟: 将碟片放进碟槽。
出碟: 按[ ]键弹出碟片。
收音模式
按[FM/AM]键，选择FM/AM波段。
FM1 FM2 FM3 MW1 MW2
SRC
按SRC键一次或多次可选择不同的功能：
TUNE->CD->USB->AUX
(当插入USB/AUX IN 时)
自动搜台及存储模式
收音模式下:
短按[AST]键依次浏览1-6已存电台。
长按[AST]键，自动搜索电台并将搜索到
最强信号的电台依次存储到1-6的预置台
位中。
上下选曲
在CD/MP3播放时:按/ 键
或旋转[TUNE]旋钮选择上一曲或下一曲，
按住 / 键不放可快进或快退。 1-SPORT/2-DRAMA /3-CULTURE/4-
WEATHER /5-TRAVEL /6-SOCIAL
1-ROCK/2-EASY /3-LIGHT /4-CLASSICS
/5-JAZZ /6-FOLK
按[TUNE]旋钮进入音量/低音/高音/声道平
衡/前后喇叭/低音时的响度提升/AF/TA/PTY
设置，旋转[VOL]钮进行调节。
RDS
连续按[TUNE]键直到屏幕上显示AF/TA时，旋
转VOL旋钮打开或关闭AF/TA功能。
连续按[TUNE]键直到屏幕上显示PTY时,旋转
VOL旋钮，显示NEWS/POP节目类型。
当显示为POP类型时，按1-6数字键选择以下类
型：
当显示为NEWS类型时，按1-6数字键选择以下
类型：

4
USB MP3/WMA概述
MP3概述
MP3(MPEG Audio Layer 3)是一种包含音
乐压缩技术。
本产品能播放CD-ROM，CD-R或CD-RW光
碟上的MP3文件。
主机能读以ISO9660格式记录的MP3文件，
但是不支持MP3数据以捆绑方式记录的MP3
文件。
主机不能读取".MP3"扩展名的非MP3文件,
可能听到一些噪音。
在手册里，PC术语中的“.MP3文件”和
“文件夹”分别称为“曲目”和“唱片集”。
支持最大的目录深度为8层，包括根目录支
持每个光碟最大的文件数量是512。
主机可能不按照曲目号码顺序播放曲目。
当一张光碟同时包含音频文件和MP3文件时，
主机仅播放音频文件。
当播放8kbps或VBR*光碟时，当前播放时间
可能无法正常显示，扫描播放功能也可能无
法正常使用。
*VBR：可变比特率。
创建包含MP3文件的CD-R或CD-RW
的注意事项
为了享受高质量的音乐，我们建议转换MP3
时使用44.1KHz的取样率和128Kbps的固定
比特率。
每张碟片不要存储超过512个MP3文件。
遵从ISO9660格式，允许的最大目录深度为8
层，包括根目录(文件夹)。
播放CD-R光碟时，只有已经终结刻录的光碟
才可以播放。
确保MP3 CD-R或CD-RW刻录时，应作为一
个数据光碟格式而不是作为一个音频光碟格
式来刻录。
不应将非MP3文件或不需要的文件与MP3文
件一同写入光碟，否则在开始播放MP3文件
之前会花费很长一段时间。
一些CD-R或CD-RW媒体，数据烧写可能达
不到他们的生产质量，这样的话数据不能被
正确的读取，所以建议使用高质量的CD-R或
CD-RW光碟。
支持版本为1.XX和2.XX ID3标签，多达16个字
符显示歌曲标题、唱片集标题和艺术家名字。
(不支持中文显示)
注：主机有可能不会按照您刻录的顺序去播放
曲目。
USB概述
USB功能(闪存类型)MP3/WMA歌曲播放。
1. 支持USB闪存2合1
2. 支持FAT 12/FAT 16/FAT 32
3. 64位路径名/30位ID3标签/64位文件名
4. 标签(2.0版本ID3标签)
支持多达30个字符显示歌曲标题、唱片集
标题和艺术家名字。
5. 支持USB1.1
支持USB2.0(不能支持USB2.0速度，
而是使用USB1.1的速度)
6. 因为USB规格多种多样，本产品不保证兼容
所有的USB。
7. USB接口提供最大工作电流为500mA。

5
电气连接
电气连线插座

6
故障排除指南
如果察觉出现问题，应立即关闭电源，停止使用并与经销处或指定维修站取得联系。切勿擅自进行修理，这是非常危险的。
问题现象 原 因 对 策
一般性问题
没有电源或没有声音
汽车点火开关处于关闭状态 请将汽车点火开关打开
保险丝熔断 更换指定规格保险丝
音量或静音关闭 检查音量或静音是否打开
光碟问题
光碟已经装入却没有声音 碟放反了 将光碟按正确方向放好，使其标签朝上
碟变脏了或严重划伤 将光碟清洁干净或更换新碟
光碟出现跳音现象，音质不佳 碟变脏了或严重划伤 将光碟清洁干净或更换新碟
收音问题
收音噪音大 电台过远或信号过于微弱 选择具有更高信号电平的其它电台
预选电台丢失 电池电缆的连接不正确 将电池电缆连接至常时带电的接线柱
出错信息显示
CD ERR
碟片放反了 将光碟按正确方向放好，使其标签朝上
不支持格式或文件出错 检查碟片
光碟机错误 长按[ ]键退出碟片.

7
电源 24V直流电压，阴极接地
最大输出功率 10Wx4声道 (8Ω )
适用扬声器阻抗 8Ω
ESP 10s(CD-DA)/40s(MP3)
整机尺寸(宽x深x高) 178X170.7X50mm
整机重量 1.49kg
FM立体声收音机
频率范围 87.5-108.0MHz
灵敏度 ＜14dBμ
频率响应 50Hz-10KHz
立体声分离度 ≥22dB(1KHz)
镜像频率抑制比 ≥40dB
中频抑制比 ≥60dB
信噪比 ≥50dB
AM(MW)收音机
频率范围: 522-1620KHz
灵敏度(S/N=20dB) ＜35dBμ
规 格
DISC播放机
系统 镭射数字式音频播放系统
频率响应 50Hz-20KHz
信噪比 > 72dB(A计权)
谐波失真 低于1% (1KHz)
声道分离度 > 55dB
注：因技术改进，规格和设计如有变动，恕不
另行通知。
一 般
注:对于不同码率的MP3，ESP时间不同，
40秒只针对码率为128Kbps的MP3文件。

8
Safety Information
PRECAUTIONS
• Use only in a 24-volt DC negative-
ground electrical system.
• Disconnect the vehicle's negative battery
terminal while mounting and connecting
the unit.
• When replacing the fuse, be sure to use
one with an identical amperage rating.
Using a fuse with a higher amperage
rating may cause serious damage to the
unit.
• DO NOT attempt to disassemble the unit.
Laser beams from the optical pickup are
dangerous to the eyes.
• Make sure that pins or other foreign objects
do not get inside the unit,they may cause
malfunctions, or create safety hazards
such as electrical shock or laser beam
exposure.
• If you have parked the car for a long
time in hot or cold weather, wait until the
temperature in the car becomes normal
before operating the unit.
• Keep the volume at a level you can hear
outside warning sounds (horns sirens,
etc.).
CD Notes
• Playing a defective or dusty CD can cause
dropouts in sound.
• Hold CDs as illustrated.
• Do not touch the unlabeled side.
• Do not attach any seal, label or data
protection sheet to either side of a disc.
• Do not expose a CD to direct sunlight or
excessive heat.
• Wipe a dirty CD from the center outward
with a cleaning cloth.
• Never use solvents such as benzine or
alcohol.
• This unit cannot play 3-inch ( 8cm ) CDs.
NEVER insert a 3-inch CD contained in the
adapter or an irregularly shaped CD. The
unit may not be able to eject it, resulting n a
malfunction.
• Disc can not have foreign body,the
damage caused by the disc with foreign
body do not belong to the warranty
scope.
Before Operation
• Do not raise the volume level too much,
as this will block outside sounds, making
driving dangerous. Stop the car before
performing any complicated operation.
Contents
Safety Information........................................8
Contents.........................................................8
Panel Controls...............................................9
Operate guide ..............................................10
USB MP3/WMA Overview...................11
Electrical Connections................................12
Troubleshooting..........................................13
Specifications..............................................14
CAUTION
• DO NOT open covers and do not repair
yourself. Consult the dealer or an
experienced technician for help.
* In addition to ordinary CDs, this unit can
playback CD - R or CD - RW, MP3.
Note:The system just support the english and
number display ,other letter can't display or
display *

9
1. -Disc eject
2.-Rotate to adjust volume.
-Radio:mute
-CD/MP3:Pause
-Hold it to power off
3.- EQ setup button
4.-1-6 Preset
-automatically search station
5.-channel 1/random play
6.-channel 2/ intro play (10 sec.)
7.-channel 3/repeat play
8.-channel 4
9.-channel 5/MP3 folder back
10.- Channel6/mp3 folder ahead
11.- Display paly time and clock in the CD
state.
- Turn and turn about folder name/le name
/ID3 TAG/system time
- Display PTY info and system time in the
Radio state.
12.-Band select
13.-USB connector
14.-Select previous track
15.-Select next track
16.-Disc slot
17.-SCR key
Radio
Disc play(when disc is in)
USB(when USB inserted)
AUX IN
18.-Reset hole
19.-Press to select VOL/BAS/TRE/BAL/
LOUD/FAD/
AF/TA/PTY,Rotate VOL knob to adjust
-RADIO:Rotate to adjust radio tune
-CD /MP3:Rotate to select track the
previous /next
20.1-6 Preset:
Press to tune in a preset station.
Hold for more than 2 seconds to store
Panel Controls

10
Operate guide
Disc Load / Eject
Load : Insert the disc into the slot .
Eject: Press to eject the disc .
BAND mode
Press the button to change BAND.
FM1 FM2 FM3 MW1 MW2
SRC
Press [SRC]button to select different function
once or time after time,The mode as follows:
Radio ->CD ->USB ->AUX IN mode
Auto Memory Store
Radio mode:
Press[AST]knob to scan the preset stations
1-6 for 10 seconds each.
Hold it [AST]knob more than 2 seconds,the 6
strongest available stations will automatically
saved in the memory of preset button 1-6 .
SEEK mode
Disc/USB playback: Press the /
and rotate the [TUNE]Knob to select the next
or previous track.
Hold the / to enter fast forward or
reverse back mode.
Clock setting
On the radio mode:
Press [DSP] to display PTY info/ time.
On the time display menu :
Press again for more than 2 seconds, enter
to the time setting state. the minutes blinks
on the screen ,Press [TUNE] knob to switch
minutes/hours,Rotate [VOL] knob to set the
hours or minutes, for adjusting is ok,press
[DSP] again or more than 5 seconds to exit
the clock setting.
While playing MP3 le :
Press [DSP] to display the folder/le name
and ID3 TAG
System setting
On the non time display menu:
Hold it [DSP] to enter the system setup
menu,Rotate [VOL] knob to adjust value.
BEEP TAVOL RETURN
Set the BEEP tone,setting for “on”,key-press
emit the BEEP tone,setting for “OFF” is not
emit .
TA VOL setting :Set the unit volume When
having receive RDS Station with TA info,
Rotate [VOL] knob to adjust value.
RETURN:On the FM mode ,set the TA time
space Info of auto search with RDS.
Setting for “L”, Auto search the TA time space
for 180 sec,Setting for “S”, auto search the TA
time space for 45 sec
Mp3 Track Search
CD/MP3 mode:
Press [AST] knob to select “TRACK SCH"
mode.
Press [TUNE] knob,LCD display will show
"000".
The desired track number
Press the [TUNE] knob to switch rst digit and
tenth digit ,Rotate the[VOL] knob to adjust the
rst digit and press the [TUNE] to conrm.
also to the setting tenth digit and hundredth digit
of the track number.
RDS
Press the SEL button to set AF/TA ,rotate the
VOL knob to open or close AF/TA function.
Press the SEL button to PTY function ,rotate the
VOL Knob ,display NEWS and POP program
type.
When display NEWS ,press the 1-6 button to
select opposite preset
When display POP,press the 1-6 button to
select opposite preset
Press[TUNE] button to setting VOL/BAS/TRE/
BAL/FAD/LOUD/AF/TA /PTY,Rotate [VOL] knob
to adjust value.
1-ROCK/2-EASY /3-LIGHT /4-CLASSICS
/5-JAZZ /6-FOLK
1-SPORT/2-DRAMA /3-CULTURE/4-
WEATHER /5-TRAVEL /6-SOCIAL
EQ LOUD mode
Press[EQ] button setting to sound effect
POP CLASSIC ROCK JAZZ EQ OFF

11
USB MP3/WMA Overview
Note on Mp3
• MP3 is short for MPEG Audio Layer 3
and refers to an audio compression
technology standard.
• This product allows playback of MP3 les
on CD-ROM, CD-R or CD-RW discs.
• The unit can read MP3 les written in the
format compliant with ISO 9660.
However it does not support the MP3 data
written by the method of packet write.
• The unit can not read an Mp3 le that has
a le extension other than ".mp3".
• If you play a non- MP3 file that has the
" .mp3 " extension, you may hear some
noise.
• In this manual, we refer to what are called
"MP3 le" and "folder " in PC terminology
as "track" and "Album," respectively.
• Maximum number of directory level is
8, including the root directory. Maximum
number of les and folders per disc is 256
.
• The unit may not play tracks in the order
of Track numbers.
• The unit plays only the audio Tracks if a
disc contains both audio tracks and MP3
les.
In this case, data may not be reproduced
correctly. High quality CD-R or CD-RW
disc is recommended.
• Up to 16 characters are displayed for the
name of an Album or a Track. ID3 TAG
version 1.x is required.
• Note that the unit may not play Track in
the order that you wrote them to the disc.
USB Notes
USB functions (flash memory type) MP3
music play
(1) USB ash memory 2 in 1 support
(2) FAT 12/FAT 16/FAT 32 format supported
(3) File name: 64 byte / dir name: 64 byte /
tag name: 30 byte.
(4) Tag (id3 tag ver 2.0)
- title / artist / album: 32 byte support.
(5) USB 1.1 support, USB 2.0 support (For 2.0,
speed performance is as USB 1.1)
(6) Not all USB devices are compatible with
the unit.
(7) Usb connector is support maximum
work power with 500mA.
• When playing a disc of 8kbps or VBR*, the
elapsed playing time in the display window
will not be correct and also the intro play
may not function properly. *VBR: Variable
Bit Rate
Note on creating your own CD-Rs or
CD-RWs containing MP3 les
• To enjoy high quality sound, we
recommend converting to MP3 files with
a sampling frequency of 44.1 kHz and a
xed bit rate of 128 kbps.
• DO NOT store more than 256 MP3 files
per disc.
• For ISO 9660 -compliant format, the
maximum allowable depth of nested
folders is 8, including the root directory
(folder).
• When CD-R disc is used, playback is
possible only for discs which have been
nalized.
• Make sure that when MP3 CD-R or CD-
RW is burned that it is formatted as a data
disc and NOT as an audio disc.
• You should not write non-MP3 files or
unneeded folders along with MP3 les on
the disc otherwise it takes a long time until
the unit starts to play MP3 les.
• With some CD-R or CD-RW media, data
may not be properly written depending on
their manufacturing quality .

12
Electrical Connections
Wiring Diagram

13
Option Selectable values Function
General
No power or no sound
Car's engine switch is not on Turn your car's key to ACC or ON
Fuse is burnt Replace fuse
Volume is too low Check volume or mute on / off
If the above solutions cannot help Press the RESET button
Disc
Disc is inside but is no sound Disc is upside down Place disc in the correct direction, and the label side up
Disc is dirty or damaged Clean disc or change another disc
Disc sound is skips,tone quality is low Disc is dirty or damaged Clean CD or change another CD
Radio
Much noise in broadcasts Station is too far, or signals are too weak Select other stations of higher signal level
Preset station lost Battery cable is not correctly connected Connect the battery cable to the terminal that is always live.
Error Display Messages
CD ERR
Disc is upside down Place disc in the correct direction, and the label side up
Disc format is not support or file date is wrong check the disc
Disc is wrong
Press button more than 2 seconds to eject the disc. In
case that the disc cannot be ejected by pressing button,
press the RESET switch and press the button 2 seconds
to eject the disc. If still not ejecting, consult your dealer.
Troubleshooting
If you suspect something is wrong, immediately switch power off. Do not use the unit in abnormal condition, for example without sound, or with smoke
or foul smell, can cause re or electric shock. Immediately stop using it and call the store where you purchased it. Never try to repair the unit yourself
because it is dangerous to do so.
Note: If the set inserts a non-standard size disc or card.you may long press the button for 5 second,then it will be eiected forcibly.

14
Specications
General
Power supply: 24V DC negative ground
Maximum power output: 10Wx4 channels (8 )
Suitable speaker impedance: 8
ESP: 10s(CD-DA)/40s (MP3)
Dimensions(WxDxH): 178X170.7X50mm
Weight: 1.49kg
Note: For different bit-rate MP3, ESP time are different;
40 seconds only for the bit-rate MP3 le of the 128Kbps
FM Stereo Radio
Frequency range: 87.5 - 108.0MHz
Usable sensitivity: ＜14dBμ
Frequency response: 50Hz-10KHz
Stereo separation: ≥22dB (1KHz)
Image response ratio: ≥40dB
IF response ratio: ≥60dB
Signal/noise ratio: ≥50dB
AM(MW) Radio
Frequency range: 522-1620KHz
Usable sensitivity(S/N=20dB): ＜35dBμ
Disc Player
System: Disc digital audio system
Frequency response: 50Hz-20KHz
Signal/noise ratio: > 72dB(dBA)
Total harmonic distortion: Less than 1% (1KHz)
Channel separation: > 55dB
Note: Specifications and the design are subject to change without
notice due to improvements in technology.

P/N:127075002532
