Supplementary instructions
Mounting adapter PTB 9
For mounting on the existing mounting
bracket (GM-16™)
Document ID: 55642
2
Contents
Mounting adapter PTB 9 • For mounting on the existing mounting bracket (GM-16™)
55642-EN-170815
Contents
1 Product description
2 Mounting
2.1 Mounting the mounting adapter........................................................................................ 4
2.2 Mounting of the anti-vibration clamp................................................................................. 5
3 Supplement
3.1 Technical data .................................................................................................................. 8
3.2 Dimensions ...................................................................................................................... 9
3.3 Industrial property rights................................................................................................. 11
3.4 Trademark ...................................................................................................................... 11
Editing status: 2017-08-14
3
1 Product description
Mounting adapter PTB 9 • For mounting on the existing mounting bracket (GM-16™)
55642-EN-170815
1 Product description
The PTB 9 is a mounting adapter for the radiation-based measur-
ing system MINITRAC 31 or POINTRAC 31 (short version with
46 mm/1.8 in). The PTB 9 can be mounted on an existing mounting
bracket of GM-16.
The standard version of PTB 9 for mounting on an existing mounting
bracket GM-16.
2
1
Fig. 1: Mounting adapter PTB 9 in mounted state
1 Mounting adapter PTB 9
2 Radiation-based sensor MINITRAC 31 or POINTRAC 31 (version with
46 mm/1.8 in)
In applications where strong vibration can occur, you can equip the
mounting adapter PTB 9 with an additional anti-vibration clamp.
1
2
3
Fig. 2: Mounting adapter PTB 9 with anti-vibration clamp in mounted state
1 Mounting adapter PTB 9
2 Radiation-based sensor MINITRAC 31 or POINTRAC 31 (version with
46 mm/1.8 in)
3 Anti-vibration clamp
Mounting adapter PTB 9,
standard version
Mounting adapter PTB 9,
vibration resistant ver-
sion
4
2 Mounting
Mounting adapter PTB 9 • For mounting on the existing mounting bracket (GM-16™)
55642-EN-170815
2 Mounting
2.1 Mounting the mounting adapter
Mount the mounting adapter and the sensor according to the follow-
ing assembly drawing:
As far as not otherwise stated, all parts are in the scope of delivery.
9
4
3
2
1
8
7
5
6
3
Fig. 3: Mounting of the mounting adapter (standard version)
1 Mounting adapter PTB 9
2 Screws M8 x 30 (2 pieces)
or screw 5/16" x 1¼" (2 pieces)
3 Washer - provided by customer
(recommendation: M12 or ½", 4 pieces)
4 Hexagon nut - provided by customer (recommendation: M12 or ½",
2 pieces)
5 Mounting bracket for GM-16 (provided by customer)
6 Screw - provided by customer (2 pieces)
Recommendation: M12 x 30 or ½" x 1¼"
7 Washer M8 or 5/16" (4 pieces)
8 Spring ring M8 or 5/16" (2 pieces)
9 Hexagon nut M8 or 5/16" (2 pieces)
Mounting adapter PTB 9,
standard version
5
2 Mounting
Mounting adapter PTB 9 • For mounting on the existing mounting bracket (GM-16™)
55642-EN-170815
Danger:
Before mounting, make sure that the corresponding radiation source
is securely closed. Use a padlock to secure the source holder in the
closed condition and prevent it from being inadvertently opened. Also
take note of the instructions in the operating instructions manual of
the source holder.
1. Place the mounting adapter (1) according to the above illustration
onto the existing mounting bracket (5).
2. Thexingmaterialforthemountingadapterisnotpartofthe
scope of delivery.
We recommend screws of size M12 or ½".
Insertthexingscrews(6)withthewashers(3)fromabove
through the holes of the mounting adapter (1) and the mounting
bracket (5).
3. Place two washers (3) over the screws from below and screw the
hexagon nuts (4) onto the screws (6).
Tighten the screws (6) with a torque of 60 Nm (44 lbf ft).
4. Place the sensor according to above illustration onto the mount-
ing adapter (1).
5. Insert the two screws (2) from below through the holes of the
mounting adapter (1).
6. Place one regular washer (7) and one lock washer (8) over each
screw from above and screw the hexagon nuts (9) onto the
screws (2).
Tighten the screws (2) with a torque of 15 Nm (11 lbf ft).
The radiation-based sensors MINITRAC 31 or POINTRAC 31 in the
short version (46 mm/1.8 in) can be used instead of the sensor GM-
16.
The mounting adapter is constructed in such a way that the sensors
are already in the correct position after mounting.
2.2 Mounting of the anti-vibration clamp
In applications where strong vibration is expected, you can equip the
mounting adapter with an additional anti-vibration clamp.
As far as not otherwise stated, all parts are in the scope of delivery.
Mounting adapter PTB 9,
vibration resistant ver-
sion
6
2 Mounting
Mounting adapter PTB 9 • For mounting on the existing mounting bracket (GM-16™)
55642-EN-170815
1
3
2
4
4
5
12
2
10
13
7
14
11
10
9
8
7
6
Fig. 4: Mounting of the mounting adapter with anti-vibration clamp
1 Screw M6 x 160 (2 pieces)
or screw ¼" x 6½" (2 pieces)
2 Lock washer - Nordlock for M6 or ¼" (4 pieces)
3 Cover plate (1 piece)
4 Clamp collars (2 pieces)
5 Base (1 piece)
6 Mounting adapter PTB 9
7 Lock washer - Nordlock for M8 or 5/16" (4 pieces)
8 Screws M8 x 30 (2 pieces)
or screw 5/16" x 1¼" (2 pieces)
9 Mounting bracket for GM-16 (provided by customer)
10 Washer - provided by customer (recommendation: Nordlock M12 or ½",
4 pieces)
11 Hexagon nut - provided by customer (recommendation: M12 or ½",
2 pieces)
12 Hexagon nut M6 or 5/16" (2 pieces)
13 Screw - provided by customer (2 pieces)
Recommendation: M12 x 30 or ½" x 1¼"
14 Hexagon nut M8 or 5/16" (2 pieces)
Danger:
Before mounting, make sure that the corresponding radiation source
is securely closed. Use a padlock to secure the source holder in the
closed condition and prevent it from being inadvertently opened. Also
take note of the instructions in the operating instructions manual of
the source holder.
1. Place the mounting adapter (6) according to the above illustration
onto the existing mounting bracket (9).
7
2 Mounting
Mounting adapter PTB 9 • For mounting on the existing mounting bracket (GM-16™)
55642-EN-170815
2. Thexingmaterialforthemountingadapterisnotpartofthe
scope of delivery.
We recommend screws of size M12 or ½" and Nordlock washers.
Insertthexingscrews(13)withtheNordlocklockwashers(10)
from above through the holes of the mounting adapter (6) and the
mounting bracket (9).
3. Place two Nordlock lock washers (10) over the screws from below
and screw the hexagon nuts (11) onto the screws (13).
Tighten the screws (13) with a torque of 60 Nm (44 lbf ft).
4. Insert the screws (1), each with one Nordlock lock washer (2)
according to the above illustration, through the cover plate (3), the
two clamp collars (4) and the base plate (5).
5. Place the premounted anti-vibration clamp onto the mounting
adapter (6) and screw the two screws (1) from the front through
the holes of the mounting adapter (6).
Place one Nordlock lock washer (2) over each of the screws (1)
and screw the hexagon nuts (12) onto the screws (1). Do not
tighten the hexagon nuts, the connection should be still loose.
6. Place the sensor onto the mounting adapter (6) according to the
above illustration.
Insert the lower part of the sensor into the loosely premounted
anti-vibration clamp.
7. Place one Nordlock lock washer (7) over each of the two screws
(8) and insert the screws from below through the holes of the
mounting adapter (6).
8. Place one Nordlock lock washer (7) over each screw (8) and
screw the hexagon nuts (14) onto the screws (8).
Tightenthescrews(8)withatorqueof15Nm(11lbfft)toxthe
sensor.
9. Finally, tighten the screw connections (1) of the anti-vibration
clamp with a torque of 10 Nm (7.5 lbf ft).
The radiation-based sensors MINITRAC 31 or POINTRAC 31 in the
short version (46 mm/1.8 in) can be used instead of the sensor GM-
16.
The mounting adapter is constructed in such a way that the sensors
are already in the correct position after mounting.
8
3 Supplement
Mounting adapter PTB 9 • For mounting on the existing mounting bracket (GM-16™)
55642-EN-170815
3 Supplement
3.1 Technical data
General data
Take note of the information in the operating instructions manual of the installed MINITRAC 31,
POINTRAC 31 series level sensor and the source holder
Material 316L corresponds to 1.4404 or 1.4435
Materials
ƲMounting adapter 316L
ƲAnti-vibration clamp - cover plate and
base plate
316L
ƲAnti-vibration clamp - clamp collars Plastic PA
Weight
ƲStandard version 2.2 kg (4.9 lbs)
ƲVersion with anti-vibration clamp 3.2 kg (7.1 lbs)
Torques
ƲScrews - Fastening, mounting adapter
(M12 or ½")
60 Nm (44 lbf ft)
ƲScrews - Fastening, sensor (M8 or
5/16")
15 Nm (11 lbf ft)
ƲScrews - anti-vibration clamp (M6 or
¼")
10 Nm (7.5 lbf ft)
9
3 Supplement
Mounting adapter PTB 9 • For mounting on the existing mounting bracket (GM-16™)
55642-EN-170815
3.2 Dimensions
Mounting adapter, standard version
18,5 mm
(0.73")
ø 14 mm
(0.55")
150,5 mm
(5.92")
179 mm
(7.04")
82,5 mm
(3.25")
50,8 mm
(2.00")
Fig. 5: Mounting adapter PTB 9, standard version
10
3 Supplement
Mounting adapter PTB 9 • For mounting on the existing mounting bracket (GM-16™)
55642-EN-170815
Mounting adapter, vibration resistant version
18,5 mm
(0.73")
ø14 mm
(0.55")
120 mm
(4.72")
150,5 mm
(5.92")
147 mm
(5.79")
179 mm
(7.04")
30 mm
(1.18")
82,5 mm
(3.25")
50,8 mm
(2.00")
Fig. 6: Mounting adapter PTB 9, vibration resistant version
11
3 Supplement
Mounting adapter PTB 9 • For mounting on the existing mounting bracket (GM-16™)
55642-EN-170815
3.3 Industrial property rights
VEGA product lines are global protected by industrial property rights. Further information see
www.vega.com.
VEGA Produktfamilien sind weltweit geschützt durch gewerbliche Schutzrechte.
Nähere Informationen unter www.vega.com.
Les lignes de produits VEGA sont globalement protégées par des droits de propriété intellec-
tuelle. Pour plus d'informations, on pourra se référer au site www.vega.com.
VEGA lineas de productos están protegidas por los derechos en el campo de la propiedad indus-
trial. Para mayor información revise la pagina web www.vega.com.
Линии продукции фирмы ВЕГА защищаются по всему миру правами на интеллектуальную
собственность. Дальнейшую информацию смотрите на сайте www.vega.com.
VEGA系列产品在全球享有知识产权保护。
进一步信息请参见网站<www.vega.com。
3.4 Trademark
All the brands as well as trade and company names used are property of their lawful proprietor/
originator.
Printing date:
VEGA Grieshaber KG
Am Hohenstein 113
77761 Schiltach
Germany
55642-EN-170815
All statements concerning scope of delivery, application, practical use and operat-
ing conditions of the sensors and processing systems correspond to the information
available at the time of printing.
Subject to change without prior notice
© VEGA Grieshaber KG, Schiltach/Germany 2017
