Velleman HQ Power HQLP10012 User manual

HQLP10012
SHOWPAR 12/4 RGBW
USER MANUAL 6
HANDLEIDING 12
MODE D'EMPLOI 18
MANUAL DEL USUARIO 24
BEDIENUNGSANLEITUNG 30

HQLP10012
V. 02 –09/11/2017 2 ©Velleman nv

HQLP10012
V. 02 –09/11/2017 3 ©Velleman nv
2 CH
channel
from
to
function
1
0
255
master dimming (0-100 %)
2
0
9
no function
10
19
red
20
29
green
30
39
blue
40
49
white
50
59
yellow
60
69
magenta
70
79
cyan
80
89
dark orange
90
99
green yellow
100
109
salmon
110
119
turquoise
120
129
light green
130
139
orange
140
149
lavender
150
159
light blue
160
169
dark blue
170
255
pink
3 CH
channel
from
to
function
1
0
255
red (0-100 %)
2
0
255
green (0-100 %)
3
0
255
blue (0-100 %)
4 CH
channel
from
to
function
1
0
255
red (0-100 %)
2
0
255
green (0-100 %)
3
0
255
blue (0-100 %)
4
0
255
white (0-100 %)

HQLP10012
V. 02 –09/11/2017 4 ©Velleman nv
4-1 CH
channel
from
to
function
1
0
255
master dimming red (0-100 %)
2
0
255
stroboscope (0-100 %)
3
0
9
no function
10
19
red
20
29
green
30
39
blue
40
49
white
50
59
yellow
60
69
magenta
70
79
cyan
80
89
dark orange
90
99
green yellow
100
109
salmon
110
119
turquoise
120
129
light green
130
139
orange
140
149
lavender
150
159
light blue
160
169
dark blue
170
255
pink
4
0
9
no function
10
69
colour blending
70
129
colour change
130
189
sound colour blending
190
255
sound colour change

HQLP10012
V. 02 –09/11/2017 5 ©Velleman nv
8 CH
channel
from
to
function
1
0
255
master dimming red (0-100 %)
2
0
255
stroboscope (0-100 %)
3
0
255
red (0-100 %)
4
0
255
green (0-100 %)
5
0
255
blue (0-100 %)
6
0
255
white (0-100 %)
7
0
9
no function
10
19
red
20
29
green
30
39
blue
40
49
white
50
59
yellow
60
69
magenta
70
79
cyan
80
89
dark orange
90
99
green yellow
100
109
salmon
110
119
turquoise
120
129
light green
130
139
orange
140
149
lavender
150
159
light blue
160
169
dark blue
170
255
pink
8
0
9
no function
10
69
colour blending
70
129
colour change
130
189
sound colour blending
190
255
sound colour change

HQLP10012
V. 02 –09/11/2017 6 ©Velleman nv
USER MANUAL
1. Introduction
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that disposal of the device after its lifecycle
could harm the environment. Do not dispose of the unit (or batteries) as unsorted municipal
waste; it should be taken to a specialized company for recycling. This device should be returned
to your distributor or to a local recycling service. Respect the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for choosing HQPower™! Please read the manual thoroughly before bringing this device into
service. If the device was damaged in transit, do not install or use it and contact your dealer.
2. Safety Instructions
This device can be used by children aged from 8 years and above, and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction concerning the use of the device in
a safe way and understand the hazards involved. Children shall not play with the
device. Cleaning and user maintenance shall not be made by children without
supervision.
Always connect the device to a grounded circuit to avoid risk of electrocution.
Always disconnect mains power when the device is not in use or when servicing or
maintenance activities are performed. Handle the power cord by the plug only.
If the external flexible cable or cord of this device is damaged, it shall be replaced by
a special cord or cord exclusively available from the manufacturer or his service
agent.
All cords and cables should be routed so that they will not be walked on or pinched by
items placed upon or against them. Pay particular attention to the point where they
exit the unit.
Remove all flammable materials close to the device before switching on.
Do not install the device on a flammable surface (linoleum, carpet, wood, paper,
cardboard, plastic, etc.).
Protect this device from heat sources such as radiators, heat registers, stoves, or
other appliances (including amplifiers) that produce heat.
Do not remove the cover under any conditions. There are no user-serviceable parts
inside. Never operate this device when its cover is removed.
Do not operate a visibly damaged device. Do not attempt to operate this device if the
power cord has been frayed or broken.
Always mount this device in a safe and stable manner. Mount this device in an area
that will allow proper ventilation. Allow about 15 cm between this device and a wall.
This device should only be serviced by qualified service personnel.
Do not use the luminaire with a cracked or broken protective shield. Disconnect
immediately from the mains. The protective shield is not replaceable.
Familiarise yourself with the functions of the device before actually using it.
Keep this manual for future reference.
Always make sure to connect the device to an alternating current matching the value
stated on the device.
Always install the device in a well-ventilated location.
Keep this device away from dust and extreme temperatures. Make sure the
ventilation openings are clear at all times. For sufficient air circulation, leave at least
2.5 cm in front of the openings.

HQLP10012
V. 02 –09/11/2017 7 ©Velleman nv
Never connect the device to a dimmer or rheostat.
Never carry or move the device from the power cord or any other moving part.
Always use the bracket.
In the event of an operating problem, stop using the device immediately.
Never try to repair the device. There are no user-serviceable parts inside the device.
Refer to an authorized dealer for service and/or spare parts.
This device is not designed for permanent operation: regular operation breaks will
prolong its live.
Indoor use only. Keep this device away from rain, moisture, splashing and dripping
liquids. Never put objects filled with liquids on top of or close to the device.
This device is not suitable for ordinary lighting in household room illumination.
3. Warranty
Refer to the Velleman®Service and Quality Warranty on the last pages of this manual.
All modifications of the device are forbidden for safety reasons. Damage caused by user
modifications to the device is not covered by the warranty.
Only use the device for its intended purpose. Using the device in an unauthorised way will void
the warranty.
Damage caused by disregard of certain guidelines in this manual is not covered by the warranty
and the dealer will not accept responsibility for any ensuing defects or problems.
Nor Velleman nv nor its dealers can be held responsible for any damage (extraordinary, incidental
or indirect) –of any nature (financial, physical…) arising from the possession, use or failure of this
product.
4. Installation
4.1 General Guidelines
Have the device installed by a qualified person, respecting all applicable norms.
Install the device on an even, fire-resistant, scratch-resistant, water-resistant and
non-slippery surface.
The carrying construction must be able to support 10 times the weight of the device
for 1 hour without deforming.
Make sure there is no flammable material within a 1 m radius of the device.
Install the device in a location with few passers-by that is inaccessible to
unauthorised persons.
Install the device in a location where you can easily access the power cord.
Install the device in a well-ventilated area.
4.2 Overhead Installation
When hung, the device must always be secured with a secondary attachment e.g. a
safety cable.
Never stand directly below the device when it is being mounted, removed or serviced.
Have a qualified technician check the device once a year and once before you bring it
into service.
Overhead mounting requires extensive experience: calculating workload limits,
determining the installation material to be used… Have the material and the device
itself checked regularly. Do not attempt to install the device yourself if you lack these
qualifications as improper installation may result in injuries.
For truss mounting, use an appropriate clamp (not incl.) and fit an M10 bolt through
the centre of the (folded) bracket.

HQLP10012
V. 02 –09/11/2017 8 ©Velleman nv
4.3 Secondary Suspension
Hanger
Where a hanger is provided, the bearing parts of the hanger shall be capable of
supporting ten (10) times the weight of the luminaire without permanent deformation
and shall be manufactured from non-combustible materials such as steel or its
equivalent.
Accessories
The design of the luminaire shall be such that removable accessories, e.g. colour frames
and barn doors, when properly inserted, cannot fall out of the luminaire.
Secondary Suspension
A secondary suspension shall be provided for the luminaire, except where the luminaire is
arranged for floor mounting or if it is intended for handheld use. The secondary
suspension shall be designed and mounted in such a way that in the event of a failure of
the primary suspension, no part of the luminaire can fall. The secondary suspension must
withstand a 30 cm vertical drop for 30 times.
4.4 Connection
Have a qualified electrician carry out the electric connection.
Connect the device to the mains with the power plug. All devices must be powered
directly off a grounded switched circuit. Do not connect to a dimmer pack.
The installation has to be approved by an expert before the device is taken into
service.
5. Overview
Refer to the illustrations on page 2 of this manual.
1
DMX input and output
4
power output and input
2
display and menu buttons
5
bracket
3
safety eye
6. Operation
The device can be used in the following modes:
stand-alone mode
master/slave
with a DMX-512 controller.
6.1 Control Panel
Access the control panel functions using the four panel buttons located around the display.
Menu
scroll through the menu options
upwards through the menu list
downwards through the menu list
Enter
confirm a selection

HQLP10012
V. 02 –09/11/2017 9 ©Velleman nv
6.2 Menu
mode
programme
description
DMX mode
Addr
8CH
d001-d512
4-1CH
4CH
3CH
2CH
static colours
Stat
S01-17
static colours
auto mode
Auto
Au1-2
auto programme
sound mode
Soun
So1-2
sound programme
speed
SPEE
SP1-9
speed
mic sensitivity
SEnS
SE1-9
microphone sensitivity
edit colour
Colo
r000-255
red 0-100 %
g000-255
green 0-100 %
b000-255
blue 0-100 %
U000-255
white 0-100 %
dimming
dIMM
dl1-9
master dimming
silent scene
SILE
on/oFF
silent scene at sound programme
slave
SLAV
Slave
slave mode
IR
InFr
on/oFF
enable/disable IR remote
6.3 Stand-Alone Mode
The device starts running in stand-alone mode after connection to the mains. This mode allows you to
use the device without controller.
6.4 Master/Slave Mode
The master/slave mode allows for connecting several devices to a single master device in a daisy chain.
All slave devices will then work synchronously with the master device.
Configure all slave units before connecting the master unit to the daisy chain.
6.5 DMX Mode
The DMX mode allows you to control the device with any universal DMX controller.
All DMX-controlled devices need a digital start address so that the correct device responds to the
signals. This digital start address is the channel number from which the device starts to “listen” to
the DMX controller. The same starting address can be used for a whole group of devices or an
individual address can be set for every device.
When all devices have the same address, all the units will “listen” to the control signal on one
particular channel. In other words: changing the settings of one channel will affect all devices
simultaneously. If you set individual addresses, each device will “listen” to a separate channel
number. Changing the settings of one channel will only affect the device in question.
6.6 DMX Channel Values
Refer to page 4 of this manual.
7. IR Remote Controller
BLACK OUT
Press this button to black out the current active mode. Press again to return.
AUTO
Enables you to run the automatic programmes.
1. Press <AUTO>.
2. Press <+> or <-> to choose the different programmes.

HQLP10012
V. 02 –09/11/2017 10 ©Velleman nv
SOUND
Enables you to run the sound-controlled programmes.
1. Press <SOUND>.
2. Press <+> or <-> to choose the different programmes.
STROBE
Press this button to activate the stroboscope. Press again to de-activate.
1. Press <STROBE>.
2. Press <+> or <-> to adjust the strobe speed.
SPEED
Enables you to adjust the speed of the automatic programmes.
1. Press <SPEED>.
2. Press <+> or <-> to choose the programme.
SENSITIVITY
Enables you to adjust the microphone sensitivity.
1. Press <SENSITIVITY>.
2. Press <+> or <-> to adjust the microphone sensitivity.
DMX/%
Allows you to activate/de-activate the DMX mode.
MANUAL
Press this button to activate/de-activate the manual mode.
1. Press <MANUAL>.
2. Press <R>, <G>, <B> or <W> to select your colour.
3. Press <+> or <-> to adjust the colour intensity.
FADE
Press <FADE> to enable or disable the fader.
1-9
Press <1> to <9> to adjust the colour intensity.
8. Cleaning and Maintenance
Before starting any cleaning or maintenance activities:
1. Unplug the device's power cord from the outlet.
2. Let the device cool down.
Cleaning
Use normal glass cleaner and a soft cloth to wipe off the outside casing.
Always be sure to dry all parts completely before plugging the device back in.
Cleaning frequency depends on the environment in which the unit operates (i.e. smoke, fog residue,
dust, dew).
Do not immerse the device in any liquid.
Maintenance
All screws should be tightened and free of corrosion.
The housing, the lenses, the mounting supports and the installation location (e.g. ceiling, suspension,
trussing) should not be deformed, modified or tampered with; e.g. do not drill extra holes in
mounting supports, do not change the location of the connections…
Mechanically moving parts must not show any signs of wear and tear.
The electric power supply cables must not show any damage. Have a qualified technician maintain
the device.
There are no user-serviceable parts, apart from the fuse and the lamp.
Refer to an authorized dealer for service and/or spare parts.
