Veneroni AT Instruction manual

PUMPS TYPE AT - ET
Manual cod. 995-0005 - Ed. 10/2021 rev.10

3

We congratulate you for having chosen our machine.
We are sure that following the instructions contained in this manual, you will come to
highly value our product.
For a correct use of the machine it is compulsory, both for the operator and for all the
people who will have to operate on it, to read it attentively and to conserve it carefully;
for any doubt about the use of the machine, please contact the manufacturer.

4

i

1INDEX
1 Index ........................................................................................... 4
2 Symbols ......................................................................................... 6
3 Summery of machine parts ............................................................... 7
3.1 Key...................................................................................... 7
3.2 Contact information ............................................................... 7
4 How to use and keep the manual ....................................................... 8
4.1 User..................................................................................... 8
4.2 Purpose................................................................................ 8
4.3 Limits of Use ......................................................................... 8
4.4 Where and how to preserve the manual.................................... 8
4.5 Updates, amendments and replacements .................................. 8
5 Machine description ......................................................................... 10
5.1 Technical Data....................................................................... 12
6 Lubrication ...................................................................................... 14
7 Security warnings ............................................................................ 15
8 Accident prevention regulations ......................................................... 16
8.1 Incorrect usage ..................................................................... 16
9 Machine’s uses ................................................................................. 19
9.1 Technical description of functions ............................................. 19
9.2 Work place............................................................................ 19
9.3 Controls and operation ........................................................... 20
10 Machine accessories and components ................................................ 21
10.1 AT machine accessories .......................................................... 21
10.2 Position of delivery curve ........................................................ 22
10.3 Delivery curve with shock absorber .......................................... 22
10.4 Command for the activation of the hydraulic motor for automatic
calibration of the delivery tube ................................................ 23
10.5 Switching off – time and operation ........................................... 23
11 Shifting the machine ........................................................................ 24
12 Positioning and operation ................................................................. 27
12.1 Operation, materials and equipment for usage........................... 27
12.2 Positioning and use ................................................................ 27
13 Instructions for the use, calibration and starting of the machine ............ 31
  ........................ 31
   ................................................. 31
13.3 Maintenance of hydraulic system ............................................. 31
13.4 Risks, prevention measures and repair of breakages of the
hydraulic system ................................................................... 32

5

14 Instructions for disassembly and storage............................................ 33
14.1 Disassembly instructions......................................................... 33
14.2 Storage instructions ............................................................... 35
15 Maintenance instructions.................................................................. 36
16 Training personnel........................................................................... 37
17 Disassembly of the machine ............................................................. 37
18 Warranty ....................................................................................... 38
Declaration of compliance..................................................................... 39

19 Tables............................................................................................ 40

6

WARNING: Important safety message!
READ consult the manual carefully before using the machine
WARNING: use safety gloves
Wear safety glasses or visor, gloves and safety clothes
Follow very carefully all indications for repair shown in this manual!
2SYMBOLS
The following warnings are used in this manual.

7

3SUMMERY OF MACHINE PARTS
3.1 Key
1. Type AT: mobile pump with tubular frame that attaches to the hydraulic lifting apparatus of the
tractor.
Es.: AT30/4
AT = mobile pump type AT
30 = tube exit diameter in cm
4= Nominal frame length in meters
2. Type ET: mobile pump with tubular frame that attaches to the hydraulic lifting apparatus
of the tractor high yield rotor.
Es.: ET50/5
ET = mobile pump type AT
50 = tube exit diameter in cm
5= Nominal frame length in meters
3.2 Contact information
If necessary or in response to specific instructions from this manual,
We kindly ask you to contact:
Manufacturer: VENERONI s.r.l.
Via della Resistenza, 8
26020 Formigara (CR) - ITALY
Tel. [phone] - Fax [phone]
Refer to the machine using the Declaration of Compliance. The machine’s details are also visible
on the machine’s CE plate positioned on the front of the frame (Fig.3.1).
Fig.3.1

i
8
4UTILISATION ET CONSERVATION DU MANUEL
The reseller is obliged to consign this manual along with the machine as it is an essential part
of it, regarding the health and safety of the user.
4.1 User
The copy of this manual supplied with the machine must be read, preserved and kept in a safe
place by the machine or maintenance operators.
Upon receipt of the machine, the manufacturer recommends that the Customer read the atta-
ched manual in full, or in any case, before proceeding with any work on the machine.
4.2 Purpose
The purpose of the information contained in the manual as presented in the various sections,
is to indicate how the machine must be used as well as to provide instructions concerning
transport, movement, installation, assembly, adjustment, operation, personnel training, main-
tenance work, spare parts ordering and risks.
4.3 Limits of Use
This manual has been designed and prepared to provide all necessary instructions, indications
and warnings that the user may need to familiarise himself with the machine, to understand
the principles behind it and its operational limits and to be appropriately prepared to use it
safely.
Together with the instructions contained in this manual, we would like to remind you of the
regulations that must be observed.
This User Instruction Manual must be considered a part of the machine and preserved for all
future reference until such times as the machine is definitively dismantled.
4.4 Where and how to preserve the manual
To correctly preserve the manual, it must be kept in a safe dry place out of the way of dust
and the rays of the sun.
A copy of the manual must always be available for consultation in the vicinity of the machine
or nevertheless on request of whoever may have to work on the machine.
4.5 Updates, amendments and replacements
In the event that the manual is damaged or lost, a new copy can be requested from the Ma-
nufacturer or the Distributor.
The Manufacturer advises that the manual reflects the state of machine at the time when the
machine was distributed and cannot be considered inadequate only because it may have to be
updated in line with new knowledge acquired. The Manufacturer reserves the right to update
production and its manual, without any obligation to update earlier manuals or production, unless
in exceptional circumstances regarding the security and the safety of persons or property.

i
9
ENGLISH
If the Client would like to receive additional information or make suggestions for the manual,
they can directly contact the manufacturer or the reseller.
If the machine is sold, the client is requested to inform the constructor or reseller of the new
owners address so that any new manuals can be sent to them.
The manufacturer informs the client that it takes no responsibility for:
1. The improper use of the machine;
2. Usage that goes against established laws
3. Incorrect installation
4. Lack of maintenance
5. Unauthorised repairs or modifications
6. The use of non original or non specific spare parts
7. Not following the instructions in this manual
8. Other exceptional circumstances

10
5MACHINE DESCRIPTION
AT-ET pump type for mobile installations.
The Pumping machine type AT-ET is made up essentially of the following components, see
figure 5.1:
1. Attachment “third point”
2. Parallel attachments
3. Supporting feet
4. Blockage pin supporting foot
5. Supporting plate
6. Tubular frame
7. Machine lifting rings
8. Pump body
9. Suction pump with grill
10. Shiftable curve
11. Delivery tube
12. Hydraulic motorization (automatic rotation)
Curve regulation lever (manual rotation)
13. Dynamic oil tubes
14. Rotor
15. Transmission
16. Hydraulic jack
Shock absorber (on request)
17. Carter for double joint protection
18. Cover for power takeoff coupling protection
19. Carter for rim and pinion protection (automatic rotation)
IN PARTICULAR THE SAFETY DEVICES OF WHICH THE MACHINE IS FURNISHED ARE:
9. Grate on the pump suction
17. Carter for double joint protection
18. Cover for power takeoff coupling protection
19. Carter for rim and pinion protection (automatic rotation)

11
ITALIANO
Fig.5.1

12
AT
5.1 Technical Data
Technical characteristics and performance.
AT type pump performance
Fig.5.2
Note: The machine’s noise emissions are less than those of the tractor it is connected to.
Therefore for noise emission information consult the manual for the relative tractor.
The information refers to a pump using clean water without air suction.
Model
C A B D Max load* Power
absorbed* Min/turns
mm mm mm mm l/s mc/h kW P. T. O .
Power take-off
AT 25/
33350 1800 2810
250 220 972 21 540
44350 2700 3810
55350 3600 4810
66350 4500 5810
AT 30/
33400 1800 2825
300 300 1080 26 540
44400 2700 3825
55400 3600 4825
66400 4500 5825
AT 35/
33540 1800 2800
350 400 1440 34 540
44540 2700 3800
55540 3600 4800
66540 4500 5800
AT 40/
33590 1800 2855
400 500 1800 40 540
44590 2700 2855
55590 3600 4855
66590 4500 5855
AT 50/ 44680 2700 3950 500 750 2700 72 540
55680 3600 4950
* With 3 m head

13
ENGLISH
ET
ET/50 type pump performance
Fig.5.3
Note: The machine’s noise emissions are less than those of the tractor it is connected to.
Therefore for noise emission information consult the manual for the relative tractor.
The information refers to a pump using clean water without air suction.
Model
C A B D Max load* Power
absorbed* Min/turns
mm mm mm mm l/s mc/h kW P. T. O .
Power take-off
ET 50/ 55340 3300 3450 500 800 2880 40 750
66340 4000 4450
* With 4 m head
Ensure that the tractor unit that the pump is hooked up to, is provided with
the appropriate mass and power capacity suitable enough to support the pump
in question.
LUBRICANTS
Oil VG 78
Grease Type - 2 lithium

14
Lubricate all points indicated with the symbol (see fig 6.1), with the pump switched off.
For when and how to lubricate consult chapter 15 MAINTENANCE INSTRUCTIONS on page 36.
WARNING: !
During the lubrication ense that the transmission is switched off.
6 LUBRICATION
Fig.6.1
To carry out a proper lubrication of the rotation, use the lubricators placed on the flange
of the articulation.
By rotating slowly the delivery pipe in both directions of rotation,
grease simultaneously so that the whole surface of the gear gets properly lubricated.

15
ENGLISH
7 SECURITY WARNINGS
Fig.7.1
Keep hand away from this area: Danger of being crushed
Keep at a safe distance: Cardan joint in use
Attachment points for lifting
Keep at a safe distance: Moving parts
Read the operating manual before starting this machine
Rotation speed of the power take-off

16
8.1 Incorrect usage.
The machine must NOT be used if safety devices are NOT installed, NOT con-
nected; NOT calibrated, voluntarily removed or inefficient as this can lead to
being caught, dragging or breakage.
The machine must not be activated for pumping liquid where there are solid external mate-
rials
(gravel, wood, etc.), this may cause the blockage and breakage of the machine.
The machine must not be operated on unstable or un level ground as this could cause breakage
or the machine could tip.
WARNING: !
Switching on in unsafe scenarios
Before switching the machine on ensure that there are no persons nearby that could be en-
dangered.
If the machine stops for any reason, before approaching it ensure that the on switch is deac-
tivated, to avoid any unexpected restart.
WARNING
Stop – Emergency stop.
Wait until the machine is completely still before any intervention.
The rotor movement and the release of the liquid contained in the tube can take a few seconds
to halt, leaving the machine in motion for a few seconds.
WARNING
Breakdown of electrical and command circuits.
If the machine stops for any reason, before approaching it ensure that the machine is switched
off, to avoid any unexpected restart.
WARNING
Stability
The machine can be unstable if the ground on which it travels is not smooth, shifting, sloping
or yielding.
WARNING
Breakage of Cardan shaft.
Release the accelerator of the machine as quickly as possible. Check for overhead danger stop
the machine by pressing the emergency stop button.
8ACCIDENT PREVENTION REGULATIONS

17
ENGLISH
WARNING
Sharp corners and edges.
Exercise caution when in contact with the machine because on impact these parts can cause
bruising or injury but otherwise the machines surface is not dangerous to handle.
WARNING
Mobile elements.
Do not lean on the cardan shaft during the machine’s operations: there is a danger of being
dragged (see the user manual and maintenance booklet of the cardan). Do not go near the
turning unit when it is still moving: as there is a risk of being cut, sliced or grabbed.
WARNING
Safety devices.
If the safety features are removed or ignored there is a risk of being crushed, caught, dragged,
cut or burned.
Momentary removal of devices is permitted only if the machine is still, disconnected from the
cardan shaft and must be put back before operating the machine.
WARNING
Maintenance – Calibration.
Perform maintenance and calibration only when the machine is still
WARNING
Electrical Isolation
To ensure isolation from the power supply, remove the cardan shaft or switch off the tractor.
WARNING
Operator intervention
The operator can intervene only after having completely read this manual in order to be com-
pletely aware of all dangers linked to any intervention.
WARNING
Cleaning internal parts.
The cleaning of internal parts must only be performed when the machine is still: otherwise
there is a risk of being cut, sliced or caught in the machine

18
WARNING
When the pump is activated ensure that no persons are near the: tube there is a risk of being
crushed
WARNING
When the pump is switched off the delivery tube is lifted into the rest position: ensure that
there are no persons in the effected area: there is a danger of being crushed.
Respect all necessary safety distances from the moving machine as shown in the figure 8.1.
Fig.8.1

19
ENGLISH
9.2 Work place.
The working temperature of the machine is 0°C to +40°C. The operator’s working location is
indicated by the letter P in the figure, corresponding to the tractor cabin (fig. 9.1).
This area must not cause the operator to have physical or mental stress (such as from loud
noise, blinding lights etc).
9 MACHINE’S USES
Areas of operation: direct irrigation, lifting and transporting water.
Water used: clean or dirty (containing mud) water
Function : attach to tractor using a cardan shaft
Usage: the pump is connected to the hydraulic lifter of the tractor.
9.1 Technical description of functions.
The machine pumps water using the dip caused by the giant rotor that is moved by the tractor
engine via the cardan shaft.
The rotation speed of the rotor pump determines the quantity of the liquid extracted.
By shifting the output tube the water can be places in the desired direction.
In the version with the shock absorber, the delivery tube rests automatically on the ground
when it’s full of water.
Mounting the device is achieved using the tractor’s hydraulic lifting device. The pump’s rotor
is always immersed in water during operation therefore to access water it is simply a matter
of rotating the transmission shaft.
Working conditions: the pumps water extraction is regulated should be regulated according to
the quantity desired.
Delivery tube: for all types, the delivery tube rotates horizontally and its height can be regu-
lated.
The rotation can be manual or hydraulic. The height regulation can be done automatically using
the shock absorber or manually with the simple to use hydraulic jack.
The machine is designed and built to be controlled by an operator who positions, installs, activates
and deactivates the power take off to operate the pumps engine using the cardan shaft.
Fig.9.1

20
The machine AT-ET has the following commands (Fig. 9.2):
1. Blockage and release turning flange leavers for manual curve calibration (A) only (AT)
(AT50 and ET50 rotate hydraulically);
2. Screws for the calibration of the shock absorber (B) (only AT without hydraulic jack);
3. Control lever (C) for the automatic movement of the delivery tube (only for machines with
hydraulic jack and/or hydraulic motorization). These commands are present on the tractor
therefore consult the tractor manual.
WARNING
Refer to section 8 of this manual before operating the command controls.
9.3 Controls and operation.
Fig.9.2
When installing the machine it is important to consider the minimum room needed for to access
the operator’s cabin, for the adjustment and operation of the cardan shaft, the calibration of
the pump and the delivery tube.

21
ENGLISH
10 MACHINE ACCESSORIES AND COMPONENTS.
10.1 AT machine accessories.
Fig.10.1
A. Flow protection
B. Shock absorber (usually the hydraulic jack but if requested the shock absorber is available
for all pumps, apart from the AT35,AT40 and the 6m AT50).
C. 3° hydraulic point
D. Cardan shaft connecting the machine to the tractor
E. Pressure release valve
F. Rising outlet pipe
G. Hydraulic telescopic pipe
H. Hose
10.1.1 ET machine accessories.
C. 3° hydraulic point
D. Cardan shaft connecting the machine to the tractor
E. Check valve
H.Hose
H
