Vent 125 Derapage 2019 User manual

VENT 125 Baja + Baja RR / VENT 125 Derapage + Derapage RR
USE AND MAINTENANCE
MANUAL

VENT 125 Baja + Baja RR / VENT 125 Derapage + Derapage RR
2use and maintenance manual
This manual is an integral part of the vehi-
cle and must always be so, even when the
vehicle is sold.
VENT is entitled to modify its own models,
except for the essential characteristics de-
scribed and illustrated herein.
All rights of electronic memory, reproduc-
tion and total or partial adaptation, whatev-
er the means, are reserved in all countries.
Mentions of products or services provided
by third parties are for information purposes
only and do not represent any commitment
whatsoever.
VENT cannot be held liable for the services
or the use of these products.
Edition: 03/2019.
Produced by:
DUESSE SERVICE srl
Samarate (VA)
www.duesse.it
On behalf of:
VENT srl
I - 23815 Introbio (Lecco) Via V. Veneto, 9
Phone: [phone] (R.A.)
Fax: [phone]
E-mail: [email protected]

VENT 125 Baja + Baja RR / VENT 125 Derapage + Derapage RR 3use and maintenance manual
MAIN INDEX
SAFETY MESSAGES....................................... 4
WARNINGS - CAUTION -
GENERAL WARNINGS................................ 4
CatalytiC exhaust system .................... 4
SAFETY RULES............................................... 4
Permitted use........................................... 5
Clothing .................................................... 5
aCCessories ............................................. 5
luggage..................................................... 5
Fuel ............................................................. 5
engine oil................................................... 6
Brake Fluid................................................ 6
Cooling Fluid ........................................... 7
exhaust Fumes ......................................... 7
Battery....................................................... 7
saFe driVing .............................................. 7
Parking....................................................... 8
VehiCle identiFiCation............................. 9
engine identiFiCation .............................. 9
MAIN ELEMENTS.......................................... 10
main elements on the leFt side ........ 10
main elements on the right side ...... 10
COMMANDS ................................................. 14
start switCh........................................... 14
start Button .......................................... 14
leFt switCh ............................................. 15
ClutCh Command .................................. 16
aCCelerator Command ....................... 16
Front Brake Command ........................ 16
ComBined Braking Command ............. 16
ClutCh Command leVer....................... 17
steering loCk ........................................ 17
Fuel taP .................................................... 17
INSTRUCTIONS TO USE THE VEHICLE ..... 20
general CheCks Prior to use ........... 20
ClimBing on and oFF the VehiCle ...... 20
Break-in.................................................... 21
adjusting rear-View mirrors ................ 21
PlaCing the VehiCle on
the side kiCkstand ................................ 22
Fuelling ................................................... 22
STARTING THE ENGINE............................... 23
on your way ........................................... 24
stoPPing the VehiCle ........................... 25
stoPPing the engine............................. 25
Preliminary oPerations ...................... 25
SCHEDULED MAINTENANCE SHEETS ...... 27
Parts remoVal ....................................... 29
remoVing the seat ................................ 29
remoVing the leFt Front
ConVeyor ................................................ 29
remoVing the wheels .......................... 30
disassemBling the Front
light BraCket............................................32
COMMANDS ................................................. 33
engine oil leVel CheCk ........................ 33
Brake Fluid leVel CheCk ..................... 34
Brake lining CheCk............................... 35
Cooling Fluid leVel CheCk ................. 35
CheCking the tyres .............................. 36
insPeCtions and regulations............ 37
side kiCkstand........................................ 37
handleBar............................................... 37
swingarm................................................. 38
Fuel tank CaP ......................................... 38
air Filter .................................................. 39
transmission Chain .............................. 40
Front susPension ................................. 42
rear susPension ................................... 42
sPark Plug .............................................. 43
Front Brake Command leVer ............ 44
ComBined Braking Command leVer.. 44
ClutCh Command leVer....................... 45
aCCelerator Command regulation ...... 46
idling sPeed regulation...................... 46
Battery..................................................... 47
tyPe oF reCharge ................................. 48
FUSES............................................................ 48
light Beam ............................................... 49
Front headlight BulBs ....................... 50
rear headlight BulB ............................ 51
Front and rear Blinkers.................... 51
TRANSPORTATION....................................... 51
CLEANING..................................................... 52
washing ................................................... 52
storage ................................................... 53
TECHNICAL INFORMATION ........................ 54

VENT 125 Baja + Baja RR / VENT 125 Derapage + Derapage RR
4use and maintenance manual
SAFETY MESSAGES
This symbol indicates a safety message.
When this symbol appears in the
manual, pay particular attention to the
potential risk of harm. Failing to heed the
warnings that contain this symbol may
compromise your own safety as well as
that of other people and of the vehicle!
The following words are used throughout
the manual to indicate:
DANGER
Potential risk of serious injury or death
for the operator or other people.
WARNING
Potential risk of light injuries for the op-
erator or other people, or damage to the
vehicle.
NOTE: The term “NOTE” precedes impor-
tant information or instructions.
WARNINGS - PRECAUTIONS -
GENERAL WARNINGS
Before using or operating the vehicle, read
this manual very carefully, paying particular
attention to the chapter “SAFETY RULES”.
Your safety and that of others depend on:
- Being familiar with the vehicle in your
possession;
- Theefciencyandmaintenancestatusof
your vehicle;
- Being familiar with and respecting the
Highway Code;
- Your familiarity with movements on the
vehicle.
To familiarise yourself with the vehicle,
choose an area away from trafc and de-
void of dangers to practice.
VENT thanks you for choosing one of
our products and wishes you a pleasant
drive.
Catalytic discharge system
The catalytic discharge system must be
able to work at high temperatures, which re-
main for a certain period of time even after
the engine has been turned off.
DANGER
Do not touch or move objects, especial-
ly ammable ones, near the catalytic
discharge system until it is completely
cold.
Park the vehicle away from dry brush or
places accessible to children.
WARNING
To avoid damage to the catalytic dis-
charge system, use only lead-free gaso-
line.
SAFETY RULES
- To drive this vehicle it is necessary to
possessallrequisitesdenedbythelaw
in force in the country where it is used.
- Taking certain medications, alcohol or
other drugs increases the risk of acci-
dents. Make sure you are psychologi-
cally and physically able to drive, focus-
ing particularly on physical fatigue and
drowsiness.
- Anothersignicantcauseofaccidentsis
driver’s inexperience. DO NOT entrust
the vehicle to beginners, and make sure
the driver possesses the necessary req-
uisites to drive.
- Always respect road signs and highway
laws, nationally and locally.
- Avoid sudden manoeuvres, which are
dangerous for yourself and for others (for

VENT 125 Baja + Baja RR / VENT 125 Derapage + Derapage RR 5use and maintenance manual
example, wheeling, failing to respect the
speed limit etc).
Assess driving conditions:
- Visibility;
- Road conditions;
 - Trafc;
- Presence or possible presence of pe-
destrians.
Rule out and avoid obstacles that may
cause damage to the vehicle or lead to
loss of control of the vehicle.
- Respect and maintain all safety distanc-
es.
- Always drive holding the steering wheel
with both hands, with your feet resting on
the driver’s footrests, i.e. In the proper
driving position.
- Pay maximum attention to the act of driv-
ingandtothetrafcontheroad.
- If the vehicle has been in an accident or
has been in a crash or fall, make sure the
command levers, the tubes, the cables,
the braking system, the wheels, the tyres
and all other parts are intact.
If the damage is persistent or if you are
uncertain of its conditions, take the car to
a VENT dealer, where the vehicle will be
tested and inspected.
Always report any case of malfunctioning
to make it easier for the technicians and/
or mechanics to solve the problem.
DANGER
Do not drive or allow anyone to drive the
vehicle if the damage it has suffered is
compromising its safety.
- Itisforbiddentocarryoutanymodica-
tion to the vehicle.
NOTE: Making modications to the vehi-
cle will result in warranty annulment.
- It is advisable to follow all national and
local laws and regulations regarding ve-
hicle equipment.
- It is forbidden to use the vehicle to race,
except for competitions in tracks set
apart for this purpose.
Permitted use
Baja models are intended for use on the
road and off-road.
Derapage models are intended exclusively
for use on the road.
Clothing
- Always wear and properly snap shut the
helmet, which must be approved accord-
ing to the laws in force in the country
where it is being used.
- It is advisable to wear protective gar-
ments in the event of falls, such as jack-
et, trousers, gloves, boots etc, suitable
for motorcycle use.
Do not wear exceedingly loose or abun-
dant garments or accessories, as they
may impair driving manoeuvres.
- Do not keep in your pockets any sharp
objects that could potentially cause harm
in a fall, such as:
- Keys;
- Pens;
- Glass containers etc.
This also applies to the passenger.
Accessories:
It is advisable to purchase and install origi-
nal accessories from a VENT dealer.
Users are personally responsible for choos-
ing and installing accessories.
Luggage
- Be prudent when loading luggage. Do
not overload.
- Maintain the luggage as close as possi-
ble to the barycentre of the vehicle.
- Distribute the load uniformly on both
sides to reduce imbalances.
- Theloadmustbermlyanchoredtothe
vehicle.
- Never rest any loads on the handlebars,
swingarm or front mudguard.
- Exceedingly voluminous loads, or any-
thing that protrudes too much from the
limits of the vehicle, may cause crash-
es and therefore injury and damage to
animals or things and compromise the
stability of the vehicle, with dangerous

VENT 125 Baja + Baja RR / VENT 125 Derapage + Derapage RR
6use and maintenance manual
consequences.
- It is forbidden to transport any load that
protrudes exceedingly or that covers
the acoustic and visual signalling devic-
es.
- Overloading the vehicle compromises
its stability and manoeuvrability.
Fuel
DANGER
Fuel is highly ammable, harmful for the
health and dangerous for the environ-
ment.
DANGER
Do never use your mouth to pump fuel
from the tank using tubes or any other
means.
- Whenllingupthe tank, never usefree
ames,donotsmoke,andkeeptheen-
gine off.
Avoid inhaling fuel fumes and keep the
fuel from coming into contact with eyes
or skin.
If any fuel comes into contact with your
clothes, change them immediately.
WARNING
If you feel ill due to inhaling fuel fumes,
stay outdoors and seek medical help. If
fuel comes into contact with your eyes,
rinse abundantly with water. If it comes
into contact with your skin, wash abun-
dantly with water and soap.
In the event of fuel ingestion, seek
medical help immediately.
DANGER
Be careful not to pour fuel over the en-
gine or the exhaust pipe; re hazard. If
this happens, wash and rinse the area
involved.
DANGER
KEEP AWAY FROM THE REACH OF
CHILDREN.
DO NOT DISPOSE OF ENGINE OIL IN
THE ENVIRONMENT.
- Neverllupthetanktothetop;stopat
the maximum level permitted, indicat-
ed in the relative paragraph “Refuel-
ling”.
Engine oil
DANGER
Engine oil is highly ammable, harmful
for the health and dangerous for the en-
vironment.
- During maintenance operations, always
wear latex gloves to protect your hands.
WARNING
If the oil comes into contact with your
eyes, rinse abundantly with water. If it
comes into contact with your skin, wash
abundantly with water and soap.
In the event of engine oil ingestion, seek
medical help immediately.
DANGER
KEEP AWAY FROM THE REACH OF
CHILDREN.
DO NOT DISPOSE OF ENGINE OIL IN
THE ENVIRONMENT.
- Used oil must be collected in a suitable
container and taken to a recycling cen-
tre.
Brake uid
DANGER
Brake uid is highly ammable, harmful
for the health and dangerous for the en-
vironment.
- During maintenance operations, al-
ways wear latex gloves to protect your
hands.
WARNING
If brake uid comes into contact with
your eyes, rinse abundantly with water.
If it comes into contact with your skin,
wash abundantly with water and soap.

VENT 125 Baja + Baja RR / VENT 125 Derapage + Derapage RR 7use and maintenance manual
In the event of brake uid ingestion,
seek medical help immediately.
Cooling uid
DANGER
Cooling uid is highly ammable, harm-
ful for the health and dangerous for the
environment.
- When lling up or replacing cooling u-
id,neverusefreeames,donotsmoke,
and keep the engine off.
 Avoidinhalingcoolinguidandkeepthe
fuel from coming into contact with eyes
or skin.
 If any cooling uid comes into contact
with your clothes, change them immedi-
ately.
WARNING
If brake uid comes into contact with
your eyes, rinse abundantly with water.
If it comes into contact with your skin,
wash abundantly with water and soap.
In the event of brake uid ingestion,
seek medical help immediately.
DANGER
Be careful not to pour cooling uid over
the engine or the exhaust pipe; risk of
re with invisible ames. If this hap-
pens, wash and rinse the area involved.
DANGER
KEEP AWAY FROM THE REACH OF
CHILDREN.
DO NOT DISPOSE OF ENGINE OIL IN
THE ENVIRONMENT.
- Neverlluptheradiatortothetop;stop
at the maximum level permitted, indicat-
ed in the relative paragraph “Cooling
uid level check”.
Exhaust fumes
DANGER
Exhaust fumes consist of carbon mon-
oxide, an extremely harmful substance
if inhaled.
Avoid starting the engine in closed spac-
es or anywhere with poor ventilation.
Failure to follow this recommendation
may result in loss of senses and even
death by asphyxia.
Battery
DANGER
The battery releases explosive gases;
keep away from sparks and free ames.
Do not smoke. When recharging the bat-
tery, make sure there is sufcient air cir-
culation in the area.
SAFE DRIVING
This paragraph offers some suggestions for
driving/riding safely.
ACCELERATION. Accelerating and decel-
erating repeatedly without true need may
cause loss of vehicle control and result in
fall, with serious consequences for yourself,
for others, and for the vehicle.
BRAKING. To reduce speed in a uniform,
optimal manner:
- Decelerate and always use both brakes,
suitably dosing the amount of force ap-
plied on the brake levers;
- Avoid close braking whenever possible.
Using only one of the brakes:
- Reduces braking force;
- Risks locking the braking wheel;
- Contributes to loss of adherence and to
the possibility of falling, with serious con-
sequences for themselves and for oth-
ers, as well as for the vehicle.
BRAKING IN ASCENT. Decelerate com-
pletely and use both brakes to keep the ve-
hicle in place.
Using motion force (using the accelerator)
to keep the vehicle in place causes anom-
alous overheating of the engine and of the
clutch.
Keeping the vehicle in place using only
physical strength may cause loss of bal-
ance and fall, with serious consequences
for yourself, for others and for the vehicle.

VENT 125 Baja + Baja RR / VENT 125 Derapage + Derapage RR
8use and maintenance manual
FACING AND RIDING A
CURVE. Do not ride into a curve at high
speed.
Donotunderestimatethedifcultyinvolved
in negotiating a curve; slow down before
facing it.
When you see a curve up ahead, reduce
your speed by decelerating and then brak-
ing. Negotiate the curve at constant speed
or at moderate acceleration, being careful
not to lose adherence with the terrain or
control of the vehicle. If it is necessary to
use the brakes, do it with moderation and
attention.
NEGOTIATING DESCENTS: Never ride
the vehicle with the engine off in descents.
Using only the brakes when riding down a
slope causes overheat in the friction materi-
al (brake linings or shoes) and consequent-
ly reduces brake effectiveness.
Combine the use of brakes and the com-
pression of engine power (scaling the shifts
correctly).
DRIVING WHEN VISIBILITY IS POOR. It is
obviously not advisable to drive/ride when
visibility is poor (due to rain, fog, mist etc);
if possible, it is always better to stop and
wait until visibility conditions improve before
resuming your trip.
DRIVING/RIDING WHEN ROAD ADHER-
ENCE IS POOR.
Whenever possible, avoid driving/riding
in such conditions (snow, ice, mud etc). If
necessary, proceed at moderate speed and
avoid sudden manoeuvres; always brake
with caution so as to avoid losing control of
the vehicle.
OBSTACLES AND TRAPS ON THE
ROAD.
Disconnected roads, manholes, sudden
depressions, bumps, rail tracks, road signs
paintedover,metal slabs belonging tobuild-
ing sites along the road, may all be slippery
or otherwise jeopardise, even if only tempo-
rarily, vehicle stability, causing falls with se-
rious consequences for yourself, for others
and for the vehicle.
CHANGING LANES OR DIRECTION. Al-
ways activate the blinkers when changing
lanes or direction, and carry out the ma-
noeuvres with regularity.
Turn off the blinkers after use.
OVERTAKE CAREFULLY Whenever over-
taking another vehicle or when you are
being overtaken yourself, be particularly
attentive. Water splashes when the road
is wet and the slipstream caused by the
motion of large vehicles can cause loss of
control of the vehicle and the possibility of
falling, with serious consequences for your-
self, for others and for the vehicle.
WARNING
Always follow the recommended indica-
tions when driving/riding.
PARKING
DANGER
Accidentally falling from the vehicle can
cause:
- Fuel leaking from the tank, resulting
in re hazard;
- Cooling uid leaks;
- Engine oil leaks;
- Damages to people, things and the ve-
hicle itself.
To avoid accidental falls with the vehicle,
choose a solid, at terrain and an area of
suitable size for the vehicle and for parking
manoeuvres.
DANGER
Make sure the terrain is not exceedingly
inclined.
Always check the motorbike for stability
after lowering it on its kickstand.
If you must park on inclined terrain, park
your motorbike facing uphill, so that its
weight will keep the kickstand in place and
prevent it from caving in.
- Do not leave the vehicle sideways on the
ground or leaning on walls, fences, hand-
rails etc.
- The vehicle must always be parked on its
kickstand.

VENT 125 Baja + Baja RR / VENT 125 Derapage + Derapage RR 9
BA
C
use and maintenance manual
DANGER
The parked vehicle, and in particular its
overheated parts, must not be a hazard
for children, people or animals. NEVER
leave the vehicle parked with the engine
running.
NOTE: The kickstand is designed to sustain
the combined weight of vehicle and luggage.
- Always use the steering lock.
WARNING
Avoid parking or lounging beneath
plants or trees.
During some seasons, certain plants and
trees drop or release residues, resin, fruits
or leaves containing substances that can
damage the vehicle (especially its body).
IDENTIFICATION
Vehicle identication
Each VENT vehicle comes with a vehicle
identicationnumber(V.I.N.)
This vehicle displays its V.I.N.:
- On the chassis, on the steering head on
the right side (A);
- On the SUMMARY PLATE (B), located
on the right side of the chassis, near the
steering head.
Every request made to the dealer must be
accompanied by the V.I.N. of the vehicle in
question, so that the dealer can recognise
the vehicle and meet your demands.
Engine identication
The engine number (C) is printed on the
base of the engine casing, on the left lower
side.

VENT 125 Baja + Baja RR / VENT 125 Derapage + Derapage RR
10
16
17
8
6
15
10
11 12
use and maintenance manual
MAIN ELEMENTS
Main elements on the left side
1. Left rear view mirror.
2. Buzzer button “ ”.
3. Light switch “ ”.
4. Blinker switch “ ”
5. Buzzer
6. Airlter
7. Cold-start device.
8. Fuse holder (main and secondary).
9. Clutch lever.
10. Fuel tap (FUEL).
11. Clutch command lever.
12. Pilot’s left foothold (with spring, always
open).
13. Side kickstand.
14. Transmission chain.
15. Battery.
16. Contactor
17. Contactor fuse
18. Left handguard
19. Front brake pincers
20. Front brake disk
21. Front headlight
22. Front blinkers

VENT 125 Baja + Baja RR / VENT 125 Derapage + Derapage RR 11
19
21
20
5
14
13
22
18
1
7
9
23
4
use and maintenance manual

VENT 125 Baja + Baja RR / VENT 125 Derapage + Derapage RR
12
14
1
16
5
6
15
use and maintenance manual
Main elements on the right side
1. Start and stop switch.
2. Right rear view mirror.
3. Fuel tank cap.
4. Fuel tank.
5. Coolinguidradiatorcap.
6. Coolinguidradiator.
7. Engine oil level rod-cap.
8. Engine oil drain plug.
9. Rear brake command lever.
10. Pilot’s right foothold (with spring,
always open).
11. Frontbrakeuidreservoir.
12. Front brake command lever.
13. Accelerator.
14. Dashboard.
15. Steering lock.
16. Spark plug.
17. Start button.
18. Rearbrakeuidreservoir.
19. Engineoilltercap.
20. Rear brake lever knob.
21. Engine idling speed knob.
22. Cooling fan.
23. Right handguard.
24. Rear brake pincers.
25. Rear brake disk.
26. Rear light/plate light.
27. Rear blinkers

VENT 125 Baja + Baja RR / VENT 125 Derapage + Derapage RR 13
21
19
7
9
1020
18
11
12
13
17
2
23
3
4
26
27
24
25
8
22
use and maintenance manual

VENT 125 Baja + Baja RR / VENT 125 Derapage + Derapage RR
14
OFF OFF
OFF
1
1
use and maintenance manual
COMMANDS
Start switch
The start switch has two positions:
“OFF” position, key removal;
“ON” position, motorbike start (key
cannot be removed);
- Key extraction position “”
When the key is turned to the “ ” posi-
tion, the engine and the lights are turned
off and voltage is cut off from the circuits.
In this position, the key can be removed
from the switch.
- Start position “ ”
From the “ ” OFF key removal position,
turn the key (1) clockwise to the “ ” ON
position. The lights will light up and the
display will show that the circuits are live.
It is now possible to start the motorcycle.
DANGER
Do not tamper with the engine on/off
key (1) while the engine is running. This
would temporarily stop the engine and
then restart it when the key is used. This
might damage the engine and especially
cause loss of vehicle control, with pos-
sible serious consequences for people,
things and the vehicle itself.
Start button
Press the start button (1), with the start
switch at the ON “ ” position, the engine
will start.
WARNING
Avoid pressing the start button “ ” (1)
when the engine is on: this might dam-
age the starter.
For the engine start procedure, see the par-
agraph on “Starting the engine”.

VENT 125 Baja + Baja RR / VENT 125 Derapage + Derapage RR 15
2
3
1
1
A
B
use and maintenance manual
Left switch
Honk “ ”
Press the button (1) to honk.
WARNING
The use of the honk must be limited by
the laws of the road and to specic pro-
hibitions.
Light switch “ - ”
NOTE: When the light switch is in “ON”
position, the passing and position lamp is
always switched on.
- The light switch “ - ” (2) has two po-
sitions.
In the “ ”, position, the dipped beams
are turned on.
In position “ ”, the driving and position
lamp is switched on and the relative indi-
cator lights up on the dashboard.
Blinkers “”
The blinker “ ” (3) has three positions, re-
turning to the centre position.
- When moved to the right and released,
it turns on the right blinker. Its relative
warning light on the dashboard will turn
on;
- When moved to the left and released,
it turns on the left blinker. Its relative
warning light on the dashboard will turn
on;
To turn off the blinker, press the lever (3)
once it is back in its central position.
- After starting the vehicle, wait a few sec-
onds until the engine’s regime of rota-
tions per minute is settled (this depends
on the room temperature). Turn off the
cold-start device by releasing the lever
and making sure it returns to the “A” po-
sition.
NOTE: Prior to starting the engine, make
sure the lever (1) is completely rotated
clockwise (A).
WARNING
ONLY use the cold-start device when
the engine is off and cold. NEVER use
it while the engine is running. Use the
cold-start device only when necessary.
Cold-start device
This vehicle is equipped with a cold-start
device commanded by a lever (1).
- To activate the cold-start device, turn the
lever (1) counter-clockwise (B) and keep
it in position.

VENT 125 Baja + Baja RR / VENT 125 Derapage + Derapage RR
16
1
1
1 2
1
use and maintenance manual
Clutch command
The command lever (1) for the clutch is lo-
cated to the left of the steering wheel.
Accelerator command
The accelerator command (1) is located to
the right of the steering wheel.
According to how much it is turned, the
rotations per minute will increase or dimin-
ish.
Front brake command
The command lever (1) for the front brake
is located to the right of the steering wheel.
NOTE: The lever has a STOP switch: when
braking, it lights up the rear stop light.
- Pull the lever (2) to brake with the front
brake;
- Press the pedal (1) for combined brak-
ing. The system will split the braking be-
tween the front and the rear brakes.
Combined braking command
The motorcycle is equipped with combined
brakes.
- The command pedal (1) for the combined
braking is located on the right side of the
motorcycle.
NOTE: The pedal has a STOP switch:
when braking, it lights up the rear stop
light.

VENT 125 Baja + Baja RR / VENT 125 Derapage + Derapage RR 17
N
1
2
3
456
1
2
1
3
1
use and maintenance manual
Clutch command lever
This motorcycle is equipped with six gears.
- Use the lever (1) to change gears.
NOTE: After inserting a gear, release the
lever (1), which will return to its central
position.
WARNING
To change the gear, pull the gear lever
and lower the number of rpm using the
accelerator knob.
- From the N (neutral) position, press the
lever (1) downwards to insert the rst
gear.
- To change to the other gears, move the
lever (1) upwards.
- To reduce the gears, proceed in the op-
posite direction.
Steering lock
To lock the steering, do the following:
- Park the vehicle on its kickstand.
- Turn the handlebar completely to the left.
- Turn the protection cover (1).
- Insert the key (2) into the lock (3).
- Rotate the key (2) counter-clockwise.
- Press the key (2) inwards and turn it
clockwise.
- Remove the key.
To unlock the steering, follow the same in-
structions in the opposite order.
WARNING
Do not leave the key inserted after hav-
ing unlocking the handlebar; when the
handlebar is turned, it may break the
key.
Fuel tap
This motorcycle is equipped with a screw-
ing fuel tap (1).
- Completely closed (tightened), it closes
the feeding line of fuel to the carburettor;
- Completely open (unscrewed), it opens
the feeding line of fuel to the carburettor.
NOTE: Prior to starting the motorcycle,
make sure the tap (1) is completely open
(unscrewed).
NOTE: It is advisable to close (tighten) the
tap (1) when the motorcycle is not to be
used for a few days.
WARNING
This vehicle is NOT equipped with man-
ual fuel reserve. The use of the fuel re-
serve is automatic, and is indicated by
its specic warning light on the dash-
board. When the fuel reserve light on the
dashboard lights up, ll up the tank as
soon as possible.

VENT 125 Baja + Baja RR / VENT 125 Derapage + Derapage RR
18
7
3
8
9
11
4
2
5
6
10
1
use and maintenance manual
DASHBOARD
ODOMETER
The odometer is activated when the start key
is in the ON position.
Lights and buttons
1) Backlighted display
2) GREEN light, left blinker; it lights up
when the left blinker is on.
3) GREEN light, right blinker; it lights
up when the right blinker is on.
4) BLUE light, high beams are on
5) YELLOW light, fuel reserve.
This indicator lights up when the fuel
level is at its minimum. Drive to the
nearestfuelstationtollupthetank.
6) YELLOW light; engine anomaly.
It lights up when an engine or exhaust
anomaly has happened. Go to the
nearest VENT Dealer.
7) GREEN light, neutral gear.
8)  Cooling uid temperature alarm
light
When the warning light is on, this
means the temperature of the cool-
ing uid has reached its maximum
allowed temperature. Stop the vehi-
cle, leave the engine at idle for a few
seconds, then turn it off. Wait until
the temperature of the cooling uid
drops then restart the engine. If the
light turns on again, do not use the
vehicle. Take it to the nearest VENT
Dealer.
9) Not used
10) Select button
Multi-function button. Pressing during
use will display, in sequence:
-
Start time (when the motorcycle is
turned off, the time will go back to zero)
- Battery voltage.
11) Select button
Multi-function button. Pressing during
use will display, in sequence:
- Total km/miles
- Trip A
- Trip B
- Total hours running
- Trip A hours running
- Trip B hours running
- Maximum rotations per minute
achieved (optional)
- Maximum speed reached
- Average speed employed.

VENT 125 Baja + Baja RR / VENT 125 Derapage + Derapage RR 19
3
2
4
1
1
use and maintenance manual
Display
1) Speedometer
Indicates the speed of the vehicle
2) Multidata display
This part of the display can show the
following information:
Odometer
- Total km/miles covered
- Maximum99,999km/miles; oncethis
maximum value has been reached,
the odometer resets itself and starts
counting from 0 again. Minimum: 1
km/mile
Partial “Trip A/B” km/mile counters
It is possible to set two partial counters,
Trip A and Trip B. Indicator of maximum
km/miles covered, maximum 9999.9
km/miles; once this maximum value has
been reached, the odometer resets itself
and starts counting from 0 again. Mini-
mum: 0.1 km/mile
“Total” or partial running hours for
Trip A and Trip B
It is possible to set two partial counters,
Trip A and Trip B, and a Total hour coun-
ter.
Indicator of maximum hours covered,
maximum 9999.9 hours; once this maxi-
mum value has been reached, the odom-
eter resets itself and starts counting from
0 again. Minimum: 0.1 hour.
Indicator of total hours covered, maxi-
mum 99999.9 hours; once this maximum
value has been reached, the odometer
resets itself and starts counting from 0
again. Minimum: 0.1 hour.
Maximum rpm achieved (optional,
with additional kit)
Maximum speed reached
Average speed employed
3) RPM indicator (optional, with addition-
al kit)
4) Reserve fuel level indicator.
This indicator lights up when the fuel
level is at its minimum. Drive to the
nearestfuelstationtollupthetank.
Reset partial values
To reset the partial values Trip A, Trip B,
maximum rpm achieved, maximum speed
achieved, average speed covered, proceed
as follows:
- Press the “Set” (1) until the desired
screen is displayed, e.g. Trip A, then
press “Set” (1) again for 3 seconds to re-
set the value.
- Proceed in the same manner for all other
screens.

VENT 125 Baja + Baja RR / VENT 125 Derapage + Derapage RR
20 use and maintenance manual
INSTRUCTIONS TO USE THE
VEHICLE
General checks prior to use
Every time you are about to ride your mo-
torcycle, go through this checklist:
- Rotate the start key to the ON position
and make sure the display lights up;
- Turn on the high beam and make sure its
warning light is on;
- Turn on the blinkers and make sure their
relative warning lights are on;
- Pull the front brake lever and press the
combined brake pedal; make sure the
rear stop light turns on;
- Check fuel and engine oil levels;
- Checkthebrakeuidlevelinitstank;
- Checkthecoolinguidlevel;
- Make sure the handlebar is working by
turning it all the way to the right and to
the left;
- Check pressure in the tyres;
- Make sure tension in the chain is ade-
quate.
NOTE: For the inspection operations,
please consult their relative paragraphs.
Climbing on and off the vehicle
Pay attention to the instructions below.
They have the goal of keeping the pilot or
the passenger from falling from the vehicle
and/or the vehicle itself from toppling, which
would result in damages
to people, things and the vehicle itself.
- Only climb on and off the vehicle if you
have freedom of movement; your hands,
in particular, must not be holding objects,
such as helmet, gloves or glasses.
Climbing on the bike
- With the bike on the side kickstand, the
pilot must climb on the motorbike from
its left side, with both hands holding the
handlebar.
- Once the pilot is on the bike, lift the bike;
the side kickstand will automatically lift
as well.
DANGER
Make sure the side kickstand is fully lift-
ed.
WARNING
Do not place the pilot’s or the passen-
ger’s weight on the side kickstand.
NOTE: If you are unable to rest both your
feet on the ground on both sides of the bike,
rm your right foot on the ground and keep
the left one ready to offer support.
- The passenger must extract the rear
footrests and climb from the left side
of the bike, using the left footrest while
holding on to the pilot.
