Venta Airwasher LW15 User manual

Art.-No. 78500-36
CUSTOMER SERVICE:
Venta Airwasher Inc.
411 Business Center Drive
Suite 107
Mt. Prospect, IL 60056
Toll Free: 1-888-333-8218
www.venta-airwasher.com
e-mail: [e-mail]
The Original

Art.-No. 78500-36
The Original
VENTA AIRWASHER
User Manual FOR MODELS LW 15/25/45
READ AND SAVE THESE
IMPORTANT INSTRUCTIONS
QUESTIONS?
Service Hotline
888-333-8218
LW 15
LW 25
LW 45

2
CONTENTS:
Important Safeguards-------------------------------------------------------------------------------------- 3
Letter from Venta ------------------------------------------------------------------------------------------- 4
Unpacking your Airwasher -------------------------------------------------------------------------------- 5
Before First Use--------------------------------------------------------------------------------------------- 6
Operator panel---------------------------------------------------------------------------------------------- 7
Daily Use and Operation----------------------------------------------------------------------------------- 7
Main Components of the Venta Airwasher – Easy Access for Cleaning ----------------------------- 8
Maintenance and Cleaning -------------------------------------------------------------------------------- 9
Venta Water Treatment Additive (WTA)------------------------------------------------------------------10
Venta Cleaner ----------------------------------------------------------------------------------------------11
Venta Fragrances------------------------------------------------------------------------------------------12
Helpful Hints -----------------------------------------------------------------------------------------------12
Automatic shut-off / Troubleshooting -------------------------------------------------------------------13
Frequently Asked Questions -----------------------------------------------------------------------------14
Servicing your Venta Airwasher--------------------------------------------------------------------------16
Two (2) Year Limited Warranty ---------------------------------------------------------------------------18
VENTA AIRWASHER
User Manual
FOR MODELS LW 15 / 25 /45

3
QUESTIONS?
Service Hotline
888-333-8218
READ ALL INSTRUCTIONS:
IMPORTANT SAFEGUARDS
WARNING!
It is important that you read, fully understand, and observe the following safety precautions and
warnings. Read these instructions periodically. Careless or improper use of your Venta Airwash-
er may cause serious or even fatal injury. Keep this User Manual with your Airwasher. Be sure
anyone using your Airwasher understands the information contained in this manual.
•ChildrenshouldnotbeallowedtooperatetheAirwasher.
•AlwaysswitchthemotoroffandunplugtheswitchingpowersupplyfromtheACoutlet
beforerellingitwithwater,addingVentaWaterTreatmentadditive,VentaCleanerorVenta
Fragrances, or before moving, or handling the unit.
•Pluginto110-120VACoutletonly.DonotuseyourAirwasheriftheswitchingpowersupplyor
plug is damaged. Do not replace a damaged switching power supply or plug. Only Venta may
replace the switching power supply or plug.
•TheAirwashercanonlybeoperatedwiththe“ModelNo.BI13-240050-CdU”
switching power supply (included).
•Donotattemptanyrepairwork.MaintenanceorservicingtheVentaAirwasher,otherthan
describedinthisusermanual,shouldonlybedonebyVenta.AnymodicationtoyourVenta
Airwasher is extremely dangerous and voids your warranty.
•Donotinsertanyobjectsintotheairintakeoftheunit.Itmaydamagethefanbladesorcause
injuries. After the motor is switched off, the fan continues to rotate for a short period of time.
•Donotuseorstorethisproductwhereitcanfallorbepulledintoabathtub,sink,water,or
other liquid. Do not reach for a unit that has fallen into water or other liquid. Do not immerse
in water or other liquid, even when the unit is unplugged at that time. Moisture can cause an
electric shock hazard when the unit is again plugged into the AC outlet. Wipe moisture off the
unit with a dry cloth. Do not handle the switching power supply or the unit with wet hands.
•UseonlygenuineVentafragrances.
Read and follow separate instructions and Warnings for Venta Water Treatment Additive,
Venta Cleaner, and Venta Fragrances.
Please contact Venta Airwasher Inc. at [phone] or
www.venta-airwasher.com for additional information.

4
DEAR CUSTOMER,
ThankyouforchoosingtheVentaAirwasherhumidierandpurier.TheVentaAirwasherdoes
awaywiththeinconvenienceoflters.Withitshumidicationandpuricationsystem,Ventarep-
resentsarevolutionaryandworldwideuniquetechnology.Therearenolterstobecomecon-
taminated.Wateristhelterwhichisreneweddaily.Ifmaintainedproperly,theVentaAirwasher
will consistently provide high humidifying and purifying performance for many years.
WHY IS THE VENTA HUMIDIFICATION AND PURIFICATION SYSTEM
A REVOLUTIONARY, UNIQUE TECHNOLOGY?
1 Itcleansandimprovesdryindoorairbywashingitwithwater.Nolters,novaporization,no
ions, no ozone, and no problems with white dust.
2It automatically adds vital humidity through cold evaporation, recognized as the best method.
3 Noendlesscostofreplacingdirtylters.Wateristhelter,fresheveryday,cleans
consistentlyandalwayswiththesamehighefciency.
WHY IS HUMIDIFICATION PLUS PURIFICATION A SUPERIOR
METHOD TO CLEAN THE AIR?
Dryairisdifculttoclean.Humidicationpluspuricationisfarmoreeffective.Manyairborne
particlesfalltotheoorwhenmoistened.Impuritiesoftheairandodorsaretrappedinthewater
and eliminated while pure water evaporates.
YourinvestmentintheVentaAirwasherhumidierwillcertainlyproveworthwhile.Drymucous
membranes cannot intercept bacteria and stale tobacco smoke imposes a strain on the
respiratory tract. Not only will you be protecting yourself and your family from these common
ailmentsbutitwillalsoprovebenecialtoyourplantsandpets.Itcanhelppreservethebeauty
ofpreciousantiques,musicalinstruments,andwoodenoorsandfurnishingsbymaintaininga
levelofhumiditybetween40-55%inyourhomeorofce.
OverhalfofallVentaAirwashersaresoldonthebasisofrecommendationsbysatised
customers.OurgoalisthatyouarecompletelysatisedandthatyourecommendtheVenta
Airwasher to your family and friends. If you have any questions or concerns, please contact us
at [phone] or www.venta-airwasher.com.

5
UNPACKING YOUR AIRWASHER
1 Gently remove the Venta Airwasher from its shipping carton. Keep the packaging if you plan
to safely store your Venta Airwasher during the summer months, or in case of warranty repair.
2Lift the upper housing and remove the protective shipping cardboard from the gear.
3Note the serial # here: and on the Warranty card
included with this User Manual. The serial # is located at the inside of the upper housing
under the bar code.
4Lift the disk stack(s) from the lower housing and remove the protective shipping cardboard.
5Remove trial package containing 2 bottles of Venta Water Treatment Additive from Styrofoam
packaging (LW 15/25: 1 package, LW 45: 2 packages).
HOW DOES THE VENTA AIRWASHER IMPROVE
YOUR DRY INDOOR AIR?
Dry air is drawn in through the top of
the Venta Airwasher and passes over
a rotating disk stack(s). Dirt and dust
particles become heavy and sink to
the bottom of the lower housing. Only
humidiedpuriedairwillevaporate
through the two (2) vented sides of the
Venta Airwasher.
PATENT NO. 5,894,001
LW 15/25 LW 45

6
BEFORE FIRST USE
1 Placetheunituprightonarm,atsurface.Forproperaircirculationmakesurethevented
sidesareatleast18-20”clearofanywall.Donotblockairowinletsandoutlets.Unrestricted
airowwillresultinthebestefciencyandperformanceofyourVentaAirwasher.
2Inspect the switching power supply to insure it is free of damages.
3Make sure the upper housing is removed from the lower housing.
4Place disk stack(s) into lower housing.
5 Addfreshtapwater.Fillwatertothellline
located approximately one (1) inch below the
top on the inside of the lower housing. You can
transport the lower housing to your sink or tub
–oryoumayllthelowerhousingbycarrying
the water in a pitcher or watering can to the
lowerhousing.Becarefulwhenlling,cleaning,
or moving the Venta Airwasher to avoid water
spills.
Do not fill your Venta through the air
intake holes on top of the upper housing.
6LW 15/25: Add the entire contents of one
sample bottle of Water Treatment Additive.
LW 45: Add the entire contents of both sample
bottles of Water Treatment Additive.
7Place upper housing properly on top of lower housing.
8Plug switching power supply into standard 110-120 V AC outlet.
9 See“DailyUseandOperation”onpage7.
UPPER HOUSING
DISK STACK
LOWER HOUSING

7
OPERATOR PANEL
1ON / OFF button
2Operation indication ON / OFF
Continuous lighting: ON
No lighting: OFF
Flashing: Fault (see Eliminating faults)
3Fan stage display 1/2 (LW 15),
1/2/3 (LW 25/45)
4Automatic shut-off display
(see“Automaticshut-off”)
5Fan stage selector button
1/2 (LW 15), 1/2 /3 (LW 25/45)
DAILY USE AND OPERATION
• Switch on the appliance with button 1. The operation display 2lights up. The fan rotates on
its lowest setting.
• Select required fan stage 1/2 (LW 15), 1/2 /3 (LW 25/45) with selector button 5.
• To switch the appliance off press the button 1. The operation display 2stops lighting. Al-
though the motor is shut off, the fan blades may continue to rotate for a short period of time.
• The Venta Airwasher has a built in, automatic safety shut off switch that is indicated by
displaying 4. As soon as the upper housing is lifted off the lower housing the motor shuts off
even though the fan blades may continue to rotate for a short period of time.
1 2 3 4 5

8
MOTOR HOUSING ARMS
GEAR (SLIGHTLY DIFFERENT FOR LW
44 Plus)
COUPLING
LOCKING RING
FAN BLADE
MOTOR
HOUSING
3
4
6
4
3
5
7
1Switch the motor off and unplug the switch-
ing power supply.
2To open upper housing unit for easy access
to components, simultaneously press both
tabsnexttothespeedcontrols;“One-Click
Technology”unlockstheupperhousing.
3Lower the 2 short (solid) sides.
4Lower the 2 long (vented) sides.
5Remove main cable connector from drive unit.
6Using both hands, gently lift out
the motor housing.
7Remove main cable from holder and
pull out through opening in the upper
housing.
MAIN COMPONENTS OF THE VENTA AIRWASHER
– EASY ACCESS FOR CLEANING

9
MAINTENANCE AND CLEANING
DAILY
FILL with fresh tap water.
EVERY 10-14 DAYS
RINSE lower housing and disk stack(s)
with warm water. Wipe lower housing and fan blade
with soft cloth. RECHARGE with the
recommended dose of Venta Water Treatment Addi-
tive and fresh tap water.
TWICE A YEAR
CLEAN with ease. Use the Venta Cleaner periodi-
callyandthe“one-click”technologytothoroughlycleantheVentaAirwasher.Seepage11for
instructions.
Or if you prefer, Venta Airwasher offers a professional factory cleaning service.
Call us toll-free [phone] for details.
ANYTIME
Add 2-4 capfuls of our specially formulated fragrances to provide aromatherapy.
TRANSPORTATION
WARNING! Always switch off the motor and unplug the switching power supply from the A/C
outlet before moving the Venta Airwasher.
STORAGE
We recommend a thorough cleaning of your Venta Airwasher before storing the unit. Please make
sure that all components are clean and dry prior to storing. Do not leave water in the lower housing
when storing. Water left in the Venta Airwasher may leave mineral deposits and allow microorgan-
isms to grow. Repack your Venta Airwasher in its original packaging and store in a cool dry place.
Extremely low power consumption. Above square feet is based off eight foot ceilings.
TECHNICAL DATA LW 15 LW 25 LW 45
For rooms up to 200sq.ft. (10′×20′)400 sq.ft. (20′×20′)800 sq.ft.
Mains voltage 100-240V/50-60 Hz 100-240V/50-60Hz 100-240V/50-60Hz
Air throughput 70.6 cfm 123.6 cfm 158.9 cfm
Disk surface 15.3 sq.ft. 22.5 sq. ft. 45 sq. ft.
Speeds 233
Sound level 22 / 32 dBA 25 / 37/42 dBA 25 / 37/42 dBA
Dimensions 10.2×11×12.2 in 11.8 × 11.8 × 13 in 17.7×11.8×13 in
Weight (empty) approx. 7 lb. approx. 8.5 lb. approx. 13 lb.
Energy consumption
(Speed 1 - 2 - 3) approx. 3 - 4 watts approx. 3 - 5 - 8 watts approx. 3 - 5 - 8 watts
Water reservoir 1.4 gallons 2 gallons 3 gallons
Warranty 2 years 2 years 2 years
