OPERATOR’S MANUAL
& Parts Drawings
POWER BLOWER
LA162
Revised 02/09/10
09.10049

2
To the Owner
Contact Information and Product Identification
If you need to contact an authorized Ventrac dealer for information on servicing your product,
always provide the product model and serial numbers.
Please fill in the following information for future reference. See the picture(s) below to find the
location of the identification numbers. Record them in the spaces provided.
Date of Purchase: __________________________________________________________________
Dealer:___________________________________________________________________________
DealerAddress:____________________________________________________________________
____________________________________________________________________
Dealer Phone Number: ______________________________________________________________
Dealer Fax Number: ________________________________________________________________
Model # (A):__________________________
Serial # (B): __________________________
Affix Part/Serial Number label here.
Venture Products Inc. reserves the right to make changes
in design or specifications without obligation to make like
changes on previously manufactured products.
A
B
328 East Water St.
PO Box 148
Orrville Oh 44667
www.ventrac.com

TABLE OF CONTENTS
3
INTRODUCTION PAGE 4
Product Description................................................................................................................................4
Why Do I Need an Operator’s Manual?.................................................................................................4
Using Your Manual.................................................................................................................................5
Manual Glossary....................................................................................................................................5
SAFETY PAGE 6
Safety Decals.........................................................................................................................................6
General Safety Procedures....................................................................................................................7
Training Required...................................................................................................................................7
Personal Protective Equipment Requirements ......................................................................................7
Operating Safely ....................................................................................................................................7
Preventing Accidents..............................................................................................................................8
Keep Riders Off......................................................................................................................................8
Operating On Slopes..............................................................................................................................9
Roadway Safety.....................................................................................................................................9
Truck Or Trailer Transport......................................................................................................................9
Maintenance.........................................................................................................................................10
Fuel Safety...........................................................................................................................................10
Hydraulic Safety...................................................................................................................................11
LA162 Safety Procedures....................................................................................................................12
OPERATIONAL CONTROLS PAGE 13
Hydraulic Rotational Control ................................................................................................................13
Blower Deflector...................................................................................................................................13
Weight Transfer....................................................................................................................................13
GENERAL OPERATION PAGE 14
Daily Inspection....................................................................................................................................14
Attaching..............................................................................................................................................14
Detaching.............................................................................................................................................14
Hydraulic Rotation................................................................................................................................14
Blower Operation .................................................................................................................................14
SERVICE PAGE 15
Cleaning & General Maintenance........................................................................................................15
Lubrication............................................................................................................................................15
Drive Belt Replacement .......................................................................................................................15
Rotational Control Belt Replacement...................................................................................................16
SPECIFICATIONS PAGE 17
Dimensions ..........................................................................................................................................17
Features...............................................................................................................................................17
PARTS PAGE 18
Main Frame..........................................................................................................................................18
Fan Housing.........................................................................................................................................20
Hydraulic Rotational Control ................................................................................................................22
WARRANTY PAGE 24

Introduction - 4
Congratulations on your purchase of a Ventrac LA162 Power Blower!
We are pleased to have you as a customer and hope that your purchase of a Ventrac will bring you many
years of satisfaction as you learn how the Ventrac can meet your day to day needs.
Product Description
The LA162 Power Blower features a vertical shaft design that delivers powerful, yet quiet, performance.
The power blower can be used to remove leaves, debris, light snow, water, etc.
The blower housing can be rotated 180 degrees using the power unit’s auxiliary hydraulic control. This
allows the operator to move debris in the desired direction without hindering operation. Maximum perfor-
mance is produced throughout the 180 degree arc. Wind speed can be reduced by lowering the power unit
engine RPM.
Two gauge wheels on the power blower maintain a consistent distance from the surface being cleared.
An adjustable deflector shield allows the operator to further control the blower discharge.
Why Do I Need an Operator’s Manual?
This manual has been created in sections to help you gain the important knowledge of what is needed to
safely operate, maintain, and service this machine.
You must read and understand the operator’s manual for each piece of Ventrac equipment you own. Read-
ing the operator’s manual will help you become familiar with each specific piece of equipment. Under-
standing the operator’s manual will help you, as well as others, avoid personal injury and/or damage to the
equipment. Keep this manual with the machine at all times. The manual should remain with the machine
even if it is sold. If this manual becomes damaged or unreadable, it should be replaced immediately. Con-
tact your local Ventrac dealer for a replacement.
When using a Ventrac attachment, be sure to read and follow the safety and operating instructions of both
the power unit and the attachment being used to ensure the safest operation possible.
The information in this manual provides the operator with the safest procedures to operate the machine
while getting the maximum use out of the unit. Failure to follow the safety precautions listed in this manual
may result in personal injury and/or damage to the equipment.
INTRODUCTION

INTRODUCTION
Introduction - 5
Using Your Manual
Throughout this manual, you will encounter special messages and symbols that identify potential safety
concerns to help you as well as others avoid personal injury or damage to the equipment.
ATTENTION
This symbol identifies potential health and
safety hazards. It marks safety precautions.
Your safety and the safety of others is involved.
SYMBOL DEFINITIONS
There are three signal words that describe the level of safety concern: Danger, Warning, and Caution.
Safety should always be the #1 priority when working on or operating equipment. Accidents are more likely
to occur when proper operating procedures are not followed or inexperienced operators are involved.
Note: Right-Hand and Left-Hand orientations may be referred to at different places throughout this manual.
Right-Hand and Left-Hand is determined as if sitting on the power unit seat facing forward.
SIGNAL WORD DEFINITIONS
Indicates a potentially hazardous situation
which, if not avoided, could result in death or
serious injury.
Indicates an imminently hazardous situation
which, if not avoided, will result in death or
serious injury. This signal word is limited to the
most extreme cases.
Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderate injury and/or property damage. It may
also be used to alert against unsafe practices.
Manual Glossary
Power Unit A Ventrac tractor or other Ventrac engine powered device that may be operated by itself or
with an attachment or accessory.
Attachment A piece of Ventrac equipment that requires a Power Unit for operation.
Accessory A device that attaches to a Power Unit or Attachment to extend its capabilities.
Machine Describes any “Attachment” or “Accessory” that is used in conjunction with a power unit.

Safety - 6
Decal Description Part Number Quantity
A Warning - Moving Part Hazard 00.0101 1
B Danger - Keep Hands and Feet Away 00.0123 2
C Read Owner’s Manual 00.0217 1
SAFETY
B
B
B
B
A
A
B
B
C
C
C
C
A
A
Safety Decals
The following safety decals must be maintained on your LA162 power blower.
Keep all safety decals legible. Remove all grease, dirt, and debris from safety decals and instructional
labels. If any decals are faded, illegible, or missing, contact your dealer promptly for replacements.
When new components are installed, be sure that current safety decals are affixed to the replacement
components.

Safety - 7
SAFETY
General Safety Procedures
for Ventrac Power Units, Attachments, & Accessories
Training Required
The owner of this machine is solely responsible for properly training the operators.
The owner/operator is solely responsible for the operation of this
machine and prevention of accidents or injuries occurring to him/her-
self, other people, or property.
Do not allow operation or service by children or untrained personnel.
Local regulations may restrict the age of the operator.
Before operating this machine, read the operator’s manual and under-
stand its contents.
If the operator of the machine cannot understand this manual, then it
is the responsibility of this machine’s owner to fully explain the material
within this manual to the operator.
Learn and understand the use of all controls.
Know how to stop the power unit and all attachments quickly in the event of an emergency.
Personal Protective Equipment Requirements
It is the responsibility of the owner to be sure that the operators use the proper personal protective equip-
ment while operating the machine. Required personal protective equipment includes, but is not limited to,
the following list.
Wear a certified ear protection device to prevent loss of hearing.
Prevent eye injury by wearing safety glasses while operating the machine.
Closed toe shoes must be worn at all times.
Long pants must be worn at all times.
When operating in dusty conditions, it is recommended that a dust mask be worn.
Operating Safely
Inspect machine before operation. Repair or replace any damaged, worn, or missing parts. Be sure
guards and shields are in proper working condition and are secured in place. Make all necessary
adjustments before operating machine.
Alterations or modifications to this machine can reduce safety and could cause damage to the machine.
Do not alter safety devices or operate with shields or covers removed.
Before each use, verify that all controls function properly and inspect all safety devices. Do not operate
if controls or safety devices are not in proper working condition.
Check parking brake function before operating. Repair or adjust parking brake if necessary.
Observe and follow all safety decals.
All controls are to be operated from the operator’s seat only.
Always wear a seat belt if the machine has a roll cage/bar installed.
Ensure the attachment or accessory is locked or fastened securely to the power unit before operating.
Ensure that all bystanders are clear of the power unit and attachment before operating. Stop machine if
someone enters your work area.
Always be alert to what is happening around you, but do not lose focus on the task you are performing.
Always look in the direction the machine is moving.
Look behind and down before backing up to be sure of a clear path.
If you hit an object, stop and inspect the machine. Make all necessary repairs before operating machine again.
Stop operation immediately at any sign of equipment failure.An unusual noise can be a warning of equipment
failure or a sign that maintenance is required. Make all necessary repairs before operating machine again.
If equipped with a high/low range feature, never shift between high and low range while on a slope.
Always move the machine to level ground and place the selector lever in park before shifting range.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•

SAFETY
Safety - 8
SAFETY
Do not leave machine unattended while it is running.
Always park the machine on level ground.
Always shut off engine when connecting attachment drive belt to the power unit.
Never leave the operator’s seat without lowering the attachment to the ground, setting the parking
brake, shutting off the engine, and removing the ignition key. Make sure all moving parts have come to
a complete stop before dismounting.
Never leave equipment unattended without lowering the attachment to the ground, setting the parking
brake, shutting off the engine, and removing the ignition key.
Only operate in well-lit conditions.
Never direct the discharge of any attachment in the direction of people, buildings, animals, vehicles, or
other objects of value.
Never discharge material against a wall or obstruction. Material may ricochet back towards the operator.
Use extra caution when approaching blind corners, shrubs, trees, or other objects that may obscure vision.
Do not run the engine in a building without adequate ventilation.
Do not touch the engine or the muffler while the engine is running or immediately after stopping the engine.
These areas may be hot enough to cause a burn.
Do not change the engine governor settings or over-speed the engine. Operating engine at excessive speed
may increase the hazard of personal injury.
To reduce the hazard of fire, keep the battery compartment, engine, and muffler areas free of grass, leaves,
and excessive grease.
Preventing Accidents
Clear working area of objects that might be hit or thrown from machine.
Keep people and pets out of mowing area.
Know the work area well before operation. Do not operate where traction or
stability is questionable.
Reduce speed when you are operating over rough ground.
Equipment can cause serious injury and/or death when improperly used.
Before operating, know and understand the operation and safety of the power
unit and the attachment being used.
Do not operate machine if you are not in good physical and
mental health, if you will be distracted by personal devices, or
are under the influence of any substance which might impair
decision, dexterity, or judgment.
Children are attracted to machine activity. Be aware of children
and do not allow them in the working area. Turn off the machine
if a child enters the work area.
Keep Riders Off
Only allow the operator on the power unit. Keep riders off.
Never allow riders on any attachment or accessory.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Operating Safely (continued)Operating Safely (continued)
General Safety Procedures
for Ventrac Power Units, Attachments, & Accessories

SAFETY
Safety - 9
Operating On Slopes
Slopes can cause loss-of-control and
tip-over accidents, which can result in
severe injury or death. Be familiar with the
emergency parking brake, along with the
power unit controls and their functions.
If power unit is equipped with a fold down
roll bar, it must be locked in the upright
position when operating on any slope.
Use low range when operating on slopes
greater than 15 degrees.
Do not stop or start suddenly when operating on slopes.
Never shift between high and low range while on a slope. Always move the power unit to level ground
and place the selector lever in park before shifting range.
Variables such as wet surface and loose ground will reduce the degree of safety. Do not drive where
machine could lose traction or tip over.
Keep alert for hidden hazards in the terrain.
Stay away from drop-offs, ditches, and embankments.
Sharp turns should be avoided when operating on slopes.
Pulling loads on hills decreases safety. It is the responsibility of the owner/operator to determine loads
that can safely be controlled on slopes.
Transport machine with attachment lowered or close to the ground to improve stability.
While operating on slopes, drive in an up and down direction when possible. If turning is necessary
while driving across slopes, reduce speed and turn slowly in the downhill direction.
Assure a sufficient supply of fuel for continuous operation.Aminimum of one-half tank of fuel is recommended.
Roadway Safety
Operate with safety lights when operating on or near roadways.
Obey all state and local laws concerning operation on roadways.
Slow down and be careful of traffic when operating near or crossing roadways. Stop before crossing
roads or sidewalks. Use care when approaching areas or objects that may obscure vision.
If there is doubt of safety conditions, discontinue machine operation until a time when
operation can be performed safely.
When operating near or on roadways, have a Slow Moving Vehicle Emblem clearly
displayed.
Truck Or Trailer Transport
Use care when loading or unloading machine into a truck or trailer.
The parking brake is not sufficient to lock the machine during transport. Always secure the power unit
and/or attachment to the transporting vehicle.
Shut off fuel supply to power unit during transport on truck or trailer.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
General Safety Procedures
for Ventrac Power Units, Attachments, & Accessories

SAFETY
Safety - 10
Maintenance
Keep all safety decals legible. Remove all grease dirt, and debris from safety decals and instructional labels.
If any decals are faded, illegible, or missing, contact your dealer promptly for replacements.
When new components are installed, be sure that current safety decals are affixed to the replacement
components.
If any component requires replacement, use only original Ventrac replacement parts.
Always disconnect the negative battery cable from the battery when working with electrical components.
Keep all bolts, nuts, screws, and other fasteners properly tightened.
Always lower the attachment to the ground, engage parking brake, shut off engine, and remove the
ignition key. Make sure all moving parts have come to a complete stop before cleaning, inspection,
adjusting or repairing.
If the power unit, attachment, or accessory requires repairs or adjustments not instructed in the opera-
tor’s manual, the power unit, attachment, or accessory must be taken to an authorized Ventrac dealer
for service.
Never perform maintenance on the power unit and/or attachment if someone is sitting in the operator’s seat.
Always use protective glasses when handling the battery.
Check all fuel lines for tightness and wear on a regular basis. Tighten or repair them as needed.
To reduce the hazard of fire, keep the battery compartment, engine, and muffler areas free of grass,
leaves, and excessive grease.
Do not touch the engine or the muffler while the engine is running or immediately after stopping the
engine. These areas may be hot enough to cause a burn.
Do not change the engine governor settings or over-speed the engine. Operating engine at excessive
speed may increase the hazard of personal injury.
Springs may contain stored energy. Use caution when disengaging or removing springs.
An obstruction or blockage in a drive system or moving/rotating parts may cause a buildup of stored
energy. When the obstruction or blockage is removed, the drive system or moving/rotating parts may
move suddenly. Do not attempt to remove an obstruction or blockage with your hands. Keep hands,
feet, and clothing away from all power-driven parts.
Dispose of all fluids in accordance with local laws.
Fuel Safety Do not refuel machine while smoking or at a location near flames or sparks.
Always refuel the machine outdoors.
Do not store machine or fuel container indoors where fumes or fuel can reach an open
flame, spark, or pilot light.
Only store fuel in an approved container. Keep out of reach of children.
Never remove gas cap or add fuel with the engine running. Allow engine to cool before refueling.
Replace all fuel tank and container caps securely.
Do not overfill fuel tank. Maximum level is 1” below the neck of the fuel tank.
If fuel is spilled, do not attempt to start the engine. Move the power unit away from the fuel spill and
avoid creating any source of ignition until fuel vapors have dissipated.
If the fuel tank must be drained, it should be drained outdoors into an approved container.
Dispose of all fluids in accordance with local laws.
Check all fuel lines for tightness and wear on a regular basis. Tighten or repair them as needed.
The fuel system is equipped with a shut-off valve. Shut off the fuel when transporting the machine to
and from the job, when parking the machine indoors, or when servicing the fuel system.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
General Safety Procedures
for Ventrac Power Units, Attachments, & Accessories

SAFETY
Safety - 11
Hydraulic Safety
Make sure all hydraulic connections are tight and all hydraulic hoses and tubes are in good condition.
Repair any leaks and replace any damaged or deteriorated hoses or tubes before starting the machine.
Hydraulic leaks can occur under high pressure. Hydraulic leaks require special care and attention.
Use a piece of cardboard and a magnifying glass to locate sus-
pected hydraulic leaks.
Keep body and hands away from pinhole leaks
or nozzles that eject high pressure hydraulic
fluid. Hydraulic fluid escaping under high pres-
sure can penetrate the skin causing serious
injury. If hydraulic fluid is injected into skin, seek
immediate medical attention.
Hydraulic system may contain stored energy. Before performing maintenance or repairs on the hydraulic
system, remove attachments, engage parking brake, disengage weight transfer system (if equipped), shut
off engine, and remove ignition key. To relieve pressure on the auxiliary hydraulic system, shut off the power
unit engine and move the secondary S.D.L.A. lever left and right before disconnecting the auxiliary hydraulic
quick couplers.
Dispose of all fluids in accordance with local laws.
•
•
•
•
•
•
General Safety Procedures
for Ventrac Power Units, Attachments, & Accessories

SAFETY
Safety - 12
Remove any loose objects from the work area. The power blower produces strong wind speeds and could
blow loose objects at high velocity, causing damage or injury to other objects, buildings, vehicles, people,
or animals.
Never direct the blower discharge in the direction of people, buildings, animals, vehicles, or other
objects of value.
Do not attempt to clear leaves or other debris from the intake shield or the blower discharge while the
machine is running. Always lower the attachment to the ground, engage parking brake, shut off engine,
and remove the ignition key. Make sure all moving parts have come to a complete stop attempting to
clear a blockage.
•
•
•
LA162 Safety Procedures

Operation - 13
Hydraulic Rotational Control
The LA162 power blower is equipped with hydraulic
rotational control of the blower discharge. The
discharge direction is controlled using the auxiliary
control lever* of the power unit.
Blower Deflector
The blower discharge can be further controlled with
the blower deflector. The blower deflector can be set
to deflect the discharge slightly downward to contact
the ground closer to the power blower. The blower
deflector can also be set to direct the airflow down
at a steeper angle to remove leaves and debris from
ditches. To set the blower deflector angle, loosen the
knob on the side of the deflector. Move the deflector
to the desired angle and tighten the knob.
Knob
Blower
Deflector
Weight Transfer
If using an LE3100 or LE3200 equipped with
adjustable weight transfer, it is advisable to set
the weight transfer* to setting 2 or 3 to prevent the
gauge wheels from gouging soft ground.
1
1
2
2
3
3
4
4
OPERATIONAL CONTROLS
* Refer to power unit owner’s manual for operation of power unit controls.

Operation - 14
Daily Inspection
Always set the parking brake, shut off power
unit engine, remove the ignition key, and ensure
all moving parts have come to a complete stop
before inspecting components, or attempting
any repair or adjustment.
Park machine on a level surface, with the engine
shut off and all fluids cold.
Perform a visual inspection of both the power unit
and the power blower. Look for loose or missing
hardware, damaged components, or signs of wear.
Inspect hydraulic hoses, hydraulic fittings, and fuel
lines to ensure tight, leak free connections. Inspect
drive belts. Belts should be in good condition.
Refer to the power unit operator’s manual.
Check the power unit’s engine oil, hydraulic oil,
cooling system, tire pressure, and fuel level. Add
fluid or service as required.
Refer to the power unit operator’s manual. Test
the power unit’s operator safety interlock system*.
Attaching
Drive the power unit slowly forward into the hitch
arms of the power blower. Align the lift arms of
the power unit with the power blower hitch arms
by raising or lowering the front hitch and com-
plete the engagement.
Once completely engaged, close the front hitch
locking lever.*
Engage the parking brake* and shut off the engine.
Place the attachment belt onto the PTO drive
pulley on the power unit. Ensure the belt is prop-
erly seated in each pulley.
Engage the PTO tension spring.
PTO Tension
Spring
Wipe hose ends clean, and connect to the power
unit’s hydraulic quick couplers. If equipped, con-
nect the hoses and quick couplers so the red
indicators are paired together and the yellow
indicators are paired together.
1.
2.
3.
4.
1.
2.
3.
4.
5.
6.
Detaching
Park the power unit on a level surface and set
the parking brake.*
Lower the power blower to the ground.
Shut off power unit engine.
Disengage the PTO tension spring.
Remove the attachment belt from the PTO drive
pulley of the power unit.
A
A
Disconnect the hydraulic quick cou-
plers from the
power unit and store
the hose ends in the top frame
holes (A) on the power blower.
Restart power unit and slowly back
away from the power blower.
Hydraulic Rotation
To rotate the direction of the blower, move the auxil-
iary hydraulic lever to the left or right on the LE3100
and LE3200 or forward or backward on the LT3000.
Release the lever when the desired direction has
been achieved. If the rotation action seems back-
wards, reverse the quick coupler connections.
Blower Operation
Lower the power blower to the ground and place the
S.D.L.A. (lift) lever into the float position*.
Always use float if the gauge wheels contact the
ground surface. The power blower gauge wheels
are not designed to carry power unit weight.
The power blower can also be operated while lifted
off the ground.
Set the power blower discharge of the power blower
to the desired direction.
With the power unit engine running between 2,000
and 2,500 RPM, engage the PTO switch.
Increase the power unit engine speed until there is
sufficient force to accomplish the blowing task. Full
engine speed will produce approximately 160 MPH
wind at the blower outlet.
The power blower produces strong wind speeds
that can cause damage and/or unintentionally
displace things. Never direct the blower discharge
in the direction of people, buildings, animals,
vehicles, or other objects of value.
1.
2.
3.
4.
5.
6.
7.
GENERAL OPERATION
* Refer to power unit owner’s manual for operation of power unit controls.

SERVICE
Service - 15
Cleaning & General Maintenance
For best results, and to maintain the finish of the
LA162, clean or wash the power blower after each
use to remove leaves, dirt, and other debris.
Lubrication
Grease the upper and lower fan shaft bearings after
every 50 hours of operation or once per season.
Usually 1-2 pumps of grease is sufficient. If the
lower fan shaft bearing is subjected to water or other
harsh environments, it should be greased promptly
and/or more frequently.
Remove the gauge wheels and grease the axle
shafts as needed.
Drive Belt Replacement
Detach the power blower from the power unit.
Remove the V-idler pulley.
V-idler Pulley
Replace the drive belt.
Reinstall the V-idler pulley.
1.
2.
3.
4.
SERVICE
Always set the parking brake, shut off power
unit engine, remove the ignition key, and ensure
all moving parts have come to a complete stop
before inspecting components or attempting any
repair or adjustment.
Attention
If any component requires replacement, use only
original Ventrac replacement parts.

SERVICE
Service - 16
Rotational Control Belt Replacement
Detach the power blower from the power unit.
Release the belt tension spring.
Belt Tension
Spring
Remove the drive belt from the fan drive pulley.
Replace the rotational control belt.
Apply the belt tension spring.
Reinstall the drive belt onto the fan drive pulley.
1.
2.
3.
4.
5.
6.

Specifications - 17
Dimensions
Overall Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 inches (56 cm)
Overall Length. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46 inches (117 cm)
Overall Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 inches (71 cm)
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137 pounds (62 kg)
Fan Diameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 inches (35.5 cm)
Fan Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 inches (10 cm)
Discharge Opening . . . . . . . . . . . . . . . . . . . . . . 4-1/2 x 7-1/2 inches (11.5 x 19 cm)
Features
Blower Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Vertical Shaft
Blower Rotation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180 degrees
Blower Rotational Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Hydraulic Motor
Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Blade, Welded
Gauge Wheels. . . . . . . . . . . . . . . . . . 3 inches (7.5 cm) OD x 3-1/2 inches (9 cm) long
Wind Speed . . . . . . . . . . . . . . . . . . . . . . 160 MPH (257 km/h) at discharge opening
SPECIFICATIONS

Illustrated Parts - 18 Use only original Ventrac
replacement parts.
PARTS
ILLUSTRATED DRAWING
Main Frame

PARTS
Illustrated Parts - 19 Use only original Ventrac
replacement parts.
Main Frame
REF. PART NO. DESCRIPTION QTY.
1 . . . . . . . . . 11.0040 . . . . . . . . . . . . . . . . . . . .U-BOLT, 1/4-20 1-1/8” ID (Serial # 2001-2058). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1 . . . . . . . . . 11.0064 . . . . . . . . . . . . . . . . . . . .U-BOLT, 3/8-16 PIPE SIZE 3/4” (Serial # 2059-) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2 . . . . . . . . . 99.SF04. . . . . . . . . . . . . . . . . . . .NUT, SRF 1/4-20 USS (Serial # 2001-2058) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 . . . . . . . . . 99.SF06. . . . . . . . . . . . . . . . . . . .NUT, SRF 3/8-16 USS (Serial # 2059-) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3 . . . . . . . . . 90.0512. . . . . . . . . . . . . . . . . . . .BOLT, 5/16-18 USS X 1 1/2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
4 . . . . . . . . . 99.SF05. . . . . . . . . . . . . . . . . . . .NUT, SF 5/16-18 USS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
5 . . . . . . . . . 00.0100. . . . . . . . . . . . . . . . . . . .DECAL, MADE IN USA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
6 . . . . . . . . . 95.10. . . . . . . . . . . . . . . . . . . . . .WASHER, FLAT 5/8 SAE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
7 . . . . . . . . . 50.0047. . . . . . . . . . . . . . . . . . . .ROLLER, FRONT 3” DIA X 3 1/2”. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
8 . . . . . . . . . 40.0301. . . . . . . . . . . . . . . . . . . .SHAFT, ROLLER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
9 . . . . . . . . . 99.SF0404. . . . . . . . . . . . . . . . . .BOLT, SF 1/4-20 X 1/2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
10 . . . . . . . . 64.0877. . . . . . . . . . . . . . . . . . . .ANCHOR SHAFT, BELT TIGHTNER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
11. . . . . . . . . 41.0065. . . . . . . . . . . . . . . . . . . .SPRING, DOUBLE TORSION BLACK. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
12 . . . . . . . . 95.08. . . . . . . . . . . . . . . . . . . . . .WASHER, FLAT 1/2 SAE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
13 . . . . . . . . 85.B0027. . . . . . . . . . . . . . . . . . .BUSHING, 1/2 ID X 5/8 OD X 5/8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
14 . . . . . . . . 62.0872. . . . . . . . . . . . . . . . . . . .FRAME, MAIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
15 . . . . . . . . 99.SF06. . . . . . . . . . . . . . . . . . . .NUT, SF 3/8-16 USS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
16 . . . . . . . . 40.0284. . . . . . . . . . . . . . . . . . . .IDLERARM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
17 . . . . . . . . 95.06. . . . . . . . . . . . . . . . . . . . . .WASHER, FLAT 3/8 SAE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
18 . . . . . . . . 83.0037. . . . . . . . . . . . . . . . . . . .PULLEY, IDLER FLAT 4” X 3/8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
19 . . . . . . . . 90.0614. . . . . . . . . . . . . . . . . . . .BOLT, 3/8-16 USS X 1 3/4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
20 . . . . . . . . 83.0031. . . . . . . . . . . . . . . . . . . .PULLEY, V-IDLER 5 1/4 X 3/8 ID. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
21 . . . . . . . . 00.0101. . . . . . . . . . . . . . . . . . . .DECAL, HAZARD-MOVING PART. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
22 . . . . . . . . 60.0775. . . . . . . . . . . . . . . . . . . .COVER, BELT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
23 . . . . . . . . 00.0217. . . . . . . . . . . . . . . . . . . .DECAL, WARNING READ OWNERS MAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
24 . . . . . . . . 99.SF0406. . . . . . . . . . . . . . . . . .BOLT, SF 1/4-20 X 3/4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
25 . . . . . . . . 94.08. . . . . . . . . . . . . . . . . . . . . .WASHER, FLAT 1/2 USS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
26 . . . . . . . . 03.0011 . . . . . . . . . . . . . . . . . . . .PIN, BALL 3/8 X 2-1/2 (Serial # 2059-) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
27 . . . . . . . . 99.SF04. . . . . . . . . . . . . . . . . . . .NUT, SRF 1/4-20 USS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

PARTS
Illustrated Parts - 20 Use only original Ventrac
replacement parts.
ILLUSTRATED DRAWING
Fan Housing
