Veo Velocity Connect User manual

Page 1 of 44

Page 2 of 44
Table of Contents
Welcome to the Veo™ Web Cameras …………………………………………………………… 3 - 4
A Quick Look at the Veo Web Cameras ...………………………………....……………………. 5 - 6
Minimum System Requirements …………………………..…………………………………………. 7
Software and Installation ………………………………………………………………..………… 7 - 8
How to connect your Veo Web Camera to your computer ………...……….………...…….. 8 - 9
How to connect the microphone to your computer ………………………….…………………… 9
The Veo Creative Studio Application ………………………………………………..…………….. 10
Taking a Snapshot ………………………………………………………….………...…………. 10 - 11
Recording a Video ……………………………………………………………………………….. 12 - 13
Recording an Audio Clip ……………………………………………………….…………………….. 13
Importing Pictures from another Source ………………………………………...……………….. 14
Importing Files to a Folder in the Veo Creative Studio …………………………………………. 14
Viewing Pictures in the Gallery …………………………………………………………..…………. 14
E-Card Creator – Creating an E-Card ………………………………………………………… 15 - 16
Movie Maker – Making or Editing a Movie …………………………………………………… 17 - 19
Homepage Designer – Designing a Home Page …………………………….……………… 19 - 23
Applying Text, Images, Videos, and Animated Characters ……………………….……… 23 - 25
Game Generator – Create Fun Games with Your Photos ………………………………… 26 - 29
Configuring Your E-mail Program to Send Files …………………………………………… 29 - 31
Video Meeting ……………………………………………………………………………..……… 32 - 40
Troubleshooting ………………………………………………………………………………..… 39 - 42
Additional Help and Resources …………………………………………………………………….. 42
Veo Statement of Limited Warranty ………………………………………………………...… 42 - 44

Page 3 of 44
Welcome to the Veo™ Web Cameras
Veo is a brand of exceptionally user-friendly digital imaging products that enable people around
the world to instantly communicate.
The Veo web cameras will easily allow you to share photos, create home movies, build
personalized puzzle games, craft unique greeting cards and much more...all with intuitive, easy to
use software. Once you have created your custom project, share it with the world by placing it on
the Internet on your own web site, email it to a friend in a universal PC format, export it to create
a CD-ROM or simply print it for off screen viewing. Veo web cameras can even help you keep in
close contact with friends and family around the world through video instant messaging. No
matter how you use your camera, you are about to communicate in a whole new way...welcome
to Veo!
The Velocity Connect package includes:
The Mobile Connect package includes:
•
Velocity Connect camera
•Spider Clip Base
•Easy Tilt Desktop Base
•User’s Guide
•Velocity Connect CD-ROM
•Quick snap lens cover
•Omni-directional microphone
•
Veo Mobile Connect Web Camera
•18” USB Cable
•Brushed Aluminum Travel Case
•User’s Guide
•
Veo Mobile Connect CD-ROM

Page 4 of 44
The Advanced Connect package includes:
The Connect package includes:
The Stingray package includes:
•
Veo Advanced Connect Web Camera
•Veo Spider Clip
•User’s Guide
•Veo Advanced Connect CD-ROM
•
Veo Connect Web Camera
•User’s Guide
•Veo Connect CD-ROM
•
Veo Stingray Web Camera
•User’s Guide
•Veo Stingray CD-ROM

Page 5 of 44
Power light
A Quick Look at the Veo Web Cameras
Velocity Connect
Mobile Connect
Veo Blue On/Off LED
Easy-touch
Snapshot Button
Refined Focus Dial
Lightning Fast Connection
USB 2.0 allows for
faster frame rates
Interchangeable
Spider Clip
Attach the camera to LCD
monitors, cubicle walls or
anything 1-3 inches thick.
Focus Ring
(Rotate to focus)
Built-in microphone

Page 6 of 44
Advanced Connect
Connect
Stingray

Page 7 of 44
Minimum System Requirements
Hardware
•300 MHz Intel®Pentium®, AMD®or better
(For Velocity Connect only) 750 MHz Intel®Pentium®III, AMD®Athlon™or better
•32 MB RAM or better
(For Velocity Connect only) 256 MB RAM or better
•200 MB of available hard disk space
(For Velocity Connect only) 300 MB available hard disk space
•One available USB port
(For Velocity Connect only) Available USB 2.0 Port. (Backward compatible with USB 1.1
with functionality and performance compromises.)
•SVGA 800 x 600 Resolution Monitor
•16-bit color
(For Velocity Connect only) 24-bit color, DirectX Compatible 16 MB Video Card
•12x speed CD-ROM drive or better
•(For Connect, Stingray, and Velocity Connect only) Standard microphone for sending video
mail and videoconferencing messages
Software
•(For Advanced Connect, Connect Mobile Connect, and Stingray) Microsoft®Windows®
98SE, Me, 2000 or XP
•(For Velocity Connect) Microsoft®Windows®2000 or XP
•Internet browser application, i.e. Microsoft Internet Explorer, AOL
•E-mail program, i.e. Microsoft Outlook Express, Yahoo! Mail, AOL
Note: To find the version number of your Windows operating system, select Settings from the
Windows Start menu. Open Control Panel, and double-click on the System icon. The System
Properties dialog box indicates the version number.
Software and Installation
Install the software and restart your computer before connecting your Veo web camera!
If you have already plugged the camera into the computer, please unplug it before installing the
software.
1. Insert the CD-ROM into your CD-ROM drive.
2. Autorun will display the installation screen corresponding to your camera model. De-select any
additional software you do not wish to install. Click Install.*

Page 8 of 44
3. Follow the instructions to finish the driver installation.** Restart your computer for the new
hardware and settings to take effect.
4. After your computer restarts, you may plug your camera into the USB port.
*Note: If Autorun does not start, choose Run from the Windows Start Menu. Assuming your CD-
ROM drive is the D drive, type “d:\Autorun” in the Run dialog box. If Autorun still does not start,
consult your computer manual or manufacturer to locate the CD-ROM drive.
**Note: On Windows 2000, Windows Media Player will be installed after the bundled software is
installed. Make sure if you are running Windows 2000, you wait for the Windows Media Player
installation to finish.
Note: Veo Creative Studio must have DirectX installed to operate properly (pre-installed in
Windows XP). You will be prompted to install DirectX upon initial use of the Creative Studio
software. Please install and restart your computer to complete the installation.
How to connect your Veo Web Camera to your computer
If you have the Mobile Connect, connect the USB cable to the camera first.

Page 9 of 44
To mount the camera:
Rotate Clip Pull Clip Clip to Laptop Screen
Plug the USB connector into any available USB port (USB 2.0 port if you have the Velocity
Connect) on your computer. A window should appear and recognize a new device being installed.
Note: If your computer does not recognize the new device, please refer to “Troubleshooting” on
pages 39-42 of this User’s Guide.
How to connect the microphone to your computer
Locate the microphone jack on the back of your computer. On newer computers/sound cards, the
microphone jack will be pink or have a microphone symbol next to the microphone jack. Plug the
included microphone into the microphone jack and make sure it fits snugly.
USB connector USB ports

Page 10 of 44
The Veo Creative Studio Application
The Veo Creative Studio is an easy-to-use application that comes with your Veo Web Camera. It
enables you to take snapshots, record videos, audio clips, and manage your Veo Web Camera
files. It also provides useful tools for your pictures and videos by allowing you to make movies,
create E-cards, design homepages, create games, and hold video meetings.
To start Veo Creative Studio, double-click on the icon on your desktop or click on Start >
(All) Programs > Veo > Creative Studio - Connect.
Taking a Snapshot
1. Click the Take A Snapshot button to launch your Veo Web Camera.
2. Use the Small, Medium, Large, and Extra Large buttons to select the desired resolution, then
click [Take a Snapshot].
3. Click:
a) [Retake Snapshot] - To take another snapshot.
b) - To save your picture. Select the destination folder and rename the picture if desired.
If left unchanged, the picture will be saved in the default directory C:\Program Files\Veo
Creative Studio for Connect\Gallery\Photographs.
Note: Depending on your settings, snapshots are captured in either the JPEG or BMP file format.
c) - To send your picture to another person, type in the required information. The default
name given to the snapshot is MyPictureXXX.jpg. Note: XXX determines the picture counter.
To rename the snapshot before sending, click on the words “MyPicture XXX.jpg” in the
attachment text box and click [Rename]. Click to send your snapshot.
Note: If you are experiencing difficulties emailing your pictures, please refer to “Configuring Your
Email Program to Send Files” on pages 29-31.
Creative Studio
Home screen
Click to
return to
Home
screen

Page 11 of 44
Snapshot Settings
To change the settings of your snapshots, click [Settings].
Note: In order for the settings to take effect, you must apply the new settings before taking a
snapshot.
Advanced Settings (Depending on your camera model, some options may not be available)
A
djust Exposure
Control for added
customizing.
Check box to flip
images horizontally
(mirror image).
A
djust the white
balance to fine
tune the camera
to your lighting
conditions.
Select the lighting
type used in your
environment.
When Snapshot Timer
is enabled, you may
select the amount of
time to delay your
snapshots.
Restore all settings to default
for best overall image quality.
Choose un-compressed
BMP or compressed
JPG file formats to
capture pictures in.

Page 12 of 44
Recording a Video
1. Click the Record A Video button
2. Choose:
Standard Video - To record and save the video clip to your computer in .avi file format
for use in the Movie Maker application or one of the other Creative Studio applications.
Video Mail (Compressed Video for E-mail purposes) - To record and send a video clip
via email the file is recorded in Microsoft’s universal .wmv file format.
Note: Windows Media Player 7.1 or higher is required to play back .wmv files.
3. Use the Small, Medium, and Large buttons to select the desired resolution.
4. Adjust the volume using the Microphone Volume Adjustment Bar.
5. Click [Record] to record your video. The button turns into [Stop]. Click the Stop
button at any time to finish recording.
6. After the recording stops, the following buttons will appear on the bottom of the screen:
[Remove Audio] - Remove sound from the video.
[Save Frame] - Save the current frame as a picture file.
[Trim Video] - Trim the video to the selected size and length.
[Play] - Play the video.
[Rerecord Video] - Rerecord the video if you are not satisfied with the one you just recorded.
Note: Since Video Mail is compressed you may not remove the audio, save frames or trim the
video.
7. If recording a Standard Video, click to save your video as an .avi.
8. If recording a Video Mail, click to email your video. Type in the required email address
information. The default name given to the video is MyVideo.wmv. To rename the video before
sending, click on the words “MyVideo.wmv” in the attachment text box and click [Rename].
Click to send your video.
Note: If you are experiencing difficulties emailing your video, please refer to “Configuring Your
Email Program to Send Files” on pages 29-31.
Video Settings
[Settings] - Click this button to change the settings of your videos.
Drag to select starting/ending point of video

Page 13 of 44
Video Resolution: Select the size of the video to make it smaller or larger.
Preferred Device: Select your sound card that your microphone is connected to.
Maximum Video Size: Specify the maximum file size for your videos. Note that most Internet
Service Providers have a file size limitation when sending large files.
Maximum Video Time: Specify the time limit that you want to record your video for.
Default File Type: Select the video format that you want to record with.
Default File Name: Specify the default file name of the video you have recorded.
Note: In order for the new settings to take effect, you must apply them before recording a video.
Recording an Audio Clip
1. Click the Record An Audio Clip button
2. Adjust the volume using the Microphone Volume Adjustment Bar. Click [Record] to
record your audio clip. The button turns into [Stop]. Click the Stop button at any time to
finish recording.
3. After the recording stops, the following buttons will appear on the bottom of the screen:
[Adjust Volume] - Adjust volume of audio clip.
[Trim Audio] - Trim the audio clip to the selected size and length.
[Play] - Play the audio clip.
[Rerecord Audio] - Record another audio clip.
4. Click:
a)
- To save your audio clip.
b)
- To email your audio clip to another person.
Note: If you are experiencing difficulties emailing your audio clip, please refer to “Configuring
Your Email Program to Send Files” on pages 29-31.
Audio Settings
[Settings] - Click this button to change the settings of your audio.
Note: In order for the new settings to take effect, you must apply them before recording an audio
clip.
Drag to select starting/ending point of audio

Page 14 of 44
Importing Pictures from another Source
Importing Files to a Folder in the Veo Creative Studio
1. Click Other Source Inputs > File Import.
2. Click to locate the file you want to import.
3. In the Destination pull-down menu, click to select the folder or sub-folder that you want the
file to be imported to.
4. Click OK to import the file to the destination folder.
Note: You may need to refresh the folder if your newly imported image does not appear
immediately.
Viewing Pictures in the Gallery
1. Click the View Gallery button to view the minimized Gallery.
2. The following are buttons and folders used in the Gallery display panel along with their
description:
[Min/Max Gallery] - Toggle button used to minimize or maximize the Gallery Display Panel.
[Thumbnail Size] - To change the size of the thumbnails displayed in the gallery.
[Sort By] - To sort the thumbnails by type, time, or name. You can also use this to search for
a file in the Creative Studio Gallery. When the search is complete all matching files will be stored
in a “Search Results” folder.
Default Folders:
Animations - Contains animated character files.
Photographs - Contains still pictures.
Graphics - Contains background graphics.
Videos - Contains video files.
Music - Contains audio clips.
Projects - Contains all your previously saved projects.
To display the details of a specific file, click [Properties].
To delete a file, click on the file and click [Delete]. DO NOT drag it into the .
1. Click Other Source Inputs > Scanner or File
Import.
2. Select your source, then click to select. Your
scanner (or other TWAIN compatible device)
software will start.

Page 15 of 44
E-Card Creator – Creating an E-Card
1. Click on the E-card Creator button on the Creative Studio Home Screen.
2. Choose to Create A New Card or Find A Previously Saved Card Project.
If you choose to open a previously saved project, you may click on to view the following
options:
3. If you are creating a new card, select a theme from the left panel, then select the background
for your E-Card. Click Continue.
4. Edit your card.
Refer to “Applying Text, Images, Videos, and Animated Characters” on pages 23-25 for more
information on editing a card.
If you have selected an E-card template, it may appear similar to the one below:
Double-click to
edit text
Double-click to
chan
g
e ima
g
e

Page 16 of 44
Click Continue when you are done.
5. Define your animated characters’ path.
Refer to pages 37-38 for more information on how to define the path of an animated character.
Click Continue when finished.
6. Select the background music. Click [Set Background Music] or click and drag the
selected audio files from the Gallery.
7. Selecting background music. To listen to the music before selecting, place your cursor on any
one of without clicking.
Click [Mute] to turn background music on and off.
Note: When the Mute button is selected it does NOT remove the background music, you will
just not be able to hear it during the creation process. To remove the music entirely, click [Set
Background Music] and choose .
After you select your music, click Continue.
8. Click [Transition Effect]. Sample the effects by placing your cursor on each individual
effect without clicking.
9. Choose the opening effect (how you want the E-Card to open up). Click Continue after you
select your opening effect.
10. Preview the E-Card by clicking [Preview].
Save the E-Card to the Creative Studio Projects Folder for future editing by clicking [Save].
Save the E-Card as a new template by clicking [Save As].
Export the E-card out of Creative Studio by selecting the Export button and the save location.
11. Type in the required information. In the Attach Card As pull-down menu, select A Video
(*.wmv) if the person you are sending the card to has Windows Media Player.
12. The default name given to the E-Card is *.wmv where (*) is the name of your E-card
background you picked in step 3. To rename the E-Card before sending, click on *.wmv in the
attachment text box, then click [Rename]. If you send the file as *.wmv, the background
music will not play. To have the background music play, send the file as *.exe.
13. Click [Send This Card] to send your E-Card.
If you are experiencing difficulties emailing your card, please refer to “Configuring Your Email
Program to Send Files” on pages 29-31.

Page 17 of 44
Movie Maker – Making or Editing a Movie
1. Click on the Movie Maker button on the Creative Studio Home Screen.
2. Choose to Create A New Movie or Open An Existing Movie Or Project. If you choose to
open an existing movie, you can click on to display the following options:
3. Simply drag and drop videos or pictures from the Gallery Display Panel into the Movie Maker.
The following are buttons used in the Movie Maker along with their descriptions:
[Back] - Go back to previous screen.
[Continue] - Continue to the next screen.
[Save Finished Movie] - Save your movie at any time in the process.
[Preview Complete Movie] - Preview the movie you have created.
[Add A New Scene] - Add a new video or picture to your movie. You can either add an
existing video/picture from your computer or record a new video/picture from your Web Camera.
In order to add/record a new scene from your camera, make sure it is connected and functioning
properly.
For more information on how to take snapshots or record videos, refer to “Taking a Snapshot” on
pages 10-11 and “Recording a Video” on pages 12-13 of this User’s Guide.
Save the movie to a
specified location Preview the movie

Page 18 of 44
[Add Background Music] - Add music to your movie.
[Remove Music] - Remove music from your movie.
When you are done, click Continue.
By default, still pictures will be shown in the movie for three (3) seconds. To change this duration
or view other options, click for the following options:
Select Scene Duration.
Video (.avi) files also have a [Trim Video] feature that allows you to adjust the size and
length of the video. Refer to page 12 for more information on how to trim video.
Click Continue when you are done.
4. Select a scene from the bottom and click [Transition Effect].
5. Sample the effects by placing your cursor on each effect. Select the transition effect you would
like to use by double clicking or clicking “OK”.
6. Double-click on the remaining scenes in the Movie Maker, then repeat steps 4 and 5 above to
apply transition effects to the remaining scenes. Click Continue when you are finished.
7. Select a scene to edit by double-clicking on the scene in the Movie Maker.
8. Edit the selected scene.
Save changes
Select Duration Time
Duplicate the scene
Edit selected scene Change duration of scene
and other options
Option:
- Remove Audio
(Video files only)
- Set background color
- Zoom to fit screen
Delete the scene

Page 19 of 44
See “Applying Text, Images, Videos, and Animated Characters” on pages 23-25 for more
information on editing a scene.
Click Continue when you are done.
9. Repeat steps 7 and 8 to edit the remaining scenes. When you are finished, click Continue.
10. a) To preview the final movie, click [Preview].
b) To save the movie for future editing, simply click [Save].
c) To save the movie for future editing, with a new name click [Save As].
d) To save the movie as a locked template, click Save Finished Movie. To Export the
finished movie out of Creative Studio, select Export Movie and select the save location.
e) To send your movie to a friend:
1) Click E-mail Movie To A Friend.
2) Type in the requested information.
3) The default name given to the movie is Default.wmv. To rename the movie
before sending, click on the words “Default.wmv” in the attachment text box and
click [Rename].
4) Click to send your movie.
If you are experiencing difficulties emailing your movie, please refer to “Configuring Your Email
Program to Send Files” on pages 29-31.
Homepage Designer – Designing a Home Page
1. Click on the Homepage Designer button on the Creative Studio Home Screen.

Page 20 of 44
2. Choose to Create A New Homepage or Open A Previously Saved Homepage Project. If
you choose to open a previously saved homepage project, you may click on to get the
following options:
3. If you are designing a new homepage, select a theme from the left panel, then select the
background for your homepage. Click Continue.
4. Edit your homepage.
See “Applying Text, Images, Videos, and Animated Characters” on pages 23-25 for more
information.
To add a new page at any time, click [Add A New Page].
Click Continue when you are done.
5. Define your animated characters’ path.
Click Continue when you are finished.
6. Select a picture or animated character.
[Link All Pages] - Check the box to the left if you want all pages to be linked. Notice that if
you check the box to the left of the Link All Pages icon, it will turn into . It means that all
your pages are successfully linked. When you preview the webpage, you will see that there are
two arrow buttons on the bottom for easy navigation between pages. If you have text or pictures
on the very bottom, they may be partly covered. Try placing the text/pictures higher on the page.
Save webpage to
your computer
Publish webpage
to your Internet
Service Provider
Click to go to the
previous page Click to go to the
next page
