Veon VN2907CR-IPH User manual

2
DATE : 9 AUG, 2011
MODEL VN2907CR-IPH “VEON”
REVISED # 3 ENGLISH I/M FOR REFERENCE
SIZE : 102 (W) X 136 (H) MM
MATERIAL : 80G WOODFREE PAPER
PRINTING COLOR : BLACK
DOCKING ALARM CLOCK
FOR iPhone/iPod
DOCKING ALARM CLOCK
FOR iPhone/iPod
MODEL: VN2907CR-IPH
Instruction Manual
USER SAFETY GUIDE
WARNING
When using any electrical apparatus always observe safety regulations and use basic safety
precautions to reduce the risk of fire, electric shock and personal injury, including the following.
1. Read, Keep and Follow these instructions, heeding all Warnings.
2. Keep out of reach of young children. This apparatus is not suitable for use by young children or infirm persons without
supervision. Young children must be supervised to ensure that they do not play with the apparatus.
3. WARNING. Do not insert any objects into any openings of an electrical apparatus.
4. WARNING. Do not touch any moving parts of any electrical apparatus.
5. WARNING! Where the mains plug or an appliance coupler is used as the disconnect device, the disconnect device shall
remain readily operable
6. WARNING. Do not use this apparatus near water. To avoid the risk of fire or electric shock, do not expose this apparatus
to rain or moisture. The apparatus shall not be exposed to dripping or splashes.
7. WARNING. No objects filled with liquid, such as vases, shall be placed on any electrical apparatus.
8. Do not immerse in any liquid whilst in use or in cleaning. Clean only with a damp cloth, dry with a dry towel. Do not use
harsh abrasives as these may damage plastic parts.
9. DO NOT block any ventilation openings. Keep away from curtains, newspapers and restricted areas. Install in
accordance with any specific manufacturer’s instructions. Always allow a sufficient gap around the apparatus to avoid
overheating.
10. DO NOT install near any heat sources such as radiators, gas heaters, stoves or other apparatus (including amplifiers)
that produce heat. Do not leave in direct sunlight.
11. WARNING. Do not place any naked flame source, such as lighted candles on any electrical apparatus.
12. WARNING! Connect to a suitable 230-240V ~ 50 Hz power supply only. If a class 1 product it must be connected to a
suitably earthed mains socket.
13. Always unplug from the power source when any electrical apparatus is not in use.
14. Do not abuse or damage a power cord. If any power cord is damaged, it must be replaced by the manufacturer, its
service agent or a similarly qualified person in order to avoid a hazard. A replaceable cord must be replaced with an
authorised replacement from an authorised service agent only.
15. Only use attachments/accessories specified by the manufacturer.
16. Unplug this apparatus during lightening storms or when unused for long periods of time.
17. Attention is drawn to the environmental aspects of disposing of any battery.
18. Refer all servicing to qualified personnel. Servicing is required when the apparatus has been damaged in any way, such
as when the power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
19. Do not attempt to service any double insulated apparatus. Double insulated apparatus requires specialist servicing and
knowledge to retain the safety of the apparatus.
20. WARNING. Do not use any electrical apparatus outdoors. If any electrical apparatus is to be used outdoors, use a
suitable Isolating transformer or Electrical Safety Switch (RCD).
21. For household use only, this apparatus is not intended for commercial use.
22. If this apparatus is to be used by a third party, please supply these instructions with it.
23. No liability will be accepted for any personal injury or damage caused by failure to follow these instructions.
• TO PREVENT FIRE OR SHOCK HAZARD. DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
• THIS APPLIANCE SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING WATER AND THAT NO
OBJECT FILLED WITH LIQUID SUCH AS VASES SHALL BE PLACED ON APPARATUS.
IMPORTANT SAFETY INSTRUCTIONS

3 4
USER SAFETY GUIDE
WARNING
IMPORTANT SAFETY INSTRUCTIONS - continued
CLEANING
Always disconnect unit from power supply before attempting to clean it.
Use soft cloth moistened with soapy water, and wipe gently. Do not use
solvents or abrasive materials.
SAFETY
The apparatus shall not be exposed to dripping or splashing and that
no objects filled with liquids, such as vases, shall be placed on the
apparatus.
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
A warning that batteries (battery pack or batteries installed) shall not be
exposed to excessive heat such as sunshine, fire or the like.
ADDITIONAL IMPORTANT INSTRUCTIONS
Place the apparatus some distance from nearby objects or walls for sufficient ventilation. The
ventilation should not be impeded by covering the ventilation openings with items such as
newspapers, tablecloths,curtains, etc.
• Dispose of used batteries properly. Follow the local regulations for battery disposal.
• Use this apparatus in moderate climates. It is recommended not to use this apparatus in a
lightning storm.
VN2907CR Quick Operating Guide
Set Up
Set clock
On/Off
FUNCT/CL-SET
FUNCTION/CL-SET
FUNCTION/CL-SET
FUNCTION/CL-SET
Set Alarm
On/Off
AL-SET/AL
AL-SET/AL
AL-SET/AL
Set Alarm Mode (Buzz – Radio – iPod/iPhone)
On/Off On'
On/Off Off'
AL-SET/AL
AL = FM = iPod =
Turn Alarm Off
AL-SET/AL
SNOOZE
Automatic Power Off
EQ/SLEEP SL
EQ/SLEEP
Radio Operation
On/Off On'
FUNCTION/CL-SET FM
UP/DOWN
ST/MO
Station Preset - Memory Storage
SEARCH ±
MEMORY C01 SEARCH ±
MEMORY
iPod/iPhone Operation
FUNCTION/CL-SET
PLAY/PAUSE
Music Equaliser
EQ/SLEEP
AUX Input
FUNCTION/CL-SET AUX
Fit 2 x AAA batteries to battery compartment
Plug adaptor into wall socket and connect to unit
Press button to 'Off' (standby) setting (lights dim)
Press and hold button for 3 seconds
Press Skip/Search ± to set 24 or 12 hrs. Press to confirm
Press Skip/Search ± to set hours. Press to confirm
Press Skip/Search ± to set minutes. Press to confirm
Press button to 'Off' (standby) setting (lights dim)
Press and hold Mode button for 3 seconds (time setting will flash)
Press Skip/Search ± to set hours. Press Mode to confirm
Press Skip/Search ± to set minutes. Press Mode to confirm
Press button to ' (lights bright)
1. For iPod connect the iPod/iPhone and select desired song and set desired volume.
2. For Radio set desired station and set desired volume.
3. Buzzer does not need to be set.
Press button to ' (standby) setting (lights dim)
Press button repeatedly to choose alarm source
The clock will now display Alarm and alarm mode. At the set time the alarm will function
Note. Buzzer Alarm / Radio / ipod/iPhone
Press button once. Note this will not clear the alarm setting completely.
Press button. The alarm will deactivate for a 9 minute period
Press and hold the button until the symbol flashes
Press the button to select the desired auto off time. (Settings from 90mins to 10mins)
Press button to ' (lights bright)
Press button until display shows
Adjust volume button to set volume level
Unwind FM Arial cord for better signal
Press button to switch between mono and Stereo modes
To tune a radio station press and hold the buttons. The radio will search for the next available station.
To store in memory press button until appears in display. Use the buttons to select
the desired channel that you wish to store the station under and press once to store. Note there are
30 memory channels available.
Connect the iPod/iPhone into the docking base using adaptors supplied.
Switch both clock radio and iPod to ON.
Press the button until the iPod function appears.
Press button. The unit will start playing the first available track.
Press button repeatedly to select between sound effects Classic/Rock/Jazz/Pop
(E0 = Off) (E1=Classic) (E2 = Jazz) (E3 = Pop) (E4 = Rock)
To connect to an auxiliary music source plug the external source into the AUX input socket on the rear of the unit.
Press button until is shown on display.
For more detailed instruction refer to the main manual

5
LOCATION OF CONTROLS
1. SPEAKER
2. BLUE BACKLIT DISPLAY
3. BACK-UP BATTERY
COMPARTMENT (BOTTOM OF UNIT)
4. CAVITY FOR DOCK ADAPTOR
5. DOCK ADAPTOR FOR iPOD
(SEVERAL DIFFERENT ADAPTORS
ARE PROVIDED)
6. VOLUME DOWN ( ) KEY
7. VOLUME UP ( ) KEY
8. MEMORY KEY
9. EQ/ SLEEP KEY
10. ON/ OFF KEY
11. SKIP ( ) / SEARCH ( ) KEY
12.
AUX INPUT SOCKET
18. DC JACK (DC 6V )
19. FM ANTENNA WIRE
SKIP ( ) / SEARCH ( ) KEY
13. AL-SET/ AL-MODE KEY
14. FUNCTION/ CL-SET KEY
15. PLAY/ PAUSE / STEREO/ MONO KEY
16. SNOOZE DIMMER KEY
17.
---- - -
FRONT VIEW:
BACK VIEW:
1
2
TOP VIEW:
3
678
45
910
11 12 13 14 15
16
17
18
19
6
PREPARATION OF iPod DOCK
TO CONNECT AN iPod WITH A DOCK CONNECTOR TO THIS UNIT, FIRST INSERT THE DOCK
ADAPTOR THAT FITS YOUR iPod, AND THEN CONNECT YOUR iPod. YOUR HIFI INCLUDES
DOCK ADAPTORS THAT WORK WITH SEVERAL MODELS OF iPod WITH DOCK CONNECTORS.
IF YOU WANT TO CONNECT A DIFFERENT MODEL OF iPod AT A LATER TIME, YOU CAN EASILY
REMOVE THE DOCK ADAPTOR FROM YOUR SPEAKER SYSTEM USING A FINGERNAIL,
AND INSERT THE ADAPTOR THAT FITS THE NEW iP . IF THERE IS NO DOCK ADAPTOR
FOR YOUR MODEL OF iP INCLUDED WITH YOUR SPEAKER SYSTEM, AN ADAPTOR MAY
HAVE BEEN INCLUDED WITH YOUR iP .
PLEASE CHECK INSIDE THE BOX OF THE iPod YOU PURCHASED FOR A PLASTIC DOCK
ADAPTOR.
od
od
od
AC OPERATION (EXTERNAL AC-DC POWER ADAPTOR)
- THIS SET IS EQUIPPED WITH A "DC-JACK" CAPABLE OF ACCEPTING
AC-ADAPTORS WITH A RATING OF DC = 6V, 2A, AND WITH A PLUG
WITH THE FOLLOWING POLARITIES AS SHOWN (CENTER POSITIVE) :
- PLEASE USE ONLY THE SUPPLIED AC-ADAPTOR TO OPERATE THE UNIT.
USE OF OTHER ADAPTORS MAY DAMAGE THE UNIT OR CAUSE IT TO MALFUNCTION.
- PLUG THE TAIL END OF THE AC-ADAPTOR INTO THE DC-JACK (SOCKET)
ON THE REAR OF THE UNIT.
- INSERT THE PLUG OF THE AC-ADAPTOR INTO A WALL OUTLET WITH AC-POWER.
- PRESS THE "ON/ OFF" KEY TO SWITCH ON THE UNIT.
- THIS UNIT IS DESIGNED TO OPERATE WITHOUT EVER BEING TOTALLY POWERED "OFF".
IT WILL EITHER BE "ON" OR IN "STANDBY MODE".
- IN STANDBY MODE, THE BLUE BACK-LIGHT OF THE DIGITAL DISPLAY WILL BE DIMMED
BUT THE DISPLAY WILL SHOW THE CURRENT TIME (CLOCK FUNCTION).
- ANYTIME DURING STANDBY MODE, YOU CAN SWITCH "ON" THE UNIT BY PRESSING
THE "ON/ OFF" KEY.
- SAVE ENERGY BY SWITCHING THE SYSTEM TO "STANDBY" MODE WHEN NOT IN USE.
POWER SUPPLY
- OPEN THE BATTERY DOOR AT THE BOTTOM OF UNIT.
- INSERT 2 PCS "AAA-CELL" (UM-4/LR03 TYPE) BATTERIES IN THE BATTERY
COMPARTMENT.
THESE 2 BATTERIES ARE FOR BACKUP OF THE "CLOCK" DURING BRIEF POWER
OUTAGES".
BACK UP BATTERIES
-
+
DIMMER FUNCTION
THIS SET HAS A DIMMER FUNCTION TO ADJUST THE BRIGHTNESS LEVEL
OF THE DISPLAY BACKLIGHT. SIMPLY ADJUST IT AS DESIRED BY PRESSING
THE SNOOZE/ DIMMER KEY REPEATEDLY
TO REDUCE EYE STRAIN, AND TO
(HI-DIMMER / LOW-DIMMER / OFF.)
SAVE ENERGY.
THE DISPLAY BACKLIGHT WILL ALWAYS RETURN IN HI-DIMMER AFTER RESET THE UNIT.

7
Dock adapters: Choose the dock adapter that fits your iPod.
Your iPod fits snugly into the correct adapter.
If there is no dock adapter for your model of iPod included, you can also
use the dock adapter which was included in the box with your iPod itself.
FOR OTHER iPod MODELS:
THE NUMBER
SHOWS WHICH iPod FITS
14
16
OR
10
OR
9
10
OR
9
17
18
20
19
OR
15
8
DIGITAL CLOCK FUNCTION
- THE SET HAS A BUILT-IN DIGITAL CLOCK, WHEN THE SET IS IN "STANDBY MODE".
(THE DISPLAY WILL CONTINUOUSLY SHOW THE CURRENT TIME).
IN THIS SITUATION THE BLUE BACKLIT IS NORMALLY DIMMED (TO SAVE ELECTRICITY).
HOW TO SET CORRECT TIME:
CORRECT TIME IS NOW SET & WILL BE SHOWN IN THE DISPLAY.
SWITCH UNIT TO "STAND-BY" MODE (DISPLAY LIGHT = DIMMED)
PRESS & HOLD FUNC./ CL-SET KEY FOR 3 SECONDS DISPLAY SHOWS
HOUR OR HOUR (FLASHING)
12H 24H
PRESS SKIP- / SEARCH- OR SKIP+ /SEARCH+ KEY TO SELECT
12-HOUR OR 24-HOUR CLOCK DISPLAY SYSTEM & PRESS
O CONFIRM YOUR SELECTION
FUNC./CL-SET KEY
T
PRESS REPEATEDLY TO
SET THE CORRECT IN THE DISPLAY & PRESS
TO CONFIRM
SKIP- / SEARCH- OR SKIP+ /SEARCH+ KEY
FUNC./ CL-SET KEYMINUTE
PRESS REPEATEDLY TO
SET THE CORRECT IN THE DISPLAY & PRESS
TO CONFIRM
SKIP- / SEARCH- OR SKIP+ /SEARCH+ KEY
FUNC./ CL-SET KEYHOUR

9
ALARM FUNCTION
- THIS SET IS EQUIPPED WITH 3 ALARM MODES: BUZZER, RADIO AND iPod.
BEFORE SETTING THE ALARM, MAKE SURE TO SET THE CLOCK (SEE "DIGITAL
CLOCK FUNCTION" IN THE PERVIOUS SECTION) .
PREPARE FOR THE ALARM SETTINGS
PRESS THE KEY TO SWITCH ON THE SET (DISPLAY BLUE LIGHT WILL
BE "ON").
ON/ OFF
1. PRESS THE KEY TO PUT THE SET INTO "STANDBY" MODE
(BLUE LIGHT DIMMED).
2. PRESS AND HOLD KEY UNTIL
THE DISPLAY WILL NOW SHOW:
3. PRESS SKIP- / SEARCH- AND SKIP+ /SEARCH+ KEY TO REACH THE HOUR
OF THE DESIRED WAKE UP TIME THEN PRESS KEY TO CONFIRM.
THE DISPLAY WILL NOW SHOW:
ON/OFF
AL-SET/ AL-MODE
AL-SET/ AL-MODE
00 00
HOUR (FLASHING)
MINUTES
(FLASHING)
800
4. PRESS SKIP- / SEARCH- AND SKIP+ /SEARCH+ KEY TO REACH THE
MINUTES OF THE DESIRED WAKE UP TIME, THEN PRESS THE
KEY TO CONFIRM.
AL-SET/ AL-MODE
"ALARM" TIME SETTING
ONCE THE DESIRED SOURCE HAS BEEN READY, PRESS THE ON/ OFF KEY TO PUT THE
SET INTO STANDBY MODE AND THEN SHORT PRESS THE AL-SET/ AL-MODE KEY
REPEATEDLY TO SELECT THE SOURCE AS DESIRED.
5. "ALARM" MODE SETTING
NOW SELECT THE SOURCE THAT YOU WISH THE UNIT TO PLAY AT THE "WAKE UP"
TIME AS BELOW:
PRESS THE KEY TO SWITCH ON THE SET (DISPLAY BLUE LIGHT WILL
BE "ON").
1. CONNECT THE iPod/ iPhone AS DESCRIBED.
THE
TUNE IN THE DESIRED STATION.
2. ADJUST THE VOLUME LEVEL AS DESIRED BY PRESSING OR
KEY.
ON/ OFF
:
:
VOL. UP + VOL. DN -
FOR iPod/ iPhone
FOR RADIO
SELECT THE SONG OR THE DESIRED PLAYLIST TO PLAY AT
“WAKE UP” TIME.
START AND PAUSE PLAYBACK OF THE SONG/PLAYLIST AT
THE POINT FROM WHICH YOU WANT PLAYBACK TO BEGIN
AT THE “WAKE UP” TIME.
*REMARK: = BUZZER ALARM / = RADIO / = iPod/ iPhone
AL FM iPod
SNOOZE FUNCTION
- WHENEVER THE ALARM COMES ON, IT CAN BE TEMPORARILY SUSPENDED
FOR A SHORT PERIOD OF 9 MINUTES, BY PRESSING THE “SNOOZE/ DIMMER” KEY
ONCE.
- THE ALARM WILL THEN AUTOMATICALLY COME ON AGAIN AFTER THE 9 MINUTES
“SNOOZE” PERIOD HAS ENDED.
- THE PROCEDURE CAN BE REPEATED FOR APPROXIMATELY 90 MINUTES FROM
ORIGINAL ALARM WAKE-UP TIME.
10
7. THE SET WILL NOW AUTOMATICALLY SWITCH "ON" AT THE WAKE-UP TIME AS YOU
HAVE CHOSEN, AS LONG AS THE ALARM FUNCTION IS "ACTIVE".
8. TO TURN OFF THE UNIT AFTER IT HAS AUTOMATICALLY SWITCHED ON,
SIMPLY PRESS THE KEY ONCE. THIS WILL SWITCH OFF THE SET
BUT WILL NOT CLEAR THE ALARM SETTINGS, AND THE SET WILL SWITCH ON
AGAIN AUTOMATICALLY ON THE NEXT DAY AT EXACTLY THE SAME PRESET TIME.
9. TO DEACTIVATE THE ALARM, PRESS & RELEASE THE KEY. THE
ALARM SYMBOL "AL" DISAPPEARS FROM THE DISPLAY.
10. TO ACTIVATE THE ALARM AGAIN, REPEAT THE PROCEDURE OF "ALARM TIME
SETTING" AS DESCRIBED.
ON/OFF
AL-SET/ AL-MODE
90
MINS
80
MINS
70
MINS
60
MINS
50
MINS OFF*
40
MINS
30
MINS
20
MINS
10
MINS
- THIS SET HAS A SPECIAL SLEEP TIMER FUNCTION WHICH CAN AUTOMATICALLY
SWITCH OFF THE UNIT. THIS IS USEFUL FOR SLEEPING TO MUSIC AT NIGHT.
- AT ANY TIME WHILE THE UNIT IS OPERATING, PRESS & HOLD THE EQ/SLEEP KEY
UNTIL THE "SL" SYMBOL FLASHING, THEN PRESS THE EQ/SLEEP KEY REPEATEDLY
TO CHOOSE THE AUTOMATIC POWER OFF TIME.
(*OFF MEANS SLEEP TIMER IS DEACTIVATED)
CURRENT TIME
12:00
ALARM SYMBOL
6. THE ALARM TIME IS NOW FULLY PROGRAMMED AND THE ALARM SYMBOL WILL
APPEAR TO INDICATE THAT THE ALARM FUNCTION IS "ACTIVE".
(DISPLAY SHOWS AS FOLLOWS WITH BLUE BACKLIGHT "DIMMED")
AUTOMATIC POWER OFF SLEEP FUNCTION
AL
iPod
FM
FLASHING
FM SYMBOL FLASHING
iPod SYMBOL
THE ALARM SET-UP MODE, WHERE THE SYMBOL "AL" IS FLASHING, WILL TIME-OUT
IF THERE IS NO INPUT FOR 3 SECONDS AND RETURN TO “STANDBY MODE”.
SHOULD THE ALARM SET-UP MODE TIME-OUT, THE ALARM SYMBOL"AL" WILL NOT BE
DISPLAYED AND THE ALARM TIME SETTING INSTRUCTIONS WILL HAVE TO BE
REPEATED FOR THE ALARM TO BE SET.
IF THE ALARM IS SET AS WAKE TO iPod, YOU WILL NEED TO CONNECT
THE iPod/ iPhonePROPERLY AS DESCRIBED. OTHERWISE, THE BUZZER ALARM WILL
SOUND AT THE SET TIME IF THE iPod HAS NOT BE CONNECTED.
IMPORTANT:

12
MUSIC EQUALIZER
- AT ANYTIME DURING PLAYBACK, PRESS KEY REPEATEDLY TO
CHOOSE THE DESIRED SOUND EFFECT ACCORDING TO THE MUSIC YOU ARE
LISTENING TO :
EQ/SLEEP
E-0 = EQ OFF E-1 = CLASSIC
OPERATION WITH THE iPod/ iPhone
- TURN ON BOTH THE UNIT AND THE iPod/ iPhone.
- CONNECT THE iPod TO THE UNIT AS DESCRIBED.
- PRESS THE FUNC./ CL-SET KEY REPEATEDLY UNTIL THE DISPLAY SHOWS “iPod”.
- PRESS THE KEY ON THE UNIT, THEN THE FIRST SONG WILL
START PLAYING.
- THE iPod DISPLAY WILL INDICATE THE INFORMATION OF THE CURRENT SONG.
- YOU CAN OPERATE THE iPod USING EITHER THE UNIT'S BUTTONS,
OR DIRECTLY WITH THE iPod ITSELF.
- WHEN THE iPod HAS BEEN CONNECTED WITH THE UNIT, IT WILL START
CHARGING THE BATTERY OF THE iPod .
- NEVER REMOVE (OR UNPLUG) THE iPod FROM THE SET DURING PLAYBACK,
ALWAYS PAUSE PLAYBACK FIRST AND THEN PRESS THE FUNC/ CL-SET KEY TO
SWITCH TO ANOTHER SOURCE (EG. “RADIO” OR “AUX”) BEFORE REMOVING OR
UNPLUGGING THE iPod , TO PREVENT DAMAGE TO YOUR SONG FILES OR
MEMORY DEVICES.
/ iPhone
/ iPhone
- AT ANYTIME DURING PLAYBACK, PRESS THE KEY TO PAUSE
PLAYBACK. PRESS KEY TO RESUME PLAYBACK OF THE SAME
SONG & POSITION.
- AT ANYTIME DURING PLAYBACK, PRESS AND RELEASE THE
OR SKIP+ /SEARCH+ KEYS TO SKIP FORWARD OR BACKWARDS BY ONE SONG,
AS DESIRED.
- AT ANYTIME DURING PLAYBACK, PRESS AND HOLD THE
OR SKIP+ /SEARCH+ KEYS TO FAST-FORWARD (CUE) OR FAST-REVERSE
(REVIEW) THE SPECIFIC SONG, WHICH IS CURRENTLY PLAYING.
PLAY/ PAUSE
PLAY/PAUSE
PLAY/PAUSE
SKIP- /SEARCH-
SKIP- /SEARCH-
/ iPhone
/ iPhone
/ iPhone
/ iPhone
/ iPhone
/ iPhone
E-2 = JAZZ
E-3 = ROCKE-4 = POP
"Made for iPod," "Made for iPhone," mean that an electronic accessory has
been designed to connect specifically to iPod, iPhone, respectively, and has been certified
by the developer to meet Apple performance standards. Apple is not responsible for the operation
of this device or its compliance with safety and regulatory standards. Please note that the use
of this accessory with iPod, iPhone may affect wireless performance.
11
ELECTRONIC VOLUME CONTROL
- THIS UNIT USES AN ELECTRONIC VOLUME CONTROL .
- TO INCREASE OR DECREASE THE LOUDNESS OF UNIT, PRESS
THE VOLUME UP (VOL +) OR VOLUME DOWN (VOL -) KEYS RESPECTIVELY.
- RELEASE THE KEY WHEN VOLUME LEVEL IS AT THE DESIRED LOUDNESS.
- SOMETIMES, ESPECIALLY DURING LISTENING TO THE RADIO, YOU MAY NOTICE
A "CLICK-CLICK-CLICK" (REPEATING) SOUND WHEN YOU ARE INCREASING OR
DECREASING THE VOLUME. THIS IS A NORMAL CONDITION & THE SOUND WILL
DISAPPEAR WHEN YOU RELEASE THE VOLUME KEY (WHEN YOU REACH THE
DESIRED VOLUME LEVEL).
(PUSH BUTTON TYPE)
- AT ANY TIME, THE CURRENTLY DISPLAYED STATION OR FREQUENCY CAN BE
STORED INTO ONE OF THE MEMORY POSITIONS.
- PRESS KEY UNTIL "C01" FLASHES IN THE DISPLAY.
- PRESS AND SKIP+ /SEARCH+ KEYS TO SELECT DESIRED
MEMORY POSITION. (THERE ARE TOTAL 30 MEMORY POSITIONS).
- PRESS KEY ONCE TO SAVE THE SELECTED STATION INTO THE
SELECTED MEMORY POSITION.
- TO RECALL ANY SAVED MEMORY, SIMPLY PRESS KEY ONCE THEN SELECT
THE MEMORY POSITIONS BY PRESSING AND
SKIP+ /SEARCH+ KEYS THE SAVED RADIO-BAND WILL BE RECALLED.
- TO CLEAR THE MEMORY OF ANY POSITION, SIMPLY SAVE A NEW STATION TO THE
SAME MEMORY POSITION.
RADIO MEMORY (STATION PRESET MEMORY STORAGE)
MEMORY
SKIP- /SEARCH-
MEMORY
MEMORY
SKIP- /SEARCH-
OPERATION OF RADIO
- PRESS AND HOLD (FOR 2 SECONDS) THE AND
SKIP+ /SEARCH+ KEYS TO “SEEK” (AUTOMATICALLY ADJUST) THE RADIO
FREQUENCY “UP” OR “DOWN” TO THE NEXT AVAILABLE RADIO STATION.
- THE RADIO DIGITAL DISPLAY WILL INDICATE THE EXACT FREQUENCY OF THE NEXT
STATION THAT IS FOUND.
- WHEN A DESIRED STATION IS REACHED. IT CAN BE SAVED INTO ONE OF THE
“MEMORY” POSITIONS. (SEE “RADIO MEMORY” SECTION).
AUTOMATIC FREQUENCY ADJUSTMENT (SEEK MODE)
SKIP- /SEARCH-
- PRESS THE "ON/ OFF" KEY ONCE TO SWITCH ON THE UNIT.
- PRESS THE KEY REPEATEDLY UNTIL THE DISPLAY SHOWS "FM".
- EXTEND AND ADJUST THE FM-WIRE ANTENNA TO OBTAIN THE BEST RECEPTION.
- USE THE ST/MO KEY TO SELECT THE DESIRED MODE (STEREO/ MONO).
IN SOME CASES, WHERE RECEPTION IS POOR, IT MAY BE ADVISABLE TO
SELECT “MONO” MODE, TO IMPROVE CLARITY OF THE RADIO SIGNAL.
FUNC./CL-SET
MANUAL FREQUENCY ADJUSTMENT (SCAN MODE)
- PRESS (AND IMMEDIATELY RELEASE) THE AND
SKIP+ /SEARCH+ KEYS TO “SCAN” (MANUALLY ADJUST) THE RADIO
FREQUENCY “UP” OR “DOWN” BY 1-STEP AT A TIME.
- THE RADIO DIGITAL DISPLAY WILL INDICATE THE EXACT FREQUENCY AT EACH
STEP’S POSITION.
- WHEN A DESIRED FREQUENCY OR STATION IS REACHED. IT CAN BE SAVED INTO
ONE OF THE “MEMORY” POSITIONS. (SEE “RADIO MEMORY” SECTION).
SKIP- /SEARCH-

13
USING THE AUDIO LINE IN CONNECTION (AUX-INPUT)
- YOU CAN CONNECT THE AUDIO OUTPUT OF AN EXTERNAL DEVICE SUCH AS A MP3
PLAYER OR A TV TO THIS UNIT, TO LISTEN TO THE SOUND OF THAT DEVICE
THROUGH THE HIGH QUALITY AMPLIFIER OF THIS MUSIC SYSTEM.
- TO CONNECT THE EXTERNAL DEVICE PLEASE USE A STANDARD STEREO
HEADPHONE (3.5MM TO 3.5MM PLUGS) CABLE TO CONNECT THE
"HEADPHONE-OUT OR AUDIO LINE-OUT" OF THE DEVICE TO THE AUX-INPUT SOCKET
OF THIS UNIT.
- SWITCH THE FUNCTION TO "AU" (AUX) USING THE KEY.
- SWITCH ON THE UNIT AND THE EXTERNAL DEVICE (eg. MP3-PLAYER OR TV).
- START PLAYBACK OF THE EXTERNAL DEVICE AND ADJUST THE VOLUME CONTROL
OF THE MAIN UNIT TO THE DESIRED LEVEL.
- REMEMBER TO SWITCH OFF THE UNIT WHEN YOU ARE FINISHED USING THE
EXTERNAL DEVICE.
FUNC./CL-SET
SPECIFICATIONS
POWER SUPPLY : ............... DC 6V, 2A THOUGH BUILT-IN DC JACK
EXTERNAL AC-DC POWER ADAPTOR 110V-240V ~ 50/60Hz
POWER CONSUMPTION : .... 10 W
SPEAKER : ........................... SPEAKER 2" x 2
FREQUENCY : ..................... FM 87.5 - 108 MHz
WHEN ELECTROSTATIC DISCHARGE (ESD) OCCURS AT THE FRONT SURFACE (WHETHER
METAL OR PLASTIC) OR NEAR ANY PART OR ANY BUTTON OF THIS UNIT, OR AT THE USB
PORT AND/ OR SD-CARD SLOTS (IF THEY EXIST ON THIS PRODUCT),
THERE MAY BE A POSSIBILITY THAT THE PRODUCT MAY STOP OPERATION AND/ OR
SHUT DOWN IMMEDIATELY. THIS IS A NORMAL CONDITION AND INTENDED TO PROTECT
THE UNIT AND INTERNAL COMPONENTS AGAINST DAMAGE.
IN SUCH A CASE, PLEASE RESET THE UNIT (BY DISCONNECTING AND RECONNECTING
AC-POWER SOURCE) TO REVERT THE UNIT TO NORMAL OPERATION.
ELECTROSTATIC DISCHARGE (ESD) PRECAUTION
BATTERY SHOULD NOT BE EXPOSED TO EXCESSIVE HEAT SUCH AS SUNSHINE,
FIRE OR THE LIKE.
THE APPARATUS SHOULD NOT BE EXPOSED TO DRIPPING OR SPLASHING AND NO OBJECTS
FILLED WITH LIQUIDS SHOULD BE PLACED ON THE APPARATUS.
THE MARKING AND RATING LABEL IS LOCATED AT BOTTOM ENCLOSURE OFTHE APPARATUS.
THE MAINS PLUG IS USED AS THE DISCONNECT DEVICE AND IT SHALL REMAIN READILY
OPERABLE. TO BE COMPLETELY DISCONNECTED THE POWER INPUT, THE MAINS PLUG
OF THE APPARATUS SHALL BE DISCONNECTED FROM THE MAINS COMPLETELY.
THE MAINS PLUG SHOULD NOT BE OBSTRUCTED OR SHOULD BE EASILY ACCESSED
DURING INTENDED USE.
UNDER THE INFLUENCE OF ELECTROSTATIC PHENOMENON,
THE PRODUCT MAY MALFUNCTION AND USER TO POWER RESET.
CAUTION
DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY
WITH THE SAME OR EQUIVALENT TYPE.
ORIENTAL PACIFIC INTERNATIONAL LTD
Guarantee Card
This product is guaranteed against faulty materials and workmanship for a period
of two years from the date of purchase. The obligation to the purchaser under this
warranty is limited to servicing the unit and replacing defective parts when the
product is returned freight prepaid to the retailer. This warranty becomes void if
the product has been tampered with, damaged by accident, damaged in any other
way by improper use or has been purchased second hand. All production orders
have quality inspections. In the unlikely event of a deficiency, please contact
the retailer from which this product was purchased.
WARRANTY FOR PRODUCTS USED COMMERCIALLY LIMITED TO 90 DAY
Type of Product: _______________________________________________________________
Model No.: __________________________________ Purchase Date:____________________
Product Purchased From: ________________________________________________________
__________________________________________________________________________________
Your Name: _____________________________________________________________________
Address: _________________________________________________________________________
_______________________________________________ Phone Number: __________________
IMPORTANT!
Please retain this warranty card along with your purchase receipt. Please do not
post to the retailer or importer. If service is required, both of these documents are to
be returned with the product to your retailer, otherwise a fee may be charged.
ORIENTAL PACIFIC
P O BOX 302-158
North Harbour
Auckland 1330
New Zealand
New Zealand call Toll Free 0800-898580
Australia call Toll Free 1-800-858011
DATE : 1 AUG, 2011
MODEL VN2907CR-IPH “VEON”
WAEEANTY FOR APPROVAL
*WILL BE PRINTED WITH I/M*
SIZE : 102 (W) X 136 (H) MM
MATERIAL : 80G WOODFREE PAPER
PRINTING COLOR : BLACK

DATE : 2 AUG, 2011
MODEL VN2907CR-IPH “VEON”
REVISED FOLDING PLAN FOR APPROVAL
SIZE : 102 (W) X 136 (H) MM
MATERIAL : 80G WOODFREE PAPER
PRINTING COLOR : BLACK
COVER 234
568
(FRONT)
7
910
11 12
13
WARRANTY BLANK
(BACK)
BLANK
