Verbos Electronics Sequence Selector User manual

Sequence
SEQUENCE SELECTOR
The Sequence Selector is a 5 stage analog sequencer that
provides gate input and outputs on all stages. It is possible
to jump directly to any stage, eliminating the need for a
reset. Patching a stage’s gate output (the jack with a red
box around it at the top of the stage) to another stage’s
select input allows shorter sequences that go from any
stage to any stage. Pulses into the ADVANCE input or a
press to its button will step the sequence forward one step.
The stage can also be selected with a control voltage
plugged into the ANALOG input. With this signal at ground,
the sequencer is uneffected. When the incoming voltage is
greater than 100mV, the clocking is jammed and stage is
selected by the ANALOG signal. The master GATE output is
controlled by the toggle switches on each stage. The
TRANSPOSE input is mixed together with the CV signal
from the sliders to allow the slider row to offset an incoming
sequence, treating it like an arpeggio.
In addition to the sequencer’s CV sliders, gate switches and
pulse input/outputs, two unity gain 5:1 signal selectors are
included. These can be used to select between the two
rows of a Voltage Multistage or between both rows of up to
5 Voltage Multistages. They need not be sequencer
outputs. Modulation CVs, gates or even audio signals can
be selected using these. Signals are patched into the jacks
of the sequencer’s stages and out from the jacks on the
right side output section.
Selectors
Congratulations on obtaining your Verbos Electronics Sequence Selector. This Euro-Rack format module is a 5 stage analog
sequencer which can jump to any stage using analog voltage address, front panel buttons or external triggers. It also
includes two 5:1 signal selectors.
www.verboselectronics.com
